  1. 那些年,我們用 Javascript
    幹了一套  POS
    Base  on  XULRunner

    Rack  Lin  阿土伯      @HDM9    V2

    View Slide

  2. about:me
    •  ViViPOS  Co.,  Ltd    技術總監
    –  利用 javascript  寫 〞收銀機〞(傳統產業,全新感受)
    •  CoCo  都可、50嵐、歇腳亭、Yamaha  、星聚點KTV……

    •  PHP  /  Javascript  /  Java  Programmer  (目前移情於
    Scala  )

    •  [email protected]
    •  hSps://twiSer.com/racklin
    •  hSp://www.plurk.com/racklin
    •  hSps://www.facebook.com/racklin1002
    •  hSp://racklin.blogspot.tw/      (生小孩後就變癈墟)

    View Slide

  3. NOT  Web-­‐Based  POS
    Standalone  Applica.on
    Running  on  Client  Terminal

    View Slide

  4. NOT  Only  POS  So[ware
    POS  SDK

    View Slide

  5. What  is  POS

    View Slide

  6. What  is  POS

    View Slide

  7. What  is  POS

    View Slide

  8. POS  Development
    •  Delphi
    – 曾經王者 ,目前依然是
    •  Java
    –   非 Windows  Solu\ons  首選

    •  VIVIPOS  SDK
    – Javascript  /  html  /  xul        based  on  XULRunner

    View Slide

  9. WHY  XULRunner
    •  Cross-­‐Pla_orm
    •  Update  and  Packages  mechanism  *
    •  XPCOM  *
    •  Networking  *
    •  Storage  -­‐  SQLite  interface  *
    •  Chrome  Registra\on  *
    •  Gecko  rendering  engine  *
    –  HTML5  /  CSS3
    –  XBL  /  XUL  /  Javascript  1.8
    –  XML  (XSLT,  XMLHSpRequest,  DOMParser,  etc.)
    •  Coding  For  Fun

    View Slide

  10. Cloc  for  VIVIPOS  SDK

    View Slide

  11. Cloc  for  VIVIPOS  Exts

    View Slide

  12. Coding  For  Fun  ?
    •  over  100,000  lines  javascript
    •  over  300,000  lines  XUL

    View Slide

  13. WHY  NOT  blablabla…
    •  Before  2010
    – Why  not  Delphi  /  VB  /  Java
    •  A[er  2010
    – Why  not  Nodejs
    •  v0.1.102.zip  —  2010.07.25,  Version  0.1.102
    – Why  not  Chrome
    •  0.2.149    2008.09.08
    •  VIVIPOS  Start  at  2008

    View Slide

  14. About  VIVIPOS  (2008)
    •  Hardware:  Via  Eden  1G  512MB  Ram
    •  OS:  Ubuntu  Linux  8.04
    •  DB:  SQLite3  /  JSON
    •  XULRunner  1.8.1
    •  Languages:  C(vala)  /  Javascript

    View Slide

  15. Start  Hard  Coding  ?
    POS  Applica\on  Look  Simply…

    View Slide

  16. 別急著硬幹!!

    除非你想 75 天賣掉整個商業模式!!

    而不是產品!

    View Slide

  17. Project  or  Product
    •  經常 Branch  /  Code  Generator
    •  流行名言:你以為在創新、其實是在代工
    Customer  A
    Customer  B
    Customer  C

    View Slide

  18. Components  Based
    •  Upstream  Core  Components
    •  Customiza\on
    – Customer  A  (  SDK  +  POS  +  A1  +  B1  +  C1  ….)
    – Customer  B  (  SDK    +  POS  +  A1  +  C1  +  D1  …)
    – Customer  C  (  SDK  +  POS  +  A1  +  E1  +  F1  …)
    VIVIPOS  SDK
    VIVIECR  (POS  Main  UI)

    View Slide

  19. 自給自足,豐衣足食
    •  當 POS  主流開發是 WinForm  /  JFrame  /
    TForm  時,我在 VIM.
    •  #1:GREU\ls  and  XPCOM
    •  #2:GeckoJS
    •  #3:SDK  and  XBLs

    View Slide

  20. VIVIPOS  SDK

    View Slide

  21. VIVIPOS  SDK
    WTF  !
    Gray  Screen  ?

    View Slide

  22. 老板:
    SDK  是嗎!! OK!
    那你至少告訴我 SDK  怎麼應用!

    View Slide

  23. Hello  World

    View Slide

  24. GREU\ls
    •  2007.09  Released  and  open  source
    •  Object  Namespace
    •  Charset  Conversion
    •  Crypto  Hash  U\li\es  –  md5  /  sha1  /sha256
    •  File  And  Directory  IO
    •  JSON  encode  /  decode  use  na\ve  C++
    implemented.
    •  Threading  –  Na\ve  Mul\-­‐Threading  support
    •  XPCOM  Helper

    View Slide

  25. GeckoJS
    •  MVC  Architecture
    –  Dispatcher  /  Controller
    –  Model  –  Ac\veRecord  Like  and  Associa.ons  Support
    –  VIVIPOS  Query  Language  (VQL)
    •  Database  Adapter
    –  SQLite  and  JSON
    •  Configure  /  Registry  System
    –  Preference  System
    •  Applica\on  Scope  Session
    •  Logging  –  Log4js  !?
    •  i18n  /  l10n
    •  Event  System  –  NOT  DOM  Event

    View Slide

  26. C++  XPCOM
    •  On-­‐Screen-­‐Display  (OSD)
    •  DBUS  No\fica\on
    •  Matchbox  Virtual  Keyboard
    •  IO  Control
    –  Serial  Port  /  USB
    –  Parallel  Port
    –  DIO
    –  GPIO
    •  JSLoader


    View Slide

  27. XBL  Components
    •  ACL  /  Config  /  Session  aware  containers
    •  Data  aware  UI  components
    – Label
    – BuSon
    – BuSons  Group

    View Slide

  28. XBL  Components
    •  Scrollable  BuSons  Group

    View Slide

  29. XBL  Components
    •  Tree  and  scrollable  tree

    View Slide

  30. Debug  Tools
    •  JS  Console
    •  JS  Debuger
    •  DOM  Inspector
    •  SQLite  Manager
    •  SDK  Console  #

    View Slide

  31. Start  Hard  Coding  Now  ?
    Wait!!  SDK  /  Framework  were  tools,  not  core  values.

    View Slide

  32. Core  Values
    •  Pla_orm  For  3rd  Party  Developers
    •  Plugins  Anywhere
    – User  Interface  /  Layouts  /  Skins
    – I18n/l10n
    – Devices
    – Reports
    – Promo\ons  Modules
    – Second  Display  Modules
    – Inventory  System

    View Slide

  33. Core  Values
    •  Services  Registry
    – Binding  To  UI
    – Binding  To  Hotkey
    – Remove  Invoke  (  IPC  /  Protocol)
    •  NO  Linux  Na\ve  UI
    •  Open  Source  Addons

    View Slide

  34. Reports
    •  Reports
    – CSV  –  Template  Engine
    – HTML  –  Template  Engine
    – PDF
    •  Print  To  PDF  By  Gecko
    – Export  about  100  pages  PDF  more  than  30mins
    •  Print  To  PDF  By  WebKit  (libwkhtmltox)
    – Export  about  100  pages  PDF  less  than  3mins
    – But  Buggy  –  NOT  Support  thead/tbody/_oot.

    View Slide

  35. Promo\on  framework
    •  Cart  is  Simple  !?
    好的 PM  勝過好的 Programmers
    – 二件九折 -­‐>  第二件八折  -­‐>  第三件七折 …..
    (呀不就是全部打九折)
    •  Promo\on  Modules  *
    – Base  Condi\ons
    – Product  Trigger  –  Plugin-­‐able
    – Discount  Type  –  Plugin-­‐able


    View Slide

  36. VIVIPOS  Architecture
    VIVIPOS  APP
    ECR-­‐like  User  Interface  /  Func;ons
    LINUX  BASE
    Display
    Driver
    USB
    Driver
    Keypad
    Driver
    Touch
    Driver
    Audio
    Driver
    LAN
    Driver
    Power
    Management
    Others
    LIBRARIES
    XPCOM
    GPIO
    Database
    Serial  IO   Parallel  IO
    Network
    Others
    VIVIPOS  SDK
    Core  Libraries
    Signature  Func.on
    FRAMEWORK
    Plug-­‐in  /  Add-­‐on  Manager
    Network
    Manager
    Backup
    Manager
    Restore
    Manager
    Others
    Peripheral
    Manager
    UI
    Manager
    Func.on
    Manager
    Language
    Manager
    Update
    Manager
    Window
    Manager
    Content
    Manager
    View
    System
    Message
    Dispatch
    Database
    Interface
    Report
    Module
    Cart
    Module
    APPLICATIONS
    Clerk
    Opera.ons
    Stock
    Control
    Repor.ng
    System
    Func.on
    Others
    Add-­‐on

    -­‐  Member  Management
    -­‐  SMS  Promo.on
    -­‐  Special  Discount
    -­‐  …  etc.
                   Add-­‐on

                   -­‐  Cash  Flow  Report
                   -­‐  Gi]  Card  Payment
                   -­‐  …  etc.

    View Slide

  37. VIVIPOS  POS

    View Slide

  38. Binding  Service  To  UI

    View Slide

  39. Binding  Service  Hotkey

    View Slide

  40. I18n  /  l10n

    View Slide

  41. VIVIPOS  Add-­‐ons  For  Produc\on
    •  Main  POS  Add-­‐on    -­‐  VIVIECR
    – 690  pages  PDF  Manual
    – En  /  zhTW  /  zhCN  /  Jp  /  Thai  /  Fr
    •  Taiwan  Invoice  Add-­‐on
    •  Customer  Management  Add-­‐on
    •  Taiwan  Receipts  Format  Add-­‐on
    •  Simple  Browser
    •  Second  Display  Add-­‐on

     Open  Source

    View Slide

  42. Simple  Web  Browser  Add-­‐on
    •  Embedded  Firefox  browser
    •  Gecko  1.9.2  Engine
    – HTML5  Support
    – CSS3  Support
    •  Binding  To  BuSon
    •  Binding  To  Hotkey
    •  Disable  Popup  Window

    View Slide

  43. DEMO  VIVIPOS

    VIDEO:  hSp://youtu.be/-­‐z26mGeynok
    •  Next  Page  is  DEMO  Descrip\on

    View Slide

  44. DEMO  Descrip\on
    •  A  Produc\on  POS  Solu\on  is  combina\on  of
    many  add-­‐ons  not  ONE  App.
    •  Every  individual  Add-­‐ons  CAN  online  update.
    •  Add-­‐on  can  hook  the  event  and  change  the
    shopping  flow.
    •  EX.  ONLY  ONE  Customer  Need  BEEP  when
    product  not  found  !?
    Add  a  add-­‐on  for  him,  Not  add  BEEP  feature  in
    upstream  version.

    View Slide

  45. IPC
    •  DBUS
    •  Javascript  implemented  HSp  server
    – Binding  on  localhost:8888
    •  Dispatch  Command
    •  No\fy  Observer
    •  Session  Opera\on
    •  ...

    View Slide

  46. IPC  Samples
    •  AddItem  To  Cart
    –  curl  hSp://localhost:8888/dispatch?
    controller=Cart&command=addItemByBarcode&data=123456789
    •  Get  Current  Login  Clerk
    –   curl  hSp://localhost:8888/session?ac\on=get&key=user.username
    •  Shutdown  –  Trigger  Event/Observe
    –   curl  hSp://localhost:8888/observer?topic=shutdown
    •  Ex.  Installed  HelloWorld.xpi
    –   curl  hSp://localhost:8888/dispatch?
    controller=Helloworld&command=sayHello&data=Rack

    View Slide

  47. Last  Mile  of  the  O2O
    •  Add  a  Protocol  Handler,  ‘vivipos’  scheme.
    – Proxy  to  exists  JS  HSpd  Services.
    •  Remote/Local  Website  CAN
    – Callback  VIVIPOS  Func\ons
    – Use  VIVIPOS  Hardwares  (  Printer  /  Cash  Drawer)
    – Use  VIVIPOS  Cart  and  Promo\ons
    – Use  VIVIPOS  Reports


    View Slide

  48. VIVIPOS  Scheme  Samples
    •  Remote  website  HTML
    – AddItem  To  Cart
    controller=Cart&command=addItemByBarcode&data=123456789”>A
    ddItem
    – Shutdown  –  Trigger  Event/Observe
    Shutdown
    –   Ex.  Installed  HelloWorld.xpi
     controller=Helloworld&command=sayHello&data=Rack">Hello

    View Slide

  49. Open  PCHOME24  Example
    •  Click  ACER  E1-­‐531  Will  Add  Item  to  VIVIPOS  Cart  And  Prin\ng
    Receipt.

    View Slide

  50. What  is  Online2OffLine
    •  線上訂位  /  線上團購 <>實體消費
    •  會員積點 /  折扣
    •  線上促銷<>實體促銷
    •  線上銷售<>實體銷售
    •  消費分析

    View Slide

  51. SDK  -­‐  Last  Mile  of  O2O
    •  Online  Services  開發者不用重覆造輪子,為
    了整合服務而開發陽春 POS 系統.
    VIVIPOS 是完整的收銀系統且 Open  Source
    •  除了整合服務,更可開發自己的 POS  系統
    •  使用您熟悉的平台語言開發 POS
    JAVA  /  PHP  /  RAILS  /  NODEJS  ……..
    •  可以不需要學習 VIVIPOS  SDK.  (盡量啦)

    View Slide

  52. 3rd  Party  interes.ng  Addons
    •  Singapore  Bugis  Street
    – NetPayment  /  EZLinks
    •  Microprogram 悠遊卡 and  Life+
    •  OpenLife
    •  24卷 (大陸團購-好像掛了 orz  )
    •  USA  -­‐  KIOSK
    •  Media  Player

    View Slide

  53. About  Cloud?
    •  Running  Web  Based  Applica\on  in  Cloud
    –  Yes  ,  Simple  Web  Browser  with
    HTML5  /  CSS3  Supported
    •  Sending  Data  to  Cloud  real\me
    –  Yes,  Using  AJAX
    •  Packing  Data  to  Cloud  when  Day-­‐End
    –  YES  ,  VIVIConnect  Add-­‐on  support  Client-­‐Side  ETL  to  packing
    Databases  to  your  own  Back-­‐End  Server.
    –  HTTP/HTTPs
    –  FTP
    –  S3
    •  Running  your  own  scripts
    –  PHP  /  Python    installed  on  every  VIVIPOS  Terminal.

    View Slide

  54. JS  Loader
    •  Javascript  Encoder  For  3rd  party  Developer
    – NOT  obfuscator
    •  Add  Trial  Version  to  your  Add-­‐on
    •  Add  Expire  Date  to  your  Add-­‐on
    •  Lock  your  Add-­‐on  on  a  special  Terminal

    View Slide

  55. Any  Ideas  are  welcome
    POS  or  POS

    View Slide

  56. Thank  You
    Coding  For  Fun

    View Slide

  57. Resources
    •  Slide:
    hSp://goo.gl/TlHKf
    •  GREU\ls:
    hSps://github.com/racklin/greu\ls
    •  XULRunner  –  MDN
    hSps://developer.mozilla.org/en-­‐US/docs/
    XULRunner
