  1. Implementing a Simple Interpreter Ray Song May 27, 2012 Ray

    Song Implementing a Simple Interpreter
  2. Flow sheet Lexical analysis Grammatical analysis Figure : Flow Ray

    Song Implementing a Simple Interpreter
  3. Flow sheet Lexical analysis Grammatical analysis Figure : Flow Ray

    Song Implementing a Simple Interpreter
  4. Lexical Analysis manual flex Ray Song Implementing a Simple Interpreter

  5. Lexical Analysis manual flex Ray Song Implementing a Simple Interpreter

  6. Tokens identifier integer string while if else print NEWLINE NO

    WHITESPACE Ray Song Implementing a Simple Interpreter
  7. Tokens identifier integer string while if else print NEWLINE NO

    WHITESPACE Ray Song Implementing a Simple Interpreter
  8. Tokens identifier integer string while if else print NEWLINE NO

    WHITESPACE Ray Song Implementing a Simple Interpreter
  9. Tokens identifier integer string while if else print NEWLINE NO

    WHITESPACE Ray Song Implementing a Simple Interpreter
  10. Tokens identifier integer string while if else print NEWLINE NO

    WHITESPACE Ray Song Implementing a Simple Interpreter
  11. Tokens identifier integer string while if else print NEWLINE NO

    WHITESPACE Ray Song Implementing a Simple Interpreter
  12. Tokens identifier integer string while if else print NEWLINE NO

    WHITESPACE Ray Song Implementing a Simple Interpreter
  13. Tokens identifier integer string while if else print NEWLINE NO

    WHITESPACE Ray Song Implementing a Simple Interpreter
  14. Tokens identifier integer string while if else print NEWLINE NO

    WHITESPACE Ray Song Implementing a Simple Interpreter
  15. Off-side rule def hello(): print ‘world’ indentation sensitive Ex: ISWIM(1966),

    occam(1983), Miranda(1985), Haskell(1990), Python(1991) Ray Song Implementing a Simple Interpreter
  16. Off-side rule def hello(): print ‘world’ indentation sensitive Ex: ISWIM(1966),

    occam(1983), Miranda(1985), Haskell(1990), Python(1991) Ray Song Implementing a Simple Interpreter
  17. Off-side rule - Cont. represented as virtual tokens INDENT DEDENT

    Ray Song Implementing a Simple Interpreter
  18. Off-side rule - Cont. represented as virtual tokens INDENT DEDENT

    Ray Song Implementing a Simple Interpreter
  19. Off-side rule - Cont. represented as virtual tokens INDENT DEDENT

    Ray Song Implementing a Simple Interpreter
  20. Example if a > 2: print 5 print a IF

    a > 2 : NEWLINE INDENT PRINT 5 NEWLINE DEDENT PRINT a NEWLINE Ray Song Implementing a Simple Interpreter
  21. Grammatical analysis Cocke–Younger–Kasami algorithm Earley’s algorithm LR parser Recursive-descent parser

    Ray Song Implementing a Simple Interpreter
  22. Grammatical analysis Cocke–Younger–Kasami algorithm Earley’s algorithm LR parser Recursive-descent parser

    Ray Song Implementing a Simple Interpreter
  23. Grammatical analysis Cocke–Younger–Kasami algorithm Earley’s algorithm LR parser Recursive-descent parser

    Ray Song Implementing a Simple Interpreter
  24. Grammatical analysis Cocke–Younger–Kasami algorithm Earley’s algorithm LR parser Recursive-descent parser

    Ray Song Implementing a Simple Interpreter
  25. Tools Bison Can generate C, C++ and Java codes ANTLR

    Ray Song Implementing a Simple Interpreter
  26. Tools Bison Can generate C, C++ and Java codes ANTLR

    Ray Song Implementing a Simple Interpreter
  27. Tools Bison Can generate C, C++ and Java codes ANTLR

    Ray Song Implementing a Simple Interpreter
  28. Expression Precedence climbing method Shunting-yard algorithm Parsing expressions in infix

    notation Output in Reverse Polish notation (RPN) Output in Abstract syntax tree (AST) Operator precedence parser Ray Song Implementing a Simple Interpreter
  29. Expression Precedence climbing method Shunting-yard algorithm Parsing expressions in infix

    notation Output in Reverse Polish notation (RPN) Output in Abstract syntax tree (AST) Operator precedence parser Ray Song Implementing a Simple Interpreter
  30. Expression Precedence climbing method Shunting-yard algorithm Parsing expressions in infix

    notation Output in Reverse Polish notation (RPN) Output in Abstract syntax tree (AST) Operator precedence parser Ray Song Implementing a Simple Interpreter
  31. Expression Precedence climbing method Shunting-yard algorithm Parsing expressions in infix

    notation Output in Reverse Polish notation (RPN) Output in Abstract syntax tree (AST) Operator precedence parser Ray Song Implementing a Simple Interpreter
  32. Expression Precedence climbing method Shunting-yard algorithm Parsing expressions in infix

    notation Output in Reverse Polish notation (RPN) Output in Abstract syntax tree (AST) Operator precedence parser Ray Song Implementing a Simple Interpreter
  33. Expression Precedence climbing method Shunting-yard algorithm Parsing expressions in infix

    notation Output in Reverse Polish notation (RPN) Output in Abstract syntax tree (AST) Operator precedence parser Ray Song Implementing a Simple Interpreter
  34. Parser combinator Straightforward to construct Readability Parsec Ray Song Implementing

    a Simple Interpreter
  35. Parser combinator Straightforward to construct Readability Parsec Ray Song Implementing

    a Simple Interpreter
  36. Parser combinator Straightforward to construct Readability Parsec Ray Song Implementing

    a Simple Interpreter
  37. Impl Two top-level nonterminals: STMT and EXPR STMT: SIMPLE STMT

    ‘\n’ | COMPOUND SIMPLE STMT: EXPR SIMPLE STMT: IDENT ‘=’ EXPR SIMPLE STMT: BREAK SIMPLE STMT: print EXPR COMPOUND: if EXPR ’:’ SUITE OPT ELSE COMPOUND: while EXPR ’:’ SUITE SUITE: many1(‘\n’) INDENT many1(STMT) DEDENT SUITE: SIMPLE STMT ‘\n’ OPT ELSE: ELSE ’:’ SUITE OPT ELSE: /* empty */ Ray Song Implementing a Simple Interpreter
  38. Impl Two top-level nonterminals: STMT and EXPR STMT: SIMPLE STMT

    ‘\n’ | COMPOUND SIMPLE STMT: EXPR SIMPLE STMT: IDENT ‘=’ EXPR SIMPLE STMT: BREAK SIMPLE STMT: print EXPR COMPOUND: if EXPR ’:’ SUITE OPT ELSE COMPOUND: while EXPR ’:’ SUITE SUITE: many1(‘\n’) INDENT many1(STMT) DEDENT SUITE: SIMPLE STMT ‘\n’ OPT ELSE: ELSE ’:’ SUITE OPT ELSE: /* empty */ Ray Song Implementing a Simple Interpreter
  39. Impl Two top-level nonterminals: STMT and EXPR STMT: SIMPLE STMT

    ‘\n’ | COMPOUND SIMPLE STMT: EXPR SIMPLE STMT: IDENT ‘=’ EXPR SIMPLE STMT: BREAK SIMPLE STMT: print EXPR COMPOUND: if EXPR ’:’ SUITE OPT ELSE COMPOUND: while EXPR ’:’ SUITE SUITE: many1(‘\n’) INDENT many1(STMT) DEDENT SUITE: SIMPLE STMT ‘\n’ OPT ELSE: ELSE ’:’ SUITE OPT ELSE: /* empty */ Ray Song Implementing a Simple Interpreter
  40. Impl Two top-level nonterminals: STMT and EXPR STMT: SIMPLE STMT

    ‘\n’ | COMPOUND SIMPLE STMT: EXPR SIMPLE STMT: IDENT ‘=’ EXPR SIMPLE STMT: BREAK SIMPLE STMT: print EXPR COMPOUND: if EXPR ’:’ SUITE OPT ELSE COMPOUND: while EXPR ’:’ SUITE SUITE: many1(‘\n’) INDENT many1(STMT) DEDENT SUITE: SIMPLE STMT ‘\n’ OPT ELSE: ELSE ’:’ SUITE OPT ELSE: /* empty */ Ray Song Implementing a Simple Interpreter
  41. Impl Two top-level nonterminals: STMT and EXPR STMT: SIMPLE STMT

    ‘\n’ | COMPOUND SIMPLE STMT: EXPR SIMPLE STMT: IDENT ‘=’ EXPR SIMPLE STMT: BREAK SIMPLE STMT: print EXPR COMPOUND: if EXPR ’:’ SUITE OPT ELSE COMPOUND: while EXPR ’:’ SUITE SUITE: many1(‘\n’) INDENT many1(STMT) DEDENT SUITE: SIMPLE STMT ‘\n’ OPT ELSE: ELSE ’:’ SUITE OPT ELSE: /* empty */ Ray Song Implementing a Simple Interpreter
  42. Impl Two top-level nonterminals: STMT and EXPR STMT: SIMPLE STMT

    ‘\n’ | COMPOUND SIMPLE STMT: EXPR SIMPLE STMT: IDENT ‘=’ EXPR SIMPLE STMT: BREAK SIMPLE STMT: print EXPR COMPOUND: if EXPR ’:’ SUITE OPT ELSE COMPOUND: while EXPR ’:’ SUITE SUITE: many1(‘\n’) INDENT many1(STMT) DEDENT SUITE: SIMPLE STMT ‘\n’ OPT ELSE: ELSE ’:’ SUITE OPT ELSE: /* empty */ Ray Song Implementing a Simple Interpreter
  43. Impl Two top-level nonterminals: STMT and EXPR STMT: SIMPLE STMT

    ‘\n’ | COMPOUND SIMPLE STMT: EXPR SIMPLE STMT: IDENT ‘=’ EXPR SIMPLE STMT: BREAK SIMPLE STMT: print EXPR COMPOUND: if EXPR ’:’ SUITE OPT ELSE COMPOUND: while EXPR ’:’ SUITE SUITE: many1(‘\n’) INDENT many1(STMT) DEDENT SUITE: SIMPLE STMT ‘\n’ OPT ELSE: ELSE ’:’ SUITE OPT ELSE: /* empty */ Ray Song Implementing a Simple Interpreter
  44. Impl Two top-level nonterminals: STMT and EXPR STMT: SIMPLE STMT

    ‘\n’ | COMPOUND SIMPLE STMT: EXPR SIMPLE STMT: IDENT ‘=’ EXPR SIMPLE STMT: BREAK SIMPLE STMT: print EXPR COMPOUND: if EXPR ’:’ SUITE OPT ELSE COMPOUND: while EXPR ’:’ SUITE SUITE: many1(‘\n’) INDENT many1(STMT) DEDENT SUITE: SIMPLE STMT ‘\n’ OPT ELSE: ELSE ’:’ SUITE OPT ELSE: /* empty */ Ray Song Implementing a Simple Interpreter
  45. Impl Two top-level nonterminals: STMT and EXPR STMT: SIMPLE STMT

    ‘\n’ | COMPOUND SIMPLE STMT: EXPR SIMPLE STMT: IDENT ‘=’ EXPR SIMPLE STMT: BREAK SIMPLE STMT: print EXPR COMPOUND: if EXPR ’:’ SUITE OPT ELSE COMPOUND: while EXPR ’:’ SUITE SUITE: many1(‘\n’) INDENT many1(STMT) DEDENT SUITE: SIMPLE STMT ‘\n’ OPT ELSE: ELSE ’:’ SUITE OPT ELSE: /* empty */ Ray Song Implementing a Simple Interpreter
  46. Impl Two top-level nonterminals: STMT and EXPR STMT: SIMPLE STMT

    ‘\n’ | COMPOUND SIMPLE STMT: EXPR SIMPLE STMT: IDENT ‘=’ EXPR SIMPLE STMT: BREAK SIMPLE STMT: print EXPR COMPOUND: if EXPR ’:’ SUITE OPT ELSE COMPOUND: while EXPR ’:’ SUITE SUITE: many1(‘\n’) INDENT many1(STMT) DEDENT SUITE: SIMPLE STMT ‘\n’ OPT ELSE: ELSE ’:’ SUITE OPT ELSE: /* empty */ Ray Song Implementing a Simple Interpreter
  47. Impl Two top-level nonterminals: STMT and EXPR STMT: SIMPLE STMT

    ‘\n’ | COMPOUND SIMPLE STMT: EXPR SIMPLE STMT: IDENT ‘=’ EXPR SIMPLE STMT: BREAK SIMPLE STMT: print EXPR COMPOUND: if EXPR ’:’ SUITE OPT ELSE COMPOUND: while EXPR ’:’ SUITE SUITE: many1(‘\n’) INDENT many1(STMT) DEDENT SUITE: SIMPLE STMT ‘\n’ OPT ELSE: ELSE ’:’ SUITE OPT ELSE: /* empty */ Ray Song Implementing a Simple Interpreter
  48. Impl Two top-level nonterminals: STMT and EXPR STMT: SIMPLE STMT

    ‘\n’ | COMPOUND SIMPLE STMT: EXPR SIMPLE STMT: IDENT ‘=’ EXPR SIMPLE STMT: BREAK SIMPLE STMT: print EXPR COMPOUND: if EXPR ’:’ SUITE OPT ELSE COMPOUND: while EXPR ’:’ SUITE SUITE: many1(‘\n’) INDENT many1(STMT) DEDENT SUITE: SIMPLE STMT ‘\n’ OPT ELSE: ELSE ’:’ SUITE OPT ELSE: /* empty */ Ray Song Implementing a Simple Interpreter
  49. Impl - Cont. EXPR: EXPR ‘==’ TERM EXPR: EXPR ’!=’

    TERM EXPR: TERM TERM: TERM ‘+’ FACTOR TERM: FACTOR FACTOR: FACTOR ‘*’ ATOM FACTOR: ATOM ATOM: identifier ATOM: literal integer ATOM: literal string ATOM: ‘(’ EXPR ’)’ Ray Song Implementing a Simple Interpreter
  50. Impl - Cont. EXPR: EXPR ‘==’ TERM EXPR: EXPR ’!=’

    TERM EXPR: TERM TERM: TERM ‘+’ FACTOR TERM: FACTOR FACTOR: FACTOR ‘*’ ATOM FACTOR: ATOM ATOM: identifier ATOM: literal integer ATOM: literal string ATOM: ‘(’ EXPR ’)’ Ray Song Implementing a Simple Interpreter
  51. Impl - Cont. EXPR: EXPR ‘==’ TERM EXPR: EXPR ’!=’

    TERM EXPR: TERM TERM: TERM ‘+’ FACTOR TERM: FACTOR FACTOR: FACTOR ‘*’ ATOM FACTOR: ATOM ATOM: identifier ATOM: literal integer ATOM: literal string ATOM: ‘(’ EXPR ’)’ Ray Song Implementing a Simple Interpreter
  52. Impl - Cont. EXPR: EXPR ‘==’ TERM EXPR: EXPR ’!=’

    TERM EXPR: TERM TERM: TERM ‘+’ FACTOR TERM: FACTOR FACTOR: FACTOR ‘*’ ATOM FACTOR: ATOM ATOM: identifier ATOM: literal integer ATOM: literal string ATOM: ‘(’ EXPR ’)’ Ray Song Implementing a Simple Interpreter
  53. Impl - Cont. EXPR: EXPR ‘==’ TERM EXPR: EXPR ’!=’

    TERM EXPR: TERM TERM: TERM ‘+’ FACTOR TERM: FACTOR FACTOR: FACTOR ‘*’ ATOM FACTOR: ATOM ATOM: identifier ATOM: literal integer ATOM: literal string ATOM: ‘(’ EXPR ’)’ Ray Song Implementing a Simple Interpreter
  54. Impl - Cont. EXPR: EXPR ‘==’ TERM EXPR: EXPR ’!=’

    TERM EXPR: TERM TERM: TERM ‘+’ FACTOR TERM: FACTOR FACTOR: FACTOR ‘*’ ATOM FACTOR: ATOM ATOM: identifier ATOM: literal integer ATOM: literal string ATOM: ‘(’ EXPR ’)’ Ray Song Implementing a Simple Interpreter
  55. Impl - Cont. EXPR: EXPR ‘==’ TERM EXPR: EXPR ’!=’

    TERM EXPR: TERM TERM: TERM ‘+’ FACTOR TERM: FACTOR FACTOR: FACTOR ‘*’ ATOM FACTOR: ATOM ATOM: identifier ATOM: literal integer ATOM: literal string ATOM: ‘(’ EXPR ’)’ Ray Song Implementing a Simple Interpreter
  56. Impl - Cont. EXPR: EXPR ‘==’ TERM EXPR: EXPR ’!=’

    TERM EXPR: TERM TERM: TERM ‘+’ FACTOR TERM: FACTOR FACTOR: FACTOR ‘*’ ATOM FACTOR: ATOM ATOM: identifier ATOM: literal integer ATOM: literal string ATOM: ‘(’ EXPR ’)’ Ray Song Implementing a Simple Interpreter
  57. Impl - Cont. EXPR: EXPR ‘==’ TERM EXPR: EXPR ’!=’

    TERM EXPR: TERM TERM: TERM ‘+’ FACTOR TERM: FACTOR FACTOR: FACTOR ‘*’ ATOM FACTOR: ATOM ATOM: identifier ATOM: literal integer ATOM: literal string ATOM: ‘(’ EXPR ’)’ Ray Song Implementing a Simple Interpreter
  58. Impl - Cont. EXPR: EXPR ‘==’ TERM EXPR: EXPR ’!=’

    TERM EXPR: TERM TERM: TERM ‘+’ FACTOR TERM: FACTOR FACTOR: FACTOR ‘*’ ATOM FACTOR: ATOM ATOM: identifier ATOM: literal integer ATOM: literal string ATOM: ‘(’ EXPR ’)’ Ray Song Implementing a Simple Interpreter
  59. Impl - Cont. EXPR: EXPR ‘==’ TERM EXPR: EXPR ’!=’

    TERM EXPR: TERM TERM: TERM ‘+’ FACTOR TERM: FACTOR FACTOR: FACTOR ‘*’ ATOM FACTOR: ATOM ATOM: identifier ATOM: literal integer ATOM: literal string ATOM: ‘(’ EXPR ’)’ Ray Song Implementing a Simple Interpreter
  60. Example if a > 2: print 5 print a Ray

    Song Implementing a Simple Interpreter
  61. Example - Cont. Figure : Parse Ray Song Implementing a

    Simple Interpreter
  62. Interpreting Abstract syntax tree (AST). Define semantics for each class

    of nodes object(atom): trivial binary operator BinOP(operator, lhs, rhs, RESULT) :- obj1 = eval(lhs), obj2 = eval(rhs), calc(op, obj1, obj2, RESULT). Object & BinOP inherit from Expr Ray Song Implementing a Simple Interpreter
  63. Interpreting Abstract syntax tree (AST). Define semantics for each class

    of nodes object(atom): trivial binary operator BinOP(operator, lhs, rhs, RESULT) :- obj1 = eval(lhs), obj2 = eval(rhs), calc(op, obj1, obj2, RESULT). Object & BinOP inherit from Expr Ray Song Implementing a Simple Interpreter
  64. Interpreting Abstract syntax tree (AST). Define semantics for each class

    of nodes object(atom): trivial binary operator BinOP(operator, lhs, rhs, RESULT) :- obj1 = eval(lhs), obj2 = eval(rhs), calc(op, obj1, obj2, RESULT). Object & BinOP inherit from Expr Ray Song Implementing a Simple Interpreter
  65. Interpreting Abstract syntax tree (AST). Define semantics for each class

    of nodes object(atom): trivial binary operator BinOP(operator, lhs, rhs, RESULT) :- obj1 = eval(lhs), obj2 = eval(rhs), calc(op, obj1, obj2, RESULT). Object & BinOP inherit from Expr Ray Song Implementing a Simple Interpreter
  66. Interpreting Abstract syntax tree (AST). Define semantics for each class

    of nodes object(atom): trivial binary operator BinOP(operator, lhs, rhs, RESULT) :- obj1 = eval(lhs), obj2 = eval(rhs), calc(op, obj1, obj2, RESULT). Object & BinOP inherit from Expr Ray Song Implementing a Simple Interpreter
  67. Subclasses of Stmt - Cont. Assign eval() need a parameter:

    Binding (which variable holds which object) ExprStmt Print Continue (throwing an exception) Ray Song Implementing a Simple Interpreter
  68. Subclasses of Stmt - Cont. Assign eval() need a parameter:

    Binding (which variable holds which object) ExprStmt Print Continue (throwing an exception) Ray Song Implementing a Simple Interpreter
  69. Subclasses of Stmt - Cont. Assign eval() need a parameter:

    Binding (which variable holds which object) ExprStmt Print Continue (throwing an exception) Ray Song Implementing a Simple Interpreter
  70. Subclasses of Stmt - Cont. Assign eval() need a parameter:

    Binding (which variable holds which object) ExprStmt Print Continue (throwing an exception) Ray Song Implementing a Simple Interpreter
  71. Subclasses of Stmt - Cont. Assign eval() need a parameter:

    Binding (which variable holds which object) ExprStmt Print Continue (throwing an exception) Ray Song Implementing a Simple Interpreter
