Story of a kubectl command

A lot goes on under the hood with every kubectl command that is run against a Kubernetes cluster. In this talk I spoke about the various steps involved.

Transcript

1. Story of a kubectl command DevConf, India 4th August, 2018
2. Hi, I'm Indra Indradhanush Gupta Software Engineer, Kinvolk Github: indradhanush Twitter: indradhanush92 Email: indra@kinvolk.io
3. The Deep-stack Kubernetes Experts Engineering services and products for Kubernetes, containers, process management and Linux user-space + kernel Blog: kinvolk.io/blog Github: kinvolk Twitter: kinvolkio Email: hello@kinvolk.io Kinvolk
4. What we will talk about? 1. What is Kubernetes? 2. What are the different components of Kubernetes? 3. What goes on behind the scenes of a kubectl command?
5. What we will talk about? 1. What is Kubernetes? 2. What are the different components of Kubernetes? 3. What goes on behind the scenes of a kubectl command?
6. What we will talk about? 1. What is Kubernetes? 2. What are the different components of Kubernetes? 3. What goes on behind the scenes of a kubectl command?
7. What we will talk about? 1. What is Kubernetes? 2. What are the different components of Kubernetes? 3. What goes on behind the scenes of a kubectl command?
8. What is Kubernetes?
9. Kubernetes ❏ Cluster manager ❏ Scheduler ❏ Orchestrator
10. Kubernetes ❏ Cluster manager ❏ Scheduler ❏ Orchestrator ...for containerized applications
11. Kubernetes Worker Worker Worker Worker Master Master Master
12. Moving parts!
13. Components in Master ❏ API Server ❏ etcd ❏ Controller Manager ❏ Scheduler
14. Components in Worker ❏ kubelet ❏ kube-proxy ❏ kube-dns
15. kubectl Master Worker Worker kubectl apply -f manifest.yaml
16. $ kubectl run nginx --image=nginx
17. $ kubectl run nginx --image=nginx deployment.apps "nginx" created
18. $ kubectl get pods
19. $ kubectl get pods NAME READY STATUS RESTARTS AGE nginx-65899c769f-58xbc 0/1 ContainerCreating 0 5s
20. $ kubectl get pods NAME READY STATUS RESTARTS AGE nginx-65899c769f-58xbc 1/1 Running 0 16s
21. Nginx Pod
23. API Server kubectl etcd
24. Client side validation ❏ Manifest ❏ Resources ❏ Image name
25. Generators $ kubectl run nginx --image=nginx deployment.apps "nginx" created
26. Generators $ kubectl run nginx --image=nginx deployment.apps "nginx" created $ kubectl run nginx --image=nginx --generator run-pod/v1 pod "nginx" created
27. Kubernetes resources are generated
28. And it’s time to send the request!
29. But where?
30. API discovery ❏ OpenAPI schema exposed ❏ API group and version ❏ Cached at ~/.kube/cache
31. Nginx Pod Group: core Version: v1
32. Let’s take a verbose look at a request
33. $ kubectl get pods -v 6
34. $ kubectl get pods -v 6 I0802 16:04:15.085956 9383 loader.go:357] Config loaded from file /home/dhanush/.kube/config
35. $ kubectl get pods -v 6 I0802 16:04:15.085956 9383 loader.go:357] Config loaded from file /home/dhanush/.kube/config I0802 16:04:15.102658 9383 round_trippers.go:405] GET https://192.168.99.102:8443/api/v1/namespaces/default/pods?limit=50 0 200 OK in 9 milliseconds
36. $ kubectl get pods -v 6 I0802 16:04:15.085956 9383 loader.go:357] Config loaded from file /home/dhanush/.kube/config I0802 16:04:15.102658 9383 round_trippers.go:405] GET https://192.168.99.102:8443/api/v1/namespaces/default/pods?limit=50 0 200 OK in 9 milliseconds I0802 16:04:15.109898 9383 round_trippers.go:405] GET https://192.168.99.102:8443/openapi/v2 200 OK in 6 milliseconds
37. $ kubectl get pods -v 6 I0802 16:04:15.085956 9383 loader.go:357] Config loaded from file /home/dhanush/.kube/config I0802 16:04:15.102658 9383 round_trippers.go:405] GET https://192.168.99.102:8443/api/v1/namespaces/default/pods?limit=50 0 200 OK in 9 milliseconds I0802 16:04:15.109898 9383 round_trippers.go:405] GET https://192.168.99.102:8443/openapi/v2 200 OK in 6 milliseconds NAME READY STATUS RESTARTS AGE nginx-65899c769f-ndt2k 1/1 Running 0 9m
38. kubectl get pods -v 10
40. Client authentication ❏ Credentials from $KUBECONFIG ❏ Client certificates ❏ Bearer Tokens ❏ Username / Password
41. API Server kubectl
42. Server side authentication ❏ Client certificates ❏ Bearer Tokens ❏ Username / Password
43. API Server kubectl
44. Authorization chain ❏ ABAC ❏ RBAC ❏ Node ❏ Webhook
45. Admission controllers ❏ Not a chain ❏ Modify or reject requests ❏ No role in read requests
46. Examples: Admission controllers ❏ AlwaysPullImages ❏ PodSecurityPolicy
47. etcd ❏ Resource saved to data store ❏ <namespace>/<name> API Server kubectl etcd
48. Initializers ❏ Dynamic controller ❏ Intercepts resource before creation ❏ Context specific logic
49. Initializers $ kubectl get pods --include-uninitialized
50. Deployments controller ❏ Detects new Deployment resource Deployment
51. ❏ Creates ReplicaSet resource Deployments controller ReplicaSet Deployment
52. Replicasets controller ❏ Detects new ReplicaSet resource ReplicaSet Deployment
53. Replicasets controller ❏ Creates Pod resource ReplicaSet Deployment Pod
54. Replicasets controller $ kubectl run nginx --image=nginx --replicas=3 ReplicaSet Deployment Pod Pod Pod
55. Pods ❏ State: Pending ❏ NodeName: empty ReplicaSet Deployment Pod
56. Scheduler ❏ Filters pods with empty NodeName ❏ Filter worker nodes based on resources and affinity ❏ Prioritizes filtered worker nodes ❏ Choose node with highest priority ❏ Creates Binding resource
57. Scheduler Binding Node Pod Name & UID Namespace
58. Kubelet ❏ Runs on worker node ❏ Manages Pods (containers, volume mounts etc) kubelet Worker 1 kubelet kubelet Worker 3 Worker 2
59. Kubelet ❏ Queries API server for Bindings with matching NodeName ❏ Creates pods not already created on the node ❏ Launches pause container
60. Pause container (almost there!) $ docker ps CONTAINER ID IMAGE COMMAND … fccc6b7a99a k8s.gcr.io/pause-amd64:3.1 "/pause" …
61. Pause container ❏ Holds namespace for all containers of the pod ❏ All application container share the same namespaces ❏ Simplified intra pod networking ❏ Reap zombies if PID namespace sharing is enabled
62. Containers ❏ Pull the image ❏ Create the container ❏ Update Pod status
63. Summary ❏ Client side ❏ Validation and Authentication ❏ Server side ❏ Authentication ❏ Authorization ❏ Admission controllers ❏ Write to etcd!
64. Summary ❏ Wait for Initializers ❏ Deployments controller ❏ Create ReplicaSet ❏ ReplicaSets controller ❏ Create Pod
65. Summary ❏ Scheduler assigns a Node ❏ Kubelet ❏ Pause container ❏ Application container
66. Indradhanush Gupta Github: indradhanush Twitter: indradhanush92 Email: indra@kinvolk.io Kinvolk Blog: kinvolk.io/blog Github: kinvolk Twitter: kinvolkio Email: hello@kinvolk.io Thank you!
67. Questions?
