Learning from Uncurated Regular Expressions for Semantic Type Classification - SiMoD 2023

Significant work has been done on learning regular expressions from a set of data values. Depending on the domain, this approach can be very successful. However, significant time is required to learn these expressions and the resulting expressions can become either very complex or inaccurate in the presence of dirty data. The alternative of manually writing regular expressions becomes unattractive when faced with a large number of values that must be matched.

As an alternative, we propose learning from a large corpus of manually authored, but uncurated regular expressions mined from a public repository. The advantage of this approach is that we are able to extract salient features from a set of strings with limited overhead to feature engineering. Since the set of regular expressions covers a wide range of application domains, we expect them to be widely applicable.

To demonstrate the potential effectiveness of our approach, we train a model using the extracted corpus of regular expressions for the class of semantic type classification. While our approach yields results that are overall inferior to the state-of-the-art, our feature extraction code is an order of magnitude smaller, and our model outperforms a popular existing approach on some classes. We also demonstrate the possibility of using uncurated regular expressions for unsupervised learning.

Transcript

1. Learning from Uncurated Regular Expressions for Semantic Type Classification Michael Mior
2. • Semantic Type Classification • Uncurated Regular Expressions • Applications • Future Work
3. • Semantic Type Classification • Uncurated Regular Expressions • Applications • Future Work
4. Semantic Types ▸ Semantic types result in a more detailed schema than syntactic types ▸ Types should capture semantic similarity between sets of values ▸ Semantic types are much more difficult to infer than syntactic types 4
5. Example 5 Person Dorothy Vaughn Alan Turing Josef Burg Settlement Pittsburgh Edinburgh Johannesburg Salzburg
6. • Semantic Type Classification • Uncurated Regular Expressions • Applications • Future Work
7. Why not regexes? ▸ Regular expressions can’t match many semantic type classes (e.g. cities) ▸ Dirty data could cause a valid regular expression not to match ▸ Even when regexes might work, they can be complicated to write 7
8. Learning regexes ▸ Regular expressions can be learned from sets of examples ▸ Learning can be slow and expressions can be too precise 8 Source: Sherlock: A Deep Learning Approach to Semantic Data Type Detection, Hulsebos et al., 2019
9. Learning regexes 9 Source: Sherlock: A Deep Learning Approach to Semantic Data Type Detection, Hulsebos et al., 2019
10. Regex101 ▸ Users can enter and test regular expressions of various flavors ▸ Importantly, there is a “library” of saved regular expressions ▸ These expressions can be anything 10
13. Why use regexes anyway? ▸ Multiple regular expressions can extract useful information ▸ Each regular expression does not have to be perfect ▸ We don’t necessarily have to write them! 13
14. 14 Multiple regex matching https?:\/\/(www\\.)? (([a-z\-]+)(?:\.com|\.vn|\.co.uk)) \.(jpg|jpeg) http://example.com/image.jpg
15. • Semantic Type Classification • Uncurated Regular Expressions • Applications • Future Work
16. Regexes for learning ▸ Even if we don’t know why each regex is meaningful, we assume it is ▸ Whether a set of values matches a regex gives some semantic information ▸ 16
17. 17 Feature extraction 3-5 K-2 9-12 … PK K-12 PK … KG - 05 PK - 05 KG - 05 … \d+(.*) [a-zA-Z]([a-zA-Z]|[0-9])+ … Input data Regexes Features < 0.8, 0.4, .. > < 0.84, 0.72, .. > < 1.0, 1.0, .. >
18. Supervised learning ▸ Extract regex features from a labeled set of column values ▸ Train a neural network to classify based on the extracted features ▸ Currently, weighted F-1 score is 0.75 compared to 0.9 for Sherlock 18
19. Supervised learning 19
20. Supervised learning 20
21. Unsupervised clustering ▸ Calculate feature vectors from each set of data values ▸ Cluster using DBSCAN ▸ Predefined semantic classes are not required
22. Unsupervised clustering
23. Unsupervised clustering ▸ Consider all semantic classes where our F-1 score > 0.9 ▸ Clustering without supervision, yields an F-1 score of 0.86 ▸ Suggests minimal information is lost by discarding labels
24. • Semantic Type Classification • Uncurated Regular Expressions • Applications • Future Work
25. Future Work ▸ More unsupervised learning ▸ Expanded regular expression corpus ▸ Explaining regular expression matches ▸ Learning expression fragments ▸ Blocking for entity resolution 25
26. Questions? cs.rit.edu/~dataunitylab
27. Feature Selection ▸ Many regexes are probably redundant ▸ Use the top 10 highest Shapley values for each class to select regexes ▸ Retrain the model with fewer regexes 27
28. Feature Selection 28 (\d\D?){10}\b \d\d.-?.\\w.-?.\d\d \b[^ aeiouAEIOU][a-zA-Z]*\b
29. Feature Selection ▸ Final model has 264 regexes ▸ Weighted performance is approximately the same ▸ Some classes have worse performance 29
