Manufacturing Preparation

Talk by Jude Abalaka at v2.3, Saturday August 19 2017.

Transcript

1. Manufacturing JUDE ABALAKA TRANOS
2. Introduction  My name is Jude Abalaka, the Managing Director of Tranos Contracting Limited  TRANOS is a diversified technology company focused on improving lives through innovative solutions  We have products in power generation, electrical distribution, control and automation and enclosure solutions. I AND MY COMPANY
3. Engineering Design  Engineering Design & Drawings  Bill of Materials  Manufacturability and Production Methodology  Tooling  Routing
4. Supply Chain  Procurement of Materials  Logistics  Warehousing & Inventory Management  YOU CANNOT PRODUCE IF ALL THE MATERIALS ARE NOT AVAILABLE
5. ROUTING 1. Laser or Plasma Cutting, 2. CNC Turret Punching 3. Bending (with Press Brakes) 4. Joining (Welding, Riveting) 5. Powder Coating and Painting 6. Assembly 7. Packing / Packaging DISCRETE MANUFACTURING WORK CENTRES Final destination  In Discrete Manufacturing, the raw materials are processed from one Work Centre to the next
6. Sheet Metal Manufacturing 1. We program a CNC cutting machine that carries out the cutting operation based on design. CUTTING  We cut the different parts that makes up the full assembly 2. We check the cut the parts and move to bending.
7. Sheet Metal Manufacturing 1. We program an NC bending machine that carries out the bending operation based on bending drawings BENDING 2. We insert the parts into the machine and the bend is accomplished
8. Sheet Metal Manufacturing Depending on the kind of joint required and the material being worked on JOINING Join the parts to form sub assemblies Fluxed core Arc welding Gas Metal Arc Welding Gas Tungsten Arc Welding Shielded Metal Arc Welding Stud Welding Resistance (spot) Welding Paramete rs
9. We program the machine to perform spray operations based on the parts in the booth POWDER COATING Powder coat the parts • Pretreatment • Spray coating • Curing/ Baking Sheet Metal Manufacturing
10. Assemblies of the parts to form the individual parts are done using an exploded assy drawing ASSEMBLY Assemble the coated parts to the full assembly Sheet Metal Manufacturing
11. 1. We program a CNC cutting machine that carries out the cutting operation based on designs DELIVERY Deliver a quality product to the client Sheet Metal Manufacturing
