  1. @lcolladotor
    lcolladotor.github.io
    lcolladotor.github.io/bioc_team_ds
    Applying Visium Spatial
    Proteogenomics (Visium-SPG) to
    study Alzheimer’s Disease
    Leonardo Collado Torres #Visium_SPG_AD
    May 17th 2023
    #GBD23
    Slides available at speakerdeck.com/lcolladotor

    View Slide

  2. twitter.com/sanghokwon17/status/1650589385379962881 from 2023-04-24
    Sang Ho Kwon
    @sanghokwon17
    DOI: 10.1101/2023.04.20.537710
    #Visium_SPG_AD

    View Slide

  3. DOI: 10.1038/s41593-020-00787-0
    twitter.com/lcolladotor/status/1233661576433061888 from 2020-02-29

    View Slide

  4. DOI: 10.1038/s41593-020-00787-0
    twitter.com/lcolladotor/status/1233661576433061888 from 2020-02-29
    DOI 10.1093/bioinformatics/btac299
    Since Feb 2020
    spatialLIBD::fetch_data()
    provides access to
    SpatialExperiment
    R/Bioconductor objects

    View Slide

  5. DOI: 10.1038/s41593-020-00787-0
    twitter.com/lcolladotor/status/1233661576433061888 from 2020-02-29
    twitter.com/CrowellHL/status/1597579271945715717
    DOI 10.1093/bioinformatics/btac299
    Since Feb 2020
    spatialLIBD::fetch_data()
    provides access to
    SpatialExperiment
    R/Bioconductor objects

    View Slide

  6. Visium spatial clustering works for variables with high %
    variance explained. But what about other ones?
    DOI: 10.1038/s41593-020-00787-0

    View Slide

  7. Alzheimer’s disease related neuropathology
    Adopted and modified from B Wang (2018) and the Brain from the Top to Bottom in McGill University
    20 um
    Sang Ho Kwon
    Amyloid beta
    pTau

    View Slide

  8. Hypothesis
    Local tissue microenvironments in close proximity to AD-related
    neuropathology have distinct cellular and molecular signatures. Sang Ho Kwon

    View Slide

  9. Visium Spatial Proteogenomics (Visium-SPG)
    Visium-SPG = Visium SRT + immunofluorescence
    (using identical tissue samples)
    Sang Ho Kwon

    View Slide

  10. Experimental design & study overview
    Braak V-VI & CERAD frequent
    Sang Ho Kwon

    View Slide

  11. AD pathology signal is too small to detect by
    spatially-resolved gene expression alone research.libd.org/Visium_SPG_AD/

    View Slide

  12. Visium
    * ~5k spots in honeycomb
    * gene expression per spot
    * tissue (H&E staining)
    Immunofluorescence (IF)
    * multi-channel (6) images
    * identifies morphological features of interest
    * large: might be broken in tiles
    Channel 1
    * triangle feature
    Channel 2
    * cloud feature
    Channel 6
    * xyz feature
    Tissue (bright field image)
    Visium spot
    Channel 1 feature
    Channel 2 feature
    +
    Visium Spatial Proteogenomics (Visium-SPG / IF) raw data: 2 types

    View Slide

  13. Spot ID Gene 1 Gene 2 Gene X
    spot0001 0 12 39
    spot0002 4 0 27
    Spot ID Gene 1 Gene 2 Gene X In Tissue # cells
    spot0001 0 12 39 true 3
    spot0002 4 0 27 false 0
    * spaceranger
    * Loupe Browser
    * VistoSeg on H&E bright
    field image
    Visium Analysis
    @MadhaviTippani
    @HeenaDivecha
    cell
    VistoSeg DOI:
    10.1101/2021.08.04.452489

    View Slide

  14. Feature ID X center Y center type intensity
    feat0001 5 102 triangle 130.4
    feat0002 10 30 cloud 99.1
    Max (X, Y)
    Min (X, Y)
    Area
    ...
    SPG / IF Image Analysis
    * segment each
    channel
    * find features
    Challenges:
    * morphological
    features can be
    quite diverse
    * images are large
    * multiple tiles
    +

    View Slide

  15. Spot ID # Triangle # Cloud % triangle % cloud
    spot0001 0 12 0 17
    spot0002 4 0 27 0
    Merge Visium & IF
    IF
    Spot ID Gene 1 Gene 2 Gene X In Tissue # cells
    spot0001 0 12 39 true 3
    spot0002 4 0 27 false 0
    Visium
    downstream
    * QC
    * analyses
    spatialLIBD DOI:
    10.1186/s12864-022-08601-w
    VistoSeg DOI:
    10.1101/2021.08.04.452489
    Check version 2!!
    @MadhaviTippani

    View Slide

  16. Estimating pathological burden per spot
    to generate transcriptome-scale maps of AD pathology

    View Slide

  17. Identifying transcriptional signatures of AD-related neuropathology
    Principal component analysis
    Sang Ho Kwon

    View Slide

  18. Identifying transcriptional signatures of Abeta-related neuropathology
    Sang Ho Kwon

    View Slide

  19. Validation study design using RNAscope FISH-IF
    Sang Ho Kwon

    View Slide

  20. bioconductor.org/packages/spatialLIBD
    Pardo et al, 2022 DOI 10.1186/s12864-022-08601-w
    Maynard, Collado-Torres, 2021 DOI 10.1038/s41593-020-00787-0
    Brenda Pardo Abby Spangler
    @PardoBree @abspangler
    Louise A. Huuki-Myers
    @lahuuki
    Check her #GDB2023
    poster for more!
    Session 1: #7

    View Slide

  21. Conclusions
    • Visium-SPG can identify local transcriptional signatures of late-stage AD pathology
    • RNAscope FISH-IF can further explore spatial gene expression patterns of a few select
    features
    • Proof-of-concept study: our work lays the groundwork. Can now use Visium-SPG for other
    diseases too
    • Future studies are needed to produce mechanistic insights
    • Explore our code & data at research.libd.org/Visium_SPG_AD & download it with
    spatialLIBD::fetch_data()
    ○ There’s lots more to explore with this data!
    Sang Ho Kwon
    Slide adapted from:

    View Slide

  22. Contributors for this project
    Investigation
    Data analysis
    Mentorship
    Web resources
    Sang Ho Kwon
    @sanghokwon17
    #Visium_SPG_AD
    In collaboration with
    Slides available at
    speakerdeck.com
    /lcolladotor
    Download data with
    spatialLIBD::fetch_data()
    Madhavi Tippani
    Keri Martinowich Kristen Maynard
    Sowmya Parthiban Jashandeep Lobana
    Stephanie Hicks Stephanie Page
    Heena Divecha
    Nicholas Eagles

    View Slide

  23. View Slide

  24. Identifying transcriptional signatures of Abeta microenvironment
    VS
    Neural plasticity*
    Previously not significant
    Sang Ho Kwon

    View Slide

  25. 6 Abeta-associated DEGs on RNAscope FISH-IF
    (Kruskal-Wallis test,
    *p<0.05, &p<0.005, and #p<0.0001)
    Sang Ho Kwon

    View Slide

  26. Visium + RNAscope
    to provide additional insights into spatial gene expression gradients
    Sang Ho Kwon

    View Slide
