Maestro - UI testing framework

The talk was discussing the implementation of Maestro UI testing framework to address the challenge of time-consuming regression testing in the context of Android and iOS platforms.

This talk showcased how Maestro streamlined the regression testing process, enhancing efficiency and test coverage across platforms.

Transcript

1. Maestro 10 | 2023 © TRADE REPUBLIC BANK 2023 1
2. Topic Zhanibek Marshal Senior Engineer at Trade Republic © TRADE REPUBLIC BANK 2023 | Paparazzi: Snapshot testing made easy Hello again 👋 • Twitter: @megasuperhero • Mastodon: @zhanibek@androiddev.social • TR engineering blog: https://engineering.traderepublic.com/ 2
3. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 01. How we ended up to Maestro? Brief overview of the investigation objectives. 02. Integration of Maestro Explanation of the steps taken to integrate Maestro into Android project and iOS 03. Writing Test Case Flows Overview of the approach to writing test case flows using Maestro 04. Maestro Studio An overview of Maestro Studio, the integrated development environment (IDE) for creating Maestro test cases. 05. Maestro Cloud Introduction to Maestro Cloud, a platform for test execution and collaboration. 06. Learnings All views mine, no one else’s. 07. Q&A 3
4. How we ended up to Maestro? Brief overview of the investigation objectives. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 4
5. Our regression testing* started to take a lot of time on each release train *manual That's why we proposed Maestro as one of the options. “ © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 5
6. Topic We have over 100 test cases to verify before we deploy a new version © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 6
7. Then I heard* that Maestro is very simple and effective solution for writing UI tests *from colleagues and at Droidcon Berlin 23 “ © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 7
8. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 8
9. Integration of Maestro Explanation of the steps taken to integrate Maestro into Android project © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 9
10. Topic Run the following command to install Maestro on Mac OS, Linux or Windows (WSL) Install Maestro © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 10
11. Topic Will automatically detect and use any local emulator or physical* device. *USB connection has an issue[829] Run Maestro test © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 11
12. Topic Had to find a solution to resolve an One Time Password(OTP) on test environment Automatic OTP retriever © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 12
13. Topic Before running Flows on iOS Simulator*, install Facebook IDB tool *At the moment, Maestro does not support real iOS devices 🍎 iOS © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 13
14. Writing Test Case Flows Overview of the approach to writing test case flows using Maestro © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 14
15. Topic • launchApp • tapOn - tap on anything that visible on screen • inputText • runFlow - run commands from another file • takeScreenshot - saves a screenshot in a PNG file • assertVisible Common commands © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 15
16. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework Started from Login flow 16
17. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework appId: specify the application id to launch the application 17
18. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework appId: specify the application id to launchApp 18
19. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework tapOn: anything on a view 19
20. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework inputText: regardless of whether any text field is currently focused or not 20
21. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework env: 1. Supply env variable to test: $maestro test -e ... 2. Consume: —> 21
22. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework tapOn: id of the view* *not preferred option to consider a11y 22
23. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework assertVisible: same parameters as tapOn 23
24. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework runFlow: to avoid duplication of code and thereby modularize your Flow files 24
25. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework Then tried to check our new product Bond instrument “ 25
26. Topic Now you can write a test cases © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 26
27. Topic © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 27
28. Maestro Studio An overview of Maestro Studio, the integrated development environment (IDE) for creating Maestro test cases. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 28
29. Topic Run $maestro studio on command line © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 29
30. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 30
31. Maestro Cloud Introduction to Maestro Cloud, a platform for test execution and collaboration. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 31
32. Has Github Actions integration *need to grant an access to pull requests “ © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 32
33. Topic Running Github Action workflow © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 33
34. Cloud console Free $10.00 credit for each month to experiment the usage. “ © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 34
35. Cloud console Free $10.00 credit for each month to experiment the usage. “ © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 35
36. Topic © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 36
37. Topic Monthly Cost = (# of Uploads per Month) x (# of Flows) x ($0.10 USD) Monthly Cost = (2 + 30) x 100 x ($0.10 USD) Monthly Cost = $320 Pricing model © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 37
38. Learnings *All views mine, no one else’s © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 38
39. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 1: If we don’t rely on id and instead access by text Then we can run regression testing on both Android and iOS 39
40. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 2: If we don’t rely on id and instead access by text Then we can find many issues with a11y and improve them 40
41. Topic 41 © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework
42. © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 3: It’s really easy to write a regression test No extra setup required on a platform and everybody without knowledge of the platform can write them. 42
43. Q&A What do you think about it? © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework 43
44. Topic • Maestro documentation: https://maestro.mobile.dev/ • Maestro Cloud: https://cloud.mobile.dev/ • Pricing calculator: https://console.mobile.dev/pricing-calculator Related links 44 © TRADE REPUBLIC BANK 2023 |Maestro - UI testing framework
45. Topic Zhanibek Marshal Senior Engineer at Trade Republic © TRADE REPUBLIC BANK 2023 | Paparazzi: Snapshot testing made easy Hello again 👋 • Twitter: @megasuperhero • Mastodon: @zhanibek@androiddev.social • TR engineering blog: https://engineering.traderepublic.com/ 45
