Immer und überall: offlinefähige Progressive Web Apps – am Beispiel Angular

Immer und überall: offlinefähige Progressive Web Apps – am Beispiel Angular

"Keine Internetverbindung" – ein Satz, den wir alle aus genutzten Apps kennen, sei es Desktopanwendung oder Smartphone App. Oftmals sind die Clients auf dem jeweiligen Zielgerät installiert, bedienen sich aber einer externen Datenquelle, bspw. in Form eines Web API. Bei einer offline-fähigen Implementierung sind nicht nur Lese-, sondern vor allem auch Schreibzugriffe wichtig. Sprich, die Daten müssen in beide Richtungen synchronisiert werden können, sobald die Internetverbindung wiederhergestellt wurde. Gerade in der heutigen Zeit, in der Menschen immer mobiler werden, in Autos, Zügen und Flugzeugen unterwegs sind und arbeiten, benötigt man oftmals offline Zugriff auf die Anwendungsdaten. Wie man diese echt offline-fähigen Single-Page Applications/Progressive Web Apps realisiert, zeigen Thomas Hilzendegen und Manuel Rauber von Thinktecture in diesem Ganztagesworkshop. Allgemein werden Themen wie Synchronisationsstrategien von Anwendungsdaten und großen Binärdaten, Konfliktmanagement oder Datenbankarchitektur sowohl für neue als auch bestehende Anwendungen diskutiert. Am Beispiel einer Angular-basierten App mit einem exemplarischen Backend in .NET Core werden Client und Server zur Umsetzung der besprochenen Konzepte und Patterns implementiert.

GitHub: https://github.com/thinktecture/thinktecture-boardist

Manuel Rauber

March 26, 2019
Tweet

More Decks by Manuel Rauber

Other Decks in Programming

Transcript

  1. Offlinefähige Progressive Web Apps
    Immer & überall
    Thomas Hilzendegen
    @hilzendegent
    Consultant
    Manuel Rauber
    @ManuelRauber
    Consultant

    View Slide

  2. Thomas Hilzendegen
    Speakers
    Manuel Rauber
    [email protected]
    @hilzendegent
    [email protected]
    @manuelrauber
    https://manuel-rauber.com
    Microsoft MVP

    View Slide

  3. Timetable
    Time Doing
    09:00 - 10:30 Part I
    10:30 - 11:00 ☕
    11:00 - 12:30 Part II
    12:30 - 13:30
    13:30 - 15:00 Part III
    15:00 - 15:30 ☕
    15:30 - 17:00 Part IV

    View Slide

  4. • Progressive Web Apps
    • Offline availability
    • Offline synchronization
    • Security considerations
    • Pitfalls
    Agenda

    View Slide

  5. Intro

    View Slide

  6. Offline… but why?

    View Slide

  7. • Just because the phone has a connection,

    e.g. Edge, it does not mean we are online
    • Depends on the use case which connection

    quality is required to determine, if the

    app is reliable online
    • Connection quality could be measured

    by the time an exclusive request takes
    • Duration < 150 ms: online
    • Duration !>=150 ms: bad connection
    What does “offline” mean?

    View Slide

  8. • A lot of reasons to be offline
    • Traveling, Train, Flights (bad or no signal)
    • Server is not available
    • Routing problems
    • Roaming
    • Costs
    Motivation

    View Slide

  9. Demo Application

    View Slide

  10. • A little application to manage boardgames
    • Angular, .NET Core, MS SQL Server
    • Brownfield application, started as a pure online application
    • As typical for any good demo: no security
    • Available on Azure: https://tt-boardist.azurewebsites.net
    • GitHub: https://github.com/thinktecture/thinktecture-boardist
    Demo Application “Thinktecture Boardist”

    View Slide

  11. Demo Application Database Scheme

    View Slide

  12. Live Demo

    View Slide

  13. Now let’s go offline!

    View Slide

  14. Duh! And now?!

    View Slide

  15. Progressive Web Apps

    View Slide

  16. • Motivation: Get rid of app stores!
    • Web App = App App
    • Support native features like: Push notifications,
    offline availability, installable
    • Backwards-compatibility: runs in non-PWA
    browsers, with a reduced feature set
    Progressive Web Apps

    View Slide

  17. PWA Technology Overview
    Progressive Web Apps
    HTML5, JavaScript, CSS3
    Service Worker API Web App Manifest HTTPS
    Fetch API
    Web
    Notifications
    Web
    Workers
    Push API

    View Slide

  18. PWA Platform Support
    40 44 11.1 17 4.1 11.3

    View Slide

  19. Progressive Web Apps

    are not a technology ,

    but a collection of features an
    application must/should support

    View Slide

  20. PWA Collection Of Features
    Responsive Linkable Discoverable Installable App-Like
    Connectivity

    Independent
    Fresh Safe Re-engageable Progressive

    View Slide

  21. • A JavaScript running in its own thread
    • No access to the DOM
    • Communicates via postMessage-API
    • Acts as a controller/proxy/interceptor
    • Can perform background tasks
    • Has to be installed before usage
    • Runs whenever the browser is running
    PWA ServiceWorker

    View Slide

  22. PWA ServiceWorker
    Website Internet
    Cache Service
    Worker

    View Slide

  23. PWA ServiceWorker Lifecycle
    Parse Installing
    Error
    Activated Idle Terminated
    fetch/message

    View Slide

  24. PWA Connectivity Independent
    Website Internet
    Cache storage
    Server
    Remote storage
    ServiceWorker

    View Slide

  25. • Cache only
    • Network only
    • Cache falling back to network
    • Cache & network race
    • Network falling back to cache
    • Cache then network
    • Generic fallback
    • ServiceWorker-side templating
    PWA Caching Strategies

    View Slide

  26. PWA Cache Then Network
    Website Internet
    Cache storage
    Server
    Remote storage
    ServiceWorker
    HTTP
    1. Lookup
    2. fetch

    View Slide

  27. • “One-size-fits-all” ServiceWorker implementation
    • Instrumented via ngsw-config.json
    • Restricted feature set (e.g. no communication between app and SW)
    • Initial caching of static content
    • Caching external content
    • Dynamic data caching
    • Push notifications
    PWA Angular ServiceWorker

    View Slide

  28. Are we offline now?

    View Slide

  29. Nope.

    View Slide

  30. Real offline availability

    View Slide

  31. • ServiceWorker is only able to take data offline which has been requested by
    the application
    • If all the URLs are known beforehand, the ServiceWorker could cache them
    all
    • Data which was not requested, is not available offline (no real offline
    synchronisation)
    • But what about … the Background Sync API?
    What’s the problem?

    View Slide

  32. • Name is misleading
    • It does not offer any data synchronisation possibilities, but offers the
    possibility to start a (periodic) “sync” event
    • It’s totally up to the developer what to do in the “sync” event
    • In case the user agent is offline, the sync will be automatically scheduled to
    be sent, when the user agent is online again
    • Since the sync is done in the ServiceWorker, the page can be closed, the
    sync will be fulfilled anyway
    • It does not help anything with syncing your actual data!
    Background Sync API

    View Slide

  33. Background Sync API

    View Slide

  34. • Cookies (“old & outdated”, not meant for large data or binaries)
    • Web Storage API (Session Storage, Local Storage, not meant for large data
    or binaries)
    • IndexedDB
    • Cache Storage
    Storage capabilities

    View Slide

  35. User can clear anything
    at any time by
    “Remove temporary internet files”

    View Slide

  36. • Key-Value database within the browser
    • Stores data permanently
    • ServiceWorker and Web App share access to the same IndexedDB
    • Possibility of scenarios, where the ServiceWorker (or Web App) stores
    synchronised data in the IndexedDB and the Web App reads the data
    IndexedDB

    View Slide

  37. IndexedDB Availability
    11 4 7.1 10 4.4 8

    View Slide

  38. • The standard API of IndexedDB is inconvenient to use (lots of callback)
    • Dexie.js is a minimalistic wrapper for IndexedDB
    • Operations are promise-based instead of callback
    • Near native performance (even for bulk inserts)
    • Open Source @ GitHub: https://github.com/dfahlander/Dexie.js
    IndexedDB API

    View Slide

  39. Offline Sync

    View Slide

  40. • Offline Sync means to download all data available to client into a persistent
    offline storage, without the user having to explicitly request the data
    • Depending on the scenario, client can do CRUD on the offline data
    • Data will be synced back to the server, whenever a connection is possible
    Offline Sync Basics

    View Slide

  41. • Online/offline recognition
    • Conflict management
    • Binary data
    • Local changes
    • Update interval (incoming new data)
    • Error handling
    Offline Sync Challenges

    View Slide

  42. • Client needs to be online for write operations
    • Locks the data, so no other client can overwrite it
    • Data stays locked, until the client either saves or discards changes
    • Last One (Write) Wins
    • Visual conflict management (diffing like in Git, SVN, etc.)
    Offline Sync Conflict Management Scenarios

    View Slide

  43. Backend Preparation

    View Slide

  44. • All syncable entities need to have rowversion column
    • rowversion is updated by MS SQL Server automatically whenever the row
    is changed (created & updated)
    • For deleted entities
    • Either set a IsDeleted flag to true (never delete any rows physically)
    • Or save the deleted IDs of the entities somewhere else (by trigger)
    Backend Preparation - MS SQL Server

    View Slide

  45. Backend Preparation - MS SQL Server
    public class Syncable : ISyncable
    {
    public Guid Id { get; set; }
    public byte[] RowVersion { get; set; }
    }
    public abstract class SyncableEntityTypeConfiguration : IEntityTypeConfiguration
    where T : class, ISyncable
    {
    public virtual void Configure(EntityTypeBuilder builder)
    {
    builder.HasKey(p !=> p.Id);
    builder.Property(p !=> p.RowVersion).IsRowVersion();
    }
    }

    View Slide

  46. Backend Preparation - MS SQL Server
    public async Task> SyncAsync(string timestamp)
    where TSource : Syncable
    where TResult : SyncableDto
    {
    var rowVersion = Convert.FromBase64String(timestamp !?? string.Empty);
    var baseQuery = _context.Set()
    .Where(p !=> (ulong)(object)p.RowVersion !>= (ulong)(object)rowVersion);
    var changed = await _mapper.ProjectTo(baseQuery.WithoutDeleted()).ToListAsync();
    var deleted = await baseQuery.Where(p !=> p.IsDeleted).Select(p !=> p.Id).ToListAsync();
    return new SyncDto()
    {
    Timestamp = await _context.GetMinActiveRowVersionAsync(),
    Changed = changed,
    Deleted = deleted
    };
    }

    View Slide

  47. Backend Preparation - MS SQL Server
    public class Context : DbContext {
    private DbQuery DbQueryValue { get; set; }
    public async Task GetMinActiveRowVersionAsync()
    {
    return await DbQueryValue
    .FromSql("SELECT MIN_ACTIVE_ROWVERSION() AS Value")
    .Select(p !=> p.Value)
    .FirstAsync();
    }
    }

    View Slide

  48. • Use equivalents of rowversion and triggers
    • Manual implement mechanism in business logic (error-prone!)
    • Update tracking column manually by incrementing a database global
    number (during one transaction!)
    • Will be very hard für multi-row updates/inserts
    • Manual implement mechanism in triggers (if available)
    Backend Preparation - Other Database Systems

    View Slide

  49. Frontend Preparation

    View Slide

  50. • Choose storage area for data (e.g. IndexedDB)
    • Write all the code
    • Periodic data synchronization
    • Binary synchronization when data changes
    • Tracking of timestamps
    Frontend Preparation

    View Slide

  51. Security

    View Slide

  52. Typical token-based security
    Security API level
    Browser
    Identity
    Provider
    Web API

    View Slide

  53. • User is only able to see data based on this security level
    • Permissions
    • Roles
    • Policies
    • What happens, if the user rights change leading to different data visible to
    the user?
    • What about data, which he does not see due to rights, but is connected to
    other data?
    Security Data Level

    View Slide

  54. Pitfalls

    View Slide

  55. • Highest rowversion within result
    • @@DBTS
    • MIN_ACTIVE_ROWVERSION()
    Change Tracking - MS SQL Server’s ROWVERSION

    View Slide

  56. • Not reliable – a later committed (but started earlier) transaction results in
    skipped values
    Change Tracking - Highest ROWVERSION within result
    Timestamp Transaction #1 Transaction #2 Sync
    T1
    MAX !=> ROWVERSION(1)
    T2
    INSERT !=> ROWVERSION(2) UPDATE !=> ROWVERSION(3) MAX !=> ROWVERSION(1)
    T3
    COMMIT MAX !=> ROWVERSION(3)

    Tn
    COMMIT ROW LOST!

    View Slide

  57. • Not reliable – represents the maximum rowversion of the database
    (including not yet committed transactions )
    Change Tracking - @@DBTS
    Timestamp Transaction #1 Transaction #2 Sync
    T1
    @@DBTS !=> ROWVERSION(1)
    T2
    INSERT !=> ROWVERSION(2) UPDATE !=> ROWVERSION(3) @@DBTS !=> ROWVERSION(3)
    T3
    COMMIT @@DBTS !=> ROWVERSION(3)

    Tn
    COMMIT ROW LOST!

    View Slide

  58. • Reliable – represents the minimum rowversion of the database (including
    not yet committed transactions)
    • Small drawback: could result in repetitive selection of same data
    Change Tracking - MIN_ACTIVE_ROWVERSION()
    Timestamp Transaction #1 Transaction #2 Sync
    T1
    SELECT !=> ROWVERSION(2)
    T2
    INSERT !=> ROWVERSION(2) UPDATE !=> ROWVERSION(3) SELECT !=> ROWVERSION(2)
    T3
    COMMIT SELECT !=> ROWVERSION(2)

    Tn
    COMMIT SELECT !=> ROWVERSION(4)

    View Slide

  59. • De-normalize the relational data (document style)
    • Results in multiple rowversion for one entry (use most recent one)
    • Multiplies the data (more traffic)
    • Consistent data for one entry
    • Keep the relations up to the frontend
    • Explicit rowversion for each entry
    • Partial consistency (related data may not be synced yet)
    Relational Data

    View Slide

  60. • Keep some relational data and de-normalize some of it
    • De-normalize many-to-many relations
    • Needs trigger or business logic to change main entry’s rowversion when
    relation changes
    • Partial consistency (related data may not be synced yet)
    Relational Data

    View Slide

  61. • Native Cordova app out-of-the box possible
    • Native features could be used
    • Store restrictions apply
    • What about Electron?
    Native Packaging??

    View Slide

  62. • PWA helps bringing offline the application, but not the data
    • Online !== Edge is available
    • Offline data is “temporary” (“Remove temporary internet files”)
    • Use MIN_ACTIVE_ROWVERSION and “greater than” operator
    • RxJS helps building a sync engine, but a lot knowledge is needed
    • Think about data level security (permissions, roles, etc.)
    • Think about conflict management
    • Depends heavily on your use case
    Summary

    View Slide

  63. And… now?
    • Slides: https://speakerdeck.com/manuelrauber
    • Repository: https://github.com/thinktecture/thinktecture-boardist

    View Slide
