SVG para leigos do vetor à animação
Lívia Amorim UI Developer na Resultados Digitais liviamorim liviavamorim
SOBRE SVG NA PRÁTICA ANIMAÇÃO
1. Sobre SVG
“Linguagem XML para descrever de forma vetorial desenhos e gráficos
bidimensionais, de forma estática, dinâmica ou animada.” http://pt.wikipedia.org/wiki/SVG
<svg height="100" width="100"> <circle cx="50" cy="50" r="40" stroke="#573b5d" stroke-width="3" fill="#7e5686"
/> Isto é um fallback dizendo que o browser não suporta SVG inline. </svg>
None
1998 SVG Begins 2001 Adobe SVG Viewer 3 2005 Adobe
adopts Flash 2008 Apple blocks flash 2012 Android 2010 IE9 2011 Retina 2014 Today Poucos Muitos Evolução do SVG por Doug Schepers
Mas por que?
Acessibilidade
Responsividade
Retina Display
Agilidade
Mas tem o Canvas!
<canvas id="meow"> Isto é um fallback dizendo que o browser
não suporta a tag Canvas </canvas> <script> var a_canvas = document.getElementById("meow"), context = a_canvas.getContext("2d"); context.fillStyle = "#7e5686"; context.fillRect(0, 0, 80, 100); </script>
Canvas SVG JavaScript XML Sem manipulação via DOM Manipulação via
DOM “Mais” performático “Menos” performático Não é acessível Acessível
2. Na prática
<svg height="100" width="100"> Isto é um fallback dizendo que o
browser não suporta SVG inline. </svg>
100px 100px 100px 100px
Elemento <rect>
<svg height="100" width="100"> <rect height="100" width="100" fill="#7e5686" /> Isto é
um fallback dizendo que o browser não suporta SVG inline. </svg>
100px 100px 100px 100px
E se eu quiser posicionar o retângulo na tela?
Y 100px X 100px Y 100px X 100px
Sabe matemática?
Y=10 X=5
Y=10 X=5
Um ponto é a intersecção de duas retas
Y=10 X=5
<svg height="100" width="100"> <rect x="5" y="10" height="20" width="20" fill="#7e5686" />
Isto é um fallback dizendo que o browser não suporta SVG inline. </svg>
Y=10 X=5
Elemento <text> Meow meow meow
<svg height="100" width="100"> <text x="20" y="0" fill="#7e5686">Meow meow meow</text> Isto
é um fallback dizendo que o browser não suporta SVG inline. </svg>
Y X Meow meow meow
Elemento <circle>
<svg height="100" width="100"> <circle cx="50" cy="50" r="50" fill="#7e5686" /> Isto
é um fallback dizendo que o browser não suporta SVG inline. </svg>
R 50px CY 50px CX 50px
Elemento <ellipse>
<svg height="100" width="100"> <ellipse cx="100" cy="50" ry="50" rx="100" /> Isto
é um fallback dizendo que o browser não suporta SVG inline. </svg>
RY 50px CY 50px CX 50px RX 100px
Elemento <line>
<svg height="100" width="100"> <line x1="0" y1="0" x2="100" y2="100" stroke="#7e5686" />
Isto é um fallback dizendo que o browser não suporta SVG inline. </svg>
Y1 0px X1 0px Y2 100px X2 100px
Elemento <polygon>
<svg height="100" width="100"> <polygon points="50,5 20,99 95,39 5,39 80,99" fill="#7e5686"
/> Isto é um fallback dizendo que o browser não suporta SVG inline. </svg>
<svg height="100" width="100"> <polygon points=" X,Y 20,99 95,39 5,39 80,99"
fill="#a5aad9" /> </svg>
Y X
Elemento <polyline>
Elemento <path>
<svg height="100" width="100"> <path d=" D X,Y" fill="#a5aad9" /> </svg>
M L H V C S Q T A Z
Move to X,Y Line to X,Y Horizontal line to X,Y Vertical line to X,Y Curve to X,Y Smooth curve to X,Y Quadratic Bézier curve to X,Y Smooth quadratic Bézier curve to X,Y Elliptical Arc Close path Direções
Dica Amiga
E o CSS?
<svg height="100" width="100"> <circle cx="50" cy="50" r="40" style="fill: #7e5686; stroke:
#573b5d; stroke- width: 3;" /> Isto é um fallback dizendo que o browser não suporta SVG inline. </svg>
<svg height="100" width="100"> <circle cx="50" cy="50" r="40" class="myCircle" /> Isto
é um fallback dizendo que o browser não suporta SVG inline. </svg> <style> .myCircle { fill: #7e5686; stroke: #573b5d; stroke-width: 3; } </style>
border-color stroke
border-width stroke-width
background-color fill
3. Animação
None
<!DOCTYPE html> <html lang="pt-BR"> <head> <meta charset="UTF-8"> <title>Exemplo lindão</title> <script
src="js/snap.svg.js"></script> <script src="js/meu-js.js"></script> </head> <body> <svg id="svg"></svg> </body> </html>
var s = Snap("#svg"), bigCircle = s.circle(150, 150, 100); bigCircle.attr({
fill: "#bada55", stroke: "#000", strokeWidth: 5 }); bigCircle.animate({r: 50}, 1000);
None
None
None
Obrigada!
