From Mobile to Backend with Kotlin and Ktor - FOSDEM 2022

As mobile developers, we often see the backend world as something magical that “does things”. But what if I tell you that you can easily build a backend even if mobile is your thing?

With this talk, I want to show how it is possible to bring your mobile knowledge (and shift it a little bit) to build a backend with Kotlin and Ktor. I will show how to structure the project, set up Dependency Injection, connect to a database and test everything to have a working backend ready to be deployed.

Transcript

1. Marco Gomiero
   FOSDEM
   From Mobile to
   Backend with
   Kotlin and Ktor


   View Slide

2. FOSDEM - @marcoGomier
   Marco Gomiero
   👨💻 Android Engineer @ TIER 🛴 🇩🇪 🇮🇹


   Google Developer Expert for Kotlin
   > Twitter: @marcoGomier


   > Github: prof18


   > Website: marcogomiero.com


   View Slide

3. FOSDEM - @marcoGomier
   🤔 Why?


   View Slide

4. FOSDEM - @marcoGomier
   • Side project


   • Understand how things works “on the other side”


   • Help you teammates
   🤔 Why?


   View Slide

5. FOSDEM - @marcoGomier
   * based on a true story


   View Slide

6. FOSDEM - @marcoGomier
   Ktor
   https://ktor.io/


   View Slide

7. FOSDEM - @marcoGomier
   Ktor
   • Kotlin


   • Lightweight and flexible


   • Asynchronous with Coroutines


   • Unopinionated


   View Slide

8. FOSDEM - @marcoGomier
   Unopinionated
   • Whatever architecture


   • Whatever pattern
   Knowledge Transfer


   View Slide

9. FOSDEM
   @marcoGomier
   Architecture


   View Slide

10. FOSDEM - @marcoGomier
    Android
    Activity/Fragment
    ViewModel
    Repository
    Local Data Source Remote Data Source
    Application


    View Slide

11. FOSDEM - @marcoGomier
    Resource*
    Repository
    Local Data Source Remote Data Source
    Application
    * or Controller
    Ktor


    View Slide

12. FOSDEM - @marcoGomier
    Resource
    Repository
    Local Data Source Remote Data Source
    Application
    Activity/Fragment
    ViewModel
    Repository
    Local Data Source Remote Data Source
    Application


    View Slide

13. FOSDEM - @marcoGomier
    Domain
    Data
    Resource
    Repository
    Local Data Source Remote Data Source
    Application
    Activity/Fragment
    ViewModel
    Repository
    Local Data Source Remote Data Source
    Application
    Presentation
    Application


    View Slide

14. FOSDEM - @marcoGomier
    Application
    class MyApp : Application() {


    override fun onCreate() {


    super.onCreate()


    if (BuildConfig.DEBUG) {


    Timber.plant(Timber.DebugTree())


    }


    initAnalytics()


    initCrashReporting()


    initRandomLib()


    }


    }


    View Slide

15. FOSDEM - @marcoGomier
    fun Application.module() {


    install(Koin) {


    slf4jLogger()


    modules(koinModules)


    }


    setupConfig()


    setupDatabase()


    install(ContentNegotiation) {


    json()


    }


    install(CallLogging) {


    level = Level.INFO


    }


    install(Locations)


    routing {


    setupEndpoint()


    }


    }
    Application


    View Slide

16. FOSDEM - @marcoGomier
    Plugin
    https://ktor.io/docs/plugins.html
    • Add a specific feature to your backend


    • Highly customisable


    • No plugin activated by default


    View Slide

17. FOSDEM - @marcoGomier
    Plugin
    https://ktor.io/docs/


    View Slide

18. FOSDEM - @marcoGomier
    Domain
    Data
    Presentation
    Application


    View Slide

19. FOSDEM - @marcoGomier
    Presentation
    class MainActivity : AppCompatActivity() {


    override fun onCreate(savedInstanceState: Bundle?) {


    super.onCreate(savedInstanceState)


    setContentView(R.layout.activity_main)


    ...

    }


    }


    View Slide

20. FOSDEM - @marcoGomier
    fun Route.jokeEndpoint() {


    val jokeRepository by inject()


    get {


    call.respond(jokeRepository.getRandomJoke())


    }


    post { apiCallParams
    ->

    val name = apiCallParams.name


    jokeRepository.watch(name)


    call.respond("Ok")


    }


    }
    Presentation


    View Slide

21. FOSDEM - @marcoGomier
    Domain
    Data
    Presentation
    Application


    View Slide

22. FOSDEM - @marcoGomier
    Domain
    class JokeRepositoryImpl(


    private val jokeLocalDataSource: JokeLocalDataSource


    ) : JokeRepository {


    override suspend fun getRandomJoke(): JokeDTO {


    // ...

    }


    }


    View Slide

23. FOSDEM - @marcoGomier
    Domain
    Data
    Presentation
    Application


    View Slide

24. FOSDEM - @marcoGomier
    Room
    class LocalDatasource(


    private val db: RoomDatabase


    ) {


    suspend fun getAllowedApps(): List {


    return db.allowedAppDAO().getAllAllowedApps()


    }


    }
    @Entity(tableName = "allowed_app")


    data class AllowedApp(


    @PrimaryKey val packageName: String,


    @ColumnInfo val appName: String


    )
    @Dao


    interface AllowedAppDAO {


    @Query("SELECT * FROM allowed_app")


    suspend fun getAllAllowedApps(): List


    }
    Data


    View Slide

25. FOSDEM - @marcoGomier
    Exposed
    https://github.com/JetBrains/Exposed


    View Slide

26. FOSDEM - @marcoGomier
    Exposed
    class JokeLocalDataSourceImpl : JokeLocalDataSource {


    override suspend fun getAllJokes(): List {


    val joke = newSuspendedTransaction {


    val query = JokeTable.selectAll()


    Joke.wrapRows(query).toList()


    }


    }


    }
    object JokeTable: IdTable(name = "joke") {


    val createdAt = datetime("created_at")


    val updatedAt = datetime("updated_at")


    val value = text("value")


    override val id: Column>>
    = varchar("joke_id", 255).entityId()


    override val primaryKey: PrimaryKey = PrimaryKey(id)


    }
    class Joke(id: EntityID): Entity(id) {


    companion object: EntityClass(JokeTable)


    var createdAt by JokeTable.createdAt


    var updatedAt by JokeTable.updatedAt


    var value by JokeTable.value


    }
    Data


    View Slide

27. FOSDEM - @marcoGomier
    EmailThreadTable.join(EmailFolderTable, JoinType.INNER, additionalConstraint = {


    (EmailThreadTable.id eq EmailFolderTable.threadId).and(


    EmailThreadTable.account eq EmailFolderTable.accountId


    )


    })


    .select { EmailThreadTable.account eq account.id.value and (EmailFolderTable.folderId eq folderId) }


    .orderBy(EmailThreadTable.lastEmailDate, SortOrder.DESC)


    .limit(n = pageSize)




    View Slide

28. FOSDEM
    @marcoGomier
    Dependency Injection


    View Slide

29. FOSDEM - @marcoGomier https://insert-koin.io/docs/quickstart/ktor
    Koin


    View Slide

30. FOSDEM - @marcoGomier
    val appModule = module {


    single { HelloRepositoryImpl() }


    factory { MySimplePresenter(get()) }


    }


    View Slide

31. FOSDEM - @marcoGomier
    class MyApplication : Application() {


    override fun onCreate() {


    super.onCreate()




    startKoin {


    androidLogger()


    androidContext(this@MyApplication)


    modules(appModule)


    }


    }


    }


    View Slide

32. FOSDEM - @marcoGomier
    class MainActivity : AppCompatActivity() {


    val firstPresenter: MySimplePresenter by inject()


    override fun onCreate(savedInstanceState: Bundle?) {


    super.onCreate(savedInstanceState)


    setContentView(R.layout.activity_main)


    ...

    }


    }


    View Slide

33. FOSDEM - @marcoGomier
    val appModule = module {


    single { JokeLocalDataSourceImpl() }


    single { JokeRepositoryImpl(get()) }


    }


    View Slide

34. FOSDEM - @marcoGomier
    fun Application.module() {


    install(Koin) {


    slf4jLogger()


    modules(koinModules)


    }


    ...

    }


    View Slide

35. FOSDEM - @marcoGomier
    fun Route.jokeEndpoint() {


    val jokeRepository by inject()


    get {


    call.respond(jokeRepository.getRandomJoke())


    }


    post { apiCallParams
    ->

    val name = apiCallParams.name


    jokeRepository.watch(name)


    call.respond("Ok")


    }


    }


    View Slide

36. FOSDEM
    @marcoGomier
    Logging


    View Slide

37. FOSDEM - @marcoGomier
    Timber
    class MyApplication : Application() {


    override fun onCreate() {


    super.onCreate()


    if (BuildConfig.DEBUG) {


    Timber.plant(Timber.DebugTree())


    } else {


    //
    Log to somewhere else


    }


    }


    }
    https://github.com/JakeWharton/timber


    View Slide

38. FOSDEM - @marcoGomier https://github.com/JakeWharton/timber
    Timber.d(“Message")


    Timber.v("Message")


    Timber.i("Message")


    Timber.w("Message")


    Timber.wtf("Message")


    Timber.e(exception)
    Timber


    View Slide

39. FOSDEM - @marcoGomier
    SLF4J
    http://www.slf4j.org/index.html
    routing {


    get("/api/v1") {


    call.application.environment.log.info("Hello from /api/v1!")


    }


    }
    fun Application.module(testing: Boolean = false) {


    log.info("Hello from module!")


    }


    View Slide

40. FOSDEM - @marcoGomier
    val logger = LoggerFactory.getLogger(MyClass
    ::
    class.java)
    inline fun T.getLogger(): Logger {


    return LoggerFactory.getLogger(T
    ::
    class.java)


    }
    class MyClass {


    private val logger = getLogger()


    fun main() {


    logger.info("Hello World")


    }


    }


    View Slide

41. FOSDEM - @marcoGomier
    logger.trace("Message")


    logger.debug("Message")


    logger.info("Message")


    logger.warn("Message")


    logger.error("Message")
    SLF4J


    View Slide

42. FOSDEM - @marcoGomier
    logback.xml


    View Slide

43. FOSDEM - @marcoGomier
    logback.xml









    %d{YYYY-MM-dd HH:mm:ss.SSS} [%thread] %-5level %logger{36} - %msg%n

    pattern>



    encoder>



    appender>





    ${LOG_DEST}/ktor-chuck-norris-sample.log

    file>







    ${LOG_DEST}/ktor-chuck-norris-sample.%d{yyyy-MM-dd}.log

    fileNamePattern>




    ${LOG_MAX_HISTORY}

    maxHistory>


    3GB

    totalSizeCap>



    rollingPolicy>





    %d{YYYY-MM-dd HH:mm:ss.SSS} [%thread] %-5level %logger{36} - %msg%n

    pattern>



    encoder>



    appender>





    />

    />


    root>


    />

    />

    />


    configuration>




    View Slide

44. FOSDEM
    @marcoGomier
    Secrets


    View Slide

45. FOSDEM - @marcoGomier
    local.properties
    tmdbKey="private_key"


    View Slide

46. FOSDEM - @marcoGomier
    val String.byProperty: String?


    get() {


    val local = java.util.Properties()


    val localProperties: File = rootProject.file("local.properties")


    if (localProperties.exists()) {


    localProperties.inputStream().use { local.load(it) }


    return local.getProperty(this)


    }


    return null


    }
    tmdbKey="private_key"
    buildConfigField("String", "TMDB_KEY", "\"${"tmdbKey".byProperty
    ?:
    "")}\"")
    build.gradle.kts


    View Slide

47. FOSDEM - @marcoGomier
    tmdbKey="private_key"
    buildConfigField("String", "TMDB_KEY", "\"${"tmdbKey".byProperty
    ?:
    "")}\"")
    val myKey: String = BuildConfig.TMDB_KEY
    NetworkApiInterceptor.kt


    View Slide

48. FOSDEM - @marcoGomier
    application.conf


    View Slide

49. FOSDEM - @marcoGomier
    application.conf
    ktor {


    deployment {


    port = 8080


    port = ${?PORT}


    }


    application {


    modules = [com.prof18.ktor.chucknorris.sample.ApplicationKt.module]


    }


    server {


    isProd = false


    }


    database {


    driverClass = "com.mysql.cj.jdbc.Driver"


    url = "jdbc:mysql:
    /
    /
    localhost:3308/chucknorris?useUnicode=true&characterEncoding=UTF-8"


    user = "root"


    password = "password"


    maxPoolSize = 3


    }


    }


    View Slide

50. FOSDEM - @marcoGomier
    fun Application.setupConfig() {


    val appConfig by inject()


    //
    Server


    val serverObject = environment.config.config("ktor.server")


    val isProd = serverObject.property("isProd").getString().toBoolean()


    appConfig.serverConfig = ServerConfig(isProd)


    }
    data class ServerConfig(


    val isProd: Boolean


    )
    class AppConfig {


    lateinit var serverConfig: ServerConfig


    //
    Place here other configurations


    }


    View Slide

51. FOSDEM - @marcoGomier
    fun Application.module() {


    ...



    setupConfig()


    val appConfig by inject()


    ...

    }




    View Slide

52. FOSDEM - @marcoGomier
    java -jar ktor-backend.jar -config=/config-folder/application.conf


    View Slide

53. FOSDEM
    @marcoGomier
    Testing


    View Slide

54. FOSDEM - @marcoGomier
    • Unit Test
    ->
    Just regular Kotlin Unit tests


    • androidTest
    ->
    TestEngine
    Testing
    https://ktor.io/docs/testing.html


    View Slide

55. FOSDEM - @marcoGomier
    @Test


    fun testRequests() = withTestApplication(module(testing = true)) {


    with(handleRequest(HttpMethod.Get, "/")) {


    assertEquals(HttpStatusCode.OK, response.status())


    assertEquals("Hello from Ktor Testable sample application", response.content)


    }
    https://ktor.io/docs/testing.html


    View Slide

56. FOSDEM
    @marcoGomier
    Deploy


    View Slide

57. FOSDEM - @marcoGomier
    Deploy
    • aar


    • apk


    • aab


    View Slide

58. FOSDEM - @marcoGomier https://github.com/johnrengelman/shadow
    ./gradlew assembleRelease
    ./gradlew bundleRelease


    View Slide

59. FOSDEM - @marcoGomier
    Deploy
    • Fat JAR


    • Executable JVM application


    • WAR


    • GraalVM
    https://ktor.io/docs/deploy.html


    View Slide

60. FOSDEM - @marcoGomier
    • Fat JAR


    • Executable JVM application


    • WAR


    • GraalVM
    https://ktor.io/docs/deploy.html
    Deploy


    View Slide

61. FOSDEM - @marcoGomier
    build.gradle.kts
    https://github.com/johnrengelman/shadow
    plugins {


    ...

    id("com.github.johnrengelman.shadow") version "7.0.0"


    }


    View Slide

62. FOSDEM - @marcoGomier https://github.com/johnrengelman/shadow
    tasks {


    shadowJar {


    manifest {


    attributes(Pair("Main-Class", "io.ktor.server.netty.EngineMain"))


    }


    }


    }
    build.gradle.kts


    View Slide

63. FOSDEM - @marcoGomier https://github.com/johnrengelman/shadow
    tasks {


    shadowJar {


    manifest {


    attributes(Pair("Main-Class", "io.ktor.server.netty.EngineMain"))


    }


    }


    }
    application {


    mainClass.set("io.ktor.server.netty.EngineMain")


    }
    build.gradle.kts


    View Slide

64. FOSDEM - @marcoGomier https://github.com/johnrengelman/shadow
    ./gradlew shadowJar


    View Slide

65. FOSDEM - @marcoGomier


    View Slide

66. FOSDEM
    @marcoGomier
    Conclusions


    View Slide

67. FOSDEM - @marcoGomier
    • Ktor is flexible and unopinionated
    ->
    Knowledge Transfer


    • Mobile knowledge can be adapted


    • Effective scaling and deploying can be hard


    • “Going to the other side” enrich your dev vision
    Conclusions


    View Slide

68. FOSDEM - @marcoGomier https://github.com/prof18/ktor-chuck-norris-sample


    View Slide

69. Bibliography / Useful Links
    • https:
    //
    ktor.io/


    • https:
    //
    ktor.io/learn/


    • https:
    //
    ktor.io/docs/welcome.html


    • https:
    //
    github.com/JetBrains/Exposed/wiki


    • https:
    //
    www.marcogomiero.com/posts/2021/ktor-project-structure/


    • https:
    //
    www.marcogomiero.com/posts/2021/ktor-logging-on-disk/


    • https:
    //
    www.marcogomiero.com/posts/2021/ktor-in-memory-db-testing/


    View Slide

70. Marco Gomiero
    FOSDEM
    Thank you!


    > Twitter: @marcoGomier


    > Github: prof18


    > Website: marcogomiero.com


    View Slide
