  1. Think ahead. Act now. Docker managed properly: Introducing Kubernetes for

    ITPro’s Cornell Knulst @cornellknulst Pascal Naber @pascalnaber
  2. Container orchestrators Cluster High Availability Hyper-Scale Hybrid Operations High Density

    Rolling Upgrades Stateful services Low Latency Fast startup & shutdown Container Orchestration & lifecycle management Replication & Failover Load balancing Self-healing Automated Rollback Health Monitoring Placement Constraints Microservices Service Fabric
  3. Kubernetes K8s OOS Extensible Facilitates declarative configuration and automation Large,

    rapidly growing ecosystem Κυβερνήτης -- Greek: meaning helmsman or pilot 1 2 3 4 5 6 7 8
  4. Hosting of Kubernetes Local Minikube Docker for Windows (Edge) Docker

    for Mac (Edge) Raspberry Pi Private datacenter Public Cloud GKE EKS AKS
  5. Think ahead. Act now. Partly managed Kubernetes Only pay for

    worker nodes Upgrades managed by Azure Workers are Managed IaaS Azure Kubernetes Service (AKS) Azure Kubernetes
  6. Kubernetes architecture Master API Server Scheduler Controller Manager Node (Minion)

    etcd kubelet Kube- Proxy cAdvisor Pod Pod Pod Kubectl (CLI) Dashboard (UI) REST client (Code)
  7. Install AKS using CLI ## Create resourcegroup az group create

    --name clouddemo --location eastus ## Create Kubernetes cluster az aks create -g clouddemo -n gamingcluster --generate-ssh-keys ## Create Kubernetes cluster az aks create --resource-group clouddemo --name gamingcluster --kubernetes-version 1.9.6 --node-vm-size Standard_DS2_v2 --node-count 3 --max-pods 1000 --enable-rbac --enable-addons http_application_routing --ssh-key-value "C:\repos\pascal\ssh\public.pub" --service-principal d6e55af7-17fc-4cf5-b140-8b37729da10e --client-secret 94bCIHcSuniCvjq9
  8. Think ahead. Act now. ## download & install kubectl az

    aks install-cli ## download credentials az aks get-credentials --resource-group clouddemo --name gamingcluster Post Install steps
  9. Pod Group of 1 or more containers Shared Storage Shared

    Network Same IP-address and port Pod 10.0.0.1 Storage Pod 10.0.0.2 Storage Port 80 Port 8080 Port 80
  10. leaderboard-api.yaml Pod Pod Pod Replica Set Deployment Label: backend Selector

    Label: backend Label: backend Label: backend Label: backend Selector Label: backend C:> kubectl apply –f leaderboard-api.yaml
  11. Think ahead. Act now. C:> kubectl apply –f secret.yaml Secrets:

    Base64 encoded values Environment variables & Secrets C:> kubectl create secret generic db-user-pass -- from-file=./username.txt --from-file=./password.txt ## Create Secret to access Azure Container Registry kubectl create secret docker-registry clouddemoimages --docker-server=https://clouddemo.azurecr.io --docker-username=clouddemo --docker-password=kD98ddl$= [email protected]
  12. Health checks livenessProbe Indicates whether the Container is running Restart

    in case of failure Container: https://www.app-metrics.io/ HealthChecks library https://github.com/dotnet-architecture/HealthChecks readinessProbe Indicates whether the Container is ready to service requests No traffic is routed to the Pod C:> kubectl apply –f leaderboard-api.yaml
  13. Resource Management requests: Minimum required resources limits: Capped resource usage

    100m = 0.1 cpu 500m = 0.5 cpu 64Mi = 64 MB memory 128Mi = 128 MB memory C:> kubectl apply –f leaderboard-api.yaml
  14. Horizontal Pod Autoscaler Required: Resource requests & limit Heapster Scaling

    based on 1 or multiple items CPU Memory Custom Metrics C:> kubectl apply –f leaderboard-api.yaml
  15. Horizontal Pod Autoscaler Required: Resource requests & limit Heapster C:\kubectl

    get hpa NAME REFERENCE TARGETS MINPODS MAXPODS REPLICAS AGE autoscaler leaderboard-api 0% / 50% 1 10 1 9m C:\kubectl get hpa NAME REFERENCE TARGETS MINPODS MAXPODS REPLICAS AGE autoscaler leaderboard-api 218% / 50% 1 10 1 10m C:\kubectl get hpa NAME REFERENCE TARGETS MINPODS MAXPODS REPLICAS AGE autoscaler leaderboard-api 218% / 50% 1 10 4 10m C:\kubectl get hpa NAME REFERENCE TARGETS MINPODS MAXPODS REPLICAS AGE autoscaler leaderboard-api 44% / 50% 1 10 7 13m C:\kubectl get hpa NAME REFERENCE TARGETS MINPODS MAXPODS REPLICAS AGE autoscaler leaderboard-api 51% / 50% 1 10 6 21m
  16. Think ahead. Act now. Node 1 Pod Label: backend 10.0.0.2

    Pod Label: backend 10.0.0.3 Node 0 Pod Label: backend 10.0.0.1 Node 2 Pod Label: backend 10.0.0.4 Pod Label: backend 10.0.0.5 Pods are mortal
  17. Service Service Type: ClusterIP Selector Label: backend Node 1 Pod

    Label: backend 10.0.0.2 Node 0 Pod Label: backend 10.0.0.1 Node 2 Pod Label: backend 10.0.0.4 Pod Label: backend 10.0.0.5 192.168.0.1
  18. Service Service Type: LoadBalancer Selector Label: backend Node 1 Pod

    Label: backend 10.0.0.2 Node 0 Pod Label: backend 10.0.0.1 Node 2 Pod Label: backend 10.0.0.4 Pod Label: backend 10.0.0.5 Public ip address: 192.168.0.1 192.168.0.2
  19. Frontend Backend Pod Pod Pod Pod Pod Pod Pod Pod

    Service Type: ClusterIP Service Type: LoadBalancer Public ip address: 192.168.0.1 C:> kubectl apply –f leaderboard-service.yaml C:> kubectl apply –f gamingwebapp.yaml 192.168.0.2 192.168.0.1
  20. Too many ip-addresses. Now what? Or: I want to access

    all my services through the same ip-address
  21. Ingress Pod 10.0.0.1 Pod 10.0.0.2 Pod 10.0.0.3 Service Type: ClusterIP

    Pod 10.0.0.4 Pod 10.0.0.5 Pod 10.0.0.6 Service Type: ClusterIP Pod 10.0.0.7 Pod 10.0.0.8 Pod 10.0.0.9 Service Type: ClusterIP Service Type: LoadBalancer Public ip address: 192.168.0.1 Pod quay.io/kubernetes-ingress-controller/ nginx-ingress-controller:0.15.0 Selector Label: ingresscontroller Label: ingresscontroller Ingress host: gaming.expertslive.cf serviceName: gamingwebapp Ingress host: erp.expertslive.cf serviceName: erpsvc Ingress host: www. expertslive.cf/crm serviceName: crmsvc nginx.conf gaming.mydomain.com 10.0.0.1 10.0.0.2 10.0.0.3 erp.mydomain.com 10.0.0.4 10.0.0.5 10.0.0.6 /crm 10.0.0.7 10.0.0.8 10.0.0.9 Automatically generated Label: erp Label: frontend Label: crm
  22. Helm Helm is a tool for managing packages of pre-configured

    Kubernetes resources https://github.com/kubernetes/helm Linkerd Logstash Magento Mariadb Mongodb Mssql-linux Mysql Neo4j Newrelic Openvpn Postgresql Presto Prometheus Rabbitmq Redis Selenium Sonarqube Spinnaker Sysdig Tensorflow Traefik Wordpress Artifactory Cert-manager Consul Cassandra Couchdb Datadog Docker-registry Drupal Elasticsearch Ethereum fluentd Gitlab Grafana Hadoop Heapster Jenkins Joomla Kafka Kibana Kong Kubeless Lamp
  23. Helm # Download Helm https://github.com/kubernetes/helm/releases # To install Tiller on

    the cluster run helm init # Get latest version of the stable charts helm repo update # Install a chart helm install --name monitor stable/Prometheus helm install --name dashboard stable/grafana -f "C:\Demos\monitoring\values.yaml"
  24. Think ahead. Act now. Starts in seconds No VM Management

    Billed per second Linux and Windows containers Azure Container Instances (ACI) Azure Azure Container Instances (ACI) Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod
  25. Kubernetes on Azure Kubernetes cluster Master Azure Container Instances (ACI)

    Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod
  26. Deployment Replica set Pod Label Rolling update Health check Environment

    variables Secret Resource management Horizontal Pod Autoscaler Namespace Service Ingress Annotation Affinity Persistent Volume Cron Job Deamon Set Job Stateful Set Config Map
  27. Think ahead. Act now. Wrap up Kubernetes Deployment, Pods, Services,

    Ingress, Namespaces, Secrets Repeatable, Secure, Self healing, scalable, rolling updates, rollback Azure offerings AKS: Managed Master + Managed IaaS for workers AKS+ACI: Managed Kubernetes Faster Time to Market
  28. Wrap up Kubernetes Deployment, Pods, Services, Ingress, Namespaces, Secrets Repeatable,

    Secure, Self healing, scalable, rolling updates Azure offerings AKS: Managed Master + IaaS++ for workers AKS+ACI: Managed Kubernetes Faster Time to Market C5l Knulst Cloud Architect DevOps Consultant @CornellKnulst – [email protected] http://www.solidalm.com P4l Naber Coding Azure Architect Microsoft Azure MVP @pascalnaber – [email protected] http://pascalnaber.wordpress.com https://pages.xpirit.com/magazine2018 https://github.com/pascalnaber/expertslivenl2018
