How Good Are Your Types?

Mutation workshop 2017 at Tokyo

Transcript

1. How Good Are Your Types?
   Rahul Gopinath
   Eric Walkingshaw


   View Slide

2. Tests & Types
   March 1, 2017
   2
   Means of reducing susceptibility of programs to faults


   View Slide

3. Tests & Types
   March 1, 2017
   3
   Tests
   • Concrete
   • Probabilistic guarantee
   def factorial(n):
   > assert(factorial(0)==1)
   > assert(factorial(3)==6)
   if n < 1:
   return 1
   else:
   return factorial(n-1)
   Types
   • Abstract
   • Absolute guarantee
   def factorial(n : Int) -> Int:
   if n < 1:
   return 1
   else:
   return factorial(n-1)


   View Slide

4. Tests & Types
   March 1, 2017
   4
   Tests
   • Verbose
   • Typically easy to understand
   • Generally, aim to cover the
   complete specification
   • Can have failing test cases
   Types
   • Terse
   • Can be harder to understand
   • Typically a much smaller set
   of properties covered than
   the complete specification
   • All types, if specified should
   be correct


   View Slide

5. Aside: When they are applied
   March 1, 2017
   5
   Specify types Write tests
   TDD Gradual Typing
   Write program


   View Slide

6. How do we choose?
   March 1, 2017
   6
   • Both test suites and types are used to prevent bugs
   • Both tests and types can be improved with more resources
   • We have finite budget
   • We need a way to compare


   View Slide

7. We know how to evaluate tests
   March 1, 2017
   7
   Code Coverage
   • Adequate coverage says
   something about correctness
   def factorial(n):
   > assert(factorial(0)==1)
   > assert(factorial(3)==6)
   if n == 0:
   return 1
   else:
   return factorial(n-1)
   Doesn't translate well to types
   • A program usually has a
   complete type specification
   def factorial(n : Int) -> Int:
   if n == 0:
   return 1
   else:
   return factorial(n-1)


   View Slide

8. We improve types by refining them
   March 1, 2017
   8
   weak
   def factorial(n : Any) -> Any:
   if n < 1: return 1
   else: return factorial(n-1)
   strong
   def factorial(n : Number )-> Number:
   if n < 1: return 1
   else: return factorial(n-1)
   stronger
   def factorial(n : Integral) -> Integral:
   if n < 1: return 1
   else: return factorial(n-1)
   weak
   def hashtags(jr : Any)
   -> Any:
   ....
   strong
   def hashtags(jr : Dict[str, Any])
   -> Tuple[int, List[str]]:
   ...
   stronger
   def hashtags(jr : Dict[str, List[Tuple[int, str]]])
   -> Tuple[int, Any]:
   ...
   How much better is stronger compared to strong?


   View Slide

9. Idea! use mutation testing
   March 1, 2017
   9


   View Slide

10. Evaluation
    March 1, 2017
    10


    View Slide

11. Tools
    March 1, 2017
    11
    • Language: Python
    • Annotations verified by MyPy for Python 3.6
    • Mutation testing tool: MutPy
    • Standard (traditional) mutation operators


    View Slide

12. MutPy Operators
    March 1, 2017
    12


    View Slide

13. Subjects
    March 1, 2017
    13
    • twitter-graph (own project)
    • 83 LOC
    • 10/10 Functions type annotated
    • 25 test cases with 99% statement coverage
    • w3lib
    • 369 LOC
    • 34/42 Functions type annotated
    • 97 test cases with 94.7% statement coverage
    In both, type annotations were added after the test suite
    Did not find any undetected faults on adding type annotations


    View Slide

14. Methodology
    March 1, 2017
    14
    • Started with the strictest annotations available in MyPy
    • Progressively weakened innermost type annotations
    • (int|str|...) -> Any
    • Container[Any*] -> Any
    Examples:
    def hashtags(jr : Dict[str, List[Tuple[int, str]]]) -> Tuple[int, List[str]]:
    def hashtags(jr : Dict[str, List[Any]]) -> Tuple[int, Any]:
    def hashtags(jr : Dict[str, Any]) -> Any:


    View Slide

15. Results
    March 1, 2017
    15


    View Slide

16. Results Summary
    March 1, 2017
    16
    • The mutant kills from types is a strict subset of kills by the test suite
    • No difference in mutation scores between stronger and weaker
    annotations in either projects
    Type Test Total
    twitter-graph 62 142 171
    w3lib 94 545 677


    View Slide

17. Examples of Type Errors
    March 1, 2017
    17
    - print("Hello" + " World")
    + print("Hello" - " World")
    def square(x: int) -> int:
    - y = x**2
    + pass
    return y
    class A(object):
    def add(self, x: int) -> int:
    - y = x + self.val
    + y = x + val
    return y
    class A(object):
    ...
    - @staticmethod
    def mymethod(x: int) -> int:
    return x
    ...
    a = A()
    a.mymethod()
    Operator Replacement Statement Deletion
    Decorator Deletion Self Deletion


    View Slide

18. Discussion
    March 1, 2017
    18
    Mutants Killed:
    • Type assertions ⊂ Test suite
    • Type errors ⊂ Semantic errors
    • Strength of type annotations in MyPy for Python 3.6
    • Weaker type assertions ~ Stronger type assertions
    • Mutants targeted towards tests, so insufficient to detect differences
    in type assertions


    View Slide

19. Failure to distinguish type assertions
    March 1, 2017
    19
    • Our mutation tools usually mutate the AST
    • Many simple errors that programmers make have a larger impact in the AST
    • Single token mutation of AST fails to reproduce them
    fn('Ex %s' % 1 * 2)
    (fn
    (% ’Ex %s’
    (* 1 2)))
    fn('Ex %s' % 1 + 2)
    (fn
    (+ (% ’Ex %s’ 1)
    2)


    View Slide

20. Conclusions
    March 1, 2017
    20
    Two possibilities
    • Current mutation operators are inadequate for measuring quality of type annotations
    • Need operators that target types
    • Investigate source based rather than AST based mutants
    • Stronger type annotations aren't that helpful
    • Farfetched, but worth investigating


    View Slide
