Modernize Application Development with Highly Scalable Architecture using Docker and Azure

Slidedeck from the presentation done at Global Azure Bootcamp Singapore event held on 21st April 2018. The talk demostrated the end to end workflow of containerizing an application for managing Tech Talks. Using Docker multi stage builds and docker compose, the multi-container app was tested locally on a single node Kubernetes cluster using Minikube. The demo was scaled to Azure cloud using managed Kubernetes instance using Azure Container Service (AKS). Scalability features were added using messaging layer with RabbitMQ. ElasticSearch with Kibana was used to build a self service UI for a denormalised representation of data and for visualisations Kibana provided a real time dashboard. The demo concluded with incorporating the Container Monitoring Solution (OMS).

Transcript

1. - - - - - Modernize Application Development with Highly Scalable Architecture using Docker & Azure - Nilesh Gule
2. Aha, that tweet! Wow, never knew the bot could do chit-chat #GlobalAzure #GABSG #Singapore ” “ A Saturday well spent! Love Azure #GlobalAzure #GABSG #Singapore” “ Your tweet could get you some digital give-away in today’s closing session.. But wait, do use hash tags #GlobalAzure #GABSG
3. Tell us or ask us.. Show us some love through your feedback, or ask questions to the experts around you… http://bit.ly/GABQs We will monitor this through-out the day and we’ll try to answer questions asked. If we are not able to answer questions due to volume, we will arrange meetups to help you in areas of your interest
4. Agenda - Managed Kubernetes cluster (AKS) on Azure - State Management with Persistent Volume - Scale using Messaging - Index data using ELK - Monitor containerized workloads using OMS - Containerize Apps with Docker - Container Orchestration using Kubernetes (Minikube)
5. Application Overview
6. Containerize Apps
7. Inner loop Development workflow Source: https://docs.microsoft.com/en-us/dotnet/standard/microservices-architecture/docker-application-development-process/docker-app-development-workflow
8. Docker Multi Stage build
9. Docker-compose
10. Kubernetes
11. Kubernetes Open-source system for automating deployment, scaling, and management of containerized application across clusters of machines Basic Objects - Namespace - Pod - Volume - Service Controllers - ReplicaSet - Deployment - StatefulSet - DemonSet
12. Minikube local cluster
13. Demo - Minikube
14. Managed Kubernetes Cluster (AKS) on Azure
15. Provision AKS cluster
16. Kubernetes cluster resources
17. State Management with Persistent Volume
18. Persistent Volumes Node1 Node 2 Node 3 Node1 Node 2 Node 3 Node1 Node 2 Node 3 Node1 Node 2 Node 3 Without PV With PV
19. Demo - AKS Deployment
20. Scale using Messaging
21. Queue based load levelling Source: https://azureinteractives.azurewebsites.net/CloudDesignPatterns/default.html TechTalksProcessor TechTalksWeb TechTalksAPI TechTalksDB
22. Indexing using Elastic Search
23. Visualize Denormalized Data with Elastic Search & Kibana TechTalksProcessor TechTalksWeb TechTalksAPI TechTalksDB TechTalksELKProcessor
24. Elastic Search And Kibana
25. Monitoring using OMS
26. Container Monitoring Solution using OMS
27. OMS results
28. References Blog - https://www.handsonarchitect.com Demo code Github repo - https://github.com/NileshGule/ABC2018 EshopOnContainers reference app (EventBus, CQRS) - https://github.com/dotnet- architecture/eShopOnContainers OnlineStore reference app - https://github.com/mirfanmcs/OnlineStore Azure Interactives - https://azureinteractives.azurewebsites.net Docker getting started - https://docs.docker.com/get-started/ Docker Compose V3 - https://docs.docker.com/compose/compose-file/#build Docker Multi-Stage builds - https://docs.docker.com/engine/userguide/eng-image/multistage- build/ Monitor AKS with Log Analytics - https://docs.microsoft.com/en-us/azure/aks/tutorial- kubernetes-monitor Kubernetes Basics - https://kubernetes.io/docs/tutorials/kubernetes-basics/ Twelve Factor App - https://12factor.net
29. Q&A
