1. Scalable
   Application rchitecture
   github.com/mgechev
   twitter.com/mgechev
   blog.mgechev.com
   Minko Gechev


   View Slide

2. View Slide

3. View Slide

4. View Slide

5. Hold on for the
   second edition!


   View Slide

6. Story Time


   View Slide

7. Disclaimer
   • High-level architecture, doesn’t define interfaces
   • Suggestions, not rules
   • Works for me, may not work for you


   View Slide

8. Design Architecture
   ⚡


   View Slide

9. – Martin Fowler
   “…decisions that are hard
   to change…”
   Architecture


   View Slide

10. High-level constraints
    of the project


    View Slide

11. Dynamic
    requirements


    View Slide

12. View Slide

13. Scalable & flexible
    data layer


    View Slide

14. Data layer
    • RESTful API
    • WebSocket application service
    • WebRTC data-channel
    • Various data packages
    • Bert-RPC
    • JSON
    • etc.


    View Slide

15. Scalable
    team & codebase


    View Slide

16. View Slide

17. High-level decisions
    for the architecture


    View Slide

18. Dynamic Requirements
    Scalable & flexible data layer
    Scalable team & codebase


    View Slide

19. Dynamic Requirements
    Scalable & flexible data layer
    Scalable team & codebase


    View Slide

20. abstraction |əbˈstrakʃ(ə)n|
    noun [ mass noun ]
    …
    4 the process of considering something
    independently of its associations or attributes: the
    question cannot be considered in abstraction from
    the historical context in which it was raised.


    View Slide

21. WebRTC
    Gateway
    WebSocket
    Gateway


    View Slide

22. Gateway
    WebRTC
    Gateway
    WebSocket
    Gateway


    View Slide

23. Dynamic Requirements
    Scalable & flexible data layer
    Scalable team & codebase


    View Slide

24. Explicitness


    View Slide

25. Explicitness
    • Explicit state mutation
    • Explicit package mapping
    • Others…


    View Slide

26. Dynamic Requirements
    Scalable & flexible data layer
    Scalable team & codebase


    View Slide

27. Consistent
    state management


    View Slide

28. Consistent state
    • Domain objects should:
    • Have a single instance
    • Explicit update


    View Slide

29. Single instance !=>


    View Slide

30. Single instance !=> Identity map


    View Slide

31. Single instance !=> Identity map
    Explicit update !=>


    View Slide

32. Single instance !=> Identity map
    Explicit update !=> Strict conventions


    View Slide

33. redux++


    View Slide

34. redux++


    View Slide

35. Sample Tech Stack
    • Angular 2
    • RxJS
    • ngrx
    • TypeScript
    • ImmutableJS


    View Slide

36. Sample application


    View Slide

37. View Slide

38. View Slide

39. High-level architecture


    View Slide

40. UI components
    Façade (Active Record-like)
    (provides simplified interface to the components)
    State management Async services
    Gateways
    (HTTP, WS, WebRTC)
    Commands
    (RESTful, RPC)
    Payloads
    (BERT, JSON)
    Store Reducers


    View Slide

41. UI components
    Façade (Active Record-like)
    (provides simplified interface to the components)
    State management Async services
    Gateways
    (HTTP, WS, WebRTC)
    Commands
    (RESTful, RPC)
    Payloads
    (BERT, JSON)
    Store Reducers


    View Slide

42. UI components
    Façade (Active Record-like)
    (provides simplified interface to the components)
    State management Async services
    Gateways
    (HTTP, WS, WebRTC)
    Commands
    (RESTful, RPC)
    Payloads
    (BERT, JSON)
    Store Reducers


    View Slide

43. UI components
    Façade (Active Record-like)
    (provides simplified interface to the components)
    State management Async services
    Gateways
    (HTTP, WS, WebRTC)
    Commands
    (RESTful, RPC)
    Payloads
    (BERT, JSON)
    Store Reducers


    View Slide

44. UI components
    Façade (Active Record-like)
    (provides simplified interface to the components)
    State management Async services
    Gateways
    (HTTP, WS, WebRTC)
    Commands
    (RESTful, RPC)
    Payloads
    (BERT, JSON)
    Store Reducers


    View Slide

45. UI components


    View Slide

46. UI components
    Façade (Active Record-like)
    (provides simplified interface to the components)
    State management Async services
    Gateways
    (HTTP, WS, WebRTC)
    Commands
    (RESTful, RPC)
    Payloads
    (BERT, JSON)
    Store Reducers


    View Slide

47. game.component.ts
    @Component({
    selector: 'sd-game',
    template: `...`,
    styles: [...]
    })
    export class GameComponent {
    constructor(private _model: GameModel) {}
    changeHandler(data: string) {
    this._model.onProgress(data);
    }
    }


    View Slide

48. game.component.ts
    @Component({
    selector: 'sd-game',
    template: `...`,
    styles: [...]
    })
    export class GameComponent {
    constructor(private _model: GameModel) {}
    changeHandler(data: string) {
    this._model.onProgress(data);
    }
    }


    View Slide

49. game.component.ts
    @Component({
    selector: 'sd-game',
    template: `...`,
    styles: [...]
    })
    export class GameComponent {
    constructor(private _model: GameModel) {}
    changeHandler(data: string) {
    this._model.onProgress(data);
    }
    }


    View Slide

50. UI components
    • Simple presentational logic
    • As stateless as possible
    • Delegate business logic to models


    View Slide

51. UI components
    Façade (Active Record-like)
    (provides simplified interface to the components)
    State management Async services
    Gateways
    (HTTP, WS, WebRTC)
    Commands
    (RESTful, RPC)
    Payloads
    (BERT, JSON)
    Store Reducers


    View Slide

52. class GameModel extends Model {
    game$: Observable;
    constructor(protected _store: Store,
    @Inject(AsyncService) _services: AsyncService[]) {
    super(_services || []);
    this.game$ = this._store.select('game');
    }
    completeGame(time: number, text: string) {
    const action = GameActions.completeGame(time, text);
    this.performAsyncAction(action)
    .subscribe(() => this._store.dispatch(action));
    }
    }
    game.model.ts


    View Slide

53. game.model.ts
    class GameModel extends Model {
    game$: Observable;
    constructor(protected _store: Store,
    @Inject(AsyncService) _services: AsyncService[]) {
    super(_services || []);
    this.game$ = this._store.select('game');
    }
    completeGame(time: number, text: string) {
    const action = GameActions.completeGame(time, text);
    this.performAsyncAction(action)
    .subscribe(() => this._store.dispatch(action));
    }
    }


    View Slide

54. class GameModel extends Model {
    game$: Observable;
    constructor(protected _store: Store,
    @Inject(AsyncService) _services: AsyncService[]) {
    super(_services || []);
    this.game$ = this._store.select('game');
    }
    completeGame(time: number, text: string) {
    const action = GameActions.completeGame(time, text);
    this.performAsyncAction(action)
    .subscribe(() => this._store.dispatch(action));
    }
    }
    game.model.ts


    View Slide

55. BaseModel
    Model B
    Model A
    State tree Component tree
    state stream (game$)
    references (store.select(…))


    View Slide

56. class GameModel extends Model {
    game$: Observable;
    constructor(protected _store: Store,
    @Inject(AsyncService) _services: AsyncService[]) {
    super(_services || []);
    this.game$ = this._store.select('game');
    }
    completeGame(time: number, text: string) {
    const action = GameActions.completeGame(time, text);
    this.performAsyncAction(action)
    .subscribe(() => this._store.dispatch(action));
    }
    }
    game.model.ts


    View Slide

57. class GameModel extends Model {
    game$: Observable;
    constructor(protected _store: Store,
    @Inject(AsyncService) _services: AsyncService[]) {
    super(_services || []);
    this.game$ = this._store.select('game');
    }
    completeGame(time: number, text: string) {
    const action = GameActions.completeGame(time, text);
    this.performAsyncAction(action)
    .subscribe(() => this._store.dispatch(action));
    }
    }
    game.model.ts


    View Slide

58. Component
    Model
    ngrx


    View Slide

59. Component
    Model
    completeGame()
    ngrx


    View Slide

60. Component
    Model
    dispatch(action)
    ngrx
    completeGame()


    View Slide

61. Component
    Model
    ngrx
    stateObserver.next(state)
    dispatch(action)
    completeGame()


    View Slide

62. Component
    Model
    stateObserver.next(state)
    dispatch(action)
    ngrx
    completeGame()


    View Slide

63. class GameModel extends Model {
    game$: Observable;
    constructor(protected _store: Store,
    @Inject(AsyncService) _services: AsyncService[]) {
    super(_services || []);
    this.game$ = this._store.select('game');
    }
    completeGame(time: number, text: string) {
    const action = GameActions.completeGame(time, text);
    this.performAsyncAction(action)
    .subscribe(() => this._store.dispatch(action));
    }
    }
    game.model.ts


    View Slide

64. Models (Façade)
    • Map the state stream
    • Delegate business logic to reducers
    • Delegate data-access logic to async services


    View Slide

65. Beware for violations of the SRP


    View Slide

66. UI components
    Façade (Active Record-like)
    (provides simplified interface to the components)
    State management Async services
    Gateways
    (HTTP, WS, WebRTC)
    Commands
    (RESTful, RPC)
    Payloads
    (BERT, JSON)
    Store Reducers


    View Slide

67. Component
    Model
    stateObserver.next(state)
    dispatch(action)
    ngrx
    onProgress()


    View Slide

68. ngrx
    reducers
    dispatch(action)
    State tree
    Action
    New state
    New state


    View Slide

69. game.reducer.ts
    export const gameReducer =
    (state: any = initialState.get('game'),
    action: Action) => {
    switch (action.type) {
    case START_GAME:
    state = fromJS({});
    break;
    case GAME_PROGRESS:
    state = state.set('currentText',
    action.payload.text);
    break;
    }
    return state;
    };


    View Slide

70. game.reducer.ts
    export const gameReducer =
    (state: any = initialState.get('game'),
    action: Action) => {
    switch (action.type) {
    case START_GAME:
    state = fromJS({});
    break;
    case GAME_PROGRESS:
    state = state.set('currentText',
    action.payload.text);
    break;
    }
    return state;
    };


    View Slide

71. game.reducer.ts
    export const gameReducer =
    (state: any = initialState.get('game'),
    action: Action) => {
    switch (action.type) {
    case START_GAME:
    state = fromJS({});
    break;
    case GAME_PROGRESS:
    state = state.set('currentText',
    action.payload.text);
    break;
    }
    return state;
    };


    View Slide

72. game.reducer.ts
    export const gameReducer =
    (state: any = initialState.get('game'),
    action: Action) => {
    switch (action.type) {
    case START_GAME:
    state = fromJS({});
    break;
    case GAME_PROGRESS:
    state = state.set('currentText',
    action.payload.text);
    break;
    }
    return state;
    };


    View Slide

73. game.component.ts
    …
    get currentText$() {
    return this._model.game$
    .map((game: Game) => game.currentText);
    }
    …


    View Slide

74. game.component.ts
    …
    get currentText$() {
    return this._model.game$
    .map((game: Game) => game.currentText);
    }
    …


    View Slide

75. game.component.ts
    …
    get currentText$() {
    return this._model.game$
    .map((game: Game) => game.currentText);
    }
    …


    View Slide

76. game.component.html
    …

    {{ currentText$ | async }}

    …


    View Slide

77. game.component.html
    …

    {{ currentText$ | async }}

    …


    View Slide

78. Reducers
    • Pure functions of the state and an action
    • Implement the business logic


    View Slide

79. Async Services


    View Slide

80. UI components
    Façade (Active Record-like)
    (provides simplified interface to the components)
    State management Async services
    Gateways
    (HTTP, WS, WebRTC)
    Commands
    (RESTful, RPC)
    Payloads
    (BERT, JSON)
    Store Reducers


    View Slide

81. Remote
    Service
    App


    View Slide

82. Remote
    Service
    App


    View Slide

83. Remote
    Service
    App


    View Slide

84. export abstract class AsyncService {
    abstract process(data: Action): Observable;
    }
    base.async-service.ts


    View Slide

85. export class GameP2PService extends AsyncService {
    constructor(private _rtcGateway: WebRTCGateway,
    private _store: Store) {
    _rtcGateway.dataStream
    .map((data: any) => JSON.parse(data.toString()))
    .subscribe((command: any) => {
    command.method === PROGRESS &&
    _store.dispatch(P2PActions.progress(command.payload.text));
    });
    }
    process(action: Action) {
    const commandBuilder = buildP2PCommand(action);
    if (commandBuilder)
    return commandBuilder().invoke();
    }
    }
    game-p2p.async-service.ts


    View Slide

86. export class GameP2PService extends AsyncService {
    constructor(private _rtcGateway: WebRTCGateway,
    private _store: Store) {
    _rtcGateway.dataStream
    .map((data: any) => JSON.parse(data.toString()))
    .subscribe((command: any) => {
    command.method === PROGRESS &&
    _store.dispatch(P2PActions.progress(command.payload.text));
    });
    }
    process(action: Action) {
    const commandBuilder = buildP2PCommand(action);
    if (commandBuilder)
    return commandBuilder().invoke();
    }
    }
    game-p2p.async-service.ts


    View Slide

87. export class GameP2PService extends AsyncService {
    constructor(private _rtcGateway: WebRTCGateway,
    private _store: Store) {
    _rtcGateway.dataStream
    .map((data: any) => JSON.parse(data.toString()))
    .subscribe((command: any) => {
    command.method === PROGRESS &&
    _store.dispatch(P2PActions.progress(command.payload.text));
    });
    }
    process(action: Action) {
    const commandBuilder = buildP2PCommand(action);
    if (commandBuilder)
    return commandBuilder().invoke();
    }
    }
    game-p2p.async-service.ts


    View Slide

88. Async services
    • Map actions to commands
    • Map responses/messages to actions
    • Use an abstract gateway


    View Slide

89. View Slide

90. Recap


    View Slide

91. Async services
    Business facade
    Business logic
    Communication logic
    Immutable app state
    Component tree
    root cmp
    sign-up form
    user
    UserModel
    User Action
    Creator
    signup(data)
    signup(data)
    RESTful Async
    Service
    process(action)
    userReducer
    register()
    RESTful
    CommandBuilder
    build(action)
    Restful
    Command
    Restful
    Gateway
    invoke()
    send()
    creates()
    uses user$
    Stream
    Dependency
    Action (manipulation/method call)
    User registration
    user.email = email
    user.name = name
    uses
    as user$


    View Slide

92. Async services
    Business facade
    Business logic
    Communication logic
    Immutable app state
    Component tree
    root cmp
    sign-up form
    user
    UserModel
    User Action
    Creator
    signup(data)
    RESTful Async
    Service
    process(action)
    userReducer
    register()
    RESTful
    CommandBuilder
    build(action)
    Restful
    Command
    Restful
    Gateway
    invoke()
    send()
    creates()
    uses user$
    Stream
    Dependency
    Action (manipulation/method call)
    User registration
    user.email = email
    user.name = name
    signup(data) uses
    as user$


    View Slide

93. Async services
    Business facade
    Business logic
    Communication logic
    Immutable app state
    Component tree
    root cmp
    sign-up form
    user
    UserModel
    User Action
    Creator
    RESTful Async
    Service
    process(action)
    userReducer
    register()
    RESTful
    CommandBuilder
    build(action)
    Restful
    Command
    Restful
    Gateway
    invoke()
    send()
    creates()
    uses user$
    Stream
    Dependency
    Action (manipulation/method call)
    User registration
    user.email = email
    user.name = name
    signup(data)
    signup(data)
    uses
    as user$


    View Slide

94. Async services
    Business facade
    Business logic
    Communication logic
    Immutable app state
    Component tree
    root cmp
    sign-up form
    user
    UserModel
    User Action
    Creator
    RESTful Async
    Service
    process(action)
    userReducer
    register()
    RESTful
    CommandBuilder
    build(action)
    Restful
    Command
    Restful
    Gateway
    invoke()
    send()
    creates()
    uses user$
    Stream
    Dependency
    Action (manipulation/method call)
    User registration
    user.email = email
    user.name = name
    signup(data)
    signup(data)
    uses
    as user$


    View Slide

95. Async services
    Business facade
    Business logic
    Communication logic
    Immutable app state
    Component tree
    root cmp
    sign-up form
    user
    UserModel
    User Action
    Creator
    RESTful Async
    Service
    process(action)
    userReducer
    register()
    RESTful
    CommandBuilder
    build(action)
    Restful
    Command
    Restful
    Gateway
    invoke()
    send()
    creates()
    uses user$
    Stream
    Dependency
    Action (manipulation/method call)
    User registration
    user.email = email
    user.name = name
    signup(data)
    signup(data)
    uses
    as user$


    View Slide

96. Async services
    Business facade
    Business logic
    Communication logic
    Immutable app state
    Component tree
    root cmp
    sign-up form
    user
    UserModel
    User Action
    Creator
    RESTful Async
    Service
    process(action)
    userReducer
    register()
    RESTful
    CommandBuilder
    build(action)
    Restful
    Command
    Restful
    Gateway
    invoke()
    send()
    creates()
    uses user$
    Stream
    Dependency
    Action (manipulation/method call)
    User registration
    user.email = email
    user.name = name
    signup(data)
    signup(data)
    uses
    as user$


    View Slide

97. Async services
    Business facade
    Business logic
    Communication logic
    Immutable app state
    Component tree
    root cmp
    sign-up form
    user
    UserModel
    User Action
    Creator
    RESTful Async
    Service
    process(action)
    userReducer
    register()
    RESTful
    CommandBuilder
    build(action)
    Restful
    Command
    Restful
    Gateway
    invoke()
    send()
    creates()
    uses user$
    Stream
    Dependency
    Action (manipulation/method call)
    User registration
    user.email = email
    user.name = name
    signup(data)
    signup(data)
    uses
    as user$


    View Slide

98. Async services
    Business facade
    Business logic
    Communication logic
    Immutable app state
    Component tree
    root cmp
    sign-up form
    user
    UserModel
    User Action
    Creator
    RESTful Async
    Service
    process(action)
    userReducer
    register()
    RESTful
    CommandBuilder
    build(action)
    Restful
    Command
    Restful
    Gateway
    invoke()
    send()
    creates()
    uses user$
    Stream
    Dependency
    Action (manipulation/method call)
    User registration
    user.email = email
    user.name = name
    signup(data)
    signup(data)
    uses
    as user$


    View Slide

99. Async services
    Business facade
    Business logic
    Communication logic
    Immutable app state
    Component tree
    root cmp
    sign-up form
    user
    UserModel
    User Action
    Creator
    RESTful Async
    Service
    process(action)
    userReducer
    register()
    RESTful
    CommandBuilder
    build(action)
    Restful
    Command
    Restful
    Gateway
    invoke()
    send()
    creates()
    uses user$
    Stream
    Dependency
    Action (manipulation/method call)
    User registration
    user.email = email
    user.name = name
    signup(data)
    signup(data)
    uses
    as user$


    View Slide

100. Async services
     Business facade
     Business logic
     Communication logic
     Immutable app state
     Component tree
     root cmp
     sign-up form
     user
     UserModel
     User Action
     Creator
     signup(data)
     RESTful Async
     Service
     process(action)
     userReducer
     register()
     RESTful
     CommandBuilder
     build(action)
     Restful
     Command
     Restful
     Gateway
     invoke()
     send()
     creates()
     uses
     as user$
     uses user$
     Stream
     Dependency
     Action (manipulation/method call)
     User registration
     user.email = email
     user.name = name
     signup(data)


     View Slide

101. View Slide

102. Properties…
     • Predictable state management
     • Testable (easy to mock services thanks to DI)
     • Not coupled to any remote service
     • Serializable state usable offline
     • Model can use different services based on context
     • Easy management of async events


     View Slide

103. Properties…
     • Predictable state management
     • Testable (easy to mock services thanks to DI)
     • Not coupled to any remote service
     • Serializable state usable offline
     • Model can use different services based on context
     • Easy management of async events


     View Slide

104. Properties…
     • Predictable state management
     • Testable (easy to mock services thanks to DI)
     • Not coupled to any remote service
     • Serializable state usable offline
     • Model can use different services based on context
     • Easy management of async events


     View Slide

105. Properties…
     • Predictable state management
     • Testable (easy to mock services thanks to DI)
     • Not coupled to any remote service
     • Serializable state usable offline
     • Model can use different services based on context
     • Easy management of async events


     View Slide

106. Properties…
     • Predictable state management
     • Testable (easy to mock services thanks to DI)
     • Not coupled to any remote service
     • Serializable state usable offline
     • Model can use different services based on context
     • Easy management of async events


     View Slide

107. Properties…
     • Predictable state management
     • Testable (easy to mock services thanks to DI)
     • Not coupled to any remote service
     • Serializable state usable offline
     • Model can use different services based on context
     • Easy management of async events


     View Slide

108. Properties…
     • Predictable state management
     • Testable (easy to mock services thanks to DI)
     • Not coupled to any remote service
     • Serializable state usable offline
     • Model can use different services based on context
     • Easy management of async events


     View Slide

109. Resources
     • redux
     • ngrx
     • mgv.io/scalable-architecture
     • mgv.io/scalable-architecture-demo


     View Slide

110. Thank you!
     github.com/mgechev
     twitter.com/mgechev
     blog.mgechev.com


     View Slide
