How to become a SHiPS wright - Building with SHiPS

Becoming a
SHiPS wright
Building with SHiPS
@glennsarti glenn-sarti

View Slide

@glennsarti

View Slide

@glennsarti
Becoming a
SHiPS wright

View Slide

@glennsarti
What is SHiPS?

View Slide

@glennsarti
SHiPS is a PowerShell provider.
More accurately it is a provider
platform that simplifies developing
PowerShell providers.
- https://www.powershellgallery.com/packages/SHiPS

View Slide

@glennsarti
PowerShell providers provide access to data
and components that would not otherwise
be easily accessible at the command line. The
data is presented in a consistent format that
resembles a file system drive..
- about_providers

View Slide

@glennsarti
PS C:\Users\glenn.sarti> Get-PSProvider
Name Capabilities Drives
---- ------------ ------
Registry ShouldProcess {HKLM, HKCU}
Alias ShouldProcess {Alias}
Environment ShouldProcess {Env}
FileSystem Filter, ShouldProcess, Credentials {C}
Function ShouldProcess {Function}
Variable ShouldProcess {Variable}

View Slide

@glennsarti
PS C:\Users\glenn.sarti> Get-ChildItem HKLM:\System
Hive: HKEY_LOCAL_MACHINE\System
Name Property
---- --------
ActivationBroker
ControlSet001
DriverDatabase Version : 167772160
SchemaVersion : 65536
Architecture : 9
UpdateDate : {64, 148, 108, 19...}
OemInfMap : {255, 255, 255, 255...}
HardwareConfig LastConfig : {a4c71b4c-22d3-11b2-a85c-f593fd660ebe}
LastId : 0
…

View Slide

@glennsarti
Why do I need SHiPS?

View Slide

@glennsarti
Providers are great

View Slide

@glennsarti
Providers are hard

View Slide

@glennsarti
File System 9,965
Registry 4,373
Certificates 3,454
Functions 388
Aliases 358
Environment 246
Variables 239

View Slide

@glennsarti
File System 13,113
Registry 7,521
Certificates 6,602
Functions 3,537
Aliases 3,507
Environment 3,388
Variables 3,395

View Slide

@glennsarti
SHiPS is a PowerShell provider.
More accurately it is a provider
platform that simplifies developing
PowerShell providers.
- https://www.powershellgallery.com/packages/SHiPS

View Slide

@glennsarti
When did SHiPS
become a thing?

View Slide

@glennsarti
2018 2019
2014 2015 2016 2017
Simplex
P2F
Azure Cloud Shell Public Preview
SHiPS on PS Gallery
Releases (0.8.1)
SHiPS

View Slide

@glennsarti
Module
You are here
SHiPS
P2F
PowerShell

View Slide

@glennsarti
using namespace Microsoft.PowerShell.SHiPS
# Root
class Parent : SHiPSDirectory
{
Parent([string]$name): base($name) { }
[object[]] GetChildItem()
{
return [Child]::new("Child");
}
}
class Child : SHiPSLeaf
{
Child($name): base($name) { }
}

View Slide

@glennsarti
What things can I SHiPS-ify?

View Slide

@glennsarti
Deepak - https://github.com/DexterPOSH
Glenn - https://github.com/glennsarti
Ravi - https://github.com/rchaganti
Patrick - https://github.com/SeeminglyScience
PS - https://github.com/PowerShell

View Slide

@glennsarti

View Slide

@glennsarti
Directed
Acyclical
Graph

View Slide

@glennsarti
Directed
Acyclical
Graph
A
B
C
D
A/B/C

View Slide

@glennsarti
Directed
Acyclical
Graph
A
B
C
D

View Slide

@glennsarti
Directed
Acyclical
Graph
❌
A
B
C
D
A/B/C/A/B/C/A …

View Slide

@glennsarti
Directed
Acyclical
Graph
A
B
C
D
A/B/C A/B/D/C

View Slide

@glennsarti
DAGs in the wild …

View Slide

@glennsarti
Filesystem Registry

View Slide

@glennsarti
AD Org. Units Certificates

View Slide

@glennsarti
Azure Resource Groups

View Slide

@glennsarti
Azure DevOps Pipelines

View Slide

@glennsarti

View Slide

@glennsarti
DAGs are everywhere!

View Slide

@glennsarti
And?

View Slide

@glennsarti
Austin
Cathy
Ben
Bill Chris

View Slide

@glennsarti
Austin
Bill
SHiPSDirectory
SHiPSLeaf
GetChildItem

View Slide

@glennsarti
Become a
SHiPS wright

View Slide

@glennsarti
Step 0
Put the computer away

View Slide

@glennsarti

View Slide

@glennsarti
Step 0.5
Install SHiPS
https://github.com/PowerShell/SHiPS#installing-ships

View Slide

@glennsarti
Step 1
Create root object

View Slide

@glennsarti
Root

View Slide

@glennsarti
@{
RootModule = 'PSSummitNA2019.psm1'
ModuleVersion = '1.0'
GUID = '2e946999-7d90-4bfb-88f1-9336e3a01587'
Author = 'glenn.sarti'
CompanyName = 'Glenn Sarti'
Description = 'A PowerShell Provider for the Pow…'
# Modules that must be imported into the global …
RequiredModules = @('SHiPS')
}

View Slide

@glennsarti
# Root
[SHiPSProvider(UseCache=$true)]
class Summit2019 : SHiPSDirectory
{
Summit2019([string]$name): base($name)
{
}
{
$obj = @()
return $obj;
}
}

View Slide

@glennsarti
# Root
{
{
}
{
$obj = @()
return $obj;
}
}
???

View Slide

@glennsarti
PS > Import-Module .\PSSummitNA2019.psd1

View Slide

@glennsarti
PS > New-PSDrive -Name Summit2019 `
-PSProvider SHiPS `
-Root 'PSSummitNA2019#Summit2019'
Name Used (GB) Free (GB) Provider Root
---- --------- --------- -------- ----
Summit2019 SHiPS PSSum…

View Slide

@glennsarti
-PSProvider SHiPS `
---- --------- --------- -------- ----
PS > gci Summit2019:\
PS >

View Slide

@glennsarti
Step 2
Create directories

View Slide

@glennsarti
Speakers
Agenda

View Slide

@glennsarti
# Directory Nodes
# Speakers
class Speakers : SHiPSDirectory
{
Speakers([string]$name): base($name)
{
}
{
return @()
}
}
# Agenda

View Slide

@glennsarti
}
}
# Agenda
class Agenda : SHiPSDirectory
{
Agenda([string]$name): base($name)
{
}
{
return @()
}
}

View Slide

@glennsarti
# Root
{
{
}
{
$obj = @()
return $obj;
}
}
# Directory Nodes
# Speakers

View Slide

@glennsarti
# Root
{
{
}
{
$obj = @()
$obj += [Speakers]::new('Speakers’);
$obj += [Agenda]::new('Agenda’);
return $obj;
}
}

View Slide

@glennsarti
-PSProvider SHiPS `
---- --------- --------- -------- ----

View Slide

@glennsarti
PS > gci Summit2019:\
Directory: Summit2019:
Mode Name
---- ----
+ Speakers
+ Agenda
PS >

View Slide

@glennsarti
Step 3
Create Speaker leaves

View Slide

@glennsarti
Bob
Alice

View Slide

@glennsarti
# Private Functions
$Script:DataSource = Join-Path -Path $PSScriptRoot -ChildPath 'Data'
Function Get-SpeakersObject {
if ($Script:SpeakerObject -eq $null) {
$Script:SpeakerObject = Get-Content … | ConvertFrom-Json
}
Write-Output $Script:SpeakerObject
}
Function Remove-HTML($RawString) {
$result = $RawString
$result = $result -replace '<[^>]+>',‘’
Write-Output $result
}

View Slide

@glennsarti
# Leaf Nodes
# A Speaker
class Speaker : SHiPSLeaf
{
[String]$Name;
[String]$FirstName;
[String]$LastName;
[String]$Bio;
Speaker ([string]$name, [Object]$data): base($name)
{
$this.PopulateFromData($data)
}
[void] PopulateFromData([Object]$data) {
$this.Name = $data.name
# VERY basic name splitting
$NameArray = $this.Name -split " ", 2
$this.FirstName = $NameArray[0]
$this.LastName = $NameArray[1]
$this.Bio = Remove-HTML -RawString $data.overview
}
}

View Slide

@glennsarti
# Speakers
{
{
}
{
return @()
}
}

View Slide

@glennsarti
# Speakers
{
{
}
{
$obj = New-Object System.Collections.ArrayList($null)
(Get-SpeakersObject).items | ForEach-Object -Process {
$obj.Add([Speaker]::new($_.name, $_))
}
return $obj;
}

View Slide

@glennsarti
PS > gci Summit2019:\Speakers | Select-Object -First 5
Directory: Summit2019:\Speakers
Mode Name
---- ----
. James O'Neill
. Christoph Bergmeister
. Walter Legowski
. Paul DeArment Jr
. Daniel Bohannon
PS >

View Slide

@glennsarti
PS > gci Summit2019:\Speakers | select -First 1 –Property *
SSItemMode : .
PSPath : SHiPS\SHiPS::PSSummitNA2019#Summit2019\Speakers\James
PSParentPath : SHiPS\SHiPS::PSSummitNA2019#Summit2019\Speakers
PSChildName : James O'Neill
PSDrive : Summit2019
PSProvider : SHiPS\SHiPS
PSIsContainer : False
Name : James O'Neill
FirstName : James
LastName : O'Neill
Bio : James O'Neill spent the first 10 years of this century
talking about it to anyone who will listen ever since.
and DSC to automate processes for one of Britiain's be
…
PS >

View Slide

@glennsarti
Step 4
Expand objects

View Slide

@glennsarti
Session 1
Session 2
Session 3
Day 1
All

View Slide

@glennsarti
Function Get-SessionsObject {
…
}
Function Get-Sessions($Filter) {
…
}
Function ConvertFrom-EpochTime($Value) {
…
}

View Slide

@glennsarti
# A Session on the agenda
class AgendaSession : SHiPSLeaf
{
[String]$Id;
[String]$Name;
[datetime]$Start;
[datetime]$End;
[String]$Location;
[String]$Description;
Hidden [Object] $Data
AgendaSession([string]$id, $data): base($id)
{
$this.Id = $Id
$this.Data = $data

View Slide

@glennsarti
[String]$Description;
Hidden [Object] $Data
{
$this.Id = $Id
$this.Data = $data
$this.Description = Remove-HTML $data.overview
$this.Start = ConvertFrom-EpochTime -Value $data.start_time
$this.End = ConvertFrom-EpochTime -Value $data.end_time
$this.Location = ($data.regions | Select-Object -First 1 |
ForEach-Object { $_.name })
}
}

View Slide

@glennsarti
Session 1
Session 2
Session 3
Day 1
All

View Slide

@glennsarti
# AgendaTrackSummary
class AgendaTrackSummary : SHiPSDirectory
{
[String]$Name;
[Int]$Sessions;
Hidden [Hashtable]$Filter;
AgendaTrackSummary([string]$name, [Hashtable]$filter): base($name)
{
$this.Name = $name
$this.Filter = $filter
$this.Sessions = (Get-Sessions -Filter $this.Filter | Measure-Object).Count;
}
{

View Slide

@glennsarti
}
{
Get-Sessions -Filter $this.Filter | ForEach-Object -Process {
$obj.Add([AgendaSession]::new($_.Id, $_))
}
return $obj;
}
}

View Slide

@glennsarti
{
return @()
}

View Slide

@glennsarti
{
$obj.Add([AgendaTrackSummary]::new('All', @{ }))
$obj.Add([AgendaTrackSummary]::new('Day 1 - Mon', @{ 'Day' = 29 }))
$obj.Add([AgendaTrackSummary]::new('Day 2 - Tue', @{ 'Day' = 30 }))
$obj.Add([AgendaTrackSummary]::new('Day 3 - Wed', @{ 'Day' = 1 }))
$obj.Add([AgendaTrackSummary]::new('Day 4 - Thu', @{ 'Day' = 2 }))
$trackList = @{}
(Get-SessionsObject).sessions | ForEach-Object -Process {
$_.tracks | ForEach-Object -Process {
$trackList[$_.name] = $true
}
}
$trackList.GetEnumerator() | ForEach-Object -Process {
$obj.Add([AgendaTrackSummary]::new($_.Key, @{ 'Track' = $_.Key }))
}
return $obj;
}

View Slide

@glennsarti
PS > gci Summit2019:\Agenda | `
Select-Object -Property Name, Sessions | `
Format-Table

View Slide

@glennsarti
Name Sessions
---- --------
All 80
Day 1 - Mon 9
Day 2 - Tue 25
Day 3 - Wed 26
Day 4 - Thu 20
In the Cloud 8
Meal 9
Vendor 2
General 12
Bits and Bytes 14
Automate All the Things 17
OnRamp 3
PowerShell Language 17

View Slide

@glennsarti
PS > gci 'Summit2019:\Agenda\Day 2 – Tue' | `
Select-Object -First 5

View Slide

@glennsarti
Directory: Summit2019:\Agenda\Day 2 - Tue
Mode Name
---- ----
. 61513
. 61461
. 61464
. 61475
. 61494
PS>

View Slide

@glennsarti
PS > gci 'Summit2019:\Agenda\Day 2 – Tue' | `
Select-Object -First 5 –Property *

View Slide

@glennsarti
SSItemMode : .
PSPath : SHiPS\SHiPS::PSSummitNA2019#Summit2019\Agenda\Day 2 - Tu
PSParentPath : SHiPS\SHiPS::PSSummitNA2019#Summit2019\Agenda\Day 2 - Tu
PSChildName : 61513
PSDrive : Summit2019
PSProvider : SHiPS\SHiPS
PSIsContainer : False
Id : 61513
Name : Breakfast
Start : 30/04/2019 08:00:00
End : 30/04/2019 09:00:00
Location : Center Hall A
Description : Join us for a hot breakfast. We'll have announcements
SSItemMode : .
PSPath : SHiPS\SHiPS::PSSummitNA2019#Summit2019\Agenda\Day 2 - Tu

View Slide

@glennsarti
Step 5
Add content

View Slide

@glennsarti
# VERY basic name splitting
$NameArray = $this.Name -split " ", 2
$this.FirstName = $NameArray[0]
$this.LastName = $NameArray[1]
$this.Bio = Remove-HTML -RawString $data.overview
}
[string] GetContent()
{
return "# " + $this.Name + "`n`n## Bio`n`n" + $this.Bio
}
}

View Slide

@glennsarti
$this.Description = Remove-HTML $data.overview
$this.Start = ConvertFrom-EpochTime -Value $data.start_time
$this.End = ConvertFrom-EpochTime -Value $data.end_time
$this.Location = ($data.regions | Select-Object -First 1 | ForEach-
}
[string] GetContent()
{
return "### " + $this.name + "`n`n" + `
"Time:" + $this.Start.ToString('hh:mm tt') + `
" Location:" + $this.Location + "`n`n" + `
$this.Description + "`n`n"
}
}

View Slide

@glennsarti
PS > Get-Content 'Summit2019:\Speakers\Glenn Sarti'
# Glenn Sarti
## Bio
I’m located in Perth (Western Australia) where I now work at
Puppet as Senior Software Developer on the Windows team. Fro
…
PS >

View Slide

@glennsarti
PS > Get-Content 'Summit2019:\Agenda\Day 2 - Tue\61451'
### Parselmouth - bending the PowerShell language
Time:11:00 AM Location:406
I want to introduce the audience to the high-level design of
the tokenizer, parser and compiler in PowerShell Core, and
then take it a step …
PS >

View Slide

@glennsarti
Step 6
Add leaf connections

View Slide

@glennsarti
Root
Alice
Session 2
Session 3
Day 1
All
Speakers
Agenda
Bob
Session 1

View Slide

@glennsarti
Bob
Session 1
❌

View Slide

@glennsarti
{
…
[String[]]$SessionIDs;
[String[]]$Sessions;
[int]$NumSessions;
[String[]]$SessionTimes;
[void] PopulateFromData([Object]$data) {
…
$this.Sessions = @()
$this.SessionIDs = @()
$this.SessionTimes = @()
Get-Sessions -Filter @{ 'Speaker' = $data.Id} | ForEach-Object {
$this.Sessions += $_.name
$start = (ConvertFrom-EpochTime -Value $_.start_time).ToString("d MMM, hh:mm tt")
$this.SessionIDs += $_.id
$this.SessionTimes += $start
}
$this.NumSessions = $this.Sessions.Count
}
…

View Slide

@glennsarti
class AgendaSession : SHiPSLeaf
{
…
[String[]]$Speakers
{
…
$this.Speakers = $this.Data.item_ids | ForEach-Object -Process {
$SpeakerID = $_
Write-Output (Get-SpeakersObject).items | `
Where-Object { $_.id -eq $SpeakerId } | `
ForEach-Object { Write-Output $_.name }
}
}
…

View Slide

@glennsarti
PS > gci 'Summit2019:\Speakers\Glenn Sarti' | Select *
...
Name : Glenn Sarti
FirstName : Glenn
LastName : Sarti
Bio : I’m located in Perth (Western Australia)…
SessionIDs : {61496, 61497}
Sessions : {Beyond Pester 102: Acceptance testing w…
NumSessions : 2
SessionTimes : {30 Apr, 02:00 PM, 1 May, 11:00 AM}

View Slide

@glennsarti
PS > gci 'Summit2019:\Agenda\Day 2 - Tue\61451' | Select *
...
Id : 61451
Name : Parselmouth - bending the PowerShell lang…
Start : 30/04/2019 11:00:00
End : 30/04/2019 11:45:00
Location : 406
Description : I want to introduce the audience to the …
Speakers : Mathias Jessen

View Slide

@glennsarti
Step 7
Make it pretty

View Slide

@glennsarti
PS > Get-Help about_Format.ps1xml

View Slide

@glennsarti
@{
RootModule = 'PSSummitNA2019.psm1’
ModuleVersion = '1.0’
GUID = '2e946999-7d90-4bfb-88f1-9336e3a01587’
Author = 'glenn.sarti’
CompanyName = 'Glenn Sarti’
Description = 'A PowerShell Provider for the Pow…’
# Modules that must be imported into the global …
RequiredModules = @('SHiPS’)
FormatsToProcess = @('PSSummitNA2019.Format.ps1xml')
}

View Slide

@glennsarti
PS > gci Summit2019:\Speakers | `
Select-Object –First 3 | Format-Table
Mode Name
---- ----
. James O'Neill
. Christoph Bergmeister
. Walter Legowski

View Slide

@glennsarti
Name Session Times Bio
---- ------------- ---
James O'Neill {2 May, 01:00 PM} James O'Neill spe…
Christoph Bergmeister {30 Apr, 02:00 PM} I am a developer …
Walter Legowski {1 May, 11:00 AM} ###**Walter Legow…

View Slide

@glennsarti
PS > gci 'Summit2019:\Agenda\In the Cloud' | `
Sort-Object –Property Start | `
Select-Object –First 3 | Format-List
Mode : .
Name : 61464
Mode : .
Name : 61501
Mode : .
Name : 61466

View Slide

@glennsarti
Id : 61464
Name : Introduction to Serverless Functions
Start : 30/04/2019 09:00:00
Location : 405
Speakers : Kirk Munro
Description : I've spent a lot of time working with server …
Id : 61501
Name : Demystifying Microsoft's Cloud Automation products
Start : 30/04/2019 11:00:00
Location : 405
Speakers : Jaap Brasser
Description : Azure offers an evergrowing suite of produ …
Id : 61466
Name : It’s PowerShell In the Cloud – Welcome to Azure Cloud Shell
Start : 30/04/2019 13:00:00
Location : 405
Speakers : Michael Bender
Description : As more organizations move towards the cloud and using Microsoft …

View Slide

@glennsarti
What did I just see?

View Slide

@glennsarti
• Start with some planning
• Create the root object first
• … then the Directories
• … then the Leaves
• Expand – Test – Iterate
• Then make it pretty

View Slide

@glennsarti
More please …

View Slide

@glennsarti
Using an API

View Slide

@glennsarti

View Slide

@glennsarti
Credentials

View Slide

@glennsarti
PS> New-PSDrive -Name Github -PSProvider SHiPS `
-root 'Github#Root’ `
-Credential (Get-Credential 'glennsarti')
PowerShell credential request
Enter your credentials.
Password for user glennsarti: *********
The provider does not support the use of credentials. Perform the operation
At line:1 char:1
+ New-PSDrive -Name Github -PSProvider SHiPS -root 'Github#Root' -Crede ...
+ ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
+ CategoryInfo : NotImplemented: (:) [], PSNotSupportedException
+ FullyQualifiedErrorId : NotSupported
PS >
☹

View Slide

@glennsarti
• Github Issue #110
• Environment Variables
• Files / Registry
• Anything outside of PS

View Slide

@glennsarti
Runspaces

View Slide

@glennsarti
Default Runspace
PS>

View Slide

@glennsarti
Default Runspace
$Global:GithubToken
Set-GitHubToken
PS> Import-Module .\Github.psd1

View Slide

@glennsarti
Default Runspace
$Global:GithubToken
Set-GitHubToken
PS> Set-GitHubToken abc123
abc123

View Slide

@glennsarti
Default Runspace
$Global:GithubToken
Set-GitHubToken
PS> New-PSDrive –Name Github –Provider SHiPS …
abc123
Drive Runspace
$Global:GithubToken
Set-GitHubToken

View Slide

@glennsarti
Caching

View Slide

@glennsarti
… for better navigation user experience … an author can
decide to set UseCache to true, to cache data returned from
Get-ChildItem to memory in the current PowerShell session.
- SHiPS documentation
{

View Slide

@glennsarti
Set-Content, Filtering,
Dynamic Parameters

View Slide

@glennsarti
Set-Content 'Summit2019:\Speakers\Glenn Sarti'
Set-Content

View Slide

@glennsarti
PS > gci Summit2019:\Speakers –Filter Glenn*
PS > gci Summit2019:\Speakers | `
Where-Object { $_.Name –like 'Glenn*'}
Filtering

View Slide

@glennsarti
PS > gci Summit2019:\Agenda\All | `
Where-Object { $_.Track –eq 'General' }
PS > gci Summit2019:\Agenda –Track General
PS > gci Summit2019:\Agenda –Day 2
PS > gci Summit2019:\Agenda –Speaker 'Glenn Sarti'
… or combine them -Track General –Day 2
Dynamic Parameters

View Slide

@glennsarti
See /samples/DynamicParameter for documentation

View Slide

@glennsarti
Testing?

View Slide

@glennsarti
Making SHiPS better

View Slide

@glennsarti
Doesn’t support credentials
Tiny supported cmdlet list
Doesn’t support New, Remove, Rename, Move, Copy,
*ItemProperty
No Drive information within
Provider Context

View Slide

@glennsarti
SHiPS is still young

View Slide

@glennsarti
Wrapping up…

View Slide

@glennsarti
SHiPS is a UX module
Start small and iterate
Read the docs
Remember the DAG

View Slide

THANK YOU!
Please use the event app or Socio to submit a session rating!
@glennsarti
http://glennsarti.github.io/
https://speakerdeck.com/glennsarti
https://github.com/glennsarti/PSSummitNA2019-Ships

View Slide

@glennsarti
Resources
Ravikanth Chaganti
PS Conf EU 2018 - SHiPS: Walk-through a bare-metal system configuration
https://github.com/psconfeu/2018/tree/master/Ravikanth%20Chaganti/SHiPS
SHiPS GH Repo
https://github.com/PowerShell/SHiPS
SHiPS PS Gallery
https://www.powershellgallery.com/packages/SHiPS
https://www.powershellgallery.com/packages?q=ships
about_format.ps1xml
https://docs.microsoft.com/en-us/powershell/module/microsoft.powershell.core/about/
about_format.ps1xml?view=powershell-5.1

View Slide

@glennsarti
Resources
Writing a PowerShell Formatting File
https://docs.microsoft.com/en-us/powershell/developer/format/
writing-a-powershell-formatting-file
SHiPS Default formatting
https://github.com/PowerShell/SHiPS/blob/master/src/Modules/SHiPS.formats.ps1xml
Images
https://unsplash.com

View Slide

How to become a SHiPS wright - Building with SHiPS

How to become a SHiPS wright - Building with SHiPS

Glenn

More Decks by Glenn

Other Decks in Technology

Featured

Transcript
