  1. NRP
    Planning
    Concepts & Tutorial
    http://mikorizal.org

    View Slide

  2. Setup
    Organization
    Plan Work
    Purchase
    Inputs
    Contribute
    Funds
    Distribute
    Income
    Coordinate
    Work
    Create
    Recipes
    Setup
    Resource
    Types
    Exchange
    Resources
    Create
    Resources
    Planning the work is not absolutely required in the NRP system….. but you really should do it!
    ● It makes it a lot easier for everyone to log their work
    ● It makes it a lot easier for everyone to coordinate their work
    ● It makes it a lot easier to know what inputs to purchase
    ● It makes it possible for people to see where they can plug into the network’s work
    Planning fits into the NRP here...

    View Slide

  3. NRP has 3 levels...and they go together like so
    Reality
    Plan
    Recipe
    Input
    Event
    Output
    Event
    Resource
    Input
    Event
    Resource
    Process
    Planned
    Input
    Planned
    Output
    Planned
    Input
    Process
    Process
    Type
    Input
    Type
    Output
    Type
    Resource
    Type
    Input
    Type
    Resource
    Type
    Process
    Type
    The Plan level depends on Recipes and prepares for Reality.

    View Slide

  4. Planning in NRP has the following purposes:
    ● figure out and explain what needs to be done
    ○ resources to be created
    ○ work to do
    ○ resources that are needed
    ● lay out process flows as a framework for coordinating work
    ● provide signals of work to do, resources that have been created or need to be obtained,
    problems that have arisen, and potential solutions to those problems
    ● and provide clear and easy ways for people to log their work.
    In other words, if you plan effectively, nobody should ever need to go looking for what to do. It
    should just come to them. And they will always be able to see the context and how they fit in.
    Planning Overview

    View Slide

  5. Also, don’t think of planning as some top-down command-and-control situation. The plans offer
    opportunities for people to work. The people choose what to do. The plans themselves can be
    created by individuals or groups (as in meetings) or generated automatically from signals of
    demand.
    There are some things that may seem complex in this tutorial, coming from the ways that
    networks do different kinds of work. And there are multiple paths through the system for planning
    in different situations. But planning follows the same basic pattern and all paths lead to the same
    place.
    We can’t emphasize enough that your lives will be a lot easier if you create recipes to use in your
    planning. Recipes define how various tasks or types of work are done. They are used to create
    the plans. Recipes hide a lot of the complexity in plans, and they only have to be defined once.
    (See the NRP Recipe Tutorial for more details.)
    Planning Overview

    View Slide

  6. Planning Overview
    Different plans follow different patterns of work based on the type of recipe.
    These can be:
    ● Manufacturing / assembly plans: a tree-like structure of processes held together by their
    inputs and outputs, where the output of one process is the input to another, leading to the
    final product or resource
    ● Workflow plans: one product or resource going through multiple stages before it is
    complete, each stage being a process that adds value to the resource
    ● Resource type list plans: a group of recipes that create different products or resources and
    can be executed in parallel, but are all part of one goal
    Plans can also be created without recipes:
    ● Single process plans
    ● To-do’s

    View Slide

  7. ● Back-scheduling a plan from a Recipe:
    ○ Start with end items and a due date, generate the plan from the end item to its inputs, to
    the outputs leading the inputs, to their inputs, etc.
    ● Forward-scheduling from a Recipe:
    ○ Start with the inputs with no predecessors and a start date, generate the plan from the
    inputs to their outputs, to the inputs that want the outputs, etc.
    ● Forward-scheduling from a Resource:
    ○ Start with a Resource and generate the plan based on its recipe.
    ■ Translation: start with a source document
    ■ Auto repair: start with an auto that needs repair.
    Scheduling Concepts

    View Slide

  8. Plan from the Demand page
    From the Demand page, you can
    ● create a customer order, which will also generate a plan for each item ordered
    ● plan a single process with inputs and outputs (creates a work order)
    ● plan work using a recipe to generate the plan (creates a work order)
    Work orders are groupings of deliverables that people want to manage together. They contain
    anything not directly related to fulfilling a customer order.

    View Slide

  9. Plan from a Resource Type page
    From any resource type page, you can:
    ● create a plan (work order) to make a resource of this type without a recipe, one process at
    a time
    ● create a plan (work order) to make a resource of this type with a recipe, which creates all
    the required processes
    (For more info on resource types, see the NRP setup tutorials.)

    View Slide

  10. Plan from the All Work page
    From the All Work page, you can
    ● plan a single process with inputs and outputs, creating or adding to a work order
    ● plan related work using a recipe to generate the plan, creating or adding to a work order
    ● create a to-do, which is a request for somebody or reminder for yourself to do something

    View Slide

  11. Plan from the My Work page
    From the My Work page, you can
    ● plan a single process with inputs and outputs, creating or adding to a work order
    ● create a to-do, which is a request for somebody or reminder for yourself to do something

    View Slide

  12. Planning creates processes, inputs and outputs
    No matter where you start, your plan will end up as processes to be done, and define the
    expected input(s) to and output(s) from the processes. These processes might be connected,
    where the expected output from one is the expected input to another. Or they may not be
    directly connected, but may be logically grouped because they are items on the same customer
    order, or because you want to manage them together.
    Processes are grouped under a customer order or a work order. (The work order gives you a
    way to manage a body of work together without a customer order.) For example:
    Process
    Planned Input
    Planned
    Output
    Process
    Planned Input
    Planned
    Output
    Process
    Planned Input
    Planned
    Output
    Order 1, Item 1
    Order 1, Item 2
    Planned Input
    You can see and refine your
    plan on the Order Schedule
    page, which can be accessed
    from the Demand page…..

    View Slide

  13. Order Schedule Page
    This order has one deliverable.
    Note more deliverables (order
    items) can always be added up at
    the top.
    This deliverable was created using
    a manufacturing / assembly
    recipe. The name and dates can
    be changed for these processes,
    using the Change Process Plan
    button. But everything else is
    fixed, since this involves making
    components and then using them
    to make the final product.

    View Slide

  14. Order Schedule Page
    This deliverable was created
    using a workflow recipe. The
    recipe defines a generic set
    of processes that occur in
    sequence, adding further
    value to the one deliverable.
    Each process represents a
    stage.
    These processes can be
    changed or deleted. A new
    process can be inserted, and
    the before and after
    processes will adjust for it.
    The project and the quantity
    can both be changed for the
    whole set of processes.

    View Slide

  15. Order Schedule Page
    Note that a recipe can be
    used to document processes,
    transmitting collective
    understanding into the plan,
    to help the contributors who
    will work on them.

    View Slide

  16. Order Schedule Page
    You will always be notified if a
    process is behind. If you want, you
    can reschedule the process and all
    subsequent processes forward from
    today.
    This plan was created from a
    resource type list, which collects
    together multiple recipes and creates
    a deliverable for each one. Use this if
    you have several things that must be
    done to accomplish a goal, but that
    can be done in parallel because they
    have no dependencies.

    View Slide

  17. Order Schedule Page
    This is a customer order where 3 items were ordered.
    You might see something like this if the ordered items
    are already onhand. In this case, no planned
    processes were created. You would deliver or ship
    from inventory.

    View Slide

  18. Order Schedule Page
    If you include something in an order that does not have a recipe, you will get the opportunity to
    create a process by hand to fulfill that deliverable. You will need to create the process here,
    and add the planned inputs and outputs on the Process Logging page or the Change Process
    page.
    So much nicer to have a recipe, especially for something complicated!

    View Slide

  19. Planning Without a Recipe

    View Slide

  20. Planning creates a context for working
    The planning effort has created a
    very specific framework and
    context for people to log and
    coordinate their work.
    Instead of people logging on a
    blank sheet and having to figure
    everything out, most selections
    are already defined, and people
    can log the details of the work
    with minimal effort.
    People can also change the plan
    in this context, before or during
    the work.

    View Slide

  21. Planning creates requirements for purchasing
    This report on the Supply page shows items that
    ● are planned but not yet used or consumed in a process
    ● are not already in inventory
    ● are not already on order

    View Slide

  22. Evolving the Plan
    Once people start working on a
    process, things can change, of
    course.
    People working on a process
    can add, change, or delete the
    input and output elements of
    the plan on the same page as
    they do their logging of the
    work.
    The process itself can also be
    changed.

    View Slide

  23. Evolving the Plan
    Note no assignments were
    made in the planning. People
    can “Take this task” based on
    their own desire to participate.
    They can change the dates
    and estimates based on their
    situation and estimate.
    Taking a task adds the “who”
    to the planned work.
    People can also invite others
    to collaborate on the process.

    View Slide

  24. The All Work page can be used to manage the planned work for a
    group who is coordinating their work. It is especially useful for
    status meetings or scrums. You can record group notes, change
    process dates, people can take tasks.
    Visualizing Your Plan

    View Slide

  25. Visualizing Your Plan On the My Work page you can see what you are working on,
    what you have committed to do, and what open tasks are
    available for you to choose to work on. It is a jumping off point
    with just your information, where the All Work page gives an
    overview of everyone’s work and its interconnections.

    View Slide

  26. Visualizing Your Plan
    The people working on
    this process
    coordinate with the
    people working on that
    process
    We are working on other ways to visualize your plans, such as networked gantt-like visuals. This is
    a start, but is not ready for use yet.

    View Slide

  27. ...also coming up: planning
    across multiple networks...
    And returning to the big picture...

    View Slide

  28. If you have any thoughts, questions, or suggestions
    about network planning or this tutorial, we’d love to
    hear from you.
    http://mikorizal.org/contact.html
