  1. Demystifying  Gradle  DSL
    !
    !
    Kunal  Dabir
    1

    View Slide

  2. About  the  Talk
    • Prerequisites
    • Basic  understanding  of  build  systems
    • Some  exposure  to  Gradle
    • Beginner  level  of  exposure  to  Groovy/Java
    !
    • Takeaways
    • Learn  a  trick  or  two  to  read  and  write  DSLs
    • A  simpler  way  to  look  at  Gradle  Scripts
    2

    View Slide

  3. Introduction  (About  me)
    • Love  writing  code  in  Groovy,  Java,  Ruby,  Scala  and
    JavaScript  (CoffeeScript).
    • Work  at  ThoughtWorks
    • Co-­‐organizer  of  Pune  Java  User  Group
    • Projects  hosted  on  Github
    • (want  to  get  better  at)  running,  playing  drums  and
    writing  book
    3

    View Slide

  4. DSL  Intro
    Repeating  the  Cliché
    4

    View Slide

  5. Domain  Specific  Language
    • “A  Domain  Specific  Language  (DSL)  is  a  programming
    language  designed  specifically  to  express  solutions  to
    problems  in  a  specific  domain”
    !
    !
    !
    !
    !
    • http://c2.com/cgi/wiki?DomainSpecificLanguage
    • http://en.wikipedia.org/wiki/Domain-­‐specific_language
    5

    View Slide

  6. Example  of  DSL
    !
    create("my-­‐project")  {
       dir("src/main/java")  {
           file("Hello.java")  {
               """
        ………
               """.stripIndent()
           }
       }
       file  "build.gradle",  "apply  plugin:  'java'"
       file  "README.md",  "#  Hello  World  Project"
    }
    !
    !
    Directree:    https://github.com/kdabir/directree
    6

    View Slide

  7. Example  of  DSL
    !
    create("my-­‐project")  {
       dir("src/main/java")  {
           file("Hello.java")  {
               """
                   public  static  void  main(String[]  args){
                           System.out.println("Hello  World");
                   }
               """.stripIndent()
           }
       }
       file  "build.gradle",  "apply  plugin:  'java'"
       file  "README.md",  "#  Hello  World  Project"
    }
    Directree:    https://github.com/kdabir/directree
    7

    View Slide

  8. External  v/s  Internal  DSL
    • Internal
    • Sinatra
    • Ratpack
    • Gradle
    • MarkupBuilder
    !

    !
    !
    !
    !
    !
    !
    !
    !
    !
    !
    • External
    • Apache  httpd  config
    • Gherkin  (cucumber)
    • Make
    • Markdown
    !
    !
    !
    8

    View Slide

  9. External  v/s  Internal  DSL
    • Groovy  MarkupBuilder
    !
       builder.html  {
           body  {
               h1  "hello  MarkupBuilder"
           }
       }
    !
    • Markdown
    !
       #  hello  Markdown
    9

    View Slide

  10. Gradle  Intro
    A  build  tool  that  needs  no  Intro
    10

    View Slide

  11. Gradle  intro
    • an  advanced  build  system
    • follows  conventions
    • yet  very  flexible
    • Groovy  build  scripts
    • rich  domain  model  for  build
    • …  And  much  more
    11

    View Slide

  12. Follows  Conventions
    • Create  a  build.gradle  file  in  project  root  :
    !
       apply  plugin:  'java'
    !
    • A  valid  minimal  Java  project  build  file
    • It  can  build  a  Jar  of  project
    • Uses  conventional  src/main/java  for  source  files
    12

    View Slide

  13. Provides  Flexibility
    • For  example,  Changing  source  directories:
    !
       sourceSets  {
           main.java.srcDir  'src'
           test.java.srcDir  'test'
       }
    13

    View Slide

  14. Reuses  Existing  Infrastructure
    • Find  dependencies  in  MavenCentral
    !
       repositories  {
           mavenCentral()
       }
    !
    • And  use  them  in  your  project
    !
       dependencies  {
           compile  'org.slf4j:slf4j-­‐api:1.7.9'
           testCompile  'junit:junit:4.10'
       }
    14

    View Slide

  15. Supports  Adding  Extra  Behaviour
    • By  defining  custom  tasks
    !
       task  sayHello  <<  {
           println  "Hello  Gradle  users"
       }
    15

    View Slide

  16. Groovy  Recap
    Groovy  Just  Enough  For  Gradle  DSL
    16

    View Slide

  17. Lists
    • Defining
    !
           def  list  =  []

           list  =  [1,2,3]

    • Accessing
    !
           println  list[2]
    17

    View Slide

  18. Maps
    • Defining
    !
           def  map  =  [:]

           map  =  [a:4,  b:5]

    • Accessing
    !
           println  map.a

           println  map['b']
    18

    View Slide

  19. Closures
    • Declaring
    !
           def  closure  =  {}

           closure  =  {  println  "closure  is  powerful"}
    !
    • Calling
    !

         closure.call()

           closure()

           closure("groovy")
    19

    View Slide

  20. Closure  Parameters
    • Sometimes  it’s  magic
    !
           closure  =  {  println  "$it  is  powerful"}

           closure("groovy")
    !
           //  groovy  is  powerful

    • Multiple  parameters
    !
           def  adder  =  {a,b  -­‐>  a  +  b}

           println  adder(1,2)
    20

    View Slide

  21. Methods
    • Declaring  a  method  that  takes  a  Map
    !
           def  method(Map  options)  {
               def  a  =  options.a  ?:  10
               def  b  =  options.b  ?:  20
           }
    !
    21

    View Slide

  22. Methods
    • Calling
    !
           method([a:30,b:40])
       !
    • Can  also  be  called  like
    !
           method(a:30,  b:40)
       !
    • Optionally
    !
           method(a:20)
    22

    View Slide

  23. Methods
    • A  method  that  takes  a  Closure
    !
           def  repeat(int  a,  Closure  c)  {
               a.times  {  c.call()  }
           }
    23

    View Slide

  24. Methods
    • Calling
    !
           repeat(2,  {println  "fun  begins"})
    !
    • Can  also  be  called  like
    !
           repeat(2)  {
               println  "fun  begins"
           }
    24

    View Slide

  25. Putting  it  all  together
    makes  a  powerful  DSL  for  build  scripts
    25

    View Slide

  26. How  it  starts
    26

    View Slide

  27. How  it  starts
         apply  plugin:  'java'
    26

    View Slide

  28. How  it  starts
         apply  plugin:  'java'
         apply(plugin:  'java')
    26

    View Slide

  29. How  it  starts
         apply  plugin:  'java'
         apply(plugin:  'java')
         apply([plugin:  'java'])
    26

    View Slide

  30. How  it  starts
         apply  plugin:  'java'
         apply(plugin:  'java')
         apply([plugin:  'java'])
         project.apply([plugin:  'java'])
    26

    View Slide

  31. And  the  credit  goes  to…
    Project
    void apply(Map options)!
    Configures this project using plugins or scripts. The following options are available:
    !•! from: A script to apply to the project. Accepts any path supported by
    Project.uri().
    !•! plugin: The id or implementation class of the plugin to apply to the project.
    !•! to: The target delegate object or objects. Use this to configure objects other than the
    project.
    For more detail, see ObjectConfigurationAction.
    !
    • http://www.gradle.org/docs/current/dsl/
    org.gradle.api.Project.html#org.gradle.api.Project:apply(java.util.Map)
    27

    View Slide

  32. Project  API
    28

    View Slide

  33. Project  API
    • Central  API  to  the  Gradle  build  script
    • Available  as  ‘project’  reference  in  build  script
    • Build  Script  is  evaluated  against  the  instance  of  this
    project  object.
    • Available  implicitly  in  the  script  top  level*
    • methods/properties  are  looked  up  on  this  object
    by  default.
    • One  project  per  build.gradle
    29

    View Slide

  34. Project  Object
    • Properties
    void  setDescription(String  description)
    Sets  a  description  for  this  project.
    !
    • Methods
    boolean  delete(Object...  paths)
    Deletes  files  and  directories.
    !
    • Script  blocks
    void  dependencies(Closure  configureClosure)
    Configures  the  dependencies  for  this  project.
    30

    View Slide

  35. Project  Properties
    • Setting  project  properties  like  :
    !
       group  =  'org.example'
       version  =  '0.1'
       description  =  'An  awesome  groovy  library'
    !
    • Find  properties  declared  on  Project  API.
    • Make  sure  they  are  not  read-­‐only.
    31

    View Slide

  36. Project  Properties
    • Getters  and  Setters  on  project  object.
      getBuildDir()/setBuildDir(Object  path)
    • Can  be  set  using  groovy  property  notation
      buildDir  =  “…”
    !
    • Extra  properties
    • can  be  declared  using  ext  namespace.
      ext.myProp  =  “abc”
    • it  becomes  property  of  project
      println  project.myProp
    32

    View Slide

  37. Where  do  methods  come  from  ?
    !
    • Methods  defined  on  Project  itself
    • Find  those  in  Project  API  Documentation
    !
    • Methods  declared  in  the  build  file
    • def  myMethod  …
    33

    View Slide

  38. Where  do  methods  come  from  ?
    • Extension/Conventions  added  by  plugins
    • Plugins  can  add  more  methods  to  project
    • like  sourceSets  is  added  by  java  plugin
    !
    • Each  task  becomes  a  method  on  project
    • Each  task  name  becomes  a  method
    ! ! taskA { description = “some task” }!
    • so  that  task  can  be  easily  referenced  in  a  script
    !
    •  Methods  of  parent  project
    34

    View Slide

  39. Script  Blocks
    !
    repositories  {
       mavenCentral()
    }

    35

    View Slide

  40. Script  Blocks
    !
    repositories  {
       mavenCentral()
    }

    can  be  rewri`en  as:
    !
    project.repositories  ({
       mavenCentral()
    })
    36

    View Slide

  41. Script  Blocks
    • Special  methods
    • Takes  in  a  Closure  as  parameter
    • Delegates  to  a  special  Handler  whose  methods  are
    available  in  the  block’s  context
    !
    !
    !
    !
    !
    http://www.gradle.org/docs/current/dsl/org.gradle.api.Project.html#N1486F
    37

    View Slide

  42. Script  Blocks  -­‐  Example
    !
    repositories  {  …  }
    !
    • RepositoryHandler  Handles  the  methods  calls
    made  in  context  of  repositories  script  block
    • Methods  like
      mavenCentral()
      jcenter()
      ivy()
    !
    http://www.gradle.org/docs/current/dsl/org.gradle.api.artifacts.dsl.RepositoryHandler.html
    38

    View Slide

  43. Script  Blocks  -­‐  Another  Example
    !
    dependencies  {  …  }
    !
    • Delegates  to  DependencyHandler
    • Executes  the  closure  in  against  the
    DependenciesHandler
    • methods  like  compile,  testCompile
    !
    !
    http://www.gradle.org/docs/current/dsl/org.gradle.api.artifacts.dsl.DependencyHandler.html
    39

    View Slide

  44. Script  Blocks
    allprojects { }

    Configures this project and each of its sub-projects.

    !
    artifacts { }

    Configures the published artifacts for this project.

    !
    buildscript { }

    Configures the build script classpath for this project.

    !
    configurations { }

    Configures the dependency configurations for this project.

    !
    dependencies { }

    Configures the dependencies for this project.

    !
    repositories { }

    Configures the repositories for this project.

    !
    sourceSets { }

    Configures the source sets of this project.

    !
    subprojects { }

    Configures the sub-projects of this project.

    !
    publishing { }

    Configures the PublishingExtension added by the publishing plugin.

    40

    View Slide

  45. Task  API
    41

    View Slide

  46. Creating  Task  Objects
    • Project  works  as  a  Task  Factory
    • Project  has  overloaded  task  method
    • All  of  which  return  an  instance  of  Task
    42

    View Slide

  47. Creating  Task  Objects
    !
    task(String  name)
    !
    !
    task(String  name,  Closure  configureClosure)
    !
    !
    task(Map  args,  String  name)
    !
    !
    task(Map  args,  String  name,
                Closure  configureClosure)
    43

    View Slide

  48. Task  Action  -­‐  the  concise  way
    !
    !
    !
    task  sayHello  <<  {
       println  "Hello  Gradle  user"
    }
    44

    View Slide

  49. Task  Config
    !
    !
    !
    sayHello  {
       group  =  "my  tasks"
       description  =  "greets  user"
    }
    45

    View Slide

  50. Config  as  map
    !
    !
    !
    task  sayBye  (description  :  "says  bye",
                             group  :  "my  tasks")
    46

    View Slide

  51. Task  object’s  methods
    !
    !
    !
    sayBye.doLast  {
       println  "B-­‐bye"
    }
    !
    !
    !
    http://www.gradle.org/docs/current/javadoc/org/gradle/api/Task.html
    47

    View Slide

  52. Available  Tasks
    !
    !
    $  gradle  tasks
    …
    My  tasks  tasks
    -­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐
    sayBye  -­‐  says  bye
    sayHello  -­‐  greets  user
    48

    View Slide

  53. Execute  tasks
    !
    !
    $  gradle  sH  sB
    :sayHello
    Hello  Gradle  user
    :sayBye
    B-­‐bye
    !
    49

    View Slide

  54. Bookmark  These
    !
    • Read  the  DSL
    • http://www.gradle.org/docs/current/dsl/
    !
    !
    • Read  the  JavaDoc
    • http://www.gradle.org/docs/current/javadoc/
    50

    View Slide

  55. Questions
    Questions  are  guaranteed  in  life,  answers  aren’t  :-­‐)
    51

    View Slide

  56. Thank  You
    @kdabir
    https://github.com/kdabir
    52

    View Slide
