Improving light rail systems in Asia: new vehicle, traction power, and train control technologies

Introducing low-floor tramways for better urban integration and faster mode transfers.
Boosting safety and aesthetic with catenary-free operations.
Developing fast, high-frequency feeder to metro lines while optimising rolling stock investments.

SmartRail Asia 2015, Global Transport Forum
November 27, 2015 - Bangkok, Thailand

Transcript

1. IMPROVING LIGHT RAIL SYSTEMS IN ASIA NEW VEHICLE, TRACTION POWER, AND TRAIN CONTROL TECHNOLOGIES JOFFREY LAUTHIER HEAD OF SALES, ASIA PACIFIC RAIL CONTROL SOLUTIONS SMARTRAIL ASIA 2015 BANGKOK, NOVEMBER 27, 2015
2. ELECTRIC TRAMWAYS 1890-1930: TRAMWAY CONSTRUCTION BOOM ACROSS ASIA 10 cities 1900 37 cities 1910 55 cities 1920 76 cities 1930 Cumulated number of cities in Asia over time with electric tramways Cities considered: Akita, Asahikawa, Bangkok, Beijing, Busan, Chennai, Colombo, Dalian, Delhi, Fukuoka, George Town, Gifu, Hachiōji, Hakodate, Hanamaki, Hanoi, Harbin, Hiroshima, Ho Chi Minh City, Hong Kong, Ichinomiya, Ise, Iwakuni, Jakarta, Kagoshima, Kanazawa, Kanpur, Kawagoe, Kitakyūshū, Kobe, Kōchi, Kolkata, Kumamoto, Kure, Kurume, Kuwana, Kyoto, Mandalay, Manila, Matsumoto, Matsushima, Matsuyama, Mito, Mumbai, Nagasaki, Nagoya, Naha, Narita, Nikko, Odawara, Oita, Okayama, Okazaki, Ōmuta, Osaka, Pyongyang, Saga, Sapporo, Sendai, Seoul, Shanghai, Shenyang, Shimizu, Shimonoseki, Shizuoka, Singapore, Surabaya, Takamatsu, Tianjin, Tokyo, Toyama, Toyohashi, Wakayama, Yangon, Yokohama, Yonago. 1893 – First in Asia: Electric tram system by Bangkok Tramways Co.
3. * based on today’s Australian dollar value (Net Present Value or NPV) Source: ACT Capital Metro Business Case Overview capitalmetro.act.gov.au CANBERRA LRT FORECASTED TO CREATE ALMOST $1 BILLION* WORTH OF ECONOMIC BENEFITS
4. Australian dollar value Source: ACT Capital Metro Business Case Overview capitalmetro.act.gov.au CANBERRA LRT THE ESTIMATED CAPITAL DELIVERY COST IS $610M + $173M CONTINGENCY
5. BOMBARDIER FLEXITY VEHICLES 3,500+ TRAMS AND LRVS IN REVENUE SERVICE OR ON ORDER TRAMS Integrated into urban traffic Small curve radius between 12m and 18m 100 % low-floor and conventional wheel-set bogies Easy access and increased passenger comfort High running stability, noise reduction LIGHT RAIL VEHICLES Segregated tracks Curve radius between 20m and 25m Ability to use Mainline infrastructure
6. GOLD COAST LIGHT RAIL 13km, 16 stations, turnkey E&M
7. FOCUS ON PASSENGERS VEHICLE INTERIOR Maximum use of the space High flexibility in terms of layout and colouring High capacity, large number of comfortable passenger seats Very low pedestal, no steps obstruct passenger flow Aisle width up to 740 mm with 2+2 seating Optimised cross section and arrangement for agreeable perception of space Generously dimensioned articulation portal gangway
8. HIGH FLEXIBILITY AND CUSTOMISATION TAILOR-MADE VEHICLES Vehicle configuration flexibility Customers given virtually unlimited scope in customizing the exterior design Interior design is a balanced mix of simple, standardized solutions and individual features – Colours – Materials – Seat-cover fabric – Lighting – Seats and stanchion arrangement – Onboard racks for bicycles or luggage
9. FLEXIBLE VEHICLE ARRANGEMENT CONFIGURATION 5 modules 7 modules 2 motor bogies 3 motor bogies 1 trailer bogies 1 trailer bogies 32m long 43m long 2.30m / 2.40m / 2.65m wide 2.30m / 2.40m / 2.65m wide CM: cab module BM: bogie module SM: saloon module
10. BOOSTING CUSTOMER COMPETITIVENESS ENERGY SAVINGS AND POWER SUPPLY OPTIMIZATION Storing energy while braking Using stored energy during acceleration Energy savings up to 30% for light rail systems Boost to the vehicle’s speed when line current or engine power are limited Optimization of power supply Reduced infrastructure investment Catenary-free operation for short distances and as a part of the PRIMOVE solution also for longer distances ENERGY STORAGE DEVICE ENERGY STORAGE DEVICE
11. SUSTAINABLE COMMUTING FOR GREENER CITIES CATENARY-FREE OPERATION Technology based on inductive power principle which enables contact free operation Operation possible under any weather condition No risk of power loss due to contact break No danger of electric hazard as all electric devices are fully isolated
13. THE FUTURE OF E-MOBILITY PRIMOVE TECHNOLOGY CAN BE APPLIED TO ALL TYPES OF VEHICLES Unlimited mobility – Continuous contactless, inductive energy transfer combined with efficient on-board energy storage systems No recharging hassles – Both dynamic and static charging possible For all types of vehicles – The same infrastructure, which is compatible at high efficiency levels from 3 to 1,000 kW Zero emissions and low maintenance – No local emissions; no wear on parts and components due to contactless power transfer Safe, invisible and tamper-proof – Hidden underground; reliable in adverse weather and ground conditions; energy transfer only active when induction segment is completely covered by the vehicle
14. NANJING, HEXI AND QILIN TRAMWAY LINES CATENARY-FREE OPERATIONS
15. NANJING, HEXI AND QILIN TRAMWAY LINES CATENARY-FREE OPERATIONS
16. WAYSIDE ENERGY STORAGE TEMPORARY BRAKING ENERGY STORED IN SUPERCAPACITORS Simple interface No house power No communications connection Only connections to traction power
17. SUZHOU LRT LINE 1 CITYFLO 150 TRAIN CONTROL Accurate preemption Effective signal priority Faster tram speed Reduced CAPEX and OPEX Reduced road traffic impact
18. POINT CONTROLLER EBI LOCK 400 Route setting commands Center Control Room: from ATS via backbone network Train: from driver’s remote control command via train to wayside loop Local: from driver’s command via local wayside button Automatic route release after Train passing over Supports route cancelation Supports emergency route release Control point heaters
19. EBI Link wayside equipment EBI Com radio block centre EBI Track train detection EBI Light signals EBI Switch point machines EBI Screen control room EBI Star vehicle telematics EBI Gate level crossings EBI Drive driver assistance system EBI Lock computerised interlocking EBI Cab ATC onboard equipment EBI Tool design and maintenance RAIL CONTROL SOLUTIONS COMPLETE RANGE OF IN-HOUSE SIGNALLING PRODUCTS
20. DRIVER ASSISTANCE SYSTEM OPTICAL 3D SENSOR SYSTEM TO AVOID COLLISIONS Driver support in critical situations Increased active safety for passengers, drivers, pedestrians, cyclists Reduced collision follow-up costs for operator
21. TRAMWAYS: BACK TO ASIA Low-floor, fast, comfortable feeder to MRT Catenary-free aesthetic Sophisticated train control and road traffic optimisation Built as integrated systems
22. Q&A ? Joffrey Lauthier Head of Sales, Asia Pacific Bombardier Transportation | Rail Control Solutions 3354/16-19 Manorom Building, Rama IV Road Bangkok 10110, Thailand +66 843 879 589 joffrey.lauthier@rail.bombardier.com
