Testing made sweet with a Mockito
Slides from my talk at Droidcon Berlin and Big Android BBQ Amsterdam 2016
audio: https://voicerepublic.com/talks/testing-made-sweet-with-a-mockito
The past year has been huge for Android testing: Testing support lib, fast JVM unit tests,... Having such great tools means writing tests is a breeze! All your apps currently have >80% code coverage, right? Yay! Or wait... is it really? Is all your common Android logic (networking, databases,...) tested? Do you isolate parts of your code base to keep your tests small? And what about providing relevant testing data?
In order to achieve this, you need to make use of mocks and stubs. And that's exactly what this talk will be about: What is a mock? What's the difference between a mock and a stub? Are mocks the only way to provide relevant data for your unit tests? What do I do with all the final classes/methods in the Android SDK? How do I architect my app to make it easier to test? ...
After having adopted TDD as my main development workflow for almost a year now, I feel comfortable saying everything can be tested. Its just a matter of having someone experience show you how.
Jeroen Mols
Transcript
86 slides
-
IF YOU DON’T LIKE UNIT TESTING YOUR PRODUCT, MOST LIKELY
YOUR CUSTOMERS WON’T LIKE TO TEST IT EITHER. Unknown -
ALWAYS WRITE A TEST TO REPRODUCE A BUG BEFORE YOU
FIX IT Robert C. Martin* -
@MOLSJEROEN GOAL UI USER WEBSERVICE Button press Login/logout command Success/failure
Update UI LOGININTERFACE RESPONSE -
@MOLSJEROEN GOAL UI USER WEBSERVICE Button press Login/logout command Success/failure
Update UI LOGININTERFACE RESPONSE -
@MOLSJEROEN TEST REQUIREMENTS ▸ All tests must ▸ Run really
fast ▸ Be small and focussed ▸ Reliable, not “flaky” ▸ Challenges: UI & WebService UI USER WEBSERVICE -
@MOLSJEROEN SOLUTION ▸ Isolate User ▸ Don’t include UI ▸
Replace WebService with dummy ▸ Mimic WebService behaviour ▸ => Verify interactions UI USER WEBSERVICE* -
@MOLSJEROEN DEFINITION: TEST DOUBLES ▸ Replace real class ▸ Same
interface ▸ Different behaviour WEBSERVICE* WEBSERVICE public void login() { // NORMAL IMPL. } public void login() { // DO NOTHING } -
@MOLSJEROEN DEFINITION: TEST DOUBLES ▸ Replace real class ▸ Same
interface ▸ Different behaviour WEBSERVICE* WEBSERVICE public void login() { // NORMAL IMPL. } public void login() { // DO NOTHING } -
@MOLSJEROEN DEFINITION: TEST DOUBLES ▸ Replace real class ▸ Same
interface ▸ Different behaviour WEBSERVICE* WEBSERVICE public void login() { // NORMAL IMPL. } public void login() { loginInterface.success(); } -
@MOLSJEROEN DEFINITION: TEST DOUBLES ▸ Replace real class ▸ Same
interface ▸ Different behaviour WEBSERVICE* WEBSERVICE public void login() { // NORMAL IMPL. } public void login() { throw new Exception(); } -
@MOLSJEROEN DEFINITION: MOCKS AND STUBS ▸ What is a mock?
▸ Generated class ▸ Doesn’t do anything ▸ Behaviour verification ▸ What is a stub? ▸ Handwritten class ▸ Returns predefined responses ▸ State verification -
@MOLSJEROEN Open source mocking framework that lets you write beautiful
tests with a clean & simple API ▸ Documentation on mockito.org ▸ Source code on Github ▸ MIT license WHAT IS IT? -
@MOLSJEROEN WHY DRINK IT? ▸ Easy to use ▸ Very
readable syntax ▸ No learning curve ▸ Annotation support ▸ Mature ▸ Large stackoverflow community ▸ Most popular Java / Android mocking framework -
@MOLSJEROEN HOW TO DRINK IT? ▸ PROJECT_HOME/build.gradle buildscript { repositories
{ jcenter() } } ▸ MODULE_HOME/build.gradle dependencies { ... testCompile "org.mockito:mockito-core:2.0.101-beta" } -
@MOLSJEROEN HOW TO DRINK IT? ▸ PROJECT_HOME/build.gradle buildscript { repositories
{ jcenter() } } ▸ MODULE_HOME/build.gradle dependencies { ... testCompile "org.mockito:mockito-core:2.0.101-beta" } -
@MOLSJEROEN INGREDIENTS ▸ Creating a mock ▸ Verifying interactions ▸
Stubbing methods ▸ Capturing arguments ▸ Mockito limitations -
@MOLSJEROEN INGREDIENTS ▸ Creating a mock ▸ Verifying interactions ▸
Stubbing methods ▸ Capturing arguments ▸ Mockito limitations -
@MOLSJEROEN CREATING A MOCK import static org.mockito.Mockito.mock; @Test public void
createMock() throws Exception { WebService mockWebService = mock(WebService.class); new User(mockWebService, 0, null); } -
@MOLSJEROEN CREATING A MOCK import static org.mockito.Mockito.mock; @Test public void
createMock() throws Exception { WebService mockWebService = mock(WebService.class); new User(mockWebService, 0, null); } -
@MOLSJEROEN CREATING A MOCK import static org.mockito.Mockito.mock; @Test public void
createMock() throws Exception { WebService mockWebService = mock(WebService.class); new User(mockWebService, 0, null); } -
@MOLSJEROEN CREATING A MOCK - ANNOTATION @Rule public MockitoRule mockitoRule
= MockitoJUnit.rule(); @Mock private WebService mockWebService; @Test public void createMockUsingAnnotation() throws Exception { new User(mockWebService, 0, null); } -
@MOLSJEROEN CREATING A MOCK - ANNOTATION @Rule public MockitoRule mockitoRule
= MockitoJUnit.rule(); @Mock private WebService mockWebService; @Test public void createMockUsingAnnotation() throws Exception { new User(mockWebService, 0, null); } -
@MOLSJEROEN CREATING A MOCK - ANNOTATION @Rule public MockitoRule mockitoRule
= MockitoJUnit.rule(); @Mock private WebService mockWebService; @Test public void createMockUsingAnnotation() throws Exception { new User(mockWebService, 0, null); } -
@MOLSJEROEN INGREDIENTS ▸ Creating a mock ▸ Verifying interactions ▸
Stubbing methods ▸ Capturing arguments ▸ Mockito limitations -
@MOLSJEROEN VERIFYING INTERACTIONS @Test public void verifyInteractionTimes() throws Exception {
User user = new User(mockWebService, USER_ID, PASSWORD); user.logout(); verify(mockWebService).logout(); } -
@MOLSJEROEN VERIFYING INTERACTIONS @Test public void verifyInteractionTimes() throws Exception {
User user = new User(mockWebService, USER_ID, PASSWORD); user.logout(); verify(mockWebService).logout(); } -
@MOLSJEROEN VERIFYING INTERACTIONS - TIMES @Test public void verifyInteractionTimes() throws
Exception { User user = new User(mockWebService, USER_ID, PASSWORD); user.logout(); verify(mockWebService, times(1) ).logout(); atLeast(1) atLeastOnce() atMost(1) only() never() } -
@MOLSJEROEN VERIFYING INTERACTIONS - TIMES @Test public void verifyInteractionTimes() throws
Exception { User user = new User(mockWebService, USER_ID, PASSWORD); user.logout(); verify(mockWebService, times(1) ).logout(); atLeast(1) atLeastOnce() atMost(1) only() never() } ▸ Being overly restrictive makes tests brittle! -
@MOLSJEROEN VERIFYING INTERACTIONS - PARAMETERS @Test public void verifyInteractionParameters() throws
Exception { User user = new User(mockWebService, USER_ID, PASSWORD); user.login(null); verify(mockWebService).login(USER_ID); } -
@MOLSJEROEN VERIFYING INTERACTIONS - PARAMETERS @Test public void verifyInteractionParameters() throws
Exception { User user = new User(mockWebService, USER_ID, PASSWORD); user.login(null); verify(mockWebService).login(anyInt() ); anyString() any(Response.class) } -
@MOLSJEROEN VERIFYING INTERACTIONS - PARAMETERS @Test public void verifyInteractionParameters() throws
Exception { User user = new User(mockWebService, USER_ID, PASSWORD); user.login(null); verify(mockWebService).login(anyInt(), eq(PASSWORD)); } ▸ One matcher -> all arguments need to be matchers -
@MOLSJEROEN VERIFYING INTERACTIONS - PARAMETERS @Test public void verifyInteractionParameters() throws
Exception { User user = new User(mockWebService, USER_ID, PASSWORD); user.login(null); verify(mockWebService).login(gt(0) ); lt(10000) leq(10000) } -
@MOLSJEROEN VERIFYING INTERACTIONS - PARAMETERS @Test public void verifyInteractionParameters() throws
Exception { User user = new User(mockWebService, USER_ID, PASSWORD); user.login(null); verify(mockWebService).login(startsWith(“n1") ); contains(“c3") matches("n[1-9]{1}c[1-9]{1}[a-z]{3}") } -
@MOLSJEROEN VERIFYING INTERACTIONS - PARAMETERS @Test public void verifyInteractionParameters() throws
Exception { User user = new User(mockWebService, USER_ID, PASSWORD); user.login(null); verify(mockWebService).login(isNotNull(Response.class)) ); not(eq(0)) not(eq(“12345678")) and(gt(0), lt(Integer.MAX_VALUE)) } ▸ Mockito.Matchers ▸ Mockito.AdditionalMatchers -
@MOLSJEROEN VERIFYING INTERACTIONS - ORDER @Test public void verifyInteractionOrder() throws
Exception { User user = new User(mockWebService, USER_ID, PASSWORD); user.login(null); user.logout(); InOrder inOrder = inOrder(mockWebService); inOrder.verify(mockWebService).login(); inOrder.verify(mockWebService).logout(); } -
@MOLSJEROEN VERIFYING INTERACTIONS - ORDER @Test public void verifyInteractionOrder() throws
Exception { User user = new User(mockWebService, USER_ID, PASSWORD); user.login(null); user.logout(); InOrder inOrder = inOrder(mockWebService); inOrder.verify(mockWebService).login(); inOrder.verify(mockWebService).logout(); } -
@MOLSJEROEN VERIFYING INTERACTIONS - ORDER @Test public void verifyInteractionOrder() throws
Exception { User user = new User(mockWebService, USER_ID, PASSWORD); user.login(null); user.logout(); InOrder inOrder = inOrder(mockWebService); inOrder.verify(mockWebService).login(); inOrder.verify(mockWebService).logout(); } -
@MOLSJEROEN INGREDIENTS ▸ Creating a mock ▸ Verifying interactions ▸
Stubbing methods ▸ Capturing arguments ▸ Mockito limitations -
@MOLSJEROEN STUBBING METHODS @Test public void stubMethod() throws Exception {
User user = new User(mockWebService, USER_ID, PASSWORD); when(mockWebService.isOffline()).thenReturn(true); user.login(mockLoginInterface); verify(mockWebService, never()).login(); } -
@MOLSJEROEN STUBBING METHODS @Test public void stubMethod() throws Exception {
User user = new User(mockWebService, USER_ID, PASSWORD); when(mockWebService.isOffline()).thenReturn(true); user.login(mockLoginInterface); verify(mockWebService, never()).login(); } -
@MOLSJEROEN STUBBING METHODS @Test public void stubMethod() throws Exception {
User user = new User(mockWebService, USER_ID, PASSWORD); when(mockWebService.isOffline()).thenReturn(true); user.login(mockLoginInterface); verify(mockWebService, never()).login(); } -
@MOLSJEROEN STUBBING METHODS @Test public void stubMethod() throws Exception {
User user = new User(mockWebService, USER_ID, PASSWORD); when(mockWebService.isOffline()).thenReturn(true, false, true); user.login(mockLoginInterface); verify(mockWebService, never()).login(); } -
@MOLSJEROEN STUBBING METHODS @Test public void stubMethod() throws Exception {
User user = new User(mockWebService, USER_ID, PASSWORD); when(mockWebService.isOffline()).thenThrow(CustomException.class); user.login(mockLoginInterface); verify(mockWebService, never()).login(); } -
@MOLSJEROEN STUBBING METHODS ▸ Normal syntax when(mockWebService.isOffline()).thenReturn(true); ▸ Alternative
syntax doReturn(true).when(mockWebService).isOffline(); ▸ BDD syntax given(mockWebService.isOffline()).willReturn(true); -
@MOLSJEROEN STUBBING METHODS ▸ Normal syntax when(mockWebService.isOffline()).thenReturn(true); ▸ Alternative
syntax doReturn(true).when(mockWebService).isOffline(); ▸ BDD syntax given(mockWebService.isOffline()).willReturn(true); -
@MOLSJEROEN STUBBING METHODS ▸ Normal syntax when(mockWebService.isOffline()).thenReturn(true); ▸ Alternative
syntax doReturn(true).when(mockWebService).isOffline(); ▸ BDD syntax given(mockWebService.isOffline()).willReturn(true); -
@MOLSJEROEN INGREDIENTS ▸ Creating a mock ▸ Verifying interactions ▸
Stubbing methods ▸ Capturing arguments ▸ Mockito limitations -
@MOLSJEROEN CAPTURING ARGUMENTS @Test public void captureArguments() throws Exception {
User user = new User(mockWebService, USER_ID, PASSWORD); user.login(mockLoginInterface); verify(mockWebService).login(responseArgumentCaptor.capture()); Response response = responseArgumentCaptor.getValue(); response.onRequestCompleted(true); verify(mockLoginInterface).onLoginSuccess(); } UI USER WEBSERVICE LOGININTERFACE RESPONSE -
@MOLSJEROEN CAPTURING ARGUMENTS @Test public void captureArguments() throws Exception {
User user = new User(mockWebService, USER_ID, PASSWORD); user.login(mockLoginInterface); verify(mockWebService).login(responseArgumentCaptor.capture()); Response response = responseArgumentCaptor.getValue(); response.onRequestCompleted(true); verify(mockLoginInterface).onLoginSuccess(); } UI USER WEBSERVICE LOGININTERFACE RESPONSE -
@MOLSJEROEN CAPTURING ARGUMENTS @Test public void captureArguments() throws Exception {
User user = new User(mockWebService, USER_ID, PASSWORD); user.login(mockLoginInterface); verify(mockWebService).login(responseArgumentCaptor.capture()); Response response = responseArgumentCaptor.getValue(); response.onRequestCompleted(true); verify(mockLoginInterface).onLoginSuccess(); } UI USER WEBSERVICE LOGININTERFACE RESPONSE -
@MOLSJEROEN CAPTURING ARGUMENTS @Test public void captureArguments() throws Exception {
User user = new User(mockWebService, USER_ID, PASSWORD); user.login(mockLoginInterface); verify(mockWebService).login(responseArgumentCaptor.capture()); Response response = responseArgumentCaptor.getValue(); response.onRequestCompleted(true); verify(mockLoginInterface).onLoginSuccess(); } UI USER WEBSERVICE LOGININTERFACE RESPONSE -
@MOLSJEROEN CAPTURING ARGUMENTS @Test public void captureArguments() throws Exception {
User user = new User(mockWebService, USER_ID, PASSWORD); user.login(mockLoginInterface); verify(mockWebService).login(responseArgumentCaptor.capture()); Response response = responseArgumentCaptor.getValue(); response.onRequestCompleted(true); verify(mockLoginInterface).onLoginSuccess(); } UI USER WEBSERVICE LOGININTERFACE RESPONSE -
@MOLSJEROEN INGREDIENTS ▸ Creating a mock ▸ Verifying interactions ▸
Stubbing methods ▸ Capturing arguments ▸ Mockito limitations -
@MOLSJEROEN MOCKITO LIMITATIONS ▸ Unable to mock ▸ final classes
▸ final methods ▸ static methods ▸ private methods ▸ hashCode() and equals() -
@MOLSJEROEN ▸ Model View Presenter ▸ Mock view & model
▸ Fully test presenter ▸ UI layer == “pass through” ▸ Dependency injection ▸ Only “inward pointing” dependencies 1. TESTING UI MODEL VIEW VIEW IMPLEMENTATION PRESENTER -
@MOLSJEROEN 2. RUNNING MOCKITO ON A DEVICE ▸ MODULE_HOME/build.gradle defaultConfig
{ … testInstrumentationRunner "android.support.test.runner.AndroidJUnitRunner" } dependencies { … androidTestCompile 'com.android.support.test:runner:0.4' androidTestCompile 'com.android.support.test:rules:0.4' androidTestCompile 'org.mockito:mockito-core:1.10.19' androidTestCompile "com.google.dexmaker:dexmaker:1.2" androidTestCompile "com.google.dexmaker:dexmaker-mockito:1.2" } -
@MOLSJEROEN 2. RUNNING MOCKITO ON A DEVICE ▸ MODULE_HOME/build.gradle defaultConfig
{ … testInstrumentationRunner "android.support.test.runner.AndroidJUnitRunner" } dependencies { … androidTestCompile 'com.android.support.test:runner:0.4' androidTestCompile 'com.android.support.test:rules:0.4' androidTestCompile 'org.mockito:mockito-core:1.10.19' androidTestCompile "com.google.dexmaker:dexmaker:1.2" androidTestCompile "com.google.dexmaker:dexmaker-mockito:1.2" } -
@MOLSJEROEN 2. RUNNING MOCKITO ON A DEVICE ▸ MODULE_HOME/build.gradle defaultConfig
{ … testInstrumentationRunner "android.support.test.runner.AndroidJUnitRunner" } dependencies { … androidTestCompile 'com.android.support.test:runner:0.4' androidTestCompile 'com.android.support.test:rules:0.4' androidTestCompile 'org.mockito:mockito-core:1.10.19' androidTestCompile "com.google.dexmaker:dexmaker:1.2" androidTestCompile "com.google.dexmaker:dexmaker-mockito:1.2" } -
@MOLSJEROEN 3. TESTING FINAL METHODS / CLASSES public class Handler
{ public Handler() {}; public final boolean post(Runnable r) { // internal implementation } public final boolean sendMessage(Message msg) { // internal implementation } } -
@MOLSJEROEN 3. TESTING FINAL METHODS / CLASSES public class Handler
{ public Handler() {}; public final boolean post(Runnable r) { // internal implementation } public final boolean sendMessage(Message msg) { // internal implementation } } -
@MOLSJEROEN 3. TESTING FINAL METHODS / CLASSES public class HandlerWrapper
{ private final Handler handler; public HandlerWrapper() { handler = new Handler(); } public boolean post(Runnable r) { return handler.post(r); } public boolean sendMessage(Message msg) { return handler.sendMessage(msg); } } -
@MOLSJEROEN 3. TESTING FINAL METHODS / CLASSES public class HandlerWrapper
{ private final Handler handler; public HandlerWrapper() { handler = new Handler(); } public boolean post(Runnable r) { return handler.post(r); } public boolean sendMessage(Message msg) { return handler.sendMessage(msg); } } -
@MOLSJEROEN 3. TESTING FINAL METHODS / CLASSES public class HandlerWrapper
{ private final Handler handler; public HandlerWrapper() { handler = new Handler(); } public boolean post(Runnable r) { return handler.post(r); } public boolean sendMessage(Message msg) { return handler.sendMessage(msg); } } -
@MOLSJEROEN 3. TESTING STATIC METHODS public class NativeCamera {
private Camera camera = null; public Camera getNativeCamera() { return camera; } public void openNativeCamera() throws RuntimeException { camera = Camera.open(CameraInfo.CAMERA_FACING_BACK); } public void releaseNativeCamera() { camera.release(); } } -
@MOLSJEROEN 3. TESTING STATIC METHODS public class NativeCamera {
private Camera camera = null; public Camera getNativeCamera() { return camera; } public void openNativeCamera() throws RuntimeException { camera = Camera.open(CameraInfo.CAMERA_FACING_BACK); } public void releaseNativeCamera() { camera.release(); } } -
@MOLSJEROEN 4. TESTING DATA @Test public void mockData() throws Exception
{ UserData mock = mock(UserData.class); when(mock.getFirstName()).thenReturn("FirstName"); when(mock.getLastName()).thenReturn("LastName"); when(mock.getUserId()).thenReturn(1111007); when(mock.getStreet()).thenReturn("StreetName"); when(mock.getHouseNumber()).thenReturn(1); when(mock.getCity()).thenReturn("City"); when(mock.getCountry()).thenReturn("Country"); // Use mock in further test } -
@MOLSJEROEN 4. TESTING DATA @Test public void testData() throws Exception
{ UserData userData = new TestUserData(); // use mock in further test } public class TestUserData extends UserData { @Override public String getFirstName() { return "FirstName"; } ... } -
@MOLSJEROEN 4. TESTING DATA @Test public void testData() throws Exception
{ UserData userData = new TestUserData(); // use mock in further test } public class TestUserData extends UserData { @Override public String getFirstName() { return "FirstName"; } ... } -
@MOLSJEROEN 5. NEW CREATION public User(int userId, String password) {
this.webService = new WebService(); } ▸ Internal created objects ▸ almost impossible to test ▸ avoid for long lived objects -
@MOLSJEROEN 5. NEW CREATION public User(int userId, String password) {
this.webService = new WebService(); } ▸ Internal created objects ▸ almost impossible to test ▸ avoid for long lived objects -
@MOLSJEROEN 5. NEW CREATION public User(int userId, String password) {
this.webService = new WebService(); } ▸ Dependency injection public User(WebService webService, int userId, String password) { if (webService == null) { throw new RuntimeException("Webservice required"); } this.webService = webService; } -
@MOLSJEROEN 5. NEW CREATION public User(int userId, String password) {
this.webService = new WebService(); } ▸ Factory pattern public User(WebServiceFactory factory, int userId, String password) { this.webService = factory.createWebService(); } -
@MOLSJEROEN 6. POWER TIPS ▸ Avoid singletons ▸ Avoid instrumentation
tests ▸ Isolate non testable code ▸ Don’t use Spies ▸ Don’t nest mocks ▸ Avoid using “For testing methods” -
IT IS BETTER TO HAVE A SIMPLE TEST THAT WORKS
THAN A COMPLICATED TEST THAT SEEMS TO WORK. Mockito documentation -
@MOLSJEROEN CONCLUSION ▸ Mockito makes mocking & stubbing easy ▸
Avoid creating internal objects ▸ Choose a good testing strategy ▸ Don’t overuse the power features ▸ Keep unit tests small and focussed ▸ Consider refactoring ▸ Prefer tests on the java VM -
@MOLSJEROEN REFERENCES ▸ Mockito homepage http://mockito.org/ ▸ Mockito reference card
https://dzone.com/refcardz/mockito ▸ Dexmaker https://github.com/crittercism/dexmaker ▸ Sample code ▸ MockitoExample https://github.com/JeroenMols/MockitoExample ▸ LandscapeVideoCamera https://github.com/JeroenMols/LandscapeVideoCamera ▸ Legofy https://github.com/JeroenMols/Legofy -
@MOLSJEROEN IMAGE CREDITS ▸ Mojito https://indraneescookingcorner.blogspot.be/2014/08/virgin-mojito.html ▸ Philips Hue living
room http://www.philips.de ▸ Bartender set http://www.vinspireuk.com/2014/12/cocktail-gifts-for-cocktail-lovers.html ▸ Mojito ingredients https://www.nelleulla.com/lv-en/products/truffles/4-mojito-truffle ▸ Mockito Mojito http://www.seedylawyer.com/history-of-hemingways-mojitos/ ▸ Raspberry Mojito http://goodpixcool.com/raspberry+mojito+in+a+bottle?image=99002602 ▸ Drinking Mojito https://www.lancerskincare.com/blog/10-ways-to-age-your-skin-prematurely/ -
@MOLSJEROEN MANY THANKS ▸ Jeroen Mols (Belgium) ▸ @MolsJeroen ▸
http://jeroenmols.com/blog
