Understanding the Web through HTTP

Ever wonder how the web really works?

Demystify the process through looking at how the HTTP protocol works through the OSI and TCP/IP model.

Transcript

1. Understanding the Web through HTTP Olivia Brundage
2. Agenda • Overall Flow of Data • How HTTP Requests Work • Introduction to HTTPS
3. Meet Datum! He’s just a baby now, but let’s see how he grows into a big data through the OSI (Open System Interconnection) model.
4. Physical Layer Datum’s home town. He communicates with everyone through a physical medium (like wires). His language is bits (0’s and 1’s).
5. Trailer Data Link Layer To talk to neighbors, Datum’s bits gets encapsulated as a frame so that the receiver know the start and end of the message. This layer provides node- to-node data transfer. Header DATA 1010 1010 01000100111 Bit pattern that specifies the start of the frame Bit pattern that specifies the end of the frame Frame
6. Network Layer In order to reach the outside world, Datum has to be transformed into a packet. Routers are responsible directing data to the correct machine. This is where you’ll find IP addresses. IP
7. Transport Layer To reach his destination, Datum must be transported via a segment or datagram. Segments are sent through the Transmission Control Protocol (TCP), which is for a connection- oriented transmission. Datagrams are sent through the User Datagram Protocol (UDP), which is for a connectionless transmission (e.g., streaming). IP
8. Session Layer Upon arriving at his destination, Datum must create an open session to the client, so that they can continue their business. Once here, Datum evolves into his final form: Data. IP
9. Presentation Layer Datum is now on the full screen! This layer takes all your backend code, CSS files, etc and delivers them to the final layer. IP
10. Application Layer This layer is the end-user product and contains high-level APIs like resource sharing and remote file access. This is also the layer you develop in! IP
11. What’s with this abstraction? • Gives us a framework on how data transforms throughout the network. • But it’s a little too specific; real networks are a lot muddier than this.
12. OSI vs TCP/IP TCP/IP combines some layers of the OSI, making it more succinct to the messier way of real life.
13. Where does HTTP fit into this?
14. First, let’s go over what HTTP is • HTTP stands for hyper-text transfer protocol. • This protocol is in plain-text and is stateless. • This protocol resides in the application layer.
15. Let’s break down these requests!
16. Make the Request! You type the URL (Uniform Resource Locator) in the browser: http://www.google.com
17. Hey, wait! What’s an URL? http://www.domain.com:1234/path/to/resource?a=b&x=y protocol host port resource path query
18. Now, time to get the IP address! After you type the address, another application layer protocol is used to get the IP address:
 the Domain Name System (DNS) What’s the IP to Google’s server? Google’s IP is 65.246.5.22 Domain Name Server Web Browser
19. HTTP makes the Request Racket
20. Generic Structure of HTTP Requests message = <start-line>
 *(<message-header>)
 CRLF # Carriage Return Line Feed (i.e., new line)
 [<message-body>] • Start line contains the initial request • Message headers give more details about the request you’re making (i.e., the host, how to maintain the connection, how to handle cookies, etc). NB: GET requests do not contain a message body, but POST requests can.
21. tl/dr: A simple request looks likes: VERB RESOURCE-URL PROTOCOL
 MESSAGE-HEADERS GET / HTTP/1.1
 HOST: www.google.com
 CONNECTION: keep-alive
22. HTTP Main Verbs • GET: fetches a resource determined by the URL • The server sends the resource in the message body if the status code is 200 • POST: creates a new resource where the requests specifies the data needed for the resource • Params are carried in the body of the request instead of the header; making this a more ‘secure’ type of request • PUT: updates a resource • DELETE: deletes a resource NB: PUT and DELETE can be considered a specialized versions of POST
23. Lesser-known Verbs • HEAD: Requests only the server headers. Primarily used for checking if the resource has changed via timestamps. • TRACE: Retrieves the hops that a request takes to round trip the serve. Used for network diagnostic purposes. • OPTIONS: Retrieves the server capabilities. For the client-side, it can be used to modify the request based on what the server can support.
24. HTTP Packet gets ready for Transportation! HTTP Request HTTP Packet TCP Packet The TCP information maintains the session.
 Now to the IP layer! TCP
25. TCP now hands it over to the Internet Protocol • Local/Sender Address: Your PC’s IP • Receiver Address: Google’s Server IP • Post Service Nodes: Routers
26. HTTP Request IP IP further encapsulates the data TCP TCP IP Packet Now we head over to the last layer!
27. Trailer HTTP Request Header The Network Interface Layer makes the Ethernet frame. IP TCP IP Packet Ethernet Frame We can finally send this HTTP request out!
28. The HTTP request is out!
29. So let’s recap.
30. But there’s still more to HTTP!!
31. Some important notes about the response: • The server will send the status code along with the message payload. • The status code tells the client how to interpret the server response.
33. 1xx: Informational Messages • This is just a provisional code and provides informational messages like: • Keep this connection alive (i.e., still sending information) • Tell the client to continue sending it’s message • Ignore the next response • This class was introduces in HTTP/1.1. Version 1.0 ignores this message.
34. 2xx: Successful Your request made it!
35. Request was completely successful.
36. Message successful, but there was no message body
37. 3xx: Redirection Your request needs to directed elsewhere.
38. Resource has moved to a new URL.
39. Resource has not been modified since last request.
40. 4xx: Client Error When the server thinks the client made a bad request.
41. Request can’t be fulfilled due to bad syntax.
42. Specifically used when authentication has failed.
43. Request was valid, but the server won’t respond.
44. Resource can’t be found. Try again later?
45. Method isn’t supported (like using a GET on a form that requires a POST method)
46. 5xx: Server Error Server failed creating the request
47. The infamous, generic server error.
48. The server doesn’t recognize the request method or can’t fulfill it.
49. The server was acting as a proxy and received something bad from the upstream server.
50. The server was acting as a proxy and did not receive a timely response from the upstream server.
51. Want more status codes? Here’s your source: https://httpstatusdogs.com/
52. Overall HTTP Interaction
53. So where does HTTPS come into play? That is: HTTP over TLS, HTTP over SSL, and HTTP Secure
54. What HTTPS Is • HTTPS provides authentication to the website and protection of the privacy and integrity of the exchanged data • Security is brought to you by the Secure Sockets Layer (SSL) or the improved Transport Layer Security (TLS). • Encryption is brought to you by Public Key Encryption and Symmetric Key Encryption. • This security component happens between HTTP request and TCP (before they connect).
55. HTTPS Happens Before the Connection is Made
56. How HTTPS Works • Client/Server Hellos • Authenticate Client and Server with Cryptography • Generate session keys • Further interactions will be based on the encrypted session keys
57. Questions?
