1. Red Hat JBoss Fuse Service Works Integration Recipes, Best Practices & Cheat Codes Keith Babo SwitchYard Project Lead, Red Hat Tuesday, April 22, 14
2. There is Still Time To Leave • We will be talking integration and SOA If your company has more than one application, this is likely relevant • Some background and overview Quick and painless • Main focus is using technology to solve problems Practitioner’s rejoice! • Lots of live demo Increased odds of crash and burn. Exciting! Tuesday, April 22, 14
3. Key • Integration Recipe Using features of the platform to get things done • Best Practice The right way to use a feature • Cheat Code Maybe not right, but fun Tuesday, April 22, 14
4. Format 10 OVERVIEW 20 RECIPE 30 BEST PRACTICE 40 CHEAT CODE 50 GOTO 20 Tuesday, April 22, 14
5. Recipes • Application Development • Implementation strategy • Testing • Connectivity • Dealing with data • Deployment & Packaging • Debugging Tuesday, April 22, 14
6. First a bit of background ... Tuesday, April 22, 14
7. Fuse Service Works 7 Enterprise Messaging JMS/STOMP/NMS/MQTT JBoss HornetQ & Apache Active-MQ Overlord RTGov Integration & Connectivity Transformation, Mediation, Enterprise Integration Patterns Apache Camel Drools Decision Management Declarative, inference rule execution JBoss EAP/Karaf Enterprise Container Secure and manageable jBPM & Riftsaw Service Orchestration Orchestrate service calls and automate processing JBoss SwitchYard Service and Integration Framework (SCA) lightweight framework to simplify development of service-oriented applications JBoss Overlord - DTGov Design Time Governance Lifecycle management, Release workflow & Repository Runtime Governance SLA Management Synchronous & Asynchronous Policy Enforcement Transaction & Service Monitoring Development Tooling Develop, test, debug, refine and deploy. Operational Management Performance & Availability Monitoring Alerting Inventory Management JBoss Developer Studio JBoss Operations Network Tuesday, April 22, 14
8. SwitchYard Structured development framework for integration applications Built on Apache Camel and Java EE Using service-oriented principles to build scalable, maintainable applications Tuesday, April 22, 14
9. Integration is Complex Message Content Based Router Message Translator Content FIlter Aggregator Messaging Gateway Message Store @WebService public class MyFancyBean { @Resource(mappedName = "jms/ConnectionFactory") private static ConnectionFactory cf; @WebMethod public void send(String msg) { } } Message Endpoint Message Endpoint Message Endpoint Tuesday, April 22, 14
10. SOA Brings Structure Tuesday, April 22, 14
11. Structured Development Tuesday, April 22, 14
12. Structured Development Tuesday, April 22, 14
13. Structured Development Tuesday, April 22, 14
14. Structured Development Tuesday, April 22, 14
15. Structured Development Tuesday, April 22, 14
16. Structured Development Tuesday, April 22, 14
17. SOA Brings Structure Message Content Based Router Message Translator Content FIlter Aggregator Messaging Gateway Message Store @WebService public class MyFancyBean { @Resource(mappedName = "jms/ConnectionFactory") private static Message Endpoint Message Endpoint Message Endpoint Tuesday, April 22, 14
18. Recipe : Application Development • Best Practices • Let the editor do its thing • Stick to your development style • Service partitioning • Cheat Codes • The button bar Tuesday, April 22, 14
19. Best Practice: Let the Editor Do Its Thing • Manages application metadata so you don’t have to • It’s not evil • Suitable for beginners and experts alike Tuesday, April 22, 14
20. SwitchYard Metadata Tuesday, April 22, 14
21. Maven Metadata Tuesday, April 22, 14
22. Best Practice: Stick To Your Development Style Top-down Tuesday, April 22, 14
23. Best Practice: Stick To Your Development Style Bottom-up Tuesday, April 22, 14
24. Best Practice: Stick To Your Development Style Meet-in-the-middle Tuesday, April 22, 14
25. Best Practice: Service Partitioning • Number of services per application • Heuristics Lifecycle Change management Distribution Reason Tuesday, April 22, 14
26. Cheat Code: The Button Bar • Context-sensitive action • Available on all nodes • Fast • Great way to learn what’s possible Tuesday, April 22, 14
27. DEMO Tuesday, April 22, 14
28. Recipe : Implementation Strategy • Best Practices • Right tool for the right job • Use service abstraction to your advantage • Beans, beans the magical fruit • Cheat Codes • Fungible implementations Tuesday, April 22, 14
29. Best Practice: Right Tool for the Job  CDI Bean POJO, Java EE, easy to implement  Camel Routing, pipeline orchestration, EIPs  Rules Declarative, decision-oriented Tuesday, April 22, 14
30. Best Practice: Right Tool for the Job  BPMN 2 Understandable to business users, stateful, long-lived  BPEL Web service orchestration, existing BPEL experience Tuesday, April 22, 14
31. Best Practice: Use Service Abstraction to Your Advantage • Invoke services by contract using a service reference • Loose coupling • Binding abstraction • Implementation hiding Tuesday, April 22, 14
32. Service Abstraction - CDI @WebService public class OrderService { @Resource(mappedName = "jms/ConnectionFactory") private static ConnectionFactory cf; @WebMethod public void submit(String msg) { // create JMS session, lookup destination, // etc., etc. } } Tuesday, April 22, 14
33. Service Abstraction - CDI @Service(OrderService.class) public class OrderServiceBean implements OrderService { @Inject @Reference private InventoryService inventory; public void submit(Order order) { // check inventory level Item item = inventory.getItem(order.getItemId()); } } Tuesday, April 22, 14
34. Service Abstraction - Camel <route xmlns="http://camel.apache.org/schema/spring"> <from uri="file://tmp/inbound"/> <to uri="direct://DestinationService"/> <choice> <when> <simple>${body.destination} == 'Red'</simple> <to uri="jms://queue:RedQueue"/> </when> <when> <simple>${body.destination} == 'Green'</simple> <to uri="vm://GreenService"/> </when> <when> <simple>${body.destination} == 'Blue'</simple> <to uri="cxf:bean:BlueWebService"/> </when> <otherwise> <log message="Unknown Destination!"/> </otherwise> </choice> </route> Tuesday, April 22, 14
35. Service Abstraction - Camel <route xmlns="http://camel.apache.org/schema/spring"> <from uri="switchyard://RoutingService"/> <to uri="switchyard://DestinationService"/> <choice> <when> <simple>${body.destination} == 'Red'</simple> <to uri="switchyard://RedService"/> </when> <when> <simple>${body.destination} == 'Green'</simple> <to uri="switchyard://GreenService"/> </when> <when> <simple>${body.destination} == 'Blue'</simple> <to uri="switchyard://BlueService"/> </when> <otherwise> <log message="Unknown Destination!"/> </otherwise> </choice> </route> Tuesday, April 22, 14
36. Local Reference Tuesday, April 22, 14
37. Remote Reference Tuesday, April 22, 14
38. Best Practice: Beans, Beans the Magical Fruit vs. Tuesday, April 22, 14
39. Camel Beans • Invoke CDI Beans directly from Camel when Logic is small and localized to the service implementation Access to Camel APIs or features is desirable Camel-specific configuration is required (e.g. Netty encoder) Tuesday, April 22, 14
40. Bean Services • Use Bean Services when Logic may be exposed as a service now or in the future Access to Java EE facilities is desirable (e.g. resource injection) Bean will invoke other services (local or remote) Tuesday, April 22, 14
41. Cheat Code: Fungible Implementations Tuesday, April 22, 14
42. Cheat Code: Fungible Implementations Tuesday, April 22, 14
43. Cheat Code: Fungible Implementations Tuesday, April 22, 14
44. Cheat Code: Fungible Implementations Tuesday, April 22, 14
45. DEMO Tuesday, April 22, 14
46. Recipe : Testing • Best Practices • Test every service • Isolate dependencies • Test application boundaries • Cheat Codes • Test kit spelunking Tuesday, April 22, 14
47. Best Practice: Test Every Service Tuesday, April 22, 14
48. Best Practice: Isolate Dependencies Tuesday, April 22, 14
49. Best Practice: Test Application Boundaries Tuesday, April 22, 14
50. Cheat Code: Test Kit Spelunking • SwitchYardTestKit • Invoker • MixIns • SwitchYardTestCaseConfig Tuesday, April 22, 14
51. Recipe : Connectivity • Best Practices • Don’t couple contract and binding • Promotion is *:1 • Cheat Codes • Extensions Tuesday, April 22, 14
52. Best Practice: Don’t Couple Contract and Binding Tuesday, April 22, 14
53. Best Practice: Promotion is 1:* • Component services can be promoted multiple times • Only needed when the contracts are different • Multiple bindings per composite service Tuesday, April 22, 14
54. Cheat Code: Extensions Tuesday, April 22, 14
55. Cheat Code: Extensions • Camel components not included directly in SwitchYard • Fuse • Custom • Using extensions • Create module(s) • Runtime registration • Configure via Camel URI gateway Tuesday, April 22, 14
56. Creating Modules • mvn dependency:tree • module.xml • jboss-eap-6.1/modules Tuesday, April 22, 14
57. Runtime Registration jboss-eap-6.1/standalone/configuration/standalone.xml Tuesday, April 22, 14
58. Camel URI Binding Tuesday, April 22, 14
59. DEMO Tuesday, April 22, 14
60. Recipe : Dealing with Data • Best Practices • Address cross-cutting concerns declaratively • Leverage multi-hop transformation Tuesday, April 22, 14
61. Best Practice: Address Cross-Cutting Concerns Declaratively • Favor declarative over procedural transformation • Procedural transformation is still legit Tuesday, April 22, 14
62. Procedural Tuesday, April 22, 14
63. Procedural in BPM Tuesday, April 22, 14
64. Procedural in Camel public class ExampleRoute extends RouteBuilder { public void configure() { from("switchyard://OrderIntake") // validate against XSD .to("validator:orderSchema.xsd") .choice() .when(header("service").equals("ABC")) // data format XML -> Java .unmarshal("JAXBOrderBinding") .to("switchyard://ABCService") .otherwise() // invoke XSL transformation on content .to("xslt:formatRegion.xsl") .to("switchyard://XYZService"); } } Tuesday, April 22, 14
65. Declarative Tuesday, April 22, 14
66. Camel with Declarative public class ExampleRoute extends RouteBuilder { public void configure() { from("switchyard://OrderIntake") .choice() .when(header("service").equals("ABC")) .to(switchyard://ABCService") .otherwise() .to("switchyard://XYZService"); } } Tuesday, April 22, 14
67. Declarative Transformation @Transformer(from = "{urn:switchyard-example:orders:1.0}submitOrder") public Order transform(Element from) { return new Order() .setOrderId(getElementValue(from, "orderId”)) .setItemId(getElementValue(from, "itemId”)) .setQuantity(Integer.valueOf(getElementValue(from, "quantity”))); } Tuesday, April 22, 14
68. Declarative Validation <validate.xml schemaType="XMLSCHEMA" name="{urn:example:purchasing}order" schemaFile="xsd/order.xsd"/> Tuesday, April 22, 14
69. Hybrid Tuesday, April 22, 14
70. Best Practice: Leverage Multi-Hop Transformation A B C transform1 transform2 A C Tuesday, April 22, 14
71. Recipe : Deployment & Packaging • Best Practices • JAR deployment • WAR deployment • EAR deployment Tuesday, April 22, 14
72. Best Practice: JAR Deployment • Default and easy • No embedded libraries • No embedded resources Tuesday, April 22, 14
73. Best Practice: WAR Deployment • Embedded libraries • Embedded resources • Isolated class loading • Web stuff • Packaging can bite you Tuesday, April 22, 14
74. Best Practice: EAR Deployment • Multiple applications • Inter-application communication with SCA binding • Embedded resources • Coordinated lifecycle • Assembly outside of SY tooling Tuesday, April 22, 14
75. Recipe : Debugging • Best Practices • Message Tracing • ExchangeInterceptors • Auditing • Choosing the right tool • Cheat Codes • SwitchYard Debugger Tuesday, April 22, 14
76. Message Tracing Tuesday, April 22, 14
77. Exchange Interceptors @Named("UpdateStatus") public class OrderInterceptor implements ExchangeInterceptor { @Override public void before(String target, Exchange exchange) throws HandlerException { // do something before the invocation } @Override public void after(String target, Exchange exchange) throws HandlerException { // do something after the invocation } @Override public List<String> getTargets() { return Arrays.asList(PROVIDER); } } Tuesday, April 22, 14
78. Exchange Interceptors 1 2 3 4 1. CONSUMER.before() 2. PROVIDER.before() 3. PROVIDER.after() 4. CONSUMER.after() Tuesday, April 22, 14
79. Auditors @Audit @Named("custom auditor") public class SimpleAuditor implements Auditor { @Override public void beforeCall( Processors processor, Exchange exchange) { } @Override public void afterCall( Processors processor, Exchange exchange) { } } Tuesday, April 22, 14
80. Debugger Tuesday, April 22, 14
81. Choosing the Right Tool • MessageTrace Suitable for dev and runtime Convenient Static • ExchangeInterceptor Useful for more than just debugging Customizable Requires coding Tuesday, April 22, 14
82. Choosing the Right Tool • Auditors Suitable for dev only! Super low-level • Debugger Suitable for dev and runtime Isolation Interruption Tuesday, April 22, 14
83. DEMO Tuesday, April 22, 14
84. Questions? Tuesday, April 22, 14
