Danian: tail latency reduction of networking application through an O(1) scheduler

Paper presented at: ISCC 2021

Abstract:
Core allocation for application threads is a problem of reasonable complexity and computational cost inside Unix systems. Caladan scheduler is a solution aiming to reduce the cost of how threads and cores are allocated in microsecond scale. Danian system optimizes through memoization the thread picking algorithm that picks the best thread for a given core. Such improvements have direct impact on applications distributed across networks on a data center. Thread picking operation cost dropped from O(n) to O(1), the CPU time reduced 7%, the tail latency reduced 3% on Caladan Synthetic experiment and 5% on the Netperf experiment.

Key words:
Real Time Communication Services,
Distributed Systems Architecture and Management,
Optimization and Management,
Network Reliability,
Network Design

Transcript

1. Danian:
   Tail latency reduction of networking
   application through an O(1) scheduler
   Gustavo Pantuza, Lucas A. C. Bleme, Marcos Augusto M. Vieira, Luiz Filipe M. Vieira
   26th IEEE Symposium on Computers and Communications
   Athens, Greece, September 5-8, 2021
   IEEE ISCC 2021


   View Slide

2. Agenda
   ■ Introduction
   ■ Thread scheduling
   ■ Caladan
   ■ Danian
   ■ Experiments
   ■ Results
   ■ Future work
   ■ Conclusion


   View Slide

3. Introduction
   ■ Tail at scale (2013)
   ■ Shenango (2019)
   ■ Caladan (2020)
   ■ Danian (2021)
   p50 p95 p99
   1ms 5ms 10ms
   Hypothetical Example


   View Slide

4. Thread scheduling
   ■ Lottery (1994)
   ■ Scheduler Activation (1991)
   ■ Caladan (2020)


   View Slide

5. Caladan
   ■ Schedule threads into CPUs
   ■ Run on top of DPDK
   ■ Reads control signals every 5 μs
   ■ Implemented inside Shenango


   View Slide

6. Caladan
   Simplified version of Caladan architecture inspired by the Caladan original paper architecture description


   View Slide

7. Danian
   “In the 5000 years between the events of the
   Arrakis Revolt and the time the Lost Ones
   returned from The Scattering, Caladan's
   name was shortened to Dan, and all things
   pertaining to Dan were known as Danian.”
   Fonte: https://dune.fandom.com/wiki/Caladan


   View Slide

8. Danian
   Fonte: https://dune.fandom.com/wiki/Caladan
   ■ Works inside Caladan ksched
   ■ Adds a memoization array
   ■ Intercepts threads join/leave
   ■ Algorithm to assign CPU→thread
   ■ O(n) → O(1)


   View Slide

9. Danian
   struct proc {
   pid_t pid;
   ...
   struct thread *last_run[NCPU];
   ...
   }


   View Slide

10. Danian
    static struct thread *
    sched_pick_last_kthread(struct proc *p, unsigned int core)
    {
    struct thread *th;
    th = p->last_run[core];
    if (!th->active) {
    return th;
    }
    return list_tail(&p->idle_threads, struct thread, idle_link);
    }


    View Slide

11. Experiments
    ■ CloudLab
    ■ Client/Server
    ■ Latency percentiles
    ■ Varying number of threads
    ■ CPU usage
    ■ Netperf


    View Slide

12. Experiments


    View Slide

13. Results


    View Slide

14. Results


    View Slide

15. Results


    View Slide

16. Results


    View Slide

17. Results


    View Slide

18. Results


    View Slide

19. Future work
    Fonte: https://dune.fandom.com/wiki/Caladan
    ■ NFVs with lthreads inside Caladan
    ■ SDN using Caladan as control plane


    View Slide

20. Conclusion
    ■ Thread picking from O(n) to O(1)
    ■ Memoization using LRU policy
    ■ -5% on tail latency (p99)
    ■ -15% CPU usage


    View Slide

21. Danian:
    Tail latency reduction of networking
    application through an O(1) scheduler
    Gustavo Pantuza, Lucas A. C. Bleme, Marcos Augusto M. Vieira, Luiz Filipe M. Vieira
    26th IEEE Symposium on Computers and Communications
    Athens, Greece, September 5-8, 2021
    IEEE ISCC 2021


    View Slide
