Designing Modern Service Architectures

Designing Modern Service Architectures

Cloud computing is becoming the primary way large web applications are deployed. The flexibility of these platforms gives us the opportunity to break out of the usual scaling patterns and deliver power precisely where and when we need it. Through practical examples, we'll explore a modern service-oriented application and discover strategies and tools that will help you make the most of the cloud.

Samantha Quiñones

August 07, 2014
Tweet

More Decks by Samantha Quiñones

Other Decks in Programming

Transcript

  1. Understanding the Problem An application is scalable when response time

    remains constant when traffic increases or decreases
  2. Scalable != Performant Scalability is not the same as highly

    performing An app that performs equally poorly at any load might technically fit the definition
  3. Scaling Can Be Hard Scaling is a very tricky problem

    Predicting traffic is nearly impossible Scalability must balance responsiveness and cost
  4. Uncontrolled Variables S at S un Mon Tue Wed Thu

    Fri 0 10000 20000 30000 40000 50000 60000
  5. Uncontrolled Variables S at S un Mon Tue Wed Thu

    Fri 0 100000 200000 300000 400000 500000 600000 700000 800000
  6. Getting Meta This experience is an interesting example of how

    the systems we design reflect more “organic” ones The news media, in a sense, is one large system Healthy parts of a system compensate for injured parts
  7. Elections Are Hard Election results are constantly updated The results

    need to be parsed and made available with minimal delay When users perceive your results as “behind,” you lose them
  8. The Problem with Election Data 3,000 sets of rules (just

    for Federal Elections) Rules change constantly Primaries are insane. Special Elections are worse. Results have to be ingested, parsed, analyzed, and published in real time
  9. And Then It Got Real 725,000 peak concurrent connections 8,000,000

    page views/hour 54,000,000 page views total
  10. Uncontrolled Variables S at S un Mon Tue Wed Thu

    Fri 0 100000 200000 300000 400000 500000 600000 700000 800000
  11. Get A Little Zen Traffic is something you can't (usually)

    control Traffic can be factored out Rather than fighting traffic, we can accept it And find inner peace
  12. The Usual Approach When traffic is factored out, scaling is

    easier and cheaper As requests increase, response time stays constant
  13. The Usual Approach Hardware-focused N+1 a necessary expense Why IT

    is often not seen as a “profit center”
  14. Scaling Behind Save money at the expense of user experience

    Frustrating for IT staff to manage Diminishes user experience
  15. Clouding the Cloud Cloud in the Cloud… Massively distributed virtualized

    computing is beginning to fill the gaps Just like “real” hardware, costs can get out of control
  16. New Methods Require New Methods Deploying applications meant for server-closet

    infrastructures doesn't make sense in the cloud. We need to build software to make maximum use of the platform it's running on.
  17. Service-Oriented Architecture Evolved in the Enterprise Software world of the

    1980s and 1990s CORBA, JINI, and SOAP are technologies born in the first generation of SOA SOA seeks to reduce the cost of highly-complex, high-volume applications
  18. Judge Not Networks were slow and unreliable Standards were not

    widely adopted Bandwidth was expensive System memory was scarce
  19. Good Ideas Done Poorly SOA is a logical outgrowth of

    Modular computing Introduced ideas like loose-coupling and object- orientation to a monolithic, procedural world
  20. Services are Granular A service is a self-contained application that…

    performs one function, or a small number of closely-related functions
  21. Services are Loosely- Coupled Services are not aware of anything

    outside of themselves Services interact through well-defined interfaces
  22. Services are Abstractions Services abstract a small, coherent set of

    logic or business rules Implementation details are hidden Services within in a single application can be implemented in many different languages and on many different platforms
  23. Services are Discoverable Given the address of a service, a

    consumer should be able to learn how to interact with it WSDLs are giving way to RESTful hypermedia APIs
  24. Services are Stateless Services are concerned with inputs and outputs

    Two identical requests should always result in identical responses
  25. Services are Portable Services do not need to live in

    one “place” in the network Services can move, expand, appear, and disappear Location is irrelevant
  26. The Infrastructure Problem Service architectures require a distributed architecture that

    didn't exist until recently Network speeds need to be sufficient to make protocol overhead less of a concern
  27. Discoverability requires Cooperation CORBA and JINI were good solutions to

    the problem of brokering services. Early methods added more complexity than they relieved Increased developer learning curve slowed adoption.
  28. HTTP & REST meet SOA HTTP - Nine standard methods,

    ~40 standard responses Implementations for nearly all platforms and languages REST - A pattern for building stateless web services
  29. Applications Do A Lot of Nothing Most components of an

    application spend most of their time idle. The majority of code performs computationally inexpensive operations Copying the whole application means duplicating the architecture needed to run everything, all the time, over and over again
  30. Cache Caching is practically a requirement to offset the transactional

    request overhead Since services are inherently cacheable, caching will offer substantial performance gains
  31. Language & Platform Agnosticism Some languages are better suited to

    some tasks than other The implementation of each task must balance development time, performance, and return on investment
  32. Our Little Service, All Grown Up Our mail service is

    an abstraction, a hostname It can be on a shared server, a dedicated server, a cluster of 100 servers The sum total of work is creating a virtual server, deploying the code to it, and changing a DNS entry.
  33. Static Content Under High Load Public Cache Public Cache Public

    Cache Public Cache Public Cache Public Cache App Server App Server Service Network
  34. Dynamic Content Under Heavy Load Public Cache Public Cache Public

    Cache App Server App Server Election Data Service Election Data Service Election Data Service Election Data Service Election Data Service Other Services
  35. Fluid Applications Respond in real-time to changing conditions Minimize MTTR

    due to sudden traffic spikes Minimize cost of adapting to traffic events Services can be turned off as a stop-gap
  36. Precision Creates Economy It's not enough to be a good

    engineer, you have to be cost effective Minimizing infrastructure costs frees up resources for new projects
