Building multiplayer game using Streams (Devoxx UK 2016)

In this talk you will learn how stream-based programming can be used to implement web frontend and multiplayer backend of the classic game: Snake.

Building dynamic applications using imperative approach tends to create lots of unmaintainable code. Stream-based programming tries to solve this problem by introducing fully declarative way of defining application logic. While using streams, you will focus on WHAT needs to be done, not HOW and WHEN.

The talk is divided into 3 parts. In the first part you will learn how to create a frontend of the Snake web game using streams as building blocks. Then, we will move to the server side and use Scala and Akka Stream library to create backend service that will allow the game to be played by multiple players. In the third part, we will discuss reactive streams and how they make asynchronous communication safe.

Transcript

1. Devoxx UK / 09.06.2016
   @miciek
   Building multiplayer game
   using Streams
   Michał
   Płachta


   View Slide

2. Devoxx UK / 09.06.2016
   @miciek
   Streams?
   ● way of defining application logic
   ● focused on data transformations
   ● explicit time dependencies
   ● declarative


   View Slide

3. Devoxx UK / 09.06.2016
   @miciek
   What’s inside?
   ● how frontend web app written
   in streams looks like
   ● how backend app written using
   streams looks like
   ● how do Reactive Streams keep
   our streams safe?


   View Slide

4. Devoxx UK / 09.06.2016
   @miciek
   Meet Snake & Fruit
   Snake
   Fruit


   View Slide

5. Devoxx UK / 09.06.2016
   @miciek
   Our First Stream: “Ticks” stream


   View Slide

6. Devoxx UK / 09.06.2016
   @miciek
   “Directions” stream


   View Slide

7. Devoxx UK / 09.06.2016
   @miciek
   “Snake’s Head Positions” stream


   View Slide

8. Devoxx UK / 09.06.2016
   @miciek
   Stream operators: map & scan
   stream.map(f)
   ● transforms values from
   stream using function f
   ● returns a new stream
   with transformed values
   stream.scan(init, f)
   ● accumulates values
   from stream using
   function f
   ○ f(acc,val)=>new_acc
   ● returns a new stream
   that outputs
   accumulator value


   View Slide

9. Devoxx UK / 09.06.2016
   @miciek
   Once again: the code


   View Slide

10. Devoxx UK / 09.06.2016
    @miciek
    Displaying values from the stream


    View Slide

11. Devoxx UK / 09.06.2016
    @miciek
    Streams are reusable


    View Slide

12. Devoxx UK / 09.06.2016
    @miciek
    Streams & Operators are lazy
    No elements
    or
    No terminal
    function


    View Slide

13. Devoxx UK / 09.06.2016
    @miciek
    “Key presses” stream


    View Slide

14. Devoxx UK / 09.06.2016
    @miciek
    “Left Key Presses” stream


    View Slide

15. Devoxx UK / 09.06.2016
    @miciek
    “Right Key Presses” stream


    View Slide

16. Devoxx UK / 09.06.2016
    @miciek
    Stream operators: filter
    stream.filter(p)
    ● checks each value from
    stream against the
    predicate passed as p
    ● returns a new stream
    that outputs only values
    that satisfy condition p
    Already used:
    ● map(f)
    ● scan(init, f(acc, val))


    View Slide

17. Devoxx UK / 09.06.2016
    @miciek
    “Left Rotations” stream


    View Slide

18. Devoxx UK / 09.06.2016
    @miciek
    “Right Rotations” stream


    View Slide

19. Devoxx UK / 09.06.2016
    @miciek
    “Actions” stream


    View Slide

20. Devoxx UK / 09.06.2016
    @miciek
    Stream operators: merge
    stream.merge(stream2)
    ● stream is merged with
    stream2
    ● returns a new stream that
    outputs values from both
    stream and stream2 as
    they appear
    Already used:
    ● map(f)
    ● scan(init, f(acc, val))
    ● filter(p)


    View Slide

21. Devoxx UK / 09.06.2016
    @miciek
    New “Directions” stream based on user input


    View Slide

22. Devoxx UK / 09.06.2016
    @miciek
    Recap: Old “Directions” stream


    View Slide

23. Devoxx UK / 09.06.2016
    @miciek
    “Directions” stream: Better, but no timing!
    vs


    View Slide

24. Devoxx UK / 09.06.2016
    @miciek
    Stream operators: sampledBy
    stream.sampledBy(stream2)
    ● last value from stream is
    taken when any value
    appears in stream2
    ● returns a new stream that
    outputs values from
    stream sampled by values
    from stream2
    Already used:
    ● map(f)
    ● scan(init, f(acc, val))
    ● filter(p)
    ● merge(stream2)


    View Slide

25. Devoxx UK / 09.06.2016
    @miciek
    “Directions” stream: user input & timing


    View Slide

26. Devoxx UK / 09.06.2016
    @miciek
    “Snake Head Positions”: no change needed


    View Slide

27. Devoxx UK / 09.06.2016
    @miciek
    User moves the snake: the code


    View Slide

28. Devoxx UK / 09.06.2016
    @miciek
    Current implementation
    ● “ticks”
    ● “key presses”
    ● “left key presses”
    ● “right key presses”
    ● “left rotations”
    ● “right rotations”
    ● “actions”
    ● “dir changes”
    ● “directions”
    ● “snake head
    positions”
    + map, scan,
    filter, merge &
    sampledBy
    10 streams


    View Slide

29. Devoxx UK / 09.06.2016
    @miciek
    “Snakes” stream


    View Slide

30. Devoxx UK / 09.06.2016
    @miciek
    Stream operators: slidingWindow
    stream.slidingWindow(n)
    ● aggregate last n values
    ● returns a new stream that
    outputs arrays of last n
    values from the stream
    ● can be implemented using
    scan
    Already used:
    ● map(f)
    ● scan(init, f(acc, val))
    ● filter(p)
    ● merge(stream2)
    ● sampledBy(stream2)


    View Slide

31. Devoxx UK / 09.06.2016
    @miciek
    Quiz: Eating a fruit?
    using 6 operators
    ● map(f)
    ● scan(init, f(acc, val))
    ● filter(p)
    ● merge(stream2)
    ● sampledBy(stream2)
    ● slidingWindow(n)
    & 11 streams
    ● “ticks”
    ● “key presses”
    ● “left key presses”
    ● “right key presses”
    ● “left rotations”
    ● “right rotations”
    ● “actions”
    ● “direction changes”
    ● “directions”
    ● “snake head positions”
    ● “snakes”


    View Slide

32. Devoxx UK / 09.06.2016
    @miciek
    “Fruit eaten events” stream


    View Slide

33. Devoxx UK / 09.06.2016
    @miciek
    Frontend in action!


    View Slide

34. Devoxx UK / 09.06.2016
    @miciek
    Architecture: 11 streams, 2 ins & 2 outs


    View Slide

35. Devoxx UK / 09.06.2016
    @miciek
    Snake’s going multiplayer


    View Slide

36. Devoxx UK / 09.06.2016
    @miciek
    Snake Server App Requirements
    ● client must send snake positions to the server each time it
    changes
    ● server must generate fruits
    ● server must keep scores
    ● server must broadcast:
    ○ positions of all snakes to other players
    ○ positions of fruits to all players
    ○ current scoreboard to all players


    View Slide

37. Devoxx UK / 09.06.2016
    @miciek
    Let’s design Server App Flow!
    one player flow Game Event


    View Slide

38. Devoxx UK / 09.06.2016
    @miciek
    WebSocket connected to the Flow


    View Slide

39. Devoxx UK / 09.06.2016
    @miciek
    WebSocket as a stream: Server App


    View Slide

40. Devoxx UK / 09.06.2016
    @miciek
    Snake App Flow (one player)


    View Slide

41. Devoxx UK / 09.06.2016
    @miciek
    Let’s implement Server Flow for one player


    View Slide

42. Devoxx UK / 09.06.2016
    @miciek
    Moved to server: “Fruit eaten events” stream


    View Slide

43. Devoxx UK / 09.06.2016
    @miciek
    “Fruits” stream


    View Slide

44. Devoxx UK / 09.06.2016
    @miciek
    “Fruits” stream using Akka Stream


    View Slide

45. Devoxx UK / 09.06.2016
    @miciek
    “Score updates” stream


    View Slide

46. Devoxx UK / 09.06.2016
    @miciek
    “Scores” stream


    View Slide

47. Devoxx UK / 09.06.2016
    @miciek
    “Scores” stream using Akka Stream


    View Slide

48. Devoxx UK / 09.06.2016
    @miciek
    Game Logic Server Flow


    View Slide

49. Devoxx UK / 09.06.2016
    @miciek
    Game Logic Flow using Akka Stream


    View Slide

50. Devoxx UK / 09.06.2016
    @miciek
    Merging Player Flows outputs


    View Slide

51. Devoxx UK / 09.06.2016
    @miciek
    Server app flow using Akka Stream


    View Slide

52. Devoxx UK / 09.06.2016
    @miciek
    Backend in action!


    View Slide

53. Devoxx UK / 09.06.2016
    @miciek
    What if there are thousands of players?


    View Slide

54. Devoxx UK / 09.06.2016
    @miciek
    Crossing Async Boundary
    Push Model
    ● not safe when
    Subscriber slower
    ● perfect when
    Subscriber faster
    ● too slow when
    Subscriber faster
    ● perfect when
    Subscriber slower
    Pull Model


    View Slide

55. Devoxx UK / 09.06.2016
    @miciek
    Reactive Streams
    Streams
    with
    supply & demand
    ● “as fast as possible, but not faster”
    ● consumer wants to pull elements (= demand)
    ● only then publisher can push
    ○ it supplies elements until demand is satisfied


    View Slide

56. Devoxx UK / 09.06.2016
    @miciek
    Reactive Streams
    Lack of demand
    =
    Backpressure


    View Slide

57. Devoxx UK / 09.06.2016
    @miciek
    Example of Reactive Streams


    View Slide

58. Devoxx UK / 09.06.2016
    @miciek
    Reactive Streams


    View Slide

59. Devoxx UK / 09.06.2016
    @miciek
    Reactive Streams API
    public interface Publisher {
    public void subscribe(Subscriber super T> s);
    }
    public interface Subscriber {
    public void onSubscribe(Subscription s);
    public void onNext(T t);
    public void onError(Throwable t);
    public void onComplete();
    }
    public interface Subscription {
    public void request(long n);
    public void cancel();
    }
    public interface Processor extends Subscriber, Publisher {}


    View Slide

60. Devoxx UK / 09.06.2016
    @miciek
    Simple API, hard implementation...
    https://github.com/reactive-streams/reactive-streams-jvm/blob/v1.0.0/README.md#specification


    View Slide

61. Devoxx UK / 09.06.2016
    @miciek
    Reactive Streams API implementations
    ● Project Reactor
    ● Ratpack
    ● Vert.x
    ● Slick
    ● Akka Stream
    ● JDK 9
    ● Integrations:
    ○ Kafka,
    ○ Mongo,
    ○ Cassandra


    View Slide

62. Devoxx UK / 09.06.2016
    @miciek
    Akka Stream model
    Publisher => Source
    Processor => Flow
    Subscriber => Sink
    Our Snake implementation uses
    Reactive Streams!


    View Slide

63. Devoxx UK / 09.06.2016
    @miciek
    ● NO
    ○ frontend is pushing every 100ms
    ● Possible solutions:
    ○ Reactive Streams web frameworks?
    ○ conflate/expand?
    ○ buffer between frontend & backend?
    Is Snake Multiplayer safe?


    View Slide

64. Devoxx UK / 09.06.2016
    @miciek
    Links
    Build YOUR OWN Snake using Streams - blog post (step-by-step tutorial)
    michalplachta.com/2016/05/11/reactive-ui-by-example/
    Client Side Code github.com/miciek/web-snake-react-bacon
    Server Side Code github.com/miciek/snake-multiplayer-akka-streams
    Play with streams and operators! rxmarbles.com/
    Akka Streams doc.akka.io/docs/akka/2.4.4/scala/stream/
    BaconJS - streams in JavaScript baconjs.github.io/


    View Slide

65. Devoxx UK / 09.06.2016
    @miciek
    Building Snake using Streams
    Michał
    Płachta
    THANK
    YOU
    www.michalplachta.com


    View Slide
