IceHawk - A PHP 7 micro framework respecting CQRS

NOVEMBER 21st 2017 • PHP USERGROUP MÜNSTER HOLGER WOLTERSDORF

View Slide

HOLGER WOLTERSDORF
CIO • FATHER • HUSBAND • PHP DEV WITH ♥
github.com/hollodotme
github.com/icehawk
@hollodotme
@F9T3ch

View Slide

View Slide

ICEHAWK FRAMEWORK • NOVEMBER 21st 2017 • PHP USERGROUP MÜNSTER HOLGER WOLTERSDORF
CONTENTS
4
HISTORY
FACTS
FEATURES
&
CODE
COMPONENTS
DISCUSSION

View Slide

HISTORY

View Slide

HISTORY
6
๏ THE MVC PATTERN
VIEW 1 VIEW 2
CONTROLLER MODEL
USER INPUT
MODIFIES
UPDATES

View Slide

HISTORY
7
๏ THE MVC PATTERN …THE PROBLEM!
VIEW 1 VIEW 2
CONTROLLER MODEL
USER INPUT
MODIFIES
UPDATES
!

View Slide

HISTORY
8
๏ THE MVC PATTERN …THE PROBLEM!
VIEW 1 VIEW 2
CONTROLLER MODEL
USER INPUT
MODIFIES
HTTP

View Slide

HISTORY
9
๏ THE MVC PATTERN …THE SOLUTION?
VIEW 1 VIEW 2
CONTROLLER MODEL
USER INPUT
MODIFIES
HTTP
RESPONDS

View Slide

HISTORY
10
"THE MVC PATTERN
SOLVES A PROBLEM
THAT DOESN’T EXIST
IN THE WEB."

View Slide

HISTORY
11
"THE MVC PATTERN
SOLVES A PROBLEM
THAT DOESN’T EXIST
IN THE WEB."

View Slide

HISTORY
12
CONTROLLER
๏ THE MVC PATTERN …CONTROLLER RESPONSIBILITIES
๏ VALIDATE USER INPUT
๏ FIND MODEL(S), REPO(S)  
HELPER(S) OR SERVICE(S)
๏ ISSUE CHANGES
๏ EVALUATE CHANGE RESULT
๏ FIND MODEL(S), REPO(S) 
๏ QUERY AND FETCH DATA
๏ RENDER VIEW (2)
๏ RESPOND TO CLIENT

View Slide

HISTORY
13
CONTROLLER
๏ THE MVC PATTERN …CONTROLLER RESPONSIBILITIES
๏ ISSUE CHANGES
๏ RENDER VIEW (2)
WRITE READ

View Slide

HISTORY
14
WRITE
CONTROLLER
๏ SEGREGATED RESPONSIBILITIES
๏ ISSUE CHANGES
๏ RENDER VIEW (2)
WRITE READ
READ
CONTROLLER

View Slide

HISTORY
15
WRITE
CONTROLLER
๏ RESPONSIBILITY SEGREGATION
๏ ISSUE CHANGES
๏ RENDER VIEW (2)
COMMAND QUERY
READ
CONTROLLER

View Slide

HISTORY
16
WRITE
CONTROLLER
๏ RESPONSIBILITY SEGREGATION
๏ ISSUE CHANGES
๏ RENDER VIEW (2)
COMMAND QUERY
READ
CONTROLLER
RESPONSIBILITY SEGREGATION
(CQRS)
TA-DA!

View Slide

HISTORY
17
๏ THE CQRS PATTERN (respecting HTTP)
WRITE
REQUESTHANDLER
APP
STATE
USER INPUT
MODIFIES QUERIES
POST
CLIENT / BROWSER
REDIRECT
TO PAGE 2
GET
READ
REQUESTHANDLER
PAGE 1 PAGE 2
RESPONDS

View Slide

PROJECTOR
CHANGE
PAGE 2
HISTORY
18
๏ OPTIMISATION FOR READ INTENSIVE APPLICATIONS
WRITE
REQUESTHANDLER
APP
STATE
USER INPUT
MODIFIES
POST
CLIENT / BROWSER
REDIRECT
TO PAGE 2
GET
PAGE 1
PAGE 2
CHANGE
MESSAGE
(ASYNC)
PROJECTOR
PREPARES
PUB SUB
QUERIES

View Slide

HISTORY
19
[…] the convention has been established
that the GET and HEAD methods
SHOULD NOT have the significance
of taking an action other than retrieval.
These methods ought
to be considered "safe".
https://www.w3.org/Protocols/rfc2616/rfc2616-sec9.html

View Slide

HISTORY
20
๏ RULES SUMMARISED (FOR WEBSITES)
๏ A POST request MUST NOT not respond with UI content
๏ A POST request SHOULD change the application state
๏ A POST request SHOULD respond with a redirect
๏ A GET request SHOULD respond with UI content  
representing the current application state
๏ A GET request MUST NOT change the application state (read-only)

View Slide

21
«We need a name!»
«Yeah, something cool and fast!»
HISTORY

View Slide

ICEHAWK

View Slide

FACTS

View Slide

FACTS
24
๏ COMPONENTS
STABLE v2.2.0 STABLE v1.1.1 STABLE v1.0.0 STABLE v1.0.1
ICEHAWK SESSION FORMS PUBSUB
COVERAGE 100% COVERAGE 100% COVERAGE 100% COVERAGE 100%

View Slide

FACTS
25
๏ MAIN COMPONENT: icehawk/icehawk
1.533 Logical lines of code (LLOC)
0 composer dependencies
0 third-party php extension dependencies
v2.2.0 current stable
v7.x.x php compatibility (only)
STRICT typed
MIT license
FULLY documented at icehawk.github.io
LOC
Lines of code 1965
Logical lines of code 1533
Comment lines of code 433
Average volume 71.86
Average comment weight 21.28
Average intelligent content 21.28
Logical lines of code by class 29
Logical lines of code by method 5
Object oriented programming
Classes 52
Interface 33
Methods 279
Methods by class 5.37
Lack of cohesion of methods 0.62
Average afferent coupling 0.66
Average efferent coupling 1.15
Average instability 0.61
Complexity
Average Cyclomatic complexity by class 1.65
Average Relative system complexity 17.92
Average Difficulty 2.6

View Slide

FACTS
26
๏ OBJECTIVES
๏ Producing comprehensible and readable code
๏ Avoiding inline comments where possible
(includes PHPDoc)
๏ Applying the SOLID and CLEAN CODE principles
๏ Covering all code with tests
๏ Refactoring continuously
๏ Targeting the latest PHP version
๏ Doing open source
๏ APPLICABLE FOR
๏ WEBSITES
๏ (RESTful) APIs
๏ MICRO SERVICES
๏ EVENT SOURCING

View Slide

FACTS
27
NAMING CONVENTION
interface BypassesRequest {}
class RequestBypass {}
trait DefaultRequestBypassing {}

View Slide

FACTS
28
POST
PUT
PATCH
DELETE
GET
HEAD
OPTIONS
WRITE
REQUEST
HANDLER
READ
REQUEST
HANDLER
AUTO-RESPONSE
BASIC ROUTING BEHAVIOUR

View Slide

FEATURES & CODE
(SELECTION)

View Slide

FEATURES & CODE
30
INSTALLATION

View Slide

FEATURES & CODE
31

View Slide

FEATURES & CODE
32
class IceHawk
{
public function __construct( $config, $delegate )
public function init() {}
public function handleRequest() {}
}

View Slide

FEATURES & CODE
33
namespace MyVendor\MyProject;
use IceHawk\IceHawk\IceHawk;
require(__DIR__ . '/../vendor/autoload.php');
$config = new IceHawkConfig();
$delegate = new IceHawkDelegate();
$application = new IceHawk( $config, $delegate );
$application->init();
$application->handleRequest();

View Slide

FEATURES & CODE
34
DELEGATION

View Slide

FEATURES & CODE - DELEGATION
35
final class IceHawkDelegate implements SetsUpEnvironment
{
public function setUpGlobalVars()
{
# Change your global vars $_SERVER, $_GET, $_POST, etc.
# here, before IceHawk will use them.
}
public function setUpErrorHandling( ProvidesRequestInfo $requestInfo )
{
# PHP's default error handling is used unless you set up
# something else here.
}
public function setUpSessionHandling( ProvidesRequestInfo $requestInfo )
{
# PHP's default session handling is used unless you set up
}
}

View Slide

36
{
{
}
{
}
{
}
}

View Slide

37
{
{
}
{
}
{
}
}

View Slide

FEATURES & CODE
38
CONFIGURATION

View Slide

FEATURES & CODE - CONFIGURATION
39
final class IceHawkConfig implements ConfiguresIceHawk
{
use Defaults\Traits\DefaultRequestInfoProviding;
use Defaults\Traits\DefaultReadRouting;
use Defaults\Traits\DefaultWriteRouting;
use Defaults\Traits\DefaultRequestBypassing;
use Defaults\Traits\DefaultEventSubscribing;
use Defaults\Traits\DefaultCookieProviding;
use Defaults\Traits\DefaultFinalReadResponding;
use Defaults\Traits\DefaultFinalWriteResponding;
}

View Slide

40
{
}

View Slide

41
final class MyHawkConfig extends IceHawkConfig
{
public function getReadRoutes()
{
return [
new ReadRoute(
new Literal( '/' ),
new SayHelloRequestHandler()
),
];
}
public function getWriteRoutes()
{
return [
new WriteRoute(
new Literal( '/do-something' ),
new DoSomethingRequestHandler()
),
];
}
}

View Slide

42
# Literal route
new ReadRoute(
new Literal( '/' ),
);
# RegExp route with parameters from matches
new ReadRoute(
new RegExp("#^/post/([0-9]+)/?$#i", ['postId'] ),
new ShowBlogPostRequestHandler()
);
# NamedRegExp route with named matches
new ReadRoute(
new NamedRegExp("^/post/(?[0-9]+)/?$", 'i'),
);

View Slide

43
# Literal route
new ReadRoute(
new Literal( '/' ),
);
new ReadRoute(
);
new ReadRoute(
);

View Slide

44
# Literal route
new ReadRoute(
new Literal( '/' ),
);
new ReadRoute(
);
new ReadRoute(
);

View Slide

45
{
public function getReadRoutes()
{
$routes = require(__DIR__ . '../config/ReadRoutes.php');
# $routes = [
# "^/post/(?[0-9]+)/?"
# => MyVendor\...\ShowPostRequestHandler::class,
# ];
foreach ($routes as $pattern => $handlerClass)
{
yield new ReadRoute(
new NamedRegExp($pattern),
new $handlerClass()
),
}
}
}

View Slide

FEATURES & CODE
46
REQUEST BYPASSING

View Slide

FEATURES & CODE - REQUEST BYPASSING
47
{
}

View Slide

48
{
public function getRequestBypasses()
{
return [
new RequestBypass(
new Literal('/came/via/get'),
'/do/some/write/action',
HttpMethod::POST
),
];
}
{
return [
new WriteRoute(
new Literal( '/do/some/write/action' ),
),
];
}
}

View Slide

49
{
public function getRequestBypasses()
{
return [
new RequestBypass(
new Literal('/came/via/get'),
'/do/some/write/action',
HttpMethod::POST
),
];
}
{
return [
new WriteRoute(
new Literal( '/do/some/write/action' ),
),
];
}
}

View Slide

FEATURES & CODE
50
REQUEST HANDLERS

View Slide

FEATURES & CODE - REQUEST HANDLERS
51
final class SayHelloRequestHandler
implements HandlesGetRequest
{
public function handle(ProvidesReadRequestData $request)
{
$info = $request->getInfo();
$input = $request->getInput();
$cookies = $request->getCookies();
(new Page())->respond('Hello!', HttpCode::OK);
}
}

View Slide

FEATURES & CODE - REQUEST HANDLERS
52
final class DoSomethingRequestHandler
implements HandlesPostRequest
{
public function handle(ProvidesWriteRequestData $request)
{
$info = $request->getInfo();
$input = $request->getInput();
$cookies = $request->getCookies();
$files = $input->getAllUploadedFiles();
(new Redirect())->respond('/done');
}
}

View Slide

FEATURES & CODE
53
EVENTS & SUBSCRIBERS

View Slide

FEATURES & CODE - EVENTS & SUBSCRIBERS
54
{
}

View Slide

55
{
public function getEventSubscribers() : array
{
return [
new LogSubscriber(),
];
}
}

View Slide

56
final class LogSubscriber extends AbstractEventSubscriber
{
private $startTime;
public function getAcceptedEvents() : array
{
return [
IceHawk\IceHawk\Events\HandlingReadRequestEvent::class,
IceHawk\IceHawk\Events\ReadRequestWasHandledEvent::class,
];
}
public function whenHandlingReadRequest(HandlingReadRequestEvent $event)
{
$this->startTime = microtime(true);
}
public function whenReadRequestWasHandled(ReadReqeustWasHandledEvent $event)
{
error_log( sprintf(
"Your app took %f seconds to handle the request on URI: %s",
(microtime(true) - $this->startTime),
$event->getRequestInfo()->getUri()
), 3, 'file.log' );
}
}

View Slide

FEATURES & CODE
57
FINAL RESPONDING

View Slide

FEATURES & CODE - FINAL RESPONDING
58
{
}

View Slide

59
{
public function getFinalReadResponder()
: RespondsFinallyToReadRequest
{
return MyFinalReadResponder();
}
}

View Slide

60
final class MyFinalReadResponder
implements RespondsFinallyToReadRequest
{
public function handleUncaughtException(
\Throwable $throwable,
ProvidesReadReqeustData $request
)
{
try
{
throw $throwable;
}
catch (UnresolvedRequest $e)
{
(new NotFound())->respond();
}
catch (\Throwable $e)
{
(new InternalServerError())->respond();
}
}
}

View Slide

COMPONENTS

View Slide

SESSION

View Slide

SESSION
63
๏ ABSTRACT REGISTRY
๏ Needs inheritance
๏ Implement typed getters, setters, issets and unsets
๏ Allows registration of data mappers

View Slide

SESSION - EXAMPLE IMPLEMENTATON
64
final class Session extends AbstractSession
{
const KEY_SOME_STRING_VALUE = 'someStringValue';
public function getSomeStringValue() : string
{
return $this->get( self::KEY_SOME_STRING_VALUE );
}
public function setSomeStringValue( string $value )
{
$this->set( self::KEY_SOME_STRING_VALUE, $value );
}
public function isSomeStringValueSet() : bool
{
return $this->isset( self::KEY_SOME_STRING_VALUE );
}
public function unsetSomeStringValue()
{
$this->unset( self::KEY_SOME_STRING_VALUE );
}
}

View Slide

SESSION - DATA MAPPER
65
final class MyDataMapper implements MapsSessionData
{
public function toSessionData( $value )
{
return base64_encode( $value );
}
public function fromSessionData( $sessionData )
{
return base64_decode( $sessionData );
}
}

View Slide

SESSION - REGISTER DATA MAPPERS
66
# Add the data mapper for all keys in the registry
$session->addDataMapper( new MyDataMapper() );
# Add the data mapper for one specific key in the registry
$session->addDataMapper(
new MyDataMapper(),
[Session::KEY_SOME_STRING_VALUE]
);
# Add the data mapper for multiple keys in the registry
$session->addDataMapper(
new MyDataMapper(),
[
Session::KEY_SOME_STRING_VALUE,
Session::KEY_SOME_OTHER_VALUE
]
);

View Slide

FORMS

View Slide

FORMS
68
๏ DTO TO BE STORED IN SESSION
๏ CSRF protection using tokens (with expiration)
๏ Data pre-setting
๏ Gets input validation feedback (with severity) on write side
๏ Provides input validation feedback on read side

View Slide

FORMS - READ SIDE INITIALISATION
69
$form = new Form( new FormId('profile') );
$form->renewToken();
if ( !$form->wasDataSet() )
{
# Set up some default data (single)
$form->set( 'username', 'johndoe' );
}

View Slide

FORMS - WRITE SIDE
70
$form = $session->getForm( new FormId('profile') );
$token = Token::fromString($input->get('token'));
$form->guardTokenIsValid($token);
$form->addFeedback(
'user',
new Feedback(
'Invalid username',
Feedback::ERROR
)
);

View Slide

PUBSUB

View Slide

PUBSUB
72
๏ BASIC PUBLISH SUBSCRIBE SYSTEM TO DECOUPLE BUSINESS LOGIC
๏ Defines interfaces for messages, channels and subscribers
๏ Provides a message bus for publishing and subscribing
๏ Provides abstract message subscriber with auto-method resolving

View Slide

PUBSUB - A MESSAGE
73
final class YourMessage implements CarriesInformation
{
public function getMessageId() : IdentifiesMessage
{
return new MessageId('message-xyz');
}
public function getMessageName() : NamesMessage
{
return new MessageName('User email address changed');
}
public function getContent() : string
{
return '[email protected]';
}
}

View Slide

PUBSUB - A SUBSCRIBER
74
final class YourSubscriber extends AbstractMessageSubscriber
{
protected function whenSomethingHadHappened(
YourMessage $yourMessage,
Channel $channel
)
{
printf(
'Message named "%s" with ID "%s" '
. 'was published on channel "%" with content: "%s"',
$yourMessage->getMessageName(),
$yourMessage->getMessageId(),
$channel,
$yourMessage->getContent()
);
}
}

View Slide

PUBSUB - THE SUBSCRIPTION
75
$messageBus = new MessageBus();
$messageBus->subscribe(
new Channel('ListenToMe'),
new YourSubscriber()
);

View Slide

PUBSUB - PUBLISH
76
$messageBus->publish(
new Channel('ListenToMe'),
new YourMessage()
);

View Slide

FULL DOCUMENTATION AT
icehawk.github.io

View Slide

QUESTIONS?

View Slide

THANK YOU!
github.com/hollodotme
@hollodotme / @F9T3ch
fortuneglobe.com
phpug-dresden.org
@phpugdd
HOLGER WOLTERSDORF
https://hollo.me
icehawk.github.io
speakerdeck.com/hollodotme
Slides available at:

View Slide

LINKS / REFERENCES
80
๏ MVC-Pattern: http://martinfowler.com/eaaDev/uiArchs.html
๏ CQRS-Pattern: http://martinfowler.com/bliki/CQRS.html
๏ GET/HEAD methods: https://www.w3.org/Protocols/rfc2616/rfc2616-sec9.html
๏ SOLID principles https://en.wikipedia.org/wiki/SOLID_(object-oriented_design)
๏ "Clean Code" by Robert C. Martin: http://amzn.to/2dthxQn
๏ "Traitful" Configs: https://hollo.me/php/traitful-configs.html
๏ IceHawk Gitter chat: https://gitter.im/icehawk/Lobby

View Slide

IceHawk - A PHP 7 micro framework respecting CQRS

IceHawk - A PHP 7 micro framework respecting CQRS

Holger Woltersdorf

More Decks by Holger Woltersdorf

Other Decks in Programming

Featured

Transcript
