  1. Edgecore Networks
    Big Monitoring Fabric Virtual Lab
    Phil Huang
    Open Networking Division

    View Slide

  2. Integrate with BMF and Firewall
    Integrate with BMF and SPAN
    Hands-On Lab Overview
    © 2016 Edgecore Networks. All rights reserved. Subject to errors and misprints. |
    www.edge-core.com
    Big Monitoring Fabric Overview
    01
    04
    05
    02
    Setting BMF Environment
    03

    View Slide

  3. Big Monitoring Fabric Overview
    3
    LEGACY
    Trusted
    Untrusted
    FIREWALL
    IPS
    INTERNET
    DMZ
    Complex &
    Expensive
    Limited Tool
    Optimization
    Operational
    Challenges



    INLINE TOOLS
    Simple & Economical
    Enhanced Tool
    Optimization
    Clear Role Separation
    between network and
    security admins
    ü
    ü
    ü
    BIG MON: INLINE
    BIG MON INLINE
    Switches
    (1/10/40/100G)
    FIREWALL
    IPS
    WEB PROXY
    Untrusted
    Trusted
    INLINE TOOLS
    TRAFFIC DISTRIBUTION /
    LOAD SHARING
    BIG MONITORING
    FABRIC CONTROLLERS
    (HA PAIR)
    ACL-based
    SPAN
    OUT-OF-BAND
    TOOL FARM
    WEB PROXY
    © 2016 Edgecore Networks. All rights reserved. Subject to errors and misprints. |
    www.edge-core.com

    View Slide

  4. Hands-On Lab Overview
    Provided by Big Switch & Edgecore Networks
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com 4

    View Slide

  5. BMF Inline Mode Hands-On Lab
    5
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Learn the fundamental concepts of Big Monitoring Fabric inline
    § How to work in BMF inline mode?
    § Create service chain
    § Create service
    § Insert Firewall service instance in chain
    § Insert SPAN service in chain

    View Slide

  6. Login BSN Labs & Edgecore Networks
    6
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    http://labs.bigswitch.com/edgecore
    Type information that you are
    given

    View Slide

  7. Launch Big Monitoring Fabric Module 1
    7
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    Press “LAUNCH” button
    Choose “Big Monitoring Fabric”

    View Slide

  8. Access Hands-On Lab
    8
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    Lab Topology & options to
    access the BMF Controller

    View Slide

  9. Lab Topology Overview
    9
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    10.0.0.1

    View Slide

  10. Introduction of Component
    10
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    1
    2
    4
    5 3
    7
    6
    10.0.0.2
    10.0.0.1
    BMF Switch
    * switch name: sw11
    BMF Controller
    * Control BMF Switch
    Firewall
    * Drop ICMP echo request
    Wireshark
    * Network traffic analyzer

    View Slide

  11. Access Big Monitoring Fabric Controller
    11
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Action
    1. Right click Big Monitoring Fabric (BMF) Controller icon
    2. Select the “Controller GUI”
    § Default controller username/password is “admin/bsn123”

    View Slide

  12. Deploy Switch in BMF Inline Mode
    Ready to ship from Edgecore Networks
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com 12

    View Slide

  13. Deploy Switch for Big Chain mode
    13
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Setting deployment to Big Chain mode
    § Default deployment is Big Tap mode
    § Action
    1. Navigate to Fabric -> Switches
    2. Click
    3. Choose Deploy for Big Chain
    Default deployment,
    Need to change
    to Big Chain mode
    1
    2
    3

    View Slide

  14. Test Traffic
    14
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Traffic will be block if no chain is
    defined over the switch ports
    connecting the hosts
    § Action
    1. Right click External host
    2. Access the Web CLI
    3. Ping the trusted host in
    internal network
    1
    2
    3

    View Slide

  15. Create a Chain
    Logical, Layer-1 and Bidirectional Wire
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com 15

    View Slide

  16. What is Chain?
    16
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Logical, Layer-1, bidirectional wire that connects
    WAN (untrusted) device and LAN switch (trusted)
    § Multiple services may be assign to a chain
    § Firewalls
    § IPS
    § Web Proxy
    § Without services, the chain letting all traffic
    through in both directions, without modifying packets Chain
    IPS: Intrusion Prevention System

    View Slide

  17. Devices Connection
    17
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § View devices connected to ports of BMF inline switch
    § Firewall, IPS, Wireshark, Trusted and Untrusted networks
    § Action
    1. Right click on the inline switch sw11
    2. Use Device Information
    1
    2
    Reminder: More clear topology at page 10 J
    Interface Devices Connect
    Ethernet1 Trusted Network
    Ethernet2 Untrusted Network
    Ethernet3 Wireshark
    Ethernet4 Firewall (In)
    Ethernet5 Firewall (Out)
    Ethernet6 IPS (In)
    Ethernet7 IPS (Out)

    View Slide

  18. Create Internal/External Chain (1/2)
    18
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Action
    1. Navigate to Big Chain -> Chains
    2. Click on + to add chain
    1
    2

    View Slide

  19. Create Internal/External Chain (2/2)
    19
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    Chain name: Edgecore_Chain Select sw11 (00::00:0a)
    Ethernet1 connected to
    trusted network
    Ethernet2 connected to
    untrusted network
    Save configuration

    View Slide

  20. Test Internal/External Chain
    20
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Verify Edgecore_Chain is
    forwarding traffic
    § Action
    1. Right click External host
    2. Access the CLI Access
    3. Ping the trusted host in
    internal network
    1
    2
    3

    View Slide

  21. Create a Firewall Service
    Services instances and Services
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com 21

    View Slide

  22. Big Chain Service Instances and Services
    22
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Service instance
    § A pair of switch ports that are connected to an inline tool (FW, IPS…etc)
    § Services
    § Include one or more service instances
    § Apply to specific subsets of chains, for enhanced tool performance
    § Configure with Health Check to alert for tool failure

    View Slide

  23. Create a Firewall Service (1/2)
    23
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Action
    1. Navigate to Fabric -> Switches
    2. Click Switch DPID
    3. Click to add a services
    1
    2
    3

    View Slide

  24. Create a Firewall Service (2/2)
    24
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Action
    4. Naming Firewall_Service
    5. For action choose Use Service, and For
    traffic type All
    6. Click submit to finish
    4
    5

    View Slide

  25. Create a Firewall Service Instance (1/2)
    25
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Action
    1. Select Firewall_Service in Service list
    2. Click New service instance
    1
    2

    View Slide

  26. Create a Firewall Service Instance (2/2)
    26
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    Ethernet4 connected to
    Firewall input interface
    Ethernet5 connected to
    Firewall output interface

    View Slide

  27. Verify Firewall Service
    27
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Show connected graph by BMF WEB GUI

    View Slide

  28. Insert Firewall Service Instance
    Drop ICMP by firewall within BMF chain
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com 28

    View Slide

  29. Insert Firewall Service Instance (1/2)
    29
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Action
    1. Select Edgecore_Chain under Chains
    2. Click Insert service to begin
    1
    2

    View Slide

  30. Insert Firewall Service Instance (2/2)
    30
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Action
    1. Select Firewall_Service and Instance 1 for Service instance
    2. Click Submit
    1
    2

    View Slide

  31. What does it look like?
    31
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    1
    2
    4
    5
    2
    1
    4
    5
    Hands-on Lab Topology View BMF Controller View

    View Slide

  32. Verify Traffic Drop on Chain Edgecore_Chain
    32
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § By default, the Firewall will drop all ICMP echo requests (type 8)
    § Action
    1. Right click External host
    2. Access the Web CLI
    3. Ping the trusted host in
    internal network
    § PING should fail in either direction
    § Firewall drops ICMP echo requests
    1
    3

    View Slide

  33. Drop Firewall Service Instance
    Remove instance easily if you want
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com 33

    View Slide

  34. Drop Firewall Service Instance
    34
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Action
    1. Click and drag to remove
    2. Click Summit
    2
    1

    View Slide

  35. Verify Traffic Drop on Chain Edgecore_Chain
    35
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Real time response
    § Action
    1. Right click External host
    2. Access the Web CLI
    3. Ping the trusted host in
    internal network
    1
    2
    3

    View Slide

  36. Create a SPAN Service
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com 36

    View Slide

  37. Create a SPAN Service (1/2)
    37
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Action
    1. Navigate to Fabric -> Switches
    2. Click Switch DPID
    3. Click to add a SPAN services
    1
    2
    3

    View Slide

  38. Create a SPAN Service (2/2)
    38
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Action
    4. Naming Wireshark, and click Next
    5. Click to add rules
    6. Select all traffic with Match All Traffic,
    click Append then Submit to finish
    5
    4
    6

    View Slide

  39. Create a SPAN Service Instance (1/2)
    39
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Action
    1. Select Wireshark in Span Services
    2. Click New span service instance
    1
    2

    View Slide

  40. Create a SPAN Service Instance (2/2)
    40
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Action
    3. Choose ethernet3, and click Submit
    4. Show WEB GUI on BMF
    3
    4

    View Slide

  41. Insert SPAN Service Instance
    Simple and easy to monitor your network
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com 41

    View Slide

  42. Insert SPAN Service Instance (1/2)
    42
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Action
    1. Click Edgecore_Chain in Chains list
    2. Insert SPAN service instance at Endpoint 2
    1
    2

    View Slide

  43. Insert SPAN Service Instance (2/2)
    43
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Action
    3. Select Wireshark, Instance 1
    4. Click Submit
    3
    4

    View Slide

  44. Trace SPAN Traffic
    44
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § All ingress traffic at ethernet2 is copied to
    Wireshark
    § External-to-Internal direction
    1
    2
    3

    View Slide

  45. Verify SPAN Traffic
    45
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com
    § Action
    1. Right click External host
    2. Access the Web CLI
    3. Ping the trusted host in
    internal network
    4. Right click the Wireshark icon
    and choose Real-time Capture
    4
    3
    Wireshark Output Result

    View Slide

  46. 46
    Open Networking
    from
    Freedom
    Control
    Innovation
    © 2016 Edgecore Networks. All rights reserved | www.edge-core.com

    View Slide

  47. © 2015 Edgecore Networks. All rights reserved. Subject to errors and misprints. | www.edge-core.com

    View Slide
