mrubyとものづくり

2013/05/18 名古屋にて

Transcript

1. mrubyͱ΋ͷͮ͘Γ
   Yuichiro MASUI a.k.a. @masuidrive
   Saturday, May 18, 13


   View Slide

2. Hi! I’m @masuidrive.
   • Yuichiro MASUI - Ichi
   • Open source developer, Ruby fun
   • Pukiwiki, Ruby on Rails tutorial movie in
   Japanese, IKEA hacker
   • Furo-grammer (Coding in hot tub)
   • FrogApps, Inc. CTO // ex-Appcelerati
   Saturday, May 18, 13


   View Slide

3. Saturday, May 18, 13


   View Slide

4. Saturday, May 18, 13


   View Slide

5. Hi! I’m @masuidrive.
   • Yuichiro MASUI - Ichi
   • Open source developer, Ruby fun
   • Pukiwiki, Ruby on Rails tutorial movie in
   Japanese, IKEA hacker
   • Furo-grammer (Coding in hot tub)
   • FrogApps, Inc. CTO // ex-Appcelerati
   Saturday, May 18, 13


   View Slide

6. Hi! I’m @masuidrive.
   • Yuichiro MASUI - Ichi
   • Open source developer, Ruby fun
   • Pukiwiki, Ruby on Rails tutorial movie in
   Japanese, IKEA hacker
   • Furo-grammer (Coding in hot tub)
   • FrogApps, Inc. CTO // ex-Appcelerati
   Saturday, May 18, 13


   View Slide

7. Hi! I’m @masuidrive.
   • Yuichiro MASUI - Ichi
   • Open source developer, Ruby fun
   • Pukiwiki, Ruby on Rails tutorial movie in
   Japanese, IKEA hacker
   • Furo-grammer (Coding in hot tub)
   • FrogApps, Inc. CTO // ex-Appcelerati
   Saturday, May 18, 13


   View Slide

8. Hi! I’m @masuidrive.
   • Yuichiro MASUI - Ichi
   • Open source developer, Ruby fun
   • Pukiwiki, Ruby on Rails tutorial movie in
   Japanese, IKEA hacker
   • Furo-grammer (Coding in hot tub)
   • FrogApps, Inc. CTO // ex-Appcelerati
   ϛΠϧ
   Saturday, May 18, 13


   View Slide

9. Webܥͷํ
   Saturday, May 18, 13


   View Slide

10. εϚϗܥͷํ
    Saturday, May 18, 13


    View Slide

11. ૊ΈࠐΈܥͷํ
    Saturday, May 18, 13


    View Slide

12. mruby
    Saturday, May 18, 13


    View Slide

13. mruby
    • Ruby for less resources
    • ISO/JIS compliant
    • CRuby subset. Not included File, Socket,
    Thread and more ext libraries
    • OS / CPU Independent
    • Not required POSIX, only C99
    Saturday, May 18, 13


    View Slide

14. Configurable
    • Drop off unnecessary features
    • Parser / Compiler
    • Struct, Time, Math, STDIO, Regexp, sprintf
    • Table algorithm - hash or list
    • NaN Boxing
    Saturday, May 18, 13


    View Slide

15. mruby target
    • Embedded
    • Digital Appliance
    • Game console
    • Vendor machine
    • Bundle with applications
    Saturday, May 18, 13


    View Slide

16. mruby target
    Saturday, May 18, 13


    View Slide

17. mruby target
    Saturday, May 18, 13


    View Slide

18. mruby target
    Saturday, May 18, 13


    View Slide

19. mruby target
    • CPU - 32bit, FPU
    • Memory - 256KB - 1MB
    • OS
    Saturday, May 18, 13


    View Slide

20. mruby internals
    • VM structure - Multi VM instance
    • No C global variable
    • Generational incremental GC (Mark&Sweep)
    • Not thread safe
    • Build system build on CRuby
    Saturday, May 18, 13


    View Slide

21. development
    • Spring 2010 - Subsidy
    • Matz, some companies and colleges
    • April 22, 2012 - Publish to GitHub
    • mruby got some contributors
    Saturday, May 18, 13


    View Slide

22. mrbgems
    • Daniel (@bovi) created extension package
    feature at end of Nov 2012.
    • Easy to install from GitHub
    • Supported cross build
    • Already provided 40+ gems
    Saturday, May 18, 13


    View Slide

23. mrbgems
    • Daniel (@bovi) created extension package
    feature at end of Nov 2012.
    • Easy to install from GitHub
    • Supported cross build
    • Already provided 40+ gems
    Saturday, May 18, 13


    View Slide

24. topics
    • mrbgems - gembox
    • Refactoring for portability
    Saturday, May 18, 13


    View Slide

25. wrap up
    • mruby͕໨ࢦ͢ͷ͸਺೥ޙͷੈք
    • CRuby͸Ruby͕ओɺmruby͸ै
    • ૊ΈࠐΉઌ͸σόΠε͚ͩ͡Όͳ͍
    • ࢓ࠐΉͳΒࠓ
    Saturday, May 18, 13


    View Slide

26. Saturday, May 18, 13


    View Slide

27. Saturday, May 18, 13


    View Slide

28. When will you release RiteVM? I want to run it on iOS/
    Android.
    It’s mruby. I need more time to make public (probably
    June) Should I give you access to private repos?
    Yes! I want to try it!
    What’s your github account?
    Saturday, May 18, 13


    View Slide

29. Saturday, May 18, 13


    View Slide

30. What’s MobiRuby?
    • iOS app development kit on mruby
    • MIT license
    • Can access native functions
    • Have plan for Android version
    • Already released MobiRuby based app
    • Search “mobiruby” in AppStore on iOS
    Saturday, May 18, 13


    View Slide

31. Vision
    • Provide Ruby power to Mobile devices
    • Meta programming is most important Ruby
    power
    Saturday, May 18, 13


    View Slide

32. Hello world
    \
    class  Cocoa::MyAlertView  <  Cocoa::UIAlertView
           define  C::Void,  :alertView,  Cocoa::Object,
               :clickedButtonAtIndex,  C::Int  do  |me,  index|
                   if  index.to_i  ==  1
                           app  =  Cocoa::UIApplication._sharedApplication
                           urlstr  =  "http://mobiruby.org"
                           url  =  Cocoa::NSURL._URLWithString(urlstr)
                           app._openURL  url
                   end
           end
    end
    alert  =  Cocoa::MyAlertView._alloc._initWithTitle  "Hello",
       :message,  "I  am  MobiRuby",
       :delegate,  nil,
       :cancelButtonTitle,  "I  know!",
       :otherButtonTitles,  "What's?",  nil
    alert._setDelegate  alert
    alert._show
    Saturday, May 18, 13


    View Slide

33. Hello world
    \
    class  Cocoa::MyAlertView  <  Cocoa::UIAlertView
           define  C::Void,  :alertView,  Cocoa::Object,
               :clickedButtonAtIndex,  C::Int  do  |me,  index|
                   if  index.to_i  ==  1
                           app  =  Cocoa::UIApplication._sharedApplication
                           urlstr  =  "http://mobiruby.org"
                           url  =  Cocoa::NSURL._URLWithString(urlstr)
                           app._openURL  url
                   end
           end
    end
    alert  =  Cocoa::MyAlertView._alloc._initWithTitle  "Hello",
       :message,  "I  am  MobiRuby",
       :delegate,  nil,
       :cancelButtonTitle,  "I  know!",
       :otherButtonTitles,  "What's?",  nil
    alert._setDelegate  alert
    alert._show
    Saturday, May 18, 13


    View Slide

34. class  Cocoa::MyAlertView  <  Cocoa::UIAlertView
       define  C::Void,  :alertView,  Cocoa::Object,
           :clickedButtonAtIndex,  C::Int  do  |me,  idx|
           if  idx.to_i  ==  1
               app  =  Cocoa::UIApplication._sharedApplica
               urlstr  =  "http://mobiruby.org"
               url  =  Cocoa::NSURL._URLWithString(urlstr)
               app._openURL  url
           end
       end
    end
    class  Cocoa::MyAlertView  <  Cocoa::UIAlertView
       define  C::Void,  :alertView,  Cocoa::Object,
           :clickedButtonAtIndex,  C::Int  do  |me,  idx|
           if  idx.to_i  ==  1
               app  =  Cocoa::UIApplication._sharedApplica
               urlstr  =  "http://mobiruby.org"
               url  =  Cocoa::NSURL._URLWithString(urlstr)
               app._openURL  url
           end
       end
    end
    Hello world - 1st half
    Saturday, May 18, 13


    View Slide

35. class  Cocoa::MyAlertView  <  Cocoa::UIAlertView
       define  C::Void,  :alertView,  Cocoa::Object,
           :clickedButtonAtIndex,  C::Int  do  |me,  idx|
           if  idx.to_i  ==  1
               app  =  Cocoa::UIApplication._sharedApplica
               urlstr  =  "http://mobiruby.org"
               url  =  Cocoa::NSURL._URLWithString(urlstr)
               app._openURL  url
           end
       end
    end
    Hello world - 1st half
    class  Cocoa::MyAlertView  <  Cocoa::UIAlertView
    Saturday, May 18, 13


    View Slide

36. class  Cocoa::MyAlertView  <  Cocoa::UIAlertView
       define  C::Void,  :alertView,  Cocoa::Object,
           :clickedButtonAtIndex,  C::Int  do  |me,  idx|
           if  idx.to_i  ==  1
               app  =  Cocoa::UIApplication._sharedApplica
               urlstr  =  "http://mobiruby.org"
               url  =  Cocoa::NSURL._URLWithString(urlstr)
               app._openURL  url
           end
       end
    end
       define  C::Void,  :alertView,  Cocoa::Object,
           :clickedButtonAtIndex,  C::Int  do  |me,  idx|
    Hello world - 1st half
    Saturday, May 18, 13


    View Slide

37. Hello world - 2nd half
    \
    alert  =  Cocoa::MyAlertView._alloc.
       _initWithTitle  "Hello",
       :message,  "I  am  MobiRuby",
       :delegate,  nil,
       :cancelButtonTitle,  "I  know!",
       :otherButtonTitles,  "What's?",  nil
    alert._setDelegate  alert
    alert._show
    alert  =  Cocoa::MyAlertView._alloc.
       _initWithTitle  "Hello",
       :message,  "I  am  MobiRuby",
       :delegate,  nil,
       :cancelButtonTitle,  "I  know!",
       :otherButtonTitles,  "What's?",  nil
    alert._setDelegate  alert
    alert._show
    Saturday, May 18, 13


    View Slide

38. Hello world - 2nd half
    \
    alert  =  Cocoa::MyAlertView._alloc.
       _initWithTitle  "Hello",
       :message,  "I  am  MobiRuby",
       :delegate,  nil,
       :cancelButtonTitle,  "I  know!",
       :otherButtonTitles,  "What's?",  nil
    alert._setDelegate  alert
    alert._show
    alert  =  Cocoa::MyAlertView._alloc.
       _initWithTitle  "Hello",
       :message,  "I  am  MobiRuby",
       :delegate,  nil,
       :cancelButtonTitle,  "I  know!",
       :otherButtonTitles,  "What's?",  nil
    alert._setDelegate  alert
    alert._show
    Saturday, May 18, 13


    View Slide

39. Next step
    \
    class  MyAlertView  <  MobiRuby::AlertView
       title  "Hello"
       message  "I  am  MobiRuby"
       cancelButton  "I  know!"  do
       end
       button  "What's?"  do
           openURL  "http://mobiruby.org"
       end
    end
    alert  =  MyAlertView.new
    alert.show
    Saturday, May 18, 13


    View Slide

40. MobiRuby stack
    iOS
    mruby
    mruby-
    cfunc
    Your code
    mruby-
    cocoa
    mobiruby-
    common
    mobiruby-
    ios
    Saturday, May 18, 13


    View Slide

41. MobiRuby stack
    iOS
    mruby
    mruby-
    cfunc
    Your code
    mruby-
    cocoa
    mobiruby-
    common
    mobiruby-
    ios
    Saturday, May 18, 13


    View Slide

42. MobiRuby stack
    iOS
    mruby
    mruby-
    cfunc
    Your code
    mruby-
    cocoa
    mobiruby-
    common
    mobiruby-
    ios
    Saturday, May 18, 13


    View Slide

43. mruby-cfunc
    • C function bridge for mruby
    • Call C based function directly
    • Based on libFFI
    • Same as Ruby/DL library on CRuby
    Saturday, May 18, 13


    View Slide

44. mruby-cfunc
    str  =  "STRING"
    CFunc::call(CFunc::Void,  "puts",  str)
    STRING
    Saturday, May 18, 13


    View Slide

45. mruby-cfunc
    str  =  "STRING"
    ptr  =  CFunc::Pointer.malloc(7)
    result_ptr  =  CFunc::call(CFunc::Pointer,
    "strcpy",  ptr,  str)
    ptr.to_s
    -­‐>  “STRING”
    Saturday, May 18, 13


    View Slide

46. mruby-cfunc
    \
    class  TestStruct  <  CFunc::Struct
           define  CFunc::SInt8,    :x,
                         CFunc::SInt16,  :y
    end
    test  =  TestStruct.new
    test[:x]  =  10
    Saturday, May 18, 13


    View Slide

47. MobiRuby stack
    iOS
    mruby
    mruby-
    cfunc
    Your code
    mruby-
    cocoa
    mobiruby-
    common
    mobiruby-
    ios
    Saturday, May 18, 13


    View Slide

48. mruby-cocoa
    • Cocoa bridge for mruby
    • Use Cocoa functions transparently
    • Based on mruby-cfunc and Cocoa runtime
    • Manipulate Cocoa objects
    • Create class/instance, inherit existing classes
    • Garbage collection
    Saturday, May 18, 13


    View Slide

49. Bridge Cocoa runtime
    • Objective-C has powerful runtime features
    • Create and modify class dynamically
    • ObjC class <- Ruby class <- ObjC class
    • ObjC value interconverted with Ruby value
    • Supported delegate and blocks
    Saturday, May 18, 13


    View Slide

50. Memory
    management
    • Objective-C - Reference count
    • mruby - Mark & Sweep
    • Swizzled Objective-C “release” method
    • awful performance bottleneck
    Saturday, May 18, 13


    View Slide

51. MobiRuby stack
    iOS
    mruby
    mruby-
    cfunc
    Your code
    mruby-
    cocoa
    mobiruby-
    common
    mobiruby-
    ios
    Saturday, May 18, 13


    View Slide

52. mobiruby-common
    • Will be common utilities with Android ver.
    • require method
    • Some POSIX based functions
    Saturday, May 18, 13


    View Slide

53. MobiRuby stack
    iOS
    mruby
    mruby-
    cfunc
    Your code
    mruby-
    cocoa
    mobiruby-
    common
    mobiruby-
    ios
    Saturday, May 18, 13


    View Slide

54. mobiruby-ios
    • iOS specific utilities
    • Bootstrap
    • Xcode integration
    • Wrapped classes
    Saturday, May 18, 13


    View Slide

55. Wrapped APIs
    \
    class  MyAlertView  <  MobiRuby::AlertView
       title  "Hello"
       message  "I  am  MobiRuby"
       cancelButton  "I  know!"  do
       end
       button  "What's?"  do
           openURL  "http://mobiruby.org"
       end
    end
    alert  =  MyAlertView.new
    alert.show
    Saturday, May 18, 13


    View Slide

56. Road map
    • Finished building Cocoa bridge
    • Fix bugs, Improvement
    • Packaging
    • Documentation
    • Build wrapped APIs
    Saturday, May 18, 13


    View Slide

57. Road map
    • Finished building Cocoa bridge
    • Fix bugs, Improvement
    • Packaging
    • Documentation
    • Build wrapped APIs
    Version 1
    Q1 2013
    Saturday, May 18, 13


    View Slide

58. Road map
    • Finished building Cocoa bridge
    • Fix bugs, Improvement
    • Packaging
    • Documentation
    • Build wrapped APIs
    Version 1
    Summer
    2013
    Saturday, May 18, 13


    View Slide

59. Current status
    • Already MobiRuby based app is in AppStore
    • Finally released alpha 1
    • Can call almost iOS native functions
    • Writing test codes
    • It's only for iOS and mruby hackers
    Saturday, May 18, 13


    View Slide

60. Pros.
    • Ruby power
    • Based on Matz implemented Ruby
    • mrbgems
    • MIT license
    • Compact (~4000 lines)
    Saturday, May 18, 13


    View Slide

61. Cons.
    • Unstable
    • Less classes / functions
    • Don't have debugging feature
    • Need to understand iOS and Cocoa
    Saturday, May 18, 13


    View Slide

62. Topics
    • ΋ͷͮ͘ΓΛऔΓרٕ͘ज़
    • Ϋϥ΢υϑΝ΢ϯσΟϯά
    Saturday, May 18, 13


    View Slide

63. PCܥٕज़ͷԠ༻
    • ૊ΈࠐΈ༻؀ڥ͸ҰੲલͷPCฒ
    • ։ൃ؀ڥ
    • ARM
    • खܰͳ࣮ߦ؀ڥ
    • Arduino, Raspberry Pi
    Saturday, May 18, 13


    View Slide

64. ݸਓతͳτϐοΫ
    • Bluetooth 4.0
    • BLE
    • iOS6Ͱαϙʔτ
    Saturday, May 18, 13


    View Slide

65. ਎ମੑ
    • ΋ͷͮ͘Γͷָ͠͞͸਎ମੑ
    • ͭ͘Δ਎ମੑ
    • σόΠεͷ਎ମੑ
    Saturday, May 18, 13


    View Slide

66. Saturday, May 18, 13


    View Slide

67. झຯ͔Β
    • झຯ͔Β࢓ࣄͷੈք͕มΘΔ
    • PCͰ͸90೥୅ʹ஍֪มಈ͕ىͬͨ͜
    Saturday, May 18, 13


    View Slide

68. ڥքʹ͍Δ
    • ෳ਺ͷٕज़΍ཁٻͷڥքʹ৽͍͠࢓ࣄ͕ੜ·
    ΕΔ
    • ໘ന͍ద౓ͳαΠζͷ໰୊Λݟ͚ͭΔ
    Saturday, May 18, 13


    View Slide

69. Ϋϥ΢υϑΝ΢ϯσΟϯά
    • Kick starterɹ
    • ੜ࢈ͷϋʔυϧ͕େ͖͘Լ͕Δ
    • ϦϦʔεޙʹࠅධΛड͚Δ͜ͱ΋͋Δ
    Saturday, May 18, 13


    View Slide

70. Saturday, May 18, 13


    View Slide

71. ·ͬͨؔ͘܎ͳ͍࿩
    http://wri.pe
    Saturday, May 18, 13


    View Slide

72. Thank you
    • Logo design: Maylis Agniel
    • English review: @tenderlove and ebi-chan
    • http://mobiruby.org
    • http://github.com/mobiruby
    • http://twitter.com/mobiruby
    • http://fb.me/mobiruby
    Saturday, May 18, 13


    View Slide
