1. Secure Microservices Adoption Grygoriy Gonchar (@ggonchar) Software Security Architect @Kreditech
2. Microservices
3. Componentization via services
4. Decentralised data management
5. As a result isolated security risks
6. Not every service is equally important
7. Isolated Microservices reduce overall security risks
8. But service distribution introduce new risks
9. Authentication & Authorization
10. Problem: End-users need to interact with multiple services
11. Problem: End-users frequently include many roles
12. Possible solution: API Gateway deals with all end-user requests
13. Possible solution: Backend for frontend (BFF) for different end-users
14. Defining Trust Boundaries
15. Security checks around Trust Boundary
16. For different use-cases fit different AuthN & AuthZ solutions
17. BFF encapsulates end-user roles and is responsible for resource AuthZ
18. Entity level AuthZ is a part of Downstream Microservices contract
19. As a Customer I want to access/update my order
20. As a Delivery Agent I want to access/update my order
21. Missing access control
22. Internal Trust Boundaries
23. TLS CCA - certificate as client identity
24. Validating client certificates server { ssl_verify_client on; ssl_client_certificate /etc/nginx/certs/zone-1-ca.crt; if ($ssl_client_s_cn !~ '/CN=shopping-cart-srv/') { return 403; } } http://nginx.org/en/docs/http/ngx_http_ssl_module.html
25. Why TLS client certificates You pay once for automated short-lived TLS certificates - you get both strong transport security and authentication Mutual authentication can be implemented Single service identity reduce amount of application secrets, asymmetric security - no shared secrets Application code can even don’t know about TLS but risk of misconfiguration exists Certificate hierarchies as additional layer of defence
26. Tools for friendly automation already there Let’s Encrypt Netflix Lemur HashiCorp Vault
27. Big picture
28. Solution Summary BFF can delegate AuthN and encapsulate roles complexity from Downstream Microservices End-user types and roles are easier to change Downstream Microservices deal with entity level AuthZ and are agnostic to end- user types and roles Downstream Microservices deal only with trust between services using TLS client certificates Downstream Microservices are more context agnostic and reusable
29. Secrets Management
30. More services - more secrets (passwords, certificates etc.)
31. https://12factor.net/
32. No secrets in code “A litmus test for whether an app has all config correctly factored out of the code is whether the codebase could be made open source at any moment, without compromising any credentials.” https://12factor.net/config
33. No secrets in code https://github.com/awslabs/git-secrets $ git-secrets --scan -r my-project/ conf//application.yml:8: AWS_ACCESS_KEY_ID: 'FR4EFR3Y76R2HE4H’ conf//application.yml:9: AWS_SECRET_KEY: 'wcwdc9wd8w8qqDDqq0 [ERROR] Matched one or more prohibited patterns
34. Secret Management Software Store secrets encrypted Transfer secrets encrypted Audit all access Rotate automatically Fine-grained access control
35. Secret Management Software Store secrets encrypted Transfer secrets encrypted Audit all access Rotate automatically Fine-grained access control - !permit role: *my-application privilege: [ read ] resource: *database-password - !permit role: *deployment-agent privilege: [ write ] resource: *database-password https://developer.conjur.net/reference/policy-markup.html
36. Secret Management Software Conjur https://www.conjur.com/secretsmanagement Vault https://github.com/hashicorp/vault Docker 1.13 Secrets https://docs.docker.com/engine/swarm/secrets/ Kubernetes Secrets https://kubernetes.io/docs/user-guide/secrets/ DC/OS Secrets https://docs.mesosphere.com/1.8/administration/secrets/ Many more https://github.com/sweis/crypto-might-not-suck
37. Vulnerable Dependencies
38. Microservices promote usage of different technologies
39. https://pivotal.io/security example of excellent vulnerability reporting
40. https://srcclr.com/ scans dependencies automatically
41. https://github.com/coreos/clair scans Docker containers
42. https://github.com/docker/docker-bench-security
43. Conclusions
44. Microservices Architecture Separation into Microservices can reduce security risks Distribution and technology diversity introduce new risks Thoughtful AuthN & AuthZ strategy required Secure Microservices adoption require automation to mitigate new risks (secrets management, vulnerability assessment etc.)
45. Automate your security http://martinfowler.com/bliki/MicroservicePrerequisites.html
46. Use other security practices Thread Modeling Secure Coding Practices Security Testing Incident Response Planning … many more
47. Questions? @ggonchar
