[ZendCon 2017] Silo-Based Architectures for High Availability Applications

Transcript

1. FOR HIGH AVAILABILITY APPLICATIONS
   SILO-BASED ARCHITECTURES
   Georgiana Gligor / Tekkie Consulting / @gbtekkie


   View Slide

2. 2
   ✤ Geek. Mother. Do-er.
   ✤ on LAMP stack since 2003
   ✤ Architecture / DevOps consultant
   ✤ RomaniaPHP Organizer
   ✤ PhD Student
   @gbtekkie
   gb@tekkie.ro
   GEORGIANA GLIGOR


   View Slide

3. 3
   advantages and disadvantages
   silos: a possible approach
   the need for high availability
   what is high availability (HA)?
   AGENDA


   View Slide

4. View Slide

5. 5
   https://youtu.be/MQm5BnhTBEQ


   View Slide

6. 6
   Tpguxbsf jnevtusz
   jt cvjmu bspvne
   bnujdjqbujnh dibnhf/


   View Slide

7. 7
   anticipate
   accommodate
   vs


   View Slide

8. TYPICAL
   APPLICATION


   View Slide

9. View Slide

10. View Slide

11. master
    Frontend
    Business
    Logic
    Frontend
    Frontend
    Browser
    internet
    Load
    balancer
    slave
    reads writes
    11
    ADJUSTING


    View Slide

12. master
    Frontend
    Business
    Logic
    Frontend
    Frontend
    Browser
    internet
    Load
    balancer
    slave
    reads writes
    12
    ADJUSTING
    redundancy


    View Slide

13. master
    Frontend
    Business
    Logic
    Frontend
    Frontend
    Browser
    internet
    Load
    balancer
    slave
    reads writes
    13
    ADJUSTING
    resilience


    View Slide

14. 14
    TYPICAL LAYERING


    View Slide

15. 15
    APPLICATION ARCHITECTURE


    View Slide

16. HIGH
    AVAILABILITY


    View Slide

17. 17
    Ability to access the system:
    ✤ retrieve information
    ✤ alter information
    ✤ send new data
    AVAILABILITY


    View Slide

18. https:/
    /flic.kr/p/dkasBz


    View Slide

19. 19
    THE 9s DANCE
    Uptime Downtime
    (per year)
    90.000 % 36.50 days one nine
    99.000 % 3.65 days two nines
    99.900 % 8.76 hrs three nines
    99.950 % 4 hrs 23 mins
    99.990 % 52.56 mins four nines
    99.999 % 5.26 mins five nines


    View Slide

20. 20
    THE 9s DANCE
    Uptime Downtime
    (per year)
    90.000 % 36.50 days
    99.000 % 3.65 days
    99.900 % 8.76 hrs
    99.950 % 4 hrs 23 mins Amazon SLA
    99.990 % 52.56 mins four nines
    99.999 % 5.26 mins five nines


    View Slide

21. 21
    IMPACT
    $ 144,000
    / hour
    3600
    $ 40
    / sec
    * =


    View Slide

22. 22
    USER BEHAVIOUR
    amazon facebook youtube
    Alexa Rank 6 3 2
    daily time on site
    12:07
    mins
    19:27
    mins
    23:44
    mins
    daily pageviews /
    visitor
    11.83 9.38 12.84
    bounce rate 21 % 29 % 33 %


    View Slide

23. 23
    HIGH AVAILABILITY TRIANGLE
    cost
    complexity
    risk


    View Slide

24. 24
    DOWNTIME
    ✤ scheduled
    ‣ you
    ✤ unscheduled
    ‣ you
    ‣ others


    View Slide

25. 25
    HAPPENS TO THE BEST


    View Slide

26. 26
    MICHAEL JACKSON


    View Slide

27. ‹#›
    H.A. SYSTEM
    CHARACTERISTICS


    View Slide

28. https://flic.kr/p/quMmFw
    NO SINGLE POINT OF FAILURE


    View Slide

29. https://en.wikipedia.org/wiki/Point_of_sale#/media/File:Cash_Registers.JPG
    RELIABLE CROSSOVER


    View Slide

30. https://flic.kr/p/4S4uDz
    DETECT FAILURES AS THEY OCCUR


    View Slide

31. 31
    HA BEST PRACTICES
    1. no single points of failure
    2. stateless application design
    3. automate infrastructure for consistency & reliability
    4. clever monitoring and alerting
    5. geographically distribute your machines
    6. keep spare capacity to meet increasing demand


    View Slide

32. 32
    B nbn“t hpu
    up lnpx ijt
    mjnjubujpnt/
    - Dirty Harry


    View Slide

33. SILOS


    View Slide

34. 34
    TRY UPGRADE TO PHP7


    View Slide

35. 35
    WHAT IS A SILO?
    ✤ frontend (SPAs, PWAs, etc)
    ✤ backend (e.g. PHP services)
    ✤ data (including cache)
    1 silo = full setup of servers that
    deliver the end-to-end functionality


    View Slide

36. 36
    WHAT IS A SILO?


    View Slide

37. 37
    SILO-BASED ARCHITECTURE


    View Slide

38. 38
    MULTIPLE CACHES


    View Slide

39. 39
    A/B TESTING


    View Slide

40. 40
    GEOGRAPHICAL DISTRIBUTION


    View Slide

41. 41
    LIVE UPGRADES


    View Slide

42. 42
    ADVANTAGES
    ✤ reuse familiar technology
    ✤ real A/B testing
    ✤ no BHUF requirements
    ✤ no disruption => brand loyalty
    ✤ lower Total Cost of Ownership
    ✤ simplify scalability


    View Slide

43. 43
    DISADVANTAGES
    ✤ needs razor-sharp DevOps team
    ✤ small increase in hardware costs on kick-off
    ✤ adds complexity to the monitoring layer
    ✤ reconsider traceability
    ✤ different bug reproducing and hunting


    View Slide

44. 44
    TAKEAWAYS


    View Slide

45. 45
    ✤ build situational awareness with
    clever monitoring
    ✤ automate outage detection
    ✤ powerful A/B testing
    TAKEAWAYS


    View Slide

46. 46
    FURTHER READING
    ✤ Wikipedia HA page
    ✤ OpenStack’s HA concepts
    ✤ Merge Hemo report from FDA
    ✤ USA Presidential Policy Directive 21
    ✤ “Beyond Legacy Code” book
    ✤ TechCrunch’s summary of sites affected by Michael Jackson’s death
    ✤ Netflix lessons learned after AWS outage
    ✤ Netflix Chaos Monkey source code
    ✤ Brian Adler’s talk on “Architecting for High Availability and Multi-Cloud”


    View Slide

47. ‹#›
    QUESTIONS?
    }
    Efficient architecture.
    Performance oriented.
    AI enhanced.
    dev@tekkie.ro


    View Slide
