  1. 1
    ©2018 VMware, Inc.
    NSX-T Data Center & Openshift
    Details of the NSX-T Data Center integration
    with Openshift

    View Slide

  2. 2
    ©2018 VMware, Inc.
    Key design goals of the NSX-T Data Center OCP/K8S Integration
    Don't stand in the way
    of the developer !
    Provide solutions to map
    the Kubernetes constructs
    to enterprise networking
    constructs
    Secure Containers, VMs
    and any other endpoints
    with overarching
    Firewall Policies
    Provide visibility &
    troubleshooting tools to
    ease the container
    adoption in the
    enterprise

    View Slide

  3. 3
    ©2018 VMware, Inc.
    VMs Containers Bare Metal
    Servers
    Consistent Networking and Security Policy across all workloads
    NSX: Networking and Security for Any Workload
    NSX Data Center

    View Slide

  4. 4
    ©2018 VMware, Inc.
    Shared T1 router for all Namespaces in a Cluster
    Network Automation for Kubernetes
    NSX / K8s topology
    10.24.0.0/24 10.24.2.0/24
    T1
    admin@k8s-master:~$ oc new-project foo
    namespace ”foo" created
    admin@k8s-master:~$ oc new-project bar
    namespace ”bar" created
    admin@k8s-master:~$ oc run nginx-foo --image=nginx -n foo
    deployment "nginx-foo" created
    admin@k8s-master:~$ oc run nginx-bar --image=nginx -n bar
    deployment "nginx-bar" created
    Active/StandBy T0
    Active/Active T0
    NAT boundary
    EBGP/Static
    Physical
    Router 1
    Physical
    Router 2
    SNAT IP per Project is
    plumbed here
    K8s nodes
    K8s masters

    View Slide

  5. 5
    ©2018 VMware, Inc.
    NSX / OCP topology
    10.24.0.0/24 10.24.2.0/24
    T1
    Active/StandBy T0
    Active/Active T0
    EBGP/Static
    Physical
    Router 1
    Physical
    Router 2
    LB for Service of type LB
    OCP compute nodes
    OCP Control Plane
    Logical Segment and subnet
    per OC Project
    vSphere, NSX-T, Storage
    SNAT IP per NS is
    plumbed here
    T1 per OCP Cluster
    Openshift 4.4

    View Slide

  6. 6
    ©2018 VMware, Inc.
    OCP / NSX-T Data Center Components
    NCP is a software component
    provided by VMware in form of a
    container image, e.g. to be run as
    a K8s/OCP Pod.
    NCP is build in a modular way, so
    that individual adapters can be
    added for different CaaS and PaaS
    systems at some point
    NSX Container Plugin (NCP)
    NCM
    Infra
    Openshift
    Adapter
    CloudFoundry
    Adapter
    NSX Container Plugin
    K8S Adapter
    NSX
    Manager
    API Client
    NSX
    Manager
    Project: foo Project: bar
    NSX/ OCP topology
    OCP/K8s master
    etcd
    API-Server
    Scheduler

    View Slide

  7. 7
    ©2018 VMware, Inc.
    Tenancy / Topology Mapping
    Persistent IPs for OCP Project
    With NSX-T each Tenant (OCP Project)
    either gets its own SNAT IP (NAT Mode),
    or is directly identifiable by its
    source subnet (No NAT Mode)
    Node VM
    OpenvSwitch
    10.12.5.5/24
    10.12.1.8/24
    172.16.1.11/24
    mgmt IP
    vnic
    Project. Foo
    T1 router
    PAS VMs
    T1 router
    VLAN Trunk
    NSX-T Logical Switch
    Project. Bar
    T1 router
    172.16.1.1/24 10.12.1.1/24 10.12.5.1/24
    Pods
    Database
    (VM based or Physical)
    Physical DC Firewall
    A new SNAT IP is allocated on the
    T1 GW for each Tenant for NAT
    Mode
    In NAT Mode, the external DC Firewall and the
    DB can distinguish tenant 'foo' and tenant 'bar'
    using the source SNAT IP that is allocated to a
    specific Tenant.
    Tenant: foo
    Tenant: bar
    In No-NAT Mode, the external DC Firewall and
    the DB can distinguish tenant 'foo' and tenant
    'bar' using the source IP Subnet that is allocated
    to a specific Tenant.

    View Slide

  8. 8
    ©2018 VMware, Inc.
    Infrastructure Teams can pre-create Firewall
    rules in existing DC physical Firewalls to
    allow traffic from specific workloads in
    Openshift
    The OCP user / DevOps can deploy
    applications that are easily identifiable in
    the physical network
    With this feature a set of Kubernetes
    Workloads (Pods) can be assigned to use a
    specific IP or group of SNAT IPs to source
    their traffic from
    Before this feature only a SNAT IP to a OCP
    Project was assigned
    Feature
    Benefits
    Persistent SNAT IP per K8s/OCP Service
    Specifying the source IP Kubernetes Workloads using the K8s service
    Tier0 LR
    Corporate network
    DB
    allow – from: 134.247.100.10 (App)
    to: 134.247.200.9 (DB)
    Tier1 LR
    Openshift Project:
    Foo
    Web-Frontend
    Pods
    App Logic
    Pods
    K8S/OCP Svc for App
    K8S/OCP Svc for Web
    Namespace LS(s)
    SNAT App Svc Pods to:
    134.247.100.10
    For all other Pods
    use projects’s SNAT IP

    View Slide

  9. K8s/OCP Metadata / NSX Logical Port Mapping
    ▶ kubectl get pod nsx-demo-rc-c7x65 -o yaml
    apiVersion: v1
    kind: Pod
    metadata:
    creationTimestamp: 2018-07-25T12:05:56Z
    generateName: nsx-demo-rc-
    labels:
    app: nsx-demo
    name: nsx-demo-rc-c7x65
    namespace: nsx-ujo
    Metadata within Kubernetes like Namespace, Pod
    names, Labels all get copied to the NSX Logical Port
    as Port Tags

    View Slide

  10. Pre-Created Security Groups / Firewall rules (admin rules)
    NSX can be configured to collect ports and switches in dynamic security groups based on Tags
    (Kubernetes Metadata) and apply Firewall rules on them
    Match on Port Tags
    Matching Pods
    are part of the
    Group
    Groups are used in
    Firewall sections as src
    and dst

    View Slide

  11. Policy support – Security per Category
    Environment
    Health-checks
    Admin Rules
    Application
    Kubernetes Network Policy
    Default rule:
    1. Allow Cluster
    2. Allow Project
    3. None
    apiVersion: networking.k8s.io/v1
    kind: NetworkPolicy
    metadata:
    name: nsx-demo-policy
    spec:
    podSelector:
    matchLabels:
    app: nsx-demo
    policyTypes:
    - Ingress
    ingress:
    - from:
    - ipBlock:
    cidr: 100.64.160.11/32
    ports:
    - port: 80
    protocol: TCP

    View Slide

  12. Built-in Load Balancing
    NCM
    Infra
    K8s / OS
    Adapter
    CloudFoundry
    Adapter
    Libnetwork
    Adapter
    NSX Container Plugin
    More…
    NSX
    Manager
    API Client
    NSX
    Manager
    K8s/ocp master
    etcd
    API-Server
    Scheduler
    Virtual Server
    10.114.209.209
    HTTP and/or
    HTTPS traffic
    Server Pool 1
    Server Pool 2
    Rule 2
    /bar/
    Rule 1
    /foo/
    LB Service
    NCM
    Infra
    K8s / OS
    Adapter
    CloudFoundry
    Adapter
    Libnetwork
    Adapter
    NSX Container Plugin
    More…
    NSX
    Manager
    API Client
    NSX
    Manager
    K8s/ocp master
    etcd
    API-Server
    Scheduler
    Virtual Server
    10.114.209.212
    TCP and/or
    UDP traffic
    Server Pool
    LB Service
    Offload the Openshift Router to the highly performant NSX-T LoadBalancer. It creates one single VIP for router
    and creates L7 rules for every Route. It also create L4 VIP for every Service of Type LoadBalancer.

    View Slide

  13. 13
    ©2018 VMware, Inc.
    Distributed IDS for Containers
    Full visibility with NCP

    View Slide

  14. Central Visibility
    With NSX-T you have deep visibility and troubleshooting tools.

    View Slide

  15. 15
    ©2018 VMware, Inc.
    Inventory Dashboards
    Network Topology visualization in NSX-T UI
    • Network topology visualization for
    Pods and VMs
    • Search and filter based on specific
    IAAS or K8 constructs
    Feature

    View Slide

  16. 16
    ©2018 VMware, Inc.
    NCP Alarms

    View Slide

  17. NSX-T Data Center Values for Containers
    Enterprise-class
    Networking
    Advanced Security Enhanced Operations
    Full Network
    Visibility
    Enterprise
    Support
    Unified VM-to-
    Container
    Networking
    Micro-
    Segmentation
    N S X - T Va l u e s f o r C o n t a i n e r s
    F e a t u r e s

    View Slide

  18. 19
    ©2018 VMware, Inc.
    Key values
    NSX-T NCP
    ➢ Avoiding double encapsulation and bypassing node TCP/IP stack
    ➢ Service type Load Balancer is realized automaticallyas NSX Virtual Server
    ➢ Admin Firewall policyenforced per service, per cluster, or across all clusters
    ➢ Distributed Firewall and Distributed Intrusion Detection Systemper Pod
    ➢ Reliableegress source IP address per OCP Project and per Service
    ➢ Mix of private and routed subnets per OpenShift Project
    ➢ Single pane of glass for OpenShift, Kubernetes, VM , and BM workload
    ➢ Network Qualityof Service, Multicast Routing, VRF
    ➢ Service Insertion to redirect traffic between Pods to third party security appliance
    ➢ Visibilityand Troubleshooting tools like NSX Traceflow, IPFIX, Port Mirroring, vRNI

    View Slide

  19. 20
    ©2018 VMware, Inc.
    Installation

    View Slide

  20. 21
    ©2018 VMware, Inc.
    Operator is essentially a custom
    controller
    NSX-NCP operator watches for
    Network CRD
    Triggers NCP deployment if
    networkType field in the CRD is
    ncp.
    Applies tags on NSX Segment Ports
    Once done the operator updates
    the network CRD status
    RedHat Universal Base Image (UBI)
    Streamlines Installation, Updates, and Management of NCP
    NSX-T Network Cluster Operator
    NSX-NCP
    operator
    OCP/K8s master
    etcd API-Server
    Controllers
    Network CRD
    cluster
    NCP
    NCP
    NCP
    bootstrap
    bootstrap
    bootstrap
    bootstrap
    bootstrap
    node-agent
    node-agent
    node-agent
    node-agent
    node-agent
    Deployment
    With replica of 3 Daemon-set
    All nodes
    Daemon-set
    All nodes
    nsx-system project/namespace
    Schedul
    er

    View Slide

  21. 22
    ©2018 VMware, Inc.
    Integrated with NSX
    Installing Openshift 4
    It is recommended to set cluster name as it is in the configmap above
    Network name
    NCP will create IP Block fin NSX for Pod networking
    openshift-install create manifests --dir=
    Configure NSX parameters
    Set NCP image name and location
    https://github.com/vmware/nsx-container-plugin-operator/tree/master/deploy
    Copy those files to manifest folder
    openshift-install create ignition-configs --dir=
    https://docs.openshift.com/container-platform/4.4/installing/installing_vsphere/installing-vsphere.html

    View Slide

  22. 23
    ©2018 VMware, Inc.
    Hipster Shop
    Cloud-Native Microservices Demo Application
    https://github.com/GoogleCloudPlatform/microservices-demo
    1
    6
    © 201
    8 VMware, Inc.
    https://github.com/GoogleCloudPlatform/microservices-demo

    View Slide

  23. Hipster Shop User Interface
    Home Page Checkout Screen

    View Slide

  24. Hipster Shop Architecture
