  1. jgs
    CSC 570
    Current Topics in Computer Science
    Applied Affective Computing
    Lecture 03:
    PAD Vector
    Dr. Javier Gonzalez-Sanchez
    [email protected]
    www.javiergs.com
    Building 14 -227
    Office Hours: By appointment

    View Slide

  2. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 2
    Affective Computing + Interactive Interaction
    (ACII 2023)
    Demo
    Deadline: 30th June 2023
    September 10–13. Cambridge, MA.
    https://acii-conf.net/2023/calls/demos/
    Conference

    View Slide

  3. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 3
    ACM Symposium on User Interface Software and Technology
    (UIST 2023)
    Demo
    Deadline: July 19, 2023
    October 29–November 1, California Bay Area.
    https://uist.acm.org/2023/cfp/#demos
    Conference

    View Slide

  4. jgs
    Previously …

    View Slide

  5. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 5
    Affect, Emotion, Mood
    Label
    🧪 🧪
    +
    ⚡ ⚡
    🧪
    +

    Label
    🧪 🧪
    +
    ⚡ ⚡
    🧪 🧪
    +
    ⚡ ⚡
    🧪 🧪
    +
    ⚡ ⚡

    View Slide

  6. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 6
    PAD
    +P+A+D
    Engagement
    +P-A+D
    Meditation
    Concentration
    Thought
    Relaxation
    +P+A-D
    Excitement
    Interest
    Dependence
    +P-A-D
    Starting
    Agreement
    Docility
    -P+A+D
    Disagreement
    Hostility
    -P-A+D
    Disdain
    -P+A-D
    Frustration
    Unsureness
    Anxiety
    -P-A-D
    Boredom
    Pleasure
    (Valence)
    Arousal
    (Activation)
    Dominance

    View Slide

  7. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 7
    PAD
    (+++)
    Engagement
    (-++)
    Disagreement
    Hostility
    (++-)
    Excitement
    Interest
    Dependence
    (-+-)
    Frustration
    Unsureness
    Anxiety
    (+-+)
    Meditation
    Concentration
    Thought
    Relaxation
    (--+)
    Disdain
    (+--)
    Starting
    Agreement
    Docility
    (---)
    Boredom
    controlled
    In control controlled
    In control
    Aroused
    Aroused
    Pleasure
    Pleasure
    🙂🫀🕹 🙂🫀👾 🙂 🕹 🙂 👾
    Pleasure
    Pleasure
    controlled
    In control controlled
    In control
    Aroused
    Aroused
    🫀🕹 🫀👾 🕹 👾

    View Slide

  8. jgs
    Test Yourselves

    View Slide

  9. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 9
    Thoughts?
    Unsureness(-+-)
    Anxiety(-+-)
    Surprised(++-)
    Hostility(-++)
    🙂
    🙂 🙂
    🫀 🫀
    🫀 🫀
    🫀 🫀 🫀 🕹
    🕹
    🙂
    Concentration(+-+)
    Excitement(++-) Dependance(++-)
    Frustration (-+-)
    🫀
    Fear(-+-)
    Disdain (---)

    View Slide

  10. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 10
    Thoughts?

    View Slide

  11. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 11
    Affective States
    thechalkboardmag.com
    👾
    🫀👾
    🫀🕹
    🙂🫀👾
    🙂🫀🕹
    🕹
    👾

    View Slide

  12. jgs
    Data Collection

    View Slide

  13. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 13
    Y = X1
    + X2
    + X3
    + …
    ML

    View Slide

  14. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 14
    Workflow

    View Slide

  15. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 15
    Emotiv EPOC X

    View Slide

  16. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 17
    Brain
    Timestamp AF3 F7 F3 FC5 T7 P7 O1 O2 P8 T8 FC6 F4 F8 AF4 AccX AccY
    101116112544901 4542.05 4831.79 4247.18 4690.26 4282.56 4395.38 4591.79 4569.23 4360 4570.77 4297.44 4311.28 4282.56 4367.18 1660 2003
    101116112544901 4536.92 4802.05 4243.08 4673.85 4272.31 4393.33 4592.82 4570.26 4354.87 4570.26 4292.31 4309.74 4277.95 4370.77 1658 2002
    101116112545010 4533.33 4798.97 4234.87 4669.74 4301.03 4396.92 4592.31 4570.77 4351.28 4561.03 4281.54 4301.54 4271.28 4363.59 1659 2003
    101116112545010 4549.23 4839.49 4241.03 4691.28 4333.85 4397.95 4596.41 4567.18 4355.9 4556.41 4286.15 4306.15 4277.95 4369.74 1659 2003
    101116112545010 4580 4865.64 4251.79 4710.26 4340 4401.54 4603.59 4572.82 4360 4558.46 4298.97 4324.62 4296.41 4395.9 1657 2004
    101116112545010 4597.44 4860 4252.82 4705.64 4350.26 4412.31 4603.59 4577.44 4357.44 4555.9 4295.38 4329.23 4296.41 4414.36 1656 2005
    101116112545010 4584.62 4847.69 4246.67 4690.26 4360 4409.23 4597.44 4569.74 4351.79 4549.74 4278.97 4316.92 4272.82 4399.49 1656 2006
    101116112545010 4566.15 4842.05 4238.46 4684.1 4322.05 4389.74 4592.82 4566.67 4351.79 4549.74 4274.36 4310.26 4262.05 4370.77 1655 2005
    101116112545010 4563.59 4844.62 4231.79 4687.69 4267.69 4387.69 4594.36 4580 4361.03 4556.41 4278.97 4310.77 4274.36 4370.77 1653 2006
    101116112545010 4567.18 4847.18 4233.33 4688.72 4285.13 4409.23 4602.05 4589.23 4368.21 4560 4280.51 4310.77 4281.54 4390.26 1655 2004
    101116112545010 4562.05 4840.51 4227.18 4673.85 4300 4405.13 4611.28 4601.03 4376.41 4561.54 4280 4303.59 4279.49 4374.87 1652 2000

    View Slide

  17. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 18
    Brain
    14 channels
    128 samples per second
    1,792 values por second
    107,520 values per minute
    6,451,200 values per hour

    View Slide

  18. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 19
    Let’s Work

    View Slide

  19. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 20
    Brain
    Timestamp Short Term Excitement Long Term Excitement Engagement Meditation Frustration
    101116091145065 0.447595 0.54871 0.834476 0.333844 0.536197
    101116091145190 0.447595 0.54871 0.834476 0.333844 0.536197
    101116091145315 0.447595 0.54871 0.834476 0.333844 0.536197
    101116091145440 0.487864 0.546877 0.834146 0.339548 0.54851
    101116091145565 0.487864 0.546877 0.834146 0.339548 0.54851
    101116091145690 0.487864 0.546877 0.834146 0.339548 0.54851
    101116091145815 0.487864 0.546877 0.834146 0.339548 0.54851
    101116091145940 0.521663 0.545609 0.839321 0.348321 0.558228
    101116091146065 0.521663 0.545609 0.839321 0.348321 0.558228
    101116091146190 0.521663 0.545609 0.839321 0.348321 0.558228
    101116091146315 0.521663 0.545609 0.839321 0.348321 0.558228
    101116091146440 0.509297 0.544131 0.84401 0.358717 0.546771
    101116091146565 0.509297 0.544131 0.84401 0.358717 0.546771
    101116091146690 0.509297 0.544131 0.84401 0.358717 0.546771
    101116091146815 0.509297 0.544131 0.84401 0.358717 0.546771
    101116091146941 0.451885 0.541695 0.848087 0.368071 0.533919

    View Slide

  20. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 21
    Brain
    21
    5 samples per second
    5 affective states
    25 values per second
    1,500 values per minute
    90,000 values per hour

    View Slide

  21. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 22
    Let’s Work

    View Slide

  22. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 23
    Homework
    A. Create your Team
    B. Decide what your project will be
    C. Start Working on a proposal
    § What - Problem to be Address
    § Why – Impact or Relevance
    § How – Your product and tools to be used
    § Have something similar been done before?
    § Why are you different?
    (Google Scholar)

    View Slide

  23. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 24
    Questions

    View Slide

  24. jgs
    Javier Gonzalez-Sanchez | CSC 309 | Winter 2023 | 25
    Office Hours
    Tuesday and Thursday 3 - 5 pm
    But an appointment required
    Sent me an email – [email protected]

    View Slide

  25. jgs
    CSC 570 Applied Affective Computing
    Javier Gonzalez-Sanchez, Ph.D.
    [email protected]
    Spring 2023
    Copyright. These slides can only be used as study material for the class CSC308 at Cal Poly.
    They cannot be distributed or used for another purpose.

    View Slide
