Data Entitlement in an API-Centric Architecture

Data Entitlement in an API-Centric Architecture

At present, application and enterprise architecture is shaping towards API centric design. Information is delivered to consumers in many forms today creating a value web through data APIs. Even though the topic of authorization is discussed at length with regard to APIs, data entitlement and authorization is a rarely discussed topic. During this webinar, Nuwan Bandara, senior lead solutions engineer at WSO2, will discuss the topic of entitlement with regard to data APIs and will also present a demonstration or how to realize an API-centric architecture with data entitlement.

E71c1071861e4f8526d75feb67371bd1?s=128

Nuwan Bandara

April 02, 2015
Tweet

More Decks by Nuwan Bandara

Other Decks in Programming

Transcript

  1. Data Entitlement in an API-Centric Architecture 04/02/2015 Nuwan Bandara Senior

    Technical Lead
  2. Entitlement in general John doe need to reed web page

    John authenticates with the system System checks John’s role and associated permissions If allowed john is presented with the page traditional application authenticate authorize access
  3. API Centric Entitlements John doe need to reed resource foo

    John authenticates with the system System checks John’s role and associated permissions If allowed john is presented with the resource API Gateway authenticate authorize access
  4. Common Aspects of the typical use case Involvement of a

    actor (john) Involvement of a resource (page / data) Use of permissions Use of an attribute (role) Involvement of an action (READ)
  5. Entitlement complexities Complex rules Too many combinations Over time maintenance

    nightmare (a role per user / too many granular permissions) Too many changes (governance nightmare) Application centric
  6. Who should provide entitlements Classic Use Case Access to ALL

    sales data Sales Managers Sales Database Sales T eam A DB Sales T eam B Whoshould provide Entitlements? Access to only sales data> belonging to> specific sales> group Application Y Application X
  7. Traditional design Entitlements Repo Presentation Data exchange (1) (2) (6)

    (3) Request for permitted> access Data Access Layer Query Data Responsewith Fil ter MetaFdata (5) (4) Authori zed Items Reques t for da ta Fil tered Data Entitlements System Business Application
  8. Where does the rules exist ? At the application layer

    ? At the API layer ? At the data access layer ? application API gateway data services
  9. Modern entitlement design principals Re-usability Application / API neutral Loosely

    coupled to the underline system Centrally manageable performance
  10. Data entitlement at the data access layer Conceptual SOA driven

    Data Entitlements Query- Based on User attribute- (i.e. Role) User Group A Request Entitlements Store Response User Group B Request for FilteredData Response Application B Data Service Application A Entitlements Service Data- Access- Service Filter Builder
  11. Challengers Externalized entitlement engines are often seen as an unnecessary

    task and an overhead Needs fresh thinking and often re-writing the applications / APIs in a permission agnostic manner Must be standards driven Need to optimize for performance
  12. Benefits Benefits are more long term Helps organizations adapt to

    changing business needs, and data security requirements easier Centralized management of platform level policies Ideal for heterogeneous systems – Unified access model to entitlements data Service mindset – everything is a service, including entitlements
  13. Entitlements at the API Layer application api gateway entitlement engine

    data services authenticate authorize data access
  14. Whats new in entitlement with regard to APIs APIs has

    define interactions (GET/PUT/POST/DELETE etc) APIs has token based authentication APIs has associated concepts (throttling / billing ) APIs are typically centrally managed
  15. Entitlement patterns for API architectures Attribute based access control User

    Doe can READ resource Foo Policy based access control User Doe can READ resource Foo only 10 time per day
  16. Entitlement policies and decision engines XACML is the standard for

    policy based entitlement XACML provides the rich entitlement rule authoring capability XACML policies are evaluated on a decision engine XAML has a defined sequence in integration to applications and APIs PEP / PDP / PAP / PIP Data service Requester PEP (Policy Enforce. Point) XACML Request XACML Response Manage XAML Policy (Policy Retrieval Point – PRP) Policy Store Attribute Store PIPB(PolicyB InformationB Point) PDPB(Policy DecisionBPoint) PAPB(PolicyB AdministrationB Point)
  17. Putting it all together Enterprise User Store DB XACML Policy

    Entitlements Mediator (2) XACML request (1) App A Request + wsse:UsernameT oken (3) XACML responseB with Advices getSalesInfo App B (4) Build dynamic query Using advices (claims) fault Response (5) getSalesInfo + entitlements based filtering (7) Sales Datastore (6) Filtered Response App X DB PEP Dynamic Query DSS PAP PIP PDP IS
  18. API gateway flow for authorization Entitlements Y es Permit? Query

    No Return Fault Send Response Call Data Service Build Dynamic Extract Claims Call Mediator Authenticate User
  19. Sample policy ator AttributeId="http://wso2.org/claims/rol :xacml:1.0:subject-category:access-subject" 2001/XMLSchema#string" MustBePresent="true"></Attrib ntExpression> n> ="Rule1">

    <Policy xmlns="urn:oasis:names:tc:xacml:3.0:core:schema:wd-17" PolicyId="CustomerServiceSales" RuleCombiningAlgId="urn:oasis:names:tc:xacml:1.0:rule-combining-algorithm:first-applicable" Version="1.0"> <Target></Target> <Rule Effect="Permit" RuleId … </Rule> <AdviceExpressions> <AdviceExpression AdviceId="customerService" AppliesTo="Permit"> <AttributeAssignmentExpression AttributeId="employee.role"> <AttributeDesign Category="urn:oasis:names:tc DataType="http://www.w3.org/ </AttributeAssignme </AdviceExpressio </AdviceExpressions> </Policy> e" uteDesignator> In this exampleweareenforcingthat3 employeerole(a PIPentry)is3 embeddedon to theXACMLresponse XACMLPolicyrulesetgoes3 here(omitted)
  20. Summary Data entitlement is central to an API architecture Entitlement

    rules needs to be loosely coupled to the API runtime Entitlement engine has to be capable to evaluating granular rules Data access has to be controlled via an entitlement engine as the permutation and combinations for data access can grow massively over time
  21. Thank You
