At-Rest Encryption for Complete Data Protection

At-Rest Encryption for Complete Data Protection

Many developers using hosted database solutions like Amazon RDS or Microsoft Azure are familiar with the “encrypt at rest” checkbox provided by their host. This will provide a modicum of security, but only defends your data against a narrow set of potential threats. Instead, we’ll discuss both the threats this feature does and does not protect against and some practical approaches to handling the uncovered edge cases. Attendees will learn how their application can both encrypt and decrypt data before communicating with an external data store for complete data protection.

Eric Mann

May 21, 2019
Tweet

More Decks by Eric Mann

Other Decks in Programming

Transcript

  1. At-Rest Encryption for
    Complete Data
    Protection
    Eric Mann

    View Slide

  2. Let’s build a web
    application. Let’s
    make it secure.

    View Slide

  3. Data Classification Tiers
    Tier 1 - Unrestricted Data
    Tier 2 - Confidential Data
    Tier 3 - Highly Secured Data
    Tier 4 - Restricted Data

    View Slide

  4. (Full image slide with caption)
    STRIDE Threat Modeling -
    https://resources.infosecinstitute.com/threat-modeling-finding-defects-early-in-the-cycle/

    View Slide

  5. (Full image slide with caption)
    Image credit: https://movieweb.com/

    View Slide

  6. DREAD Risk Ratings
    Score each of the following from 1-10
    ● Damage Potential
    ● Reproducibility
    ● Exploitability
    ● Affected Users
    ● Discoverability

    View Slide

  7. DREAD Risk Ratings
    D R E A D Rate
    Credentials sniffed from
    the network
    10 10 5 5 5 7
    SQL commands injected
    in the front-end
    10 10 10 10 5 9
    Arbitrary file navigation
    and download on the
    10 10 10 5 0 7

    View Slide

  8. In Transit
    Encrypting communication
    between two parties over a
    (potentially) insecure
    medium.
    At Rest
    Encrypting data used by a single
    party between to periods of
    time.
    Data Encryption

    View Slide

  9. (Full image slide. No text)

    View Slide

  10. At-Rest Encryption
    1. Protects data written out
    to disk
    2. Transparent to the application
    layer
    3. (Usually) Provided by hosted
    DB solutions
    4. (Often) Required for regulatory
    compliance

    View Slide

  11. (Full image slide with caption)
    Tom Cruise in "Mission: Impossible — Rogue Nation." YouTube/Paramount

    View Slide

  12. Application-level Encryption
    By allowing the application to manage its own encryption keys, the
    crypto operations lift up into the application stack itself. The database
    engine can’t read or manage the data, neither can any other process in
    memory.
    Your data’s security then relies on the security of your application’s
    authentication and access control systems.

    View Slide

  13. Application-level Encryption
    By allowing the application to manage its own encryption keys, the
    crypto operations lift up into the application stack itself. The database
    engine can’t read or manage the data, neither can any other process in
    memory.
    Your data’s security then relies on the security of your application’s
    authentication and access control systems.

    View Slide

  14. To store encrypted
    data and still search
    the plaintext, we
    need a blind index.

    View Slide

  15. Blind Index
    Store a keyed hash of the data in one column
    Store the encrypted data in a separate column
    Be sure to use separate hashing and encryption keys!

    View Slide

  16. Blind Index
    CREATE TABLE reviews (
    id INT NOT NULL,
    title TEXT NOT NULL, /* encrypted */
    review TEXT NOT NULL, /* encrypted */
    reviewer TEXT NOT NULL, /* encrypted */
    reviewer_idx TEXT NOT NULL, /* blind index */
    PRIMARY KEY (id)
    );
    CREATE INDEX ON reviews (reviewer_idx);

    View Slide

  17. class Review {
    public int $id;
    public string $title;
    public string $review;
    public string $reviewer;
    }
    interface ReviewDatabase {
    function create(Review $review);
    function get(string $reviewId);
    function update(Review $review);
    function delete(string $reviewId);
    }

    View Slide

  18. class PlaintextDatabase implements ReviewDatabase {
    private $db;
    function __construct(PDO $db)
    {
    $this->db = $db;
    }
    function create(Review $review)
    {
    $statement = $this->db->prepare("INSERT INTO reviews (title, review, reviewer) VALUES (:title,
    :review, :reviewer)");
    $statement->bindParam(':title', $review->title);
    $statement->bindParam(':review', $review->review);
    $statement->bindParam(':reviewer', $review->reviewer);
    $statement->execute();
    }
    // ...

    View Slide

  19. class PlaintextDatabase implements ReviewDatabase {
    // ...
    function get(string $reviewId)
    {
    $statement = $this->db->prepare("SELECT * FROM reviews WHERE id = :id LIMIT 0, 1")
    $statement->bindParam(':id', $reviewId);
    while ($review = $statement->fetch()) {
    return new Review($review);
    }
    return null;
    }
    // ... and so on
    }

    View Slide

  20. Let’s add crypto...

    View Slide

  21. class EncryptedDatabase implements ReviewDatabase {
    private $db;
    private $key
    function __construct(PDO $db, string $key)
    {
    $this->db = $db;
    $this->key = $key;
    }
    // ...

    View Slide

  22. class EncryptedDatabase implements ReviewDatabase {
    // ...
    private function encryptString(string $plaintext)
    {
    $block_size = 16;
    $nonce = random_bytes(SODIUM_CRYPTO_SECRETBOX_NONCE_BYTES);
    $message = sodium_pad($plaintext, $block_size);
    // Return the nonce and the encrypted messsage
    return bin2hex($nonce . sodium_crypto_secretbox($message, $nonce, $this->key));
    }
    private function decryptString(string $ciphertext)
    {
    $block_size = 16;
    $nonce = substr(hex2bin($ciphertext), 0, SODIUM_CRYPTO_SECRETBOX_NONCE_BYTES);
    $message = substr(hex2bin($ciphertext), SODIUM_CRYPTO_SECRETBOX_NONCE_BYTES);
    $message = sodium_crypto_secretbox_open($encrypted, $nonce, $this->key);
    return sodium_unpad($message, $block_size);
    }
    // ...

    View Slide

  23. class EncryptedDatabase implements ReviewDatabase {
    // ...
    function create(Review $review)
    {
    $statement = $this->db->prepare("INSERT INTO reviews (title, review, reviewer) VALUES (:title,
    :review, :reviewer)");
    $statement->bindParam(':title', encryptString($review->title));
    $statement->bindParam(':review', encryptString($review->review));
    $statement->bindParam(':reviewer', encryptString($review->reviewer));
    $statement->execute();
    }
    // ...

    View Slide

  24. class EncryptedDatabase implements ReviewDatabase {
    // ...
    function get(string $reviewId)
    {
    $statement = $this->db->prepare("SELECT * FROM reviews WHERE id = :id LIMIT 0, 1")
    $statement->bindParam(':id', $reviewId);
    while ($review = $statement->fetch()) {
    return new Review([
    "id" => $review["id"],
    "title" => decryptString($review["title"]),
    "review" => decryptString($review["review"]),
    "reviewer" => decryptString($review["reviewer"])
    ]);
    }
    return null;
    }
    // ... and so on
    }

    View Slide

  25. Let’s add an index...

    View Slide

  26. class EncryptedDatabase implements ReviewDatabase {
    private $db;
    private $key
    private $hmac_keys;
    function __construct(PDO $db, string $key, array $hmac_keys)
    {
    $this->db = $db;
    $this->key = $key;
    $this->hmac_keys = $hmac_keys;
    }
    // ...

    View Slide

  27. class EncryptedDatabase implements ReviewDatabase {
    // ...
    function hashIndex($value, $index)
    {
    $hmac_key = $this->hmac_keys[$index];
    return hash_hmac('sha256', $value, $hmac_key);
    }
    function create(Review $review)
    {
    $statement = $this->db->prepare("INSERT INTO reviews (title, review, reviewer) VALUES (:title,
    :review, :reviewer, :reviewer_idx)");
    $statement->bindParam(':title', encryptString($review->title));
    $statement->bindParam(':review', encryptString($review->review));
    $statement->bindParam(':reviewer', encryptString($review->reviewer));
    $statement->bindParam(':reviewer_idx', hashIndex($review->reviewer, 'reviewer'));
    $statement->execute();
    }
    // ... and so on
    }

    View Slide

  28. class EncryptedDatabase implements ReviewDatabase {
    // ...
    function getAllByReviwer(string $reviewer)
    {
    $reviewerIdx = hashIndex($reviewer, 'reviewer');
    $statement = $this->db->prepare("SELECT * FROM reviews WHERE reviewer_idx = :id")
    $statement->bindParam(':idx', $reviewerIdx);
    $reviews = [];
    while ($review = $statement->fetch()) {
    $records[] = new Review([
    "id" => $review["id"],
    "title" => decryptString($review["title"]),
    "review" => decryptString($review["review"]),
    "reviewer" => decryptString($review["reviewer"])
    ]);
    }
    return $reviews;
    }
    // ...
    }

    View Slide

  29. Take a deep breath

    View Slide

  30. (Full image slide with caption)
    CipherSweet by Paragon Initiative Enterprsies: Fast, searchable field-level encryption for PHP
    projects

    View Slide

  31. Application-level Encryption
    By allowing the application to manage its own encryption keys, the
    crypto operations lift up into the application stack itself. The database
    engine can’t read or manage the data, neither can any other process in
    memory.
    Your data’s security then relies on the security of your application’s
    authentication and access control systems.

    View Slide

  32. (Full image slide with caption)
    Tom Cruise in "Mission: Impossible." Paramount

    View Slide

  33. Defense-in-Depth
    1. Evaluate threat models
    2. Encrypt in transit
    3. Encrypt at rest
    4. Limit access to keys
    5. GOTO 1

    View Slide

  34. Frequent Questions
    How do I query the database directly?
    How do I debug the system?
    What data really needs to be encrypted?
    Does CipherSweet work for more than just PHP?

    View Slide

  35. Questions?

    View Slide

  36. Thank you
    [email protected] | 503.925.6266

    View Slide
