Liran Haimovitch - Understanding Python’s Debugging Internals

Knowing your enemies is as important as knowing your friends. Understanding your debugger is a little of both. Have you ever wondered how Python debugging looks on the inside? On our journey to building a Python debugger, we learned a lot about its internals, quirks and more.

During this session, we’ll share how debugging actually works in Python. We’ll discuss the differences between CPython and PyPy interpreters, explain the underlying debugging mechanism and show you how to utilize this knowledge at work and up your watercooler talk game.

https://us.pycon.org/2019/schedule/presentation/181/

Transcript

1. Rookout © 2018 All Rights Reserved. Confidential Understanding Python’s Debugging Internals Liran Haimovitch, Rookout
2. 2 Who am I? • Co-Founder and CTO of Rookout • An advocate of modern software methodologies • My passion is to understand how software ACTUALLY works
3. 3 About Rookout • Rookout is a platform for live-data collection and delivery • It slashes debugging time, saving hours and days of writing and deploying logs, then waiting for data to arrive • Rookout’s non-breaking breakpoints enable dev team to collect data on the fly with no restarts, extra coding, or redeployments
4. 4 • Python standard library pdb • PyDev Debugger • • Others IIDLE and more... Python Debuggers Out There
5. 5 sys.settrace
6. 6 What does sys.settrace do? • sys.settrace registers a callback for the Python interpreter • This callback is invoked on interpreter events: • Function call • Line Execution • Function return • Exception raised
7. 7 Example Callback def simple_tracer(frame, event, arg): co = frame.f_code func_name = co.co_name line_no = frame.f_lineno print("{e} {f} {l}".format( e=event, f=func_name, l=line_no)) return simple_tracer
8. 8 Flow example side-by-side 1) def a(): 2) return b() * 2 3) 4) def b(): 5) return 'response_from_b' 6) 7) sys.settrace(simple_tracer) 8) a() ➔ call a 1 ➔ line a 2 ➔ call b 4 ➔ line b 5 ➔ return b 5 ➔ return a 2
9. 9 Example Callback def simple_tracer(frame, event, arg): co = frame.f_code func_name = co.co_name line_no = frame.f_lineno print("{e} {f} {l}".format( e=event, f=func_name, l=line_no)) return simple_tracer
10. 10 What’s happening here? sys.settrace global trace registers callback invokes local trace returns - line - return - exception events
11. 11 Looking back 1) def a(): 2) return b() * 2 3) 4) def b(): 5) return 'response_from_b' 6) 7) sys.settrace(simple_tracer) 8) a() Global: A: B: Global: simple_ tracer A: simple_ tracer B: simple_ tracer
12. 12 How do you handle multi threading? • threading.settrace() • Must be called as early as possible - or you’ll miss threads • Doesn’t cover the underlying `thread` module and other low-level implementations • gevent/eventlet • Global tracing function will be shared among greenlets
13. 13 How easy is it to build a debugger?
14. 14 Inherit from Bdb class Debugger(Bdb): def __init__(self): Bdb.__init__(self) self.breakpoints = dict() self.set_trace()
15. 15 Add set_breakpoint def set_breakpoint(self, filename, lineno, method): self.set_break(filename, lineno) try : self.breakpoints[(filename, lineno)].add(method) except KeyError: self.breakpoints[(filename, lineno)] = [method]
16. 16 def user_line(self, frame): if not self.break_here(frame): return # Get filename and lineno from frame (filename, lineno, _, _, _) = inspect.getframeinfo(frame) methods = self.breakpoints[(filename, lineno)] for method in methods: method(frame) Override user_line
17. 17 Performance Testing
18. 18 CPython Performance Benchmarks def empty_method(): pass def simple_method(): a = 1 b = 2 c = 3 d = 4 e = 5 f = 6 g = 7 h = 8 i = 9 j = 10 We’ll test multiple scenarios with each implementation: • Test without debugger • Test with debugger but no breakpoints • Test with a breakpoint in the different file • Test with a breakpoint in the same file
19. 19 Vanilla Bdb
20. 20 • Avoid local tracing • Optimize “call” events • Optimize “line” events Performance Optimizations
21. 21 Python Optimized
22. 22 Cython
23. 23 • Python bdb is naive • Performance may be improved by a significant margin • Performance becomes gradually harder to improve • What happens if we set an empty tracer? Performance Insights def pass_tracer(frame, event, arg): return pass_tracer
24. 24 Pass Through
25. 25 Diving Into CPython • Turning on tracing, sets up CPython for extra work • Some in Python • Some in C - maybe_call_line_trace (eval.c:4384)
26. 26 So, what did we do?
27. 27 Python Bytecode Bytecode - is a form of instruction set designed for efficient execution by a software interpreter (Wikipedia). Python compiles our sources into its bytecode.
28. 28 Python Bytecode def multiply(a, b): result = a * b return result 4 0 LOAD_FAST 0 (a) 3 LOAD_FAST 1 (b) 6 BINARY_MULTIPLY 7 STORE_FAST 2 (result) 5 10 LOAD_FAST 2 (result) 13 RETURN_VALUE '|\x00\x00|\x01\x00\x14}\x02\x00|\x02\x00S'
29. 29 Interpreter Stages 1. Compile 2. Execute - interpreter loop a. Tracing
30. 30 1. Go to the byte code 2. Find the line of code 3. Insert our breakpoint The Rookout Way
31. 31 Tools for Bytecode Manipulation 1. Python Standard Library (read-only): a. inspect b. dis 2. Google: a. cloud-debug-python
32. 32 Bonus Slides - What do you do after you break?
33. 33 Confidential What do you do once you have stopped in a breakpoint? 1. frame - see into the interpreter 2. The inspect built-in module is well documented and easy to use 3. Performance is surprisingly awesome, as this is similar to how the interpreter actually works
34. 34 Getting Frame Information def test_frameinfo(): frame = inspect.currentframe() print(inspect.getframeinfo(frame)) Traceback( filename='frame_inspect.py', lineno=16, function='test_frameinfo', code_context=[' print(inspect.getframeinfo(frame)) \n'], index=0 ) output
35. 35 Getting Local Variables def test_vars(): mystr = "mystr" mydict = {"mykey": "myvalue"} mylist = [1, 2, 3] print(inspect.currentframe().f_locals) { 'mydict': { 'mykey':'myvalue' }, 'mystr': 'mystr', 'mylist': [ 1, 2, 3 ] } output
36. 36 Use cases 1. Show off your Python skills :) 2. Get source information (logging module) 3. Walk up the stack 4. Build a debugger
37. 37 Resources from this talk https://github.com/Rookout/pycon-debugging-internals
38. Rookout © 2018 All Rights Reserved. Confidential Thank you! rookout.com
