Getting started with Business Metrics in PHP applications

Getting started with Business Metrics in PHP applications

Measuring & gathering infrastructure metrics is easy nowadays thanks to free tools like prometheus, grafana and a whole lot of exporters for servers, databases, redis, docker and so on. For sure those metrics are important for the reliable operation of your systems, but do they tell you, if your business is successful?
With a few examples I want to show you how to measure & monitor business relevant values from within your application(s) by introducing you to different PHP libraries that help you accomplish transparency of success factors. In the end I will show you how to set up a dashboard and alerts that even your manager(s) like and understand.

Holger Woltersdorf
CIO - Head of FORTUNE SOLUTIONS at Fortuneglobe GmbH. About 12 years of developer and team-lead experience in mobile communication and fashion eCommerce industry. PHP developer for more than 16 years, Co-founder and chairman of the PHP USERGROUP DRESDEN e.V., avid meetup and conference speaker, core-developer of the open-source PHP framework "IceHawk", dedicated to multiple other PHP open-source projects.

- https://twitter.com/hollodotme
- https://github.com/hollodotme
- https://hollo.me

You can find the shown example project on GitHub:
- https://github.com/php-usergroup-dresden/business-metrics-for-starters

Talk was given at PHPUGMRN in Mannheim, Germany.

Holger Woltersdorf

June 27, 2019
Tweet

More Decks by Holger Woltersdorf

Other Decks in Technology

Transcript

  1. GETTING STARTED WITH
    BUSINESS METRICS
    JUNE 27, 2019

    View Slide

  2. HELLO
    MANNHEIM!
    @hollodotme
    HOLGER WOLTERSDORF

    View Slide

  3. GREETINGS
    FROM DRESDEN!
    PHP USERGROUP DRESDEN E.V.
    @phpugdd

    View Slide

  4. CIO AT FORTUNE SOLUTIONS, MEMBER OF THE FORTUNEGLOBE GROUP
    @F9T3ch

    View Slide

  5. METRICS
    WHAT ARE

    View Slide

  6. WHAT ARE METRICS?
    CONTINUOUSLY MEASURED VALUES

    TO REFLECT THE CURRENT STATE OF A SYSTEM
    ▸ UP or DOWN
    ▸ CPU USAGE
    ▸ MEMORY USAGE
    ▸ LOAD
    ▸ QUERIES PER SECOND
    ▸ REQUESTS PER SECOND
    ▸ CACHE HIT RATE
    ▸ FREE DISC SPACE
    ▸ PAGE SPEED

    View Slide

  7. A.K.A
    TELEMETRY

    View Slide

  8. View Slide

  9. ▸ https://prometheus.io
    ▸ https://hub.docker.com/r/prom/prometheus
    prometheus:
    image: prom/prometheus:latest
    restart: 'on-failure'
    volumes:
    - ./prometheus.yml:/etc/prometheus/prometheus.yml
    - ./data:/prometheus
    command:
    - '"--config.file=/etc/prometheus/prometheus.yml'
    - '"--storage.tsdb.path=/prometheus'
    - '"--storage.tsdb.retention=32d'
    - '"--web.enable-lifecycle'
    global:
    scrape_interval: 15s
    scrape_timeout: 10s
    evaluation_interval: 15s
    scrape_configs:
    # Prometheus self-monitoring
    - job_name: prometheus
    metrics_path: /metrics
    scheme: http
    static_configs:
    - targets:
    - localhost:9090

    View Slide

  10. Databases
    Aerospike exporter
    ClickHouse exporter
    Consul exporter (official)
    Couchbase exporter
    CouchDB exporter
    ElasticSearch exporter
    EventStore exporter
    Memcached exporter (official)
    MongoDB exporter
    MSSQL server exporter
    MySQL server exporter (official)
    OpenTSDB Exporter
    Oracle DB Exporter
    PgBouncer exporter
    PostgreSQL exporter
    Presto exporter
    ProxySQL exporter
    RavenDB exporter
    Redis exporter
    RethinkDB exporter
    SQL exporter
    Tarantool metric library
    Twemproxy
    Hardware related
    apcupsd exporter
    BIG-IP exporter
    Collins exporter
    IBM Z HMC exporter
    IoT Edison exporter
    IPMI exporter
    knxd exporter
    Netgear Cable Modem Exporter
    Netgear Router exporter
    Node/system metrics exporter (official)
    NVIDIA GPU exporter
    ProSAFE exporter
    Ubiquiti UniFi exporter
    Issue trackers and continuous integration
    Bamboo exporter
    Bitbucket exporter
    Confluence exporter
    Jenkins exporter
    JIRA exporter
    Messaging systems
    Beanstalkd exporter
    EMQ exporter
    Gearman exporter
    IBM MQ exporter
    Kafka exporter
    NATS exporter
    NSQ exporter
    Mirth Connect exporter
    MQTT blackbox exporter
    RabbitMQ exporter
    RabbitMQ Management
    Plugin exporter
    Storage
    Ceph exporter
    Ceph RADOSGW exporter
    Gluster exporter
    Hadoop HDFS FSImage exporter
    Lustre exporter
    ScaleIO exporter
    HTTP
    Apache exporter
    HAProxy exporter (official)
    Nginx metric library
    Nginx VTS exporter
    Passenger exporter
    Squid exporter
    Tinyproxy exporter
    Varnish exporter
    WebDriver exporter
    APIs
    AWS ECS exporter
    AWS Health exporter
    AWS SQS exporter
    Cloudflare exporter
    DigitalOcean exporter
    Docker Cloud exporter
    Docker Hub exporter
    GitHub exporter
    InstaClustr exporter
    Mozilla Observatory exporter
    OpenWeatherMap exporter
    Pagespeed exporter
    Rancher exporter
    Speedtest exporter
    Logging
    Fluentd exporter
    Google's mtail log data extractor
    Grok exporter
    Other monitoring systems
    Akamai Cloudmonitor exporter
    Alibaba Cloudmonitor exporter
    AWS CloudWatch exporter (official)
    Azure Monitor exporter
    Cloud Foundry Firehose exporter
    Collectd exporter (official)
    Google Stackdriver exporter
    Graphite exporter (official)
    Heka dashboard exporter
    Heka exporter
    InfluxDB exporter (official)
    JavaMelody exporter
    JMX exporter (official)
    Munin exporter
    Nagios / Naemon exporter
    New Relic exporter
    NRPE exporter
    Osquery exporter
    OTC CloudEye exporter
    Pingdom exporter
    scollector exporter
    Sensu exporter
    SNMP exporter (official)
    StatsD exporter (official)
    Miscellaneous
    ACT Fibernet Exporter
    BIND exporter
    Blackbox exporter (official)
    BOSH exporter
    cAdvisor
    Cachet exporter
    ccache exporter
    Dovecot exporter
    Dnsmasq exporter
    eBPF exporter
    Ethereum Client exporter
    Hostapd Exporter
    JMeter plugin
    Kannel exporter
    Kemp LoadBalancer exporter
    Kibana Exporter
    kube-state-metrics
    Meteor JS web framework exporter
    Minecraft exporter module
    OpenStack exporter
    PHP-FPM exporter
    PowerDNS exporter
    Process exporter
    rTorrent exporter
    SABnzbd exporter
    Script exporter
    Shield exporter
    Smokeping prober
    SMTP/Maildir MDA blackbox prober
    SoftEther exporter
    Transmission exporter
    Unbound exporter
    Xen exporter
    https://prometheus.io/docs/instrumenting/exporters/

    View Slide

  11. Software exposing Prometheus metrics
    Some third-party software exposes metrics in the Prometheus format, so no separate exporters are needed:
    App Connect Enterprise
    Ballerina
    Ceph
    Collectd
    Concourse
    CRG Roller Derby Scoreboard (direct)
    Docker Daemon
    Doorman (direct)
    Envoy
    Etcd (direct)
    Flink
    FreeBSD Kernel
    Grafana
    JavaMelody
    Kong
    Kubernetes (direct)
    Linkerd
    mgmt
    MidoNet
    midonet-kubernetes (direct)
    Minio
    Netdata
    Pretix
    Quobyte (direct)
    RobustIRC
    ScyllaDB
    Skipper
    SkyDNS (direct)
    Telegraf
    Traefik
    VerneMQ
    Weave Flux
    https://prometheus.io/docs/instrumenting/exporters/

    View Slide

  12. DEMO

    View Slide

  13. BUSINESS METRICS
    WHAT ARE

    View Slide

  14. View Slide

  15. WHAT ARE BUSINESS METRICS?
    CONTINUOUSLY MEASURED VALUES

    TO REFLECT THE CURRENT

    SUCCESS OF YOUR BUSINESS
    ▸ ARTICLES ONLINE
    ▸ ORDERS PER HOUR
    ▸ SALES VOLUME
    ▸ ITEMS SHIPPED IN SLA
    ▸ CONVERSION RATE
    ▸ STOCK TURN DEVELOPMENT
    ▸ CUSTOMER SATISFACTION
    ▸ COST PER OPERATION (CPO)

    View Slide

  16. ▸ COUNTERS (can only go up)
    orders_total 1234.000000
    orders_total 1235.000000 1559024925
    orders_total{shop="My-Shop"} 999.000000
    orders_total{shop="Your-Shop"} 235.000000
    orders_total{shop="My-Shop"} 999.000000 1559024925
    orders_total{shop="Your-Shop"} 236.000000 1559024925
    average_order_value 140.250000
    average_order_value 141.500000 1559024925
    average_order_value{shop="My-Shop"} 123.450000
    average_order_value{shop="Your-Shop"} 156.780000
    average_order_value{shop="My-Shop"} 101.020000 1559024925
    average_order_value{shop="Your-Shop"} 199.890000 1559024925
    ▸ GAUGES (can go up and down)

    View Slide

  17. ▸ Type-hinting and description
    # TYPE orders_total counter
    # HELP orders_total Total number of placed orders
    orders_total 1234.000000
    orders_total 1235.000000 1559024925
    orders_total{shop="My-Shop"} 999.000000
    orders_total{shop="Your-Shop"} 235.000000
    orders_total{shop="My-Shop"} 999.000000 1559024925
    orders_total{shop="Your-Shop"} 236.000000 1559024925

    View Slide

  18. openmetrics-php/exposition-text

    View Slide

  19. openmetrics-php/exposition-text
    (openmetrics-php/???)

    View Slide

  20. YOUR APP
    COLLECT METRICS IN REDIS
    WHENEVER SOMETHING
    HAPPENS IN YOUR APP
    & FLUSH THEM AS SOON AS
    PROMETHEUS CALLED THE ENDPOINT
    METRICS
    ENDPOINT

    View Slide

  21. jimdo/prometheus_client_php

    View Slide

  22. View Slide

  23. ▸ https://grafana.com
    ▸ https://hub.docker.com/r/grafana/grafana
    grafana:
    image: grafana/grafana:latest
    restart: 'on-failure'
    volumes:
    - ./data/grafana:/var/lib/grafana
    depends_on:
    - prometheus

    View Slide

  24. View Slide

  25. DEMO

    View Slide

  26. php-usergroup-dresden/business-metrics-for-starters

    View Slide

  27. QUESTIONS?

    View Slide

  28. THANK
    YOU!
    @hollodotme
    HOLGER WOLTERSDORF

    View Slide
