  1. Copyright@2015 NTT corp. All Rights Reserved.
    第28回PaaS勉強会
    @sinohara
    Container Communication on lattice

    View Slide

  2. Copyright@2015 NTT corp. All Rights Reserved.
    自己紹介
    @sinohara
    NTTでNWの研究開発してます
    (本業はクラウドではありません)
    PaaS勉強中です!

    View Slide

  3. Copyright@2015 NTT corp. All Rights Reserved.
    今日のトピック
    Lattice Appのコンテナ間通信ってどうやるの?
    どこまで出来るの?

    View Slide

  4. Copyright@2015 NTT corp. All Rights Reserved.
    https://github.com/cloudfoundry-incubator/diego-design-notes
    ↓この黄枠がlattice
    http://www.slideshare.net/jacopen/diego-45603123
    http://www.slideshare.net/jacopen/lattice-47937770
    Lattice解説資料(過去のPaaS勉強会より)

    View Slide

  5. Copyright@2015 NTT corp. All Rights Reserved.
    動機、と、(ちょっと)宣伝
    24/365無停止を実現するためのソフトウェア技術
     Consistent-Hashベースのスケール性能に優れた負荷分散構成
     障害時にもステート/キャッシュを失わないレプリケーション
     大規模災害でもサービスを止めないDisaster Recovery
    通信システム以外で面白い使い方、出来ない??
    NetroSphere構想:キャリアネットワークのあり方を変革する新R&Dコンセプトを策定
    http://www.ntt.co.jp/news2015/1502/150219a.html

    View Slide

  6. Copyright@2015 NTT corp. All Rights Reserved.
    要するに
    アイデア募集中!
     頻繁にDBに書きに行く必要がある企業情報システムとか
     スピード!リアルタイム!なソーシャルゲームとか
     課金処理とかやりたいeコマースとか
    ちょっと尖ったアプリケーション開発に如何ですか?
    × =?
    lattice

    View Slide

  7. Copyright@2015 NTT corp. All Rights Reserved.
    Virtual NW
    VM
    boot
    Location #1
    Management
    boot
    boot
    Policy
    VM
    boot
    VNF
    Manager
    (SBY)
    Application
    deployment
    VM VM
    DP MW DP MW
    LB
    (SBY)
    SIP SIP
    VIM
    Orchestrator
    (SBY)
    VM
    boot
    Location #2
    Management
    VM
    boot
    VM
    VIM
    Orchestrator
    (ACT)
    VNF
    Manager
    (ACT)
    boot
    DP MW
    SIP LB
    (ACT)
    *DP MW = Distributed processing middleware
    VM
    DP MW
    SIP
    data
    data
    data
    data R
    O R
    O
    O R
    O R
    O
    * = Data (original)
    R
    * = Data (replica)
    VNF
    Cloud Band Node
    (Alcatel-Lucent)
    Distributed processing platform
    including NTT R&D technology
    (FUJITSU)
    NFVI
    MAGONIA構成例(内部動作)
    Question:これ、latticeでも出来るの?
    クラスタメンバ(VM)間で
    ステート/キャッシュの
    レプリケーションを実施
    ETSI NFV ISG Proofs of Concept #12: Demonstration of multi-location, scalable, stateful Virtual Network Function
    http://nfvwiki.etsi.org/index.php?title=Demonstration_of_multi-location,_scalable,_stateful_Virtual_Network_Function

    View Slide

  8. Copyright@2015 NTT corp. All Rights Reserved.
    今日のトピック(再掲)
    Lattice Appのコンテナ間通信ってどうやるの?
    どこまで出来るの?
    ⇒latticeを色々触ってみて、ネットワーク周りの
    仕組みを分かった範囲で解説します。

    View Slide

  9. Copyright@2015 NTT corp. All Rights Reserved.
    LATTICEの検証内容
    •Lattice Cluster Deployment
    • https://github.com/cloudfoundry-incubator/lattice#clustered-deployment
    • provider = AWS (東京リージョン)
    • lattice version = v0.2.5 + v0.4.0(new!)
    • terraform version = 0.5.3
    • docker version = 1.7.1
    •Lattice cellのNW構造チェック
    • ひたすらifconfig
    •php::http_get(another_container_IP)で
    コンテナ間通信が出来るか確認
    • docker image : kshino/lattice-php-cluster
    • phpinfo()でIPアドレスを確認
    • $_ENV[“CF_INSTANCE_IP”] : VMのIPアドレス
    • $_SERVER[“SERVER_ADDR”] : コンテナのIPアドレス
    • HTTP_GETで?ip=xxx.xxx.xxx.xxxを渡すと、http_get(xxx.xxx.xxx.xxx)が動く

    View Slide

  10. Copyright@2015 NTT corp. All Rights Reserved.
    LATTICE DEPLOYMENT(V0.2.5)
    # Installing docker
    sudo apt-get install -y lxc-docker
    # Installing terraform
    wget -q https://dl.bintray.com/mitchellh/terraform/terraform_0.5.3_linux_amd64.zip -P $HOME/pkg
    sudo unzip -qn $HOME/pkg/terraform_0.5.3_linux_amd64.zip -d /usr/bin/
    # Installing lattice
    git clone https://github.com/cloudfoundry-incubator/lattice.git
    cd lattice
    git checkout v0.2.5
    cd
    # Installing lattice CLI(ltc)
    sudo wget -q https://lattice.s3.amazonaws.com/releases/v0.2.5/linux-amd64/ltc -P /usr/bin
    sudo chmod +x /usr/bin/ltc
    # Deploying lattice cluster
    mkdir $HOME/tf
    cp $HOME/lattice/terraform/aws/example/lattice.aws.tf $HOME/tf/
    cd $HOME/tf
    vi lattice.aws.tf
    terraform get -update
    terraform apply
    AWS access_key, secret_key, .pemの設定
    Based on Ubuntu 14.04

    View Slide

  11. Copyright@2015 NTT corp. All Rights Reserved.
    LATTICE ARCHITECTURE
    Cell-1
    Cell-0
    eth0
    10.0.1.21
    eth0
    10.0.1.193
    54.92.69.178
    54.92.69.172
    Region = ap-northeast-1
    Virtual Machine Container Network Interface
    description Network Tunnel
    V0.2.5
    Cell-brain
    54.92.69.42
    Lattice構築時

    View Slide

  12. Copyright@2015 NTT corp. All Rights Reserved.
    Container #1 Container #2 Container #3 Container #4
    LATTICE ARCHITECTURE
    Cell-1
    Cell-0
    eth0
    10.0.1.21
    w0m6uagc6vub-0
    w0m6uagc6vub-1
    10.254.0.1
    w0m6uagc6vuc-0
    w0m6uagc6vuc-1
    10.254.0.5
    wb-0m6uf716cb10
    10.254.0.2
    w0m6uf716lku-0
    w0m6uf716lku-1
    10.254.0.1
    wb-0m6uf716cb20
    10.254.0.6
    w0m6uf716lkv-0
    w0m6uf716lkv-1
    10.254.0.5
    Eth0
    10.0.1.193
    54.92.69.178
    54.92.69.172
    Region = ap-northeast-1
    Virtual Machine Container Network Interface
    description Network Tunnel
    wb-0m6uagc6m510
    10.254.0.2
    wb-0m6uagc6m500
    10.254.0.6
    kshino/lattice-php-cluster kshino/lattice-php-cluster kshino/lattice-php-cluster kshino/lattice-php-cluster
    V0.2.5
    Cell-brain
    54.92.69.42
    ltc create

    View Slide

  13. Copyright@2015 NTT corp. All Rights Reserved.
    Container #1 Container #2 Container #3 Container #4
    LATTICE ARCHITECTURE
    Cell-1
    Cell-0
    eth0
    10.0.1.36
    w0m7o5jmuq2r-0
    w0m7o5jmuq2r-1
    10.254.0.1
    w0m7o5jmuq2s-0
    w0m7o5jmuq2s-1
    10.254.0.5
    wb-0m7oavp54l10
    10.254.0.2
    w0m7oavp5co6-0
    w0m7oavp5co6-1
    10.254.0.1
    wb-0m7oavp54l20
    10.254.0.6
    w0m7oavp5co7-0
    w0m7oavp5co7-1
    10.254.0.5
    Eth0
    10.0.1.87
    52.69.211.8
    54.65.44.124
    Region = ap-northeast-1
    Virtual Machine Container Network Interface
    description Network Tunnel
    wb-0m7o5jmuii20
    10.254.0.2
    wb-0m7o5jmuii30
    10.254.0.6
    kshino/lattice-php-cluster kshino/lattice-php-cluster kshino/lattice-php-cluster kshino/lattice-php-cluster
    V0.4.0
    Cell-brain
    54.92.58.70
    (v0.4.0も同じ)

    View Slide

  14. Copyright@2015 NTT corp. All Rights Reserved.
    Container #1 Container #2 Container #3 Container #4
    LATTICE ARCHITECTURE
    Cell-1
    Cell-0
    eth0
    10.0.1.21
    w0m6uagc6vub-0
    w0m6uagc6vub-1
    10.254.0.1
    w0m6uagc6vuc-0
    w0m6uagc6vuc-1
    10.254.0.5
    wb-0m6uf716cb10
    10.254.0.2
    w0m6uf716lku-0
    w0m6uf716lku-1
    10.254.0.1
    wb-0m6uf716cb20
    10.254.0.6
    w0m6uf716lkv-0
    w0m6uf716lkv-1
    10.254.0.5
    Eth0
    10.0.1.193
    54.92.69.178
    54.92.69.172
    Region = ap-northeast-1
    Virtual Machine Container Network Interface
    description Network Tunnel
    wb-0m6uagc6m510
    10.254.0.2
    wb-0m6uagc6m500
    10.254.0.6
    kshino/lattice-php-cluster kshino/lattice-php-cluster kshino/lattice-php-cluster kshino/lattice-php-cluster
    V0.2.5
    Cell-brain
    54.92.69.42
    HTTP_GET 54.92.69.42.xip.io/index.php?ip=10.254.0.5
    (php) http_get(http://10.254.0.5/phpinfo.php)
    疎通確認方法

    View Slide

  15. Copyright@2015 NTT corp. All Rights Reserved.
    DEMO

    View Slide

  16. Copyright@2015 NTT corp. All Rights Reserved.
    • 同一Cell(VM)内であれば、コンテナのIP
    addressを指定すればOK!
    • App URLにも繋がるけど、コンテナの狙い撃ち
    は不可
    • 他Appsのコンテナにも繋げてしまいます・・
    • [v0.4.0] Cell-VMでapache2が動いてる模様
    Container #1 Container #2 Container #3 Container #4
    LATTICE ARCHITECTURE
    Cell-1
    Cell-0
    eth0
    10.0.1.21
    w0m6uagc6vub-0
    w0m6uagc6vub-1
    10.254.0.1
    w0m6uagc6vuc-0
    w0m6uagc6vuc-1
    10.254.0.5
    wb-0m6uf716cb10
    10.254.0.2
    w0m6uf716lku-0
    w0m6uf716lku-1
    10.254.0.1
    wb-0m6uf716cb20
    10.254.0.6
    w0m6uf716lkv-0
    w0m6uf716lkv-1
    10.254.0.5
    Eth0
    10.0.1.193
    54.92.69.178
    54.92.69.172
    Region = ap-northeast-1
    Virtual Machine Container Network Interface
    description Network Tunnel
    wb-0m6uagc6m510
    10.254.0.2
    wb-0m6uagc6m500
    10.254.0.6
    kshino/lattice-php-cluster kshino/lattice-php-cluster kshino/lattice-php-cluster kshino/lattice-php-cluster
    V0.2.5
    Cell-brain
    54.92.69.42
    HTTP_GET 54.92.69.42.xip.io/index.php?ip=10.254.0.5
    (php) http_get(http://10.254.0.5/phpinfo.php)
    疎通確認方法

    View Slide

  17. Copyright@2015 NTT corp. All Rights Reserved.
    Cell(VM)間は?

    View Slide

  18. Copyright@2015 NTT corp. All Rights Reserved.
    ・・次回作にご期待ください
    m(_ _)m

    View Slide

  19. Copyright@2015 NTT corp. All Rights Reserved.
    いくつか候補が有ります
    FanNetworking

    View Slide

  20. Copyright@2015 NTT corp. All Rights Reserved.
    FanNetworking
    •同一のClass B-NW内でOverlay + Tunneling
    •コンテナIPのネゴシエーションがVM内で完結
    •/8なので1 Cellあたり最大255個
    •コンテナのIPの共有は別途必要
    •現在v0.3.0/Ubuntu image(GCE/AWS)有
    172.16.0.0/16
    172.16.0.0/16
    172.16.3.5
    172.16.23.37
    10.3.5.x/8
    10.23.37.x/8
    VM#1
    VM#2
    Overlay-NW
    Class-B NW
    https://wiki.ubuntu.com/FanNetworking
    https://launchpad.net/ubuntu/+source/ubuntu-fan
    https://insights.ubuntu.com/2015/06/24/ubuntu-fan-images/

    View Slide

  21. Copyright@2015 NTT corp. All Rights Reserved.
    •etcdでコンテナ用アドレス空間を共有管理
    •VMごとにアドレス空間を切り出し
    •flanneldを通じVM間で通信
    https://github.com/coreos/flannel/blob/master/packet-01.png
    https://github.com/coreos/flannel

    View Slide

  22. Copyright@2015 NTT corp. All Rights Reserved.
    まとめ
    Lattice Appのコンテナ間通信の仕組みについて、
    分かったことを紹介
    Cell内のコンテナ間通信はPrivate IPで。
    Cellをまたがるコンテナ間通信については
    To Be Continued….
    アイデア募集中!
