Zygo Interferometry of Echelle Gratings

This deck illustrates the need to deproject interferometry of echelle gratings to understand the origin of instrumental artifacts in the device development process.

Transcript

1. zygo interferometry of gratings
   michael gully-santiago | grad student
   UT Austin Silicon Diffractive Optics Group


   View Slide

2. who
   michael gully-santiago
   astronomer, engineer,
   bicycle rider
   amanda turbyfill
   astrophysicist,
   basketball enthusiast


   View Slide

3. Interferometry tells us two things
   Where did we go wrong?
   Is it good enough?


   View Slide

4. Interferometry tells us two things
   Where did we go wrong?
   Is it good enough?
   Astronomers care about this
   Engineers care about this


   View Slide

5. There are two data products
   Where did we go wrong?
   Is it good enough?
   Astronomers care about this
   Engineers care about this
   PSF
   FULL
   MAP


   View Slide

6. PSF
   FULL
   MAP
   The two data products are
   related to each other


   View Slide

7. PSF
   FULL
   MAP
   The two data products are
   related to each other
   Sub
   aperture
   FFT
   €
   ∫∫


   View Slide

8. Let’s talk about the full map.
   Since we’re engineers


   View Slide

9. You have to de-project
   the full map.


   View Slide

10. de-project


    View Slide

11. We didn’t used to
    de-project


    View Slide

12. We didn’t used to
    probably because astronomers don’t care.
    de-project


    View Slide

13. We didn’t used to
    probably because astronomers don’t care.
    but now we’re learning something,
    because de-projected images look like
    what engineers see.
    shadow of
    grating holder
    Shadow
    of
    grating holder
    Photoresist thickening at edge
    Periodic
    structures
    resembling
    Newton’s fringes
    Comets from photoresist spin
    Photoresist
    thickening at edge
    de-project


    View Slide

14. We can do even better with
    shadow of
    grating holder
    Shadow
    of
    grating holder
    Photoresist thickening at edge
    Periodic
    structures
    resembling
    Newton’s fringes
    Comets from photoresist spin
    Photoresist
    thickening at edge


    View Slide

15. high pass*
    .
    We can do even better with
    shadow of
    grating holder
    Shadow
    of
    grating holder
    Photoresist thickening at edge
    Periodic
    structures
    resembling
    Newton’s fringes
    Comets from photoresist spin
    Horizontal artifact,
    probably from using the cart and slit.
    high pass filtering* is:
    way faster than fitting Zernike polynomials.
    k ~ 51 pixels is the median smoothing kernel
    d = d - median( d, k )


    View Slide

16. But since we are astronomers and engineers, we want
    the best of both worlds™, so:
    We are proud to introduce…
    ZIGZAG:
    Zygo Interferometry of
    Gratings with Zernike
    Analysis by Gully


    View Slide

17. View Slide

18. View Slide

19. View Slide

20. H!
    L!
    !"
    Silicon!
    Desired line
    edge position!
    Realized line
    edge position!
    Value measured by Zygo!


    View Slide

21. I’m having a hard time getting the PSF
    to work. This is either hard or I am
    not smart enough to figure it out.
    Help!



    View Slide

22. In summary: gully@astro.as.utexas.edu |
    astronomer and engineer
    You have to de-project
    the full map.
    and high pass filter
    and ZIGZAG™ does it all
    except PSFs… for now.


    View Slide
