Intro to Oracle Cloud

A less formal (and high-level) presentation that was used to introduce the audience to Oracle Cloud and cloud concepts in general (IaC).

There was a lot of live demo involved (in the OCI console) and not everything in the live demo is captured in the slides but the content of the slides should still be relevant and include links to many resources throughout for more information on various topics.

Transcript

1. Intro to Oracle Cloud Justin Biard Principal Member of Technical Staff, Oracle July 14, 2025 (opinions presented are my own)
2. Building in the cloud As of Mid-2025: SaaS: Software as a Service PaaS: Platform as a Service IaaS: Infrastructure as a Service 2
3. 3 Overview of a Cloud Use Case Customers 10.0.1.0/24 IAM Policies Example OCI Service public ip private ip 129.1.2.3 Oracle Cloud Tenancy COMPARTMENT / REGION+
4. 4 Two primary resource types for Database Tools: • Connections • Use private endpoints (optional) • Store database connection details • Use secrets from Secrets in Vault • Private Endpoints • Access databases in private subnets • Access databases with a network access control list (ACL) Example OCI Service: Database Tools
5. 5 OCI Console Demo
6. Theory: What is Infrastructure as Code? Configuration of cloud infrastructure resources documented as code (a configuration language) terraform { ... } Network Load Balancer Database Fryer Compartment Policy Drying Rack Virtual Machine ./my-project/main.tf 6
7. Why use Tools like Terraform / OpenTofu? Abstraction: Abstract the logic of each cloud API to a Terraform provider Reconciliation: Reconcile changes to resources against a known good config Automation: Automate tedious or manual infrastructure tasks (vs. console clicks) Comprehension: Comprehend of the scope and scale of deployed infrastructure 7
8. Theory: Resource state reconciliation Terraform state is reconciled and updated based on changes to the actual cloud resources terraform { ... } Cloud Service Version Control {tfstate} 8
9. Enough theory! How do we code it? • Configure a remote backend or use local (default) • Declare and configure providers • Declare resources (defined as code) • Add variables and modules as needed (refactor?) • Add outputs as needed • Terraform apply -> Donuts as a Service! $ terraform apply 9
10. Automation: OCI Terraform Provider 10 • OCI Services are supported by the OCI Terraform provider: resource "oci_database_tools_database_tools_connection" "…" { user_name = "ADMIN" connection_string = each.value ... } docs.oracle.com/en-us/iaas/tools/terraform-provider-oci/latest/index.html
11. 11 Terraform Demo
12. Example use case: ADB w/ private endpoint 12 Resources: • VCN + Private Subnet • ADB • Vault • Private endpoint • Connection Vault will contain: • Password secret • Optionally: auto-login wallet secrets [endpoint] .adb.[region] .oraclecloud.com
13. Managing resources: Prerequisites 13 • Non-tenancy administrators will need IAM policies • Define a logical role (group) for "resource managers" • Create policies to manage resources in a compartment (or tenancy) References: • https://docs.oracle.com/en-us/iaas/Content/Identity/Concepts/policies.htm allow group <group_name> to manage … in compartment <compartment_name>
14. Using resources, example: use connections 14 • Non-tenancy administrators will need IAM policies • Define a logical role (group) for "connection users" • Create policies to read secrets in the vault • Create policies to use Database Tools connections References: • https://docs.oracle.com/en-us/iaas/Content/Identity/Concepts/policies.htm • https://docs.oracle.com/en-us/iaas/database-tools/doc/policies.html allow group <group_name> to read secret-family in compartment <compartment_name> allow group <group_name> to use database-tools-connections in compartment <compartment_name>
15. Automation: OCI CLI 15 • OCI services are supported by the OCI CLI, for example: • CRUD and list operations are supported • Validation operations are supported for Connection resources $ oci dbtools connection get --connection-id ocid1...<your-connection-ocid-here> # see the help for more information about options $ oci dbtools --help docs.oracle.com/en-us/iaas/tools/oci-cli/latest/oci_cli_docs/cmdref/dbtools.html
16. Automation: OCI Language SDKs 16 docs.oracle.com/en-us/iaas/database-tools/doc/sdk-examples.html • Database Tools is supported by the OCI SDKs: (Java, Go, Python, etc.) response, err := client.CreateDatabaseToolsConnection(cfg.Ctx, databasetools.CreateDatabaseToolsConnectionRequest{ CreateDatabaseToolsConnectionDetails: details, }) if err != nil { return nil, err }
17. Thank you! Find me at: • icodealot.com • @icodealot - x.com, bsky.app 17
