  1. Offlinefähige Progressive Web Apps
    Immer & überall
    Thomas Hilzendegen
    @hilzendegent
    Consultant
    Manuel Rauber
    @ManuelRauber
    Consultant

    View full-size slide

  2. Thomas Hilzendegen
    Speakers
    Manuel Rauber
    [email protected]
    @hilzendegent
    [email protected]
    @manuelrauber
    https://manuel-rauber.com
    Microsoft MVP

    View full-size slide

  3. Timetable
    Time Doing
    09:00 - 10:30 Part I
    10:30 - 11:00 ☕
    11:00 - 12:30 Part II
    12:30 - 13:30
    13:30 - 15:00 Part III
    15:00 - 15:30 ☕
    15:30 - 17:00 Part IV

    View full-size slide

  4. • Progressive Web App
    • Offline availability
    • Offline synchronization
    • Change tracking
    • Security considerations
    • Pitfalls
    Agenda

    View full-size slide

  5. Offline… but why?

    View full-size slide

  6. • Just because the phone has a connection,

    e.g. Edge, it does not mean we are online
    • Depends on the use case which connection

    quality is required to determine, if the

    app is reliable online
    • Connection quality could be measured

    by the time an exclusive request takes
    • Duration < 150 ms: online
    • Duration !>=150 ms: bad connection
    What does “offline” mean?

    View full-size slide

  7. • A lot of reasons to be offline
    • Traveling, Train, Flights (bad or no signal)
    • Server is not available
    • Routing problems
    • Roaming
    • Costs
    Motivation

    View full-size slide

  8. Demo Application

    View full-size slide

  9. • A little application to manage boardgames
    • Angular, .NET Core, MS SQL Server
    • Brownfield application, started as a pure online application
    • As typical for any good demo: no security
    • Available on Azure: https://tt-boardist.azurewebsites.net
    • GitHub: https://github.com/thinktecture/thinktecture-boardist
    Demo Application “Thinktecture Boardist”

    View full-size slide

  10. Demo Application Database Scheme

    View full-size slide

  11. Now let’s go offline!

    View full-size slide

  12. Does it work in flight mode?
    NOPE!

    View full-size slide

  13. Progressive Web App

    View full-size slide

  14. • Motivation: Get rid of app stores!
    • Web App = App App
    • Support native features like: Push notifications,
    offline availability, installable
    • Backwards-compatibility: runs in non-PWA
    browsers, with a reduced feature set
    Progressive Web App

    View full-size slide

  15. PWA Technology Overview
    Progressive Web Apps
    HTML5, JavaScript, CSS3
    Service Worker API Web App Manifest HTTPS
    Fetch API
    Web
    Notifications
    Web
    Workers
    Push API

    View full-size slide

  16. PWA Platform Support
    40 44 11.1 17 4.1 11.3

    View full-size slide

  17. Progressive Web App

    is not a technology,

    but a collection of features an
    application must/should support

    View full-size slide

  18. PWA Collection of Features
    Responsive Linkable Discoverable Installable App-Like
    Connectivity

    Independent
    Fresh Safe Re-engageable Progressive

    View full-size slide

  19. • A JavaScript running in its own thread
    • No access to the DOM
    • Communicates via postMessage-API
    • Acts as a controller/proxy/interceptor
    • Can perform background tasks
    • Has to be installed before usage
    • Runs whenever the browser is running
    PWA ServiceWorker

    View full-size slide

  20. PWA ServiceWorker
    Website Internet
    Cache Service
    Worker

    View full-size slide

  21. PWA ServiceWorker Lifecycle
    Parse Installing
    Error
    Activated Idle Terminated
    fetch/message

    View full-size slide

  22. PWA Connectivity Independent
    Website Internet
    Cache storage
    Server
    Remote storage
    ServiceWorker

    View full-size slide

  23. • Cache only
    • Network only
    • Cache falling back to network
    • Cache & network race
    • Network falling back to cache
    • Cache then network
    • Generic fallback
    • ServiceWorker-side templating
    PWA Caching Strategies

    View full-size slide

  24. PWA Cache Then Network
    Website Internet
    Cache storage
    Server
    Remote storage
    ServiceWorker
    HTTP
    1. Lookup
    2. fetch
    1. Lookup

    View full-size slide

  25. • “One-size-fits-all” ServiceWorker implementation
    • Instrumented via ngsw-config.json
    • Restricted feature set (e.g. no communication between app and SW)
    • Initial caching of static content
    • Caching external content
    • Dynamic data caching
    • Push notifications
    PWA Angular ServiceWorker

    View full-size slide

  26. Does it work offline now?
    STILL NOPE!

    View full-size slide

  27. Real offline availability

    View full-size slide

  28. • ServiceWorker is only able to take data offline which has been requested by
    the application
    • If all the URLs are known beforehand, the ServiceWorker could cache them
    all
    • Data which was not requested, is not available offline (no real offline
    synchronisation)
    • But what about … the Background Sync API?
    What’s the problem?

    View full-size slide

  29. • Name is misleading
    • Does not offer any data synchronisation possibilities
    • Just raises an event periodically or after a delay (optionally based on the
    network type)
    • It’s totally up to the developer what to do in the onsync event
    • Since the sync is done in the ServiceWorker, the page can be closed, the
    sync will be fulfilled anyway
    • It does not help anything with syncing your actual data!
    Background Sync API

    View full-size slide

  30. Background Sync API

    View full-size slide

  31. • Cookies (not meant for large data or binaries)
    • Web Storage like session storage or local storage (not meant for large data
    or binaries)
    • IndexedDB
    • Cache Storage (based on request/response)
    Storage capabilities

    View full-size slide

  32. User can clear anything
    at any time by
    “Remove temporary internet files”
    or “Clear website data”

    View full-size slide

  33. • Key-value database of the browser
    • Stores data permanently
    • ServiceWorker and Web App share access to the same IndexedDB
    • Possibility of scenarios, where the ServiceWorker (or Web App) stores
    synchronised data in the IndexedDB and the Web App reads the data
    • Like everything based on the origin
    IndexedDB

    View full-size slide

  34. IndexedDB Availability

    View full-size slide

  35. • The standard API of IndexedDB is inconvenient to use (lots of callback)
    • Dexie.js is a minimalistic wrapper for IndexedDB
    • Operations are promise-based
    • Near native performance (even for bulk inserts)
    • Open Source @ GitHub: https://github.com/dfahlander/Dexie.js
    IndexedDB API

    View full-size slide

  36. Offline Sync

    View full-size slide

  37. • Offline Sync means to download all data available to client into a persistent
    offline storage, without the user having to explicitly request the data
    • Depending on the scenario, client can do CRUD on the offline data
    • Data will be synced back to the server, whenever a connection is possible
    Offline Sync Basics

    View full-size slide

  38. • Online/offline recognition
    • Conflict management
    • Binary data
    • Local changes
    • Deleting data
    • Update interval (incoming new data)
    • Error handling
    • Primary key generation
    Offline Sync Challenges

    View full-size slide

  39. • Having Edge may not mean that we are online
    • Being online could depend on several factors
    • Connection quality (Edge, 3G, 4G, 5G)
    • Connection speed (latency to your backend)
    • Reachability of backend systems (database, 3rd party system, storages)
    Offline Sync Challenges - Online/offline recognition

    View full-size slide

  40. • Client needs to be online for write operations
    • Locks the data, so no other client can overwrite it
    • Data stays locked, until the client either saves or discards changes
    • Last One (Write) Wins
    • Visual conflict management (diffing like in Git, SVN, etc.)
    Offline Sync Challenges - Conflict management

    View full-size slide

  41. • Downloading large binary data may not be possible on all platforms
    • A browser does not have a big enough storage for storing the data
    • Native apps (Cordova, Electron) could be a solution to directly access the
    platform’s file system
    • Uploading large binary data
    • Server needs to support chunk based upload with connection interruptions
    • Client needs permanent access to the binary file being uploaded, which
    could be hard in a browser-only scenario
    Offline Sync Challenges - Binary data

    View full-size slide

  42. • User opens an edit form and makes changes to data
    • Incoming sync from server would change the data the user is editing
    • Depending on your use-case, decide what to do
    • Inform the user about the data change?
    • Show a visual diff?
    • Override the local changed data?
    • “Do nothing” and override the server data on next sync
    Offline Sync Challenges - Local changes

    View full-size slide

  43. • Mark “deleted” data with a flag only
    • Use a trigger to keep the deleted ID in a separate table
    • Client needs some info about “deleted” data
    • Simple list of IDs “deleted” since the last sync
    Offline Sync Challenges - Deleting data

    View full-size slide

  44. • Decide when you need to sync which data
    • Not all data needs to be synced in the same interval
    • An additional real time connection (WebSocket) could be established
    • The server can send a signal when some data needs to be synchronised
    Offline Sync Challenges - Update interval

    View full-size slide

  45. • Show it, don’t hide them!
    • The user needs to know that something has occurred which shouldn’t
    • If you can’t sync to the client anymore, you may need to re-sync everything
    • Depending on your use case, you may want to write all data in one
    transaction on the server to not have partial data written into the database
    Offline Sync Challenges - Error handling

    View full-size slide

  46. Primary key generation

    View full-size slide

  47. • Inserted offline data needs to be available in the client immediately (e.g. the
    users reloads the application)
    • Behaves like “real synced data”, even if it was not written to server yet
    • Client is able to route to offline inserted data
    • Therefor it needs some kind of primary key/id to route to
    • Primary key can be generated on server-side and on client-side
    Primary key generation - challenge

    View full-size slide

  48. • Server is responsible for generating the primary key
    • Client will generate a temporary offline primary key
    • After syncing, the client needs to replace the temporary offline key with the
    server generated primary key
    • Allows to use sequential GUIDs on the server side (MSSQL)
    Primary key generation - server-side

    View full-size slide

  49. • Client is responsible for generating the primary key (GUIDs only)
    • Server inserts the client generated key into the database as the primary key
    • Server additionally needs to have a clustered key
    • Otherwise inserting a client non-sequential GUID will lead to a
    reclustering of the database, every time a client syncs new data
    Primary key generation - client-side

    View full-size slide

  50. Change Tracking

    View full-size slide

  51. • Possibilities to determine the client’s current state
    • Use highest rowversion within result
    • Determine by result set or additional query
    • Result of @@DBTS
    • Returns the last used rowversion of the database
    • Result of MIN_ACTIVE_ROWVERSION()
    • Returns the lowest (active) rowversion of the database
    Change Tracking - MS SQL Server’s ROWVERSION

    View full-size slide

  52. • If you do a million updates a second, every second, the timestamp will wrap
    around in about 585000 years
    • Could be used for concurrency checks as well (see Conflict Management)
    • Before writing data into a row, you could check if it still as the client’s
    saved row version
    • If yes: data was not modified, saving is easily possible
    • If no: data was modified, decide per use case what to do!
    Change Tracking - MS SQL Server’s ROWVERSION

    View full-size slide

  53. Change Tracking - Highest ROWVERSION within result
    Transaction #1
    ID ROWVERSION
    1 0x01
    2 0x02
    … …
    41 0x41
    Transaction #2
    ID ROWVERSION
    1 0x01
    2 0x02
    … …
    41 0x41
    42 0x42 43 0x43
    SELECT MAX(ROWVERSION) FROM TABLE
    Client’s state
    Last known rowversion 41
    43
    NOT RELIABLE!

    View full-size slide

  54. • A later started transaction but committed first results in a queryable
    rowversion higher than the pending ones
    • Data will be lost (never seen by the client’s delta request)
    Change Tracking - Highest ROWVERSION within result

    View full-size slide

  55. Change Tracking - Query @@DBTS
    Transaction #1
    ID ROWVERSION
    1 0x01
    2 0x02
    … …
    41 0x41
    Transaction #2
    ID ROWVERSION
    1 0x01
    2 0x02
    … …
    41 0x41
    42 0x42 43 0x43
    SELECT @@DBTS
    Client’s state
    Last known rowversion 41
    42
    43
    NOT RELIABLE!

    View full-size slide

  56. • Value is database global
    • Running transaction updates the value instantly (before commit or rollback)
    • Data will be lost (never seen by the client’s delta request)
    Change Tracking - Query @@DBTS

    View full-size slide

  57. Change Tracking - Query MIN_ACTIVE_ROWVERSION()
    Transaction #1
    ID ROWVERSION
    1 0x01
    2 0x02
    … …
    41 0x41
    Transaction #2
    ID ROWVERSION
    1 0x01
    2 0x02
    … …
    41 0x41
    42 0x42 43 0x43
    SELECT MIN_ACTIVE_ROWVERSION()
    Client’s state
    Last known rowversion 41
    42
    44
    RELIABLE!

    View full-size slide

  58. • Value is database global
    • Running transaction updates the value instantly (before commit or rollback)
    • Data will be safe
    • Needs to be compared with greater or equal
    • May query data multiple times
    Change Tracking - Query MIN_ACTIVE_ROWVERSION()

    View full-size slide

  59. Backend Preparation

    View full-size slide

  60. • All syncable entities need to have rowversion column
    • rowversion is updated by MS SQL Server automatically whenever the row
    is changed (created & updated)
    • For deleted entities
    • Either set a IsDeleted flag to true (never delete any rows physically)
    • Or save the deleted IDs of the entities somewhere else (by trigger)
    Backend Preparation - MS SQL Server

    View full-size slide

  61. Backend Preparation - MS SQL Server
    public class Syncable : ISyncable
    {
    public Guid Id { get; set; }
    public byte[] RowVersion { get; set; }
    }
    public abstract class SyncableEntityTypeConfiguration : IEntityTypeConfiguration
    where T : class, ISyncable
    {
    public virtual void Configure(EntityTypeBuilder builder)
    {
    builder.HasKey(p !=> p.Id);
    builder.Property(p !=> p.RowVersion).IsRowVersion();
    }
    }

    View full-size slide

  62. Backend Preparation - MS SQL Server
    public async Task> SyncAsync(string timestamp)
    where TSource : Syncable
    where TResult : SyncableDto
    {
    var rowVersion = Convert.FromBase64String(timestamp !?? string.Empty);
    var baseQuery = _context.Set()
    .Where(p !=> (ulong)(object)p.RowVersion !>= (ulong)(object)rowVersion);
    var changed = await _mapper.ProjectTo(baseQuery.WithoutDeleted()).ToListAsync();
    var deleted = await baseQuery.Where(p !=> p.IsDeleted).Select(p !=> p.Id).ToListAsync();
    return new SyncDto()
    {
    Timestamp = await _context.GetMinActiveRowVersionAsync(),
    Changed = changed,
    Deleted = deleted
    };
    }

    View full-size slide

  63. Backend Preparation - MS SQL Server
    public class Context : DbContext {
    private DbQuery DbQueryValue { get; set; }
    public async Task GetMinActiveRowVersionAsync()
    {
    return await DbQueryValue
    .FromSql("SELECT MIN_ACTIVE_ROWVERSION() AS Value")
    .Select(p !=> p.Value)
    .FirstAsync();
    }
    }

    View full-size slide

  64. • Use equivalents of rowversion and triggers
    • Manual implement mechanism in business logic (error-prone!)
    • Update tracking column manually by incrementing a database global
    number (during one transaction!)
    • Will be very hard für multi-row updates/inserts
    • Manual implement mechanism in triggers (if available)
    Backend Preparation - Other Database Systems

    View full-size slide

  65. Frontend Preparation

    View full-size slide

  66. • Choose storage area for data (e.g. IndexedDB)
    • Write all the code
    • Periodic data synchronization
    • Binary synchronization when data changes
    • Tracking of timestamps
    Frontend Preparation

    View full-size slide

  67. • Implementation of the observable pattern in JavaScript
    • In our case used for observing a stream of synced data
    • Syncing is done in the background in periodic intervals
    • RxJS is helping to build a pipeline of actions for the sync process
    RxJS

    View full-size slide

  68. Typical token-based security
    Security - API level
    Browser
    Identity
    Provider
    Web API

    View full-size slide

  69. • User is only able to see data based on his security level
    • Permissions
    • Roles
    • Policies
    • What happens, if the user permission change is leading to different data
    visible to the user?
    • What about data, which he does not see due to rights, but is connected to
    other data?
    • Remove frontend data after logout
    Security - Data Level

    View full-size slide

  70. • De-normalize the relational data (document style)
    • Results in multiple rowversion for one entry (use most recent one)
    • Multiplies the data (more traffic)
    • Consistent data for one entry
    • Keep the relations up to the frontend
    • Explicit rowversion for each entry
    • Partial consistency (related data may not be synced yet)
    Relational Data

    View full-size slide

  71. • Keep some relational data and de-normalize some of it
    • De-normalize many-to-many relations
    • Needs trigger or business logic to change main entry’s rowversion when
    relation changes
    • Partial consistency (related data may not be synced yet)
    Relational Data

    View full-size slide

  72. • Native Cordova app out-of-the box possible
    • Native features could be used
    • Store restrictions apply
    • What about Electron?
    Native Packaging??

    View full-size slide

  73. • PWA helps taking offline the application, but not the data
    • Online != Edge is available
    • Offline data may be “temporary” (“Remove temporary internet files”)
    • Use MIN_ACTIVE_ROWVERSION() and “greater or equal than” operator
    • RxJS helps building a sync engine, but a lot knowledge is needed
    • Think about data level security (permissions, roles, etc.)
    • Think about conflict management
    • Depends heavily on your use case
    Summary

    View full-size slide

  74. And… now?
    • Slides: https://speakerdeck.com/manuelrauber
    • Repository: https://github.com/thinktecture/thinktecture-boardist

    View full-size slide
