Under the Hood: Device Enrollment

Presentation from JNUC 2018, the world's largest rally of Apple IT administrators.

Session:
Under the Hood: Device Enrollment

Presented by:
Marcus Ransom, CompNow

View all session slides, recordings and more at https://www.jamf.com/events/jamf-nation-user-conference/2018/.

Transcript

2. © JAMF Software, LLC Marcus Ransom Senior Apple Systems Engineer CompNow - Melbourne, Australia >_ Melbourne Apple Admins
3. © JAMF Software, LLC 67 JAMF Related Events 35 Certified Engineers 95% Retention Rate Working Together Since 2011 849 Customers 259K Seats &
4. © JAMF Software, LLC The Artist formerly known as DEP?
5. © JAMF Software, LLC
6. © JAMF Software, LLC Device Enrollment: under the hood Presentation agenda: • What is Device Enrollment? • What’s going on? • Testing and troubleshooting
7. © JAMF Software, LLC What is Device Enrollment? “Device Enrollment lets you automate Mobile Device Management (MDM) enrollment and simplify initial device setup. You can supervise devices during activation without touching them, and lock MDM enrollment for ongoing management.”
8. © JAMF Software, LLC Device Enrollment over the years • Launched as Device Enrollment Program (DEP) • Devices purchased from Apple • deploy.apple.com • USA only February 2014
9. © JAMF Software, LLC Device Enrollment over the years • Approved resellers • 26 countries November 2014 January 2016 • Apple School Manager
10. © JAMF Software, LLC Device Enrollment over the years 2017 • iOS 11 provisional enrollment 2018 • Apple Business Manager • Now 62 Countries
11. © JAMF Software, LLC Device Enrollment over the years • Organisation registered with Apple • From an approved vendor* • iOS7 or Mac OS X 10.9 • tvOS 10.2 (4th gen Apple TV only) • Purchased after March 2011* Requirements
12. © JAMF Software, LLC Device Enrollment documentation $ man deviceEnrollment No manual entry for deviceEnrollment
13. © JAMF Software, LLC Apple Deployment Programs
 Device Enrollment Program Guide Overview The Device Enrollment Program (DEP) helps businesses easily deploy and configure Apple devices. DEP provides a fast, streamlined way to deploy organization-owned iPad and iPhone devices, Mac computers, and Apple TV purchased directly from Apple or participating Apple Authorized Resellers or carriers. This guide will give you an overview of program features, explain how to enroll, and help you get started. Program Features DEP simplifies initial setup by automating mobile device management (MDM) enrollment and supervision of devices during setup, which enables you to configure your organization’s devices without touching them. To further simplify the process, you can skip certain Setup Assistant screens so users can start using their devices right out of the box. Mandatory and lockable MDM enrollment All iOS, macOS, and tvOS devices added to DEP will be enrolled automatically in MDM. Automatic enrollment ensures that devices are configured based on your organization’s requirements, and guarantees that all users receive those configurations on their devices. Your users’ devices are also locked in MDM for ongoing management. Wireless supervision Supervision provides a higher level of device management for organization-owned iOS devices. It
 allows additional restrictions, such as turning off iMessage, AirDrop, or Game Center, and it provides additional device configurations and features, such as web content filtering and Single App Mode. With DEP, supervision is wirelessly enabled on a device as part of the setup process. Zero-touch configuration for IT With DEP, large-scale deployments of iPad, iPhone, Mac, and Apple TV are seamless. Once devices have been activated, you can immediately configure account settings, apps, and access to IT services over
 the air. You don’t need to use staging services or physically access each device to complete the setup. Streamlined Setup Assistant DEP also makes it easier for your users to set up their iOS devices, Mac computers, and Apple TV. Using an MDM solution to configure your organization’s devices, users are guided through the activation process with the built-in Setup Assistant. You can streamline the Setup Assistant even further by specifying that certain screens be skipped. Apple Deployment Programs | Device Enrollment Program Guide | December 2017 1
14. © JAMF Software, LLC
15. © JAMF Software, LLC
16. © JAMF Software, LLC
17. © JAMF Software, LLC
18. © JAMF Software, LLC
19. © JAMF Software, LLC
20. © JAMF Software, LLC Why is this so important now? User-Approved MDM - UAMDM
21. © JAMF Software, LLC
22. © JAMF Software, LLC Let’s go down the rabbit hole!
23. © JAMF Software, LLC What’s going on? • Vendor API • Cloud API • Private API Three basic pieces
24. © JAMF Software, LLC
25. © JAMF Software, LLC Vendor API 33645004YAM 33645004YAM { "requestContext": { "shipTo": "0000052010", "timeZone": "420", "langCode": "en" }, "transactionId": "TXN_001122", "depResellerId": "16FCE4A0", "orders": [ { "orderNumber": "ORDER_900123", "orderDate": "2014-08-28T10:10:10Z", "orderType": "OR", "customerId": “12345678", "poNumber": "PO_12345", "deliveries": [ { "deliveryNumber": "D1.2", "shipDate": "2014-10-10T05:10:00Z", "devices": [ { "deviceId": "33645004YAM", "assetTag": "A123456" } 33645004YAM { "requestContext": { "shipTo": "0000052010", "timeZone": "420", "langCode": "en" }, "transactionId": "TXN_001122", "depResellerId": "16FCE4A0", "orders": [ { "orderNumber": "ORDER_900123", "orderDate": "2014-08-28T10:10:10Z", "orderType": "OR", "customerId": “12345678", "poNumber": "PO_12345", "deliveries": [ { "deliveryNumber": "D1.2", "shipDate": "2014-10-10T05:10:00Z", "devices": [ { "deviceId": " "assetTag": "A123456" }
26. © JAMF Software, LLC
27. © JAMF Software, LLC Cloud API Jamf Pro school.apple.com business.apple.com
28. © JAMF Software, LLC
29. © JAMF Software, LLC Cloud API • Sync device records from Apple • Post “DEP profiles” to Apple RESTful API
30. © JAMF Software, LLC Device sync {
 ”serial_number” : ”33645004YAM”,
 ”model” : ”IPAD”,
 ”color” : ”black”,
 ”description” : ”IPAD WI-FI 16GB”,
 ”asset_tag” : ”304214”,
 ”profile_status” : ”empty”,
 ”op_type” : ”added”,
 ”op_date” : ”2013-05-09T14:30:00Z”, ”device_assigned_by” : ”facilitator1@sampleinc.com”, ”device_assigned_date” : ”2013-05-09T14:30:00Z”, ”os” : ”iOS”,
 ”device_family” : ”iPad” },
31. © JAMF Software, LLC Cloud API Jamf Pro mdmenrollment.apple.com 33645004YAM 33645004YAM 33645004YAM 33645004YAM
32. © JAMF Software, LLC
33. © JAMF Software, LLC Cloud API • POSTs information from Prestage DEP profile (prestage)
34. © JAMF Software, LLC
35. © JAMF Software, LLC Cloud API Jamf Pro mdmenrollment.apple.com 33645004YAM <!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/D$ <plist version="1.0"> <dict> <key>CloudConfigProfile</key> <dict> <key>AllowPairing</key> <false/> <key>AnchorCertificates</key> <array/> <key>AwaitDeviceConfigured</key> <true/> <key>ConfigurationURL</key> <string>https://jamfinstance.jamfcloud.com/cloudenroll</stri$ <key>IsMDMUnremovable</key> <false/> <key>IsMandatory</key> <true/> <key>IsSupervised</key> <true/> <key>OrganizationAddress</key> <string>352 Ferntree Gully Road , Notting Hill, VI, 3166 (AUS$ <key>OrganizationAddressLine1</key> <string>352 Ferntree Gully Road</string> <key>OrganizationAddressLine2</key> <string>NULL</string> <key>OrganizationCity</key> <string>Notting Hill</string> <key>OrganizationCountry</key> <string>AUS</string> <key>OrganizationDepartment</key> <string>IT</string> <key>OrganizationEmail</key> <string>its@compnow.com.au</string> <key>OrganizationMagic</key> <string>0BA88B6ExxDE4D44x998990Ax9748Ex8</string> <key>OrganizationName</key> <string>Computers Now Pty Ltd</string> <key>OrganizationPhone</key> <string>+613 9684 3600</string> <key>OrganizationSupportPhone</key> <string>+613 9684 3600</string> <key>OrganizationZipCode</key> <string>3168</string> <key>SkipSetup</key> <array> <string>Siri</string> <string>Privacy</string> <string>Restore</string> <string>iCloudStorage</string> <string>TOS</string> <string>Biometric</string> <string>Payment</string> <string>Registration</string> <string>iCloudDiagnostics</string> <string>AppleID</string> <string>Diagnostics</string> </array> </dict> </dict> </plist>
36. © JAMF Software, LLC Private API • Devices to Apple • On activation (iOS) • First network contact (macOS) RESTful API
37. © JAMF Software, LLC Language Chooser Setup Assistant boot User = _mbsetupuser User = root MacBuddy
38. © JAMF Software, LLC cloudconfigurationd User = _mbsetupuser https://iprofiles.apple.com/resource/certificate.cer https://iprofiles.apple.com/session 33645004YAM { “action”: “RequestProfileConfiguration”, “sn”: “33645004YAM” }
39. © JAMF Software, LLC cloudconfigurationd User = _mbsetupuser https://iprofiles.apple.com/macProfile 33645004YAM
40. © JAMF Software, LLC http://init-p01st.push.apple.com/bag Apple Push Notification JNUC 2017: A Push Odyssey - Bradley Chapman
41. © JAMF Software, LLC User = _mbsetupuser https://name.jamfcloud.com/cloudenroll Mdmclient User = $username InstallApplication (Jamf Binary) enrollmentcomplete Jamf Pro
42. © JAMF Software, LLC
43. © JAMF Software, LLC Testing and Troubleshooting
44. © JAMF Software, LLC
45. © JAMF Software, LLC
46. © JAMF Software, LLC Testing and Troubleshooting No network connection
47. © JAMF Software, LLC Testing and Troubleshooting
48. © JAMF Software, LLC Troubleshooting Command Line at the setup assistant
49. © JAMF Software, LLC
50. © JAMF Software, LLC Troubleshooting At Language screen - root At Setup Assistant - _mbsetupuser touch /Volumes/Macintosh\ HD/var/db/.RunLanguageChooserToo - run from recovery, prompts for language at next boot
51. © JAMF Software, LLC Trigger files drwxr-xr-x@ 6 root wheel 192 13 Jul 09:29 . drwxr-xr-x 7 root wheel 224 6 Jul 15:59 .. -rw-r--r-- 1 root wheel 0 5 Oct 13:38 .cloudConfigHasActivationRecord -rw-r--r-- 1 root wheel 1387 5 Oct 13:38 .cloudConfigRecordFound -rw-r--r-- 1 root wheel 0 5 Oct 13:38 .migrated /var/db/ConfigurationProfiles/Settings
52. © JAMF Software, LLC Trigger files
53. © JAMF Software, LLC Testing and Troubleshooting
54. © JAMF Software, LLC
55. © JAMF Software, LLC Testing and Troubleshooting Clock skew date <mmddhhmmyy> date 1023161418
56. © JAMF Software, LLC Trigger files drwxr-xr-x@ 6 root wheel 192 13 Jun 09:29 . drwxr-xr-x 7 root wheel 224 13 Jun 09:29 .. -rw-r--r-- 1 root wheel 0 17 Jun 13:38 .cloudConfigNoActivationRecord -rw-r--r-- 1 root wheel 0 17 Jun 13:38 .cloudConfigRecordNotFound -rw-r--r-- 1 root wheel 0 13 Jun 09:29 .migrated
57. © JAMF Software, LLC Network
58. © JAMF Software, LLC Network
59. © JAMF Software, LLC Network
60. © JAMF Software, LLC Network
61. © JAMF Software, LLC Network • Authenticated or manual proxies • SSL inspection • Firewall rules • Latency/flooding Potential roadblocks
62. © JAMF Software, LLC Network
63. © JAMF Software, LLC Virtualisation Serial + AutoDMG + vfuse + VMware Fusion Pro
64. © JAMF Software, LLC Virtualisation
65. © JAMF Software, LLC Virtualisation
66. © JAMF Software, LLC Remediation sudo /usr/libexec/mdmclient dep nag* sudo /usr/bin/profiles show -type enrollment sudo /usr/bin/profiles status -type enrollment sudo /usr/bin/profiles renew -type enrollment *pre 10.13.4
67. © JAMF Software, LLC Remediation 1. Re-scope prestage enrollment 2. Open a root shell (ctl-opt-cmd-t) 3. sudo profiles renew -type enrollment 4. Reboot again
68. © JAMF Software, LLC Remediation Your mileage may vary The most reliable solution is to nuke and pave
69. © JAMF Software, LLC
70. © JAMF Software, LLC Conclusion • Clear network access • Test your workflow • Understand the limitations The secrets to a smooth Device Enrollment
71. © JAMF Software, LLC Here’s to the crazy ones • Victor Vrantchan • Pepijn Bruienne • Jesse Peterson • Jesse Endahl • Max Belanger • Owen Pragel • Bradley Chapman • Richard Purves Thanks to the following folks • Joe Chilcote • Emily Kausalik-Whittle • Chris Collins • Mosen • Graham Pugh • Ross Derewianko • Per Olofsson • Charles Edge
72. © JAMF Software, LLC Conference presentations • Demystifying MDM Jesse Peterson Victor Vrantchan, PSU Macadmins 2017 • 2017: A Push Odyssey Bradley Chapman, JNUC 2017 • A Deep Dive into macOS MDM (and how it can be compromised) Jesse Endahl, Max Belanger, Black Hat 2018 • MDM Me Maybe James Barclay, Ekoparty 2018
73. © JAMF Software, LLC References Use Device Enrollment https://support.apple.com/HT204142 TCP and UDP ports used by Apple Software https://support.apple.com/HT202944 Get Started using Apple Business Manager with Mobile Device Management https://support.apple.com/HT207516 If you aren’t getting Apple push notifications https://support.apple.com/HT203609 If you service or replace a device in Apple School Manager or Apple Business Manager https://support.apple.com/en-us/HT203016 Find Apple Customer Numbers, DEP Reseller ID and DEP Reseller ID https://support.apple.com/HT204401
74. © JAMF Software, LLC Apple System Status Page https://www.apple.com/au/support/systemstatus/ Device Enrollment Program Guide https://www.apple.com/business/site/docs/DEP_Guide.pdf https://www.apple.com/au/education/docs/DEP_Guide.pdf Apple Deployment Programs Help https://help.apple.com/deployment/business/ https://help.apple.com/deployment/education/ Deployment Reference https://help.apple.com/deployment/macos/ https://help.apple.com/deployment/ios/ MDM Protocol Reference https://developer.apple.com/enterprise/documentation/MDM-Protocol-Reference.pdf AppleCare Connect DEP API guide https://applecareconnect.apple.com/api-docs/depuat/html/WSStart.html References
75. © JAMF Software, LLC MicroMDM wiki - Troubleshooting MDM and DEP https://github.com/micromdm/micromdm/wiki/Troubleshooting-MDM Using Terminal at the setup assistant https://chris-collins.io/2018/03/15/Using-Terminal-At-macOS-Setup-Assistant/ Showing the language chooser screen after reinstalling macOS https://grahamrpugh.com/2017/11/22/language-chooser.html AutoDMG https://github.com/MagerValp/AutoDMG vfuse https://github.com/chilcote/vfuse Creating VMs that work with Device Enrollment https://www.rderewianko.com/how-to-create-a-vm-thatll-work-with-dep-on-vmware-fusion/ References
76. © JAMF Software, LLC Duo Security - MDM Me Maybe https://duo.com/labs/research/mdm-me-maybe https://www.youtube.com/watch?v=lz6ikbC3Rdg Demystifying MDM: open source endeavors to manage Macs - Jesse Peterson and Victor Vrantchan https://www.youtube.com/watch?v=6DBGIDcBKFw Getting MicroMDM working and working with MicroMDM – Jesse Peterson https://www.youtube.com/watch?v=WGKT-PyHz6I A Deep Dive into macOS MDM (and how it can be compromised) https://i.blackhat.com/us-18/Thu-August-9/us-18-Endahl-A-Deep-Dive-Into-macOS-MDM- And-How-It-Can-Be-Compromised-wp.pdf A Push Odyssey: Journey to the Center of APNS | JNUC 2017 https://www.youtube.com/watch?v=Z-Lg9uBbmfk References
77. © JAMF Software, LLC References • goo.gl/YgB9XB • ransomware.ransom.net.au
78. © JAMF Software, LLC Questions?
