How to Test Your Compose UI (DroidKaigi 2022, Tokyo)

While Compose is easy to adopt, not creating legacy code right at the start of such a journey requires some extra planning, awareness, and, most importantly, testing. We'll have a look at how we can test pure Compose UIs as well as hybrid ones that have Views and composables too.

In this talk, we'll learn what the semantics tree is, what is its relation to the composition, how we can manipulate it in composables using the Semantics modifier, how we can implement composables with testability in mind, and how we can test pure Compose and hybrid UIs.

I presented this talk at DroidKaigi 2022, Tokyo.

Video is available on the following link:
https://youtu.be/OzYJIJT_9F8

Transcript

1. stewemetal
   How to Test Your Compose UI
   István Juhos


   View Slide

2. #DroidKaigi2022 – @stewemetal
   Source of examples
   github.com/stewemetal/composehydrationtracker


   View Slide

3. #DroidKaigi2022 – @stewemetal
   Testing Views - Recap ☕
   • View(Group) objects with rendering and behavior
   • Views are inflated from XML descriptors or instantiated in code
   • Views are directly referrable by View IDs


   View Slide

4. #DroidKaigi2022 – @stewemetal
   Testing Compose UI
   🧪


   View Slide

5. #DroidKaigi2022 – @stewemetal
   Testing Compose UI
   • No direct access to the Composition
   • No UI objects to look up directly
   • No UI element IDs
   • Not every Composable emits UI
   ❌
   ❌
   ❌
   ❌
   🧪


   View Slide

6. #DroidKaigi2022 – @stewemetal
   @Composable
   fun EntryList(
   entries: List = emptyList(),
   ) {
   LazyColumn {
   items(entries) { item ->
   HydrationItem(item = item)
   }
   }
   }
   @Composable
   fun HydrationItem(item: HydrationEntry) {
   Row(
   modifier = Modifier
   .wrapContentHeight(
   align = Alignment.CenterVertically,
   Composables to test: EntryList
   #DroidKaigi2022 – @stewemetal
   EntryList
   HydrationItem


   View Slide

7. #DroidKaigi2022 – @stewemetal
   HydrationItem(item = item)
   }
   }
   }
   @Composable
   fun HydrationItem(item: HydrationEntry) {
   Row(
   modifier = Modifier
   .wrapContentHeight(
   align = Alignment.CenterVertically,
   )
   .padding(16.dp)
   ) {
   Text(
   "${item.milliliters} ml",
   modifier = Modifier.weight(1f),
   )
   Text("${item.dateTime}")
   }
   }
   Composables to test: HydrationItem
   HydrationItem
   EntryList
   #DroidKaigi2022 – @stewemetal


   View Slide

8. #DroidKaigi2022 – @stewemetal
   Setting up Compose UI tests


   View Slide

9. #DroidKaigi2022 – @stewemetal
   // Test rules and transitive dependencies:
   androidTestImplementation "androidx.compose.ui:ui-test-junit4:$compose_version”
   // Needed for createComposeRule, but not createAndroidComposeRule:
   debugImplementation "androidx.compose.ui:ui-test-manifest:$compose_version"
   Setting up Compose UI tests


   View Slide

10. #DroidKaigi2022 – @stewemetal
    Setting up Compose UI tests
    @RunWith(AndroidJUnit4!::class)
    class EntryListTest {
    !// !!...
    }
    create ComposeRule ()
    Android
    @get:Rule
    val composeTestRule =


    View Slide

11. #DroidKaigi2022 – @stewemetal
    Setting up Compose UI tests
    @RunWith(AndroidJUnit4::class)
    class EntryListTest {
    // ...
    }
    create ComposeRule ()
    Android
    @get:Rule
    val composeTestRule =
    https://www.droidcon.com/2022/08/01/modern-testing-on-android/
    Modern Testing on Android


    View Slide

12. #DroidKaigi2022 – @stewemetal
    Setting up Compose UI tests
    @RunWith(AndroidJUnit4::class)
    class EntryListTest {
    // ...
    }
    create ComposeRule ()
    Android
    @get:Rule
    val composeTestRule =


    View Slide

13. #DroidKaigi2022 – @stewemetal
    Setting up Compose UI tests
    @RunWith(AndroidJUnit4!::class)
    class EntryListTest {
    !// !!...
    }
    create ComposeRule ()
    Android
    @get:Rule
    val composeTestRule =


    View Slide

14. #DroidKaigi2022 – @stewemetal
    Setting up Compose UI tests
    @RunWith(AndroidJUnit4::class)
    class EntryListTest {
    // ...
    }
    create ComposeRule ()
    Android
    @get:Rule
    val composeTestRule =


    View Slide

15. #DroidKaigi2022 – @stewemetal
    Setting up Compose UI tests
    @RunWith(AndroidJUnit4::class)
    class EntryListTest {
    // ...
    }
    createComposeRule()
    @get:Rule
    val composeTestRule =


    View Slide

16. #DroidKaigi2022 – @stewemetal
    @get:Rule val composeTestRule = createComposeRule()
    @Test
    fun entriesExist_entriesDisplayed() {
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    // ...
    }
    }
    A simple UI test
    createComposeRule()
    @get:Rule val composeTestRule =


    View Slide

17. #DroidKaigi2022 – @stewemetal
    A simple UI test
    @get:Rule val composeTestRule = createComposeRule()
    @Test
    fun entriesExist_entriesDisplayed() {
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    // ...
    }
    }


    View Slide

18. #DroidKaigi2022 – @stewemetal
    A simple UI test
    @get:Rule val composeTestRule = createComposeRule()
    @Test
    fun entriesExist_entriesDisplayed() {
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    // ...
    }
    }


    View Slide

19. #DroidKaigi2022 – @stewemetal
    A simple UI test
    @get:Rule val composeTestRule = createComposeRule()
    @Test
    fun entriesExist_entriesDisplayed() {
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    "// ""...
    }
    }


    View Slide

20. #DroidKaigi2022 – @stewemetal
    A simple UI test
    @get:Rule val composeTestRule = createComposeRule()
    @Test
    fun entriesExist_entriesDisplayed() {
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    "// ""...
    }
    }


    View Slide

21. #DroidKaigi2022 – @stewemetal
    A simple UI test
    @get:Rule val composeTestRule = createComposeRule()
    @Test
    fun entriesExist_entriesDisplayed() {
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    // ...
    }
    }
    private val entries = listOf(
    HydrationEntry(…),
    HydrationEntry(…),
    HydrationEntry(…),
    )


    View Slide

22. #DroidKaigi2022 – @stewemetal
    A simple UI test
    @get:Rule val composeTestRule = createComposeRule()
    @Test
    fun entriesExist_entriesDisplayed() {
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    "// ""...
    }
    }
    So, how can we act or assert on EntryList? 🤔


    View Slide

23. #DroidKaigi2022 – @stewemetal
    The semantics tree 🌳


    View Slide

24. #DroidKaigi2022 – @stewemetal
    The semantics tree 🌳
    • A parallel tree next to the Composition 🌲🌳
    • Used for accessibility and testing
    • Composables (can) contribute to the semantics tree


    View Slide

25. #DroidKaigi2022 – @stewemetal
    The semantics tree 🌳
    composeTestRule.apply {
    setContent {
    Text("100 ml")
    }
    }
    Semantics tree
    root node
    Semantic node with text
    "100 ml"


    View Slide

26. #DroidKaigi2022 – @stewemetal
    The semantics tree 🌳
    composeTestRule.apply {
    setContent {
    Text("100 ml")
    }
    }
    Root
    Text = '[100 ml]'


    View Slide

27. #DroidKaigi2022 – @stewemetal
    The semantics tree 🌳
    composeTestRule.apply {
    setContent {
    Row {
    Text("100 ml")
    }
    }
    }
    Root
    Text = '[100 ml]'


    View Slide

28. #DroidKaigi2022 – @stewemetal
    The semantics tree 🌳
    composeTestRule.apply {
    setContent {
    Row {
    Text("100 ml")
    Text("2022-10-05")
    }
    }
    }
    Text = '[100 ml]' Text = '[2022-10-05]'
    Root


    View Slide

29. #DroidKaigi2022 – @stewemetal
    Visualizing the semantics tree 🌳👀
    Text = '[100 ml]' Text = '[2022-10-05]'
    Root
    Row {
    Text("100 ml")
    Text("2022-10-05")
    }


    View Slide

30. #DroidKaigi2022 – @stewemetal
    Visualizing the semantics tree 🌳👀
    • In Compose tests
    onRoot()
    .printToLog("RowAndTexts") Text = '[100 ml]' Text = '[2022-10-05]'
    Root


    View Slide

31. #DroidKaigi2022 – @stewemetal
    Visualizing the semantics tree 🌳👀
    • In Compose tests
    onRoot()
    .printToLog("RowAndTexts")
    D/RowAndTexts: printToLog:
    Printing with useUnmergedTree = 'false'
    Node #1 at (l=0.0, t=66.0, r=224.0, b=125.0)px
    |-Node #2 at (l=0.0, t=66.0, r=136.0, b=125.0)px
    | Text = '[100 ml]'
    | Actions = [GetTextLayoutResult]
    |-Node #3 at (l=0.0, t=66.0, r=224.0, b=125.0)px
    Text = '[2022-10-05]'
    Actions = [GetTextLayoutResult]
    Text = '[100 ml]' Text = '[2022-10-05]'
    Root


    View Slide

32. #DroidKaigi2022 – @stewemetal
    Visualizing the semantics tree 🌳👀
    • In Compose tests
    onRoot()
    .printToLog("RowAndTexts")
    D/RowAndTexts: printToLog:
    Printing with useUnmergedTree = 'false'
    Node #1 at (l=0.0, t=66.0, r=224.0, b=125.0)px
    |-Node #2 at (l=0.0, t=66.0, r=136.0, b=125.0)px
    | Text = '[100 ml]'
    | Actions = [GetTextLayoutResult]
    |-Node #3 at (l=0.0, t=66.0, r=224.0, b=125.0)px
    Text = '[2022-10-05]'
    Actions = [GetTextLayoutResult]
    Text = '[100 ml]' Text = '[2022-10-05]'
    Root


    View Slide

33. #DroidKaigi2022 – @stewemetal
    Visualizing the semantics tree 🌳👀
    • In Compose tests
    onRoot()
    .printToLog("RowAndTexts")
    D/RowAndTexts: printToLog:
    Printing with useUnmergedTree = 'false'
    Node #1 at (l=0.0, t=66.0, r=224.0, b=125.0)px
    |-Node #2 at (l=0.0, t=66.0, r=136.0, b=125.0)px
    | Text = '[100 ml]'
    | Actions = [GetTextLayoutResult]
    |-Node #3 at (l=0.0, t=66.0, r=224.0, b=125.0)px
    Text = '[2022-10-05]'
    Actions = [GetTextLayoutResult]
    Text = '[100 ml]' Text = '[2022-10-05]'
    Root


    View Slide

34. #DroidKaigi2022 – @stewemetal
    Visualizing the semantics tree 🌳👀
    • In Compose tests
    onRoot()
    .printToLog("RowAndTexts")
    D/RowAndTexts: printToLog:
    Printing with useUnmergedTree = 'false'
    Node #1 at (l=0.0, t=66.0, r=224.0, b=125.0)px
    |-Node #2 at (l=0.0, t=66.0, r=136.0, b=125.0)px
    | Text = '[100 ml]'
    | Actions = [GetTextLayoutResult]
    |-Node #3 at (l=0.0, t=66.0, r=224.0, b=125.0)px
    Text = '[2022-10-05]'
    Actions = [GetTextLayoutResult]
    Text = '[100 ml]' Text = '[2022-10-05]'
    Root


    View Slide

35. #DroidKaigi2022 – @stewemetal
    Visualizing the semantics tree 🌳👀
    • In Android Studio
    • Layout Inspector


    View Slide

36. #DroidKaigi2022 – @stewemetal
    Modifying the semantics tree 🌳
    Row(
    modifier = Modifier
    .semantics {
    // ...
    }
    ) {
    Text("100 ml")
    Text("2022-10-05")
    }


    View Slide

37. #DroidKaigi2022 – @stewemetal
    Modifying the semantics tree 🌳
    Row(
    modifier = Modifier
    .semantics {
    // ...
    }
    ) {
    Text("100 ml")
    Text("2022-10-05")
    }


    View Slide

38. #DroidKaigi2022 – @stewemetal
    Root
    Text = '[100 ml]' Text = '[2022-10-05]'
    Modifying the semantics tree 🌳
    Row(
    modifier = Modifier
    .semantics {
    // ...
    }
    ) {
    Text("100 ml")
    Text("2022-10-05")
    }


    View Slide

39. #DroidKaigi2022 – @stewemetal
    Modifying the semantics tree 🌳
    Row(
    modifier = Modifier
    .semantics {
    contentDescription = "List item"
    }
    ) {
    Text("100 ml")
    Text("2022-10-05")
    }
    Root
    Text = '[100 ml]' Text = '[2022-10-05]'
    ContentDescription =
    '[List item]'


    View Slide

40. #DroidKaigi2022 – @stewemetal
    Modifying the semantics tree 🌳
    Row(
    modifier = Modifier
    .semantics {
    testTag = "List item"
    }
    ) {
    Text("100 ml")
    Text("2022-10-05")
    }
    Root
    Text = '[100 ml]' Text = '[2022-10-05]'
    Tag =
    '[List item]'


    View Slide

41. #DroidKaigi2022 – @stewemetal
    Merging semantics - unmerged
    Row(
    modifier = Modifier
    .wrapContentHeight(
    align
    )
    .padding(16.dp)
    ) {
    Text(
    "${item.milliliters} ml",
    modifier = Modifier.weight(1f),
    )
    Text(
    "${item.dateTime}",
    )
    }
    Text = '[2022-10-05]'
    Text = '[100 ml]'
    Root
    = Alignment.CenterVertically,


    View Slide

42. #DroidKaigi2022 – @stewemetal
    Merging semantics - unmerged
    Row(
    modifier = Modifier
    .wrapContentHeight(
    align
    )
    .padding(16.dp)
    .semantics(mergeDescendants = false) {}
    ) {
    Text(
    "${item.milliliters} ml",
    modifier = Modifier.weight(1f),
    )
    Text(
    "${item.dateTime}",
    )
    }
    =
    Text = '[2022-10-05]'
    Text = '[100 ml]'
    Root
    Alignment.CenterVertically,


    View Slide

43. #DroidKaigi2022 – @stewemetal
    Merging semantics - merged
    Row(
    modifier = Modifier
    .wrapContentHeight(
    align
    )
    .padding(16.dp)
    .semantics(mergeDescendants = true) {}
    ) {
    Text(
    "${item.milliliters} ml",
    modifier = Modifier.weight(1f),
    )
    Text(
    "${item.dateTime}",
    )
    }
    =
    Text = '[100 ml, 2022-10-05]'
    Root
    Alignment.CenterVertically,


    View Slide

44. #DroidKaigi2022 – @stewemetal
    Merged semantics by default
    Role = 'Button'
    Focused = 'false'
    Text = '[100 ml]'
    Actions = [OnClick, GetTextLayoutResult]
    MergeDescendants = 'true'
    Button(
    onClick = {},
    ) {
    Text("100 ml")
    }


    View Slide

45. #DroidKaigi2022 – @stewemetal
    Clear semantics
    Text = '[Careful with this 😉]'
    ClearAndSetSemantics = 'true'
    Button(
    onClick = {},
    modifier = Modifier
    .clearAndSetSemantics {
    text = AnnotatedString("Careful with this 😉")
    },
    ) {
    Text("100 ml")
    }


    View Slide

46. #DroidKaigi2022 – @stewemetal
    Clear semantics
    Text = '[Careful with this 😉]'
    ClearAndSetSemantics = 'true'
    Button(
    onClick = {},
    modifier = Modifier
    .clearAndSetSemantics {
    text = AnnotatedString("Careful with this 😉")
    },
    ) {
    Text("100 ml")
    }


    View Slide

47. #DroidKaigi2022 – @stewemetal
    Using the semantics tree...
    @get:Rule val composeTestRule = createComposeRule()
    @Test
    fun entriesExist_entriesDisplayed() {
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    // ...
    }
    }
    !!...we can test Compose UI 🤩


    View Slide

48. #DroidKaigi2022 – @stewemetal
    Compose testing API


    View Slide

49. #DroidKaigi2022 – @stewemetal
    Select nodes - Finders
    • onRoot
    onRoot()
    .printToLog(”TAG") Root
    Text = '[100 ml, 2022-10-05]'
    Tag = '[List item]'
    ContentDescription =
    '[100 ml on 2022-10-05]'


    View Slide

50. #DroidKaigi2022 – @stewemetal
    Select nodes - Finders
    • onNodeWithTag
    onNodeWithTag("List item")
    Root
    Text = '[100 ml, 2022-10-05]'
    Tag = '[List item]'
    ContentDescription =
    '[100 ml on 2022-10-05]'


    View Slide

51. #DroidKaigi2022 – @stewemetal
    Select nodes - Finders
    • onNodeWithContentDescription
    onNodeWithContentDescription(
    "100 ml on 2022-10-05",
    )
    Root
    Text = '[100 ml, 2022-10-05]'
    Tag = '[List item]'
    ContentDescription =
    '[100 ml on 2022-10-05]'


    View Slide

52. #DroidKaigi2022 – @stewemetal
    Select nodes - Finders
    • onNodeWithText
    onNodeWithText(
    "100 ml",
    )
    Root
    Text = '[100 ml, 2022-10-05]'
    Tag = '[List item]'
    ContentDescription =
    '[100 ml on 2022-10-05]'


    View Slide

53. #DroidKaigi2022 – @stewemetal
    Select nodes - Finders
    • onNodeWithText
    onNodeWithText(
    "100 ml",
    useUnmergedTree = false,
    )
    Root
    Text = '[100 ml, 2022-10-05]'
    Tag = '[List item]'
    ContentDescription =
    '[100 ml on 2022-10-05]'


    View Slide

54. #DroidKaigi2022 – @stewemetal
    Select nodes - Finders
    • onNodeWithText
    Root
    Text = '[100 ml]' Text = '[2022-10-05]'
    Tag = '[List item]'
    ContentDescription =
    '[100 ml on 2022-10-05]'
    onNodeWithText(
    "100 ml",
    useUnmergedTree = true,
    )


    View Slide

55. #DroidKaigi2022 – @stewemetal
    Select nodes - Finders
    • onAllNodesWith...
    Tag = '[entries_list]'
    onAllNodesNodeWithTag("List item")
    Tag = '[List item]'
    Text = '[100 ml, 2022-10-05]'
    Tag = '[List item]'
    Text = '[500 ml, 2022-07-04]'
    !!...


    View Slide

56. #DroidKaigi2022 – @stewemetal
    Matchers
    •onNode()
    • hasText
    • hasContentDescription
    • hasTestTag
    • isEnabled
    • isSelected
    • isRoot
    • ...


    View Slide

57. #DroidKaigi2022 – @stewemetal
    Actions
    • performClick
    • performScrollTo...
    • performTextInput
    • performGesture
    • performKeyPress
    • ...
    onNodeWithText("100 ml")
    .performClick()


    View Slide

58. #DroidKaigi2022 – @stewemetal
    Actions
    • performClick
    • performScrollTo...
    • performTextInput
    • performGesture
    • performKeyPress
    • ...
    Role = 'Button'
    Focused = 'false'
    Text = '[100 ml]'
    Actions = [OnClick, GetTextLayoutResult]
    MergeDescendants = 'true'
    onNodeWithText("100 ml")
    .performClick()


    View Slide

59. #DroidKaigi2022 – @stewemetal
    Actions
    • performClick
    • performScrollTo...
    • performTextInput
    • performGesture
    • performKeyPress
    • ...
    onNodeWithText("100 ml")
    .performTextInput(
    "..."
    )


    View Slide

60. #DroidKaigi2022 – @stewemetal
    Actions
    • performClick
    • performScrollTo...
    • performTextInput
    • performGesture
    • performKeyPress
    • ...
    onNodeWithText("100 ml")
    .performTextInput(
    "..."
    )


    View Slide

61. #DroidKaigi2022 – @stewemetal
    Compose testing cheatseet
    developer.android.com/jetpack/compose/testing-cheatsheet


    View Slide

62. #DroidKaigi2022 – @stewemetal
    Testing in isolation


    View Slide

63. #DroidKaigi2022 – @stewemetal
    Testing in isolation
    • Structure your composables with testing in mind
    @Composable
    fun EntryList(
    entries: List = emptyList()
    ) {
    LazyColumn(
    modifier = Modifier.testTag("entries_list")
    ) {
    items(entries) { item ->
    HydrationItem(item = item)
    }
    }
    }


    View Slide

64. #DroidKaigi2022 – @stewemetal
    Testing in isolation
    • Structure your composables with testing in mind
    @Composable
    fun EntriesScreen(
    viewModel: EntriesViewModel = hiltViewModel()
    ) {
    when (val uiState = viewModel.uiState) {
    Loading -> EntriesLoading()
    is Content -> EntryList(entries = uiState.entries)
    }
    }


    View Slide

65. #DroidKaigi2022 – @stewemetal
    Testing in isolation
    • Structure your composables with testing in mind
    @Composable
    fun EntriesScreen(
    viewModel: EntriesViewModel = hiltViewModel()
    ) {
    when (val uiState = viewModel.uiState) {
    Loading -> EntriesLoading()
    is Content -> EntryList(entries = uiState.entries)
    }
    }


    View Slide

66. #DroidKaigi2022 – @stewemetal
    Testing in isolation
    • Structure your composables with testing in mind
    @Composable
    fun EntriesScreen(
    viewModel: EntriesViewModel = hiltViewModel()
    ) {
    when (val uiState = viewModel.uiState) {
    Loading -> EntriesLoading()
    is Content -> EntryList(entries = uiState.entries)
    }
    }


    View Slide

67. #DroidKaigi2022 – @stewemetal
    Testing in isolation
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    onNodeWithTag("entries_list")
    .onChildren()
    .assertCountEquals(entries.size)
    }


    View Slide

68. #DroidKaigi2022 – @stewemetal
    Testing behavior


    View Slide

69. #DroidKaigi2022 – @stewemetal
    Testing behavior
    • Test behavior with fake callbacks
    @Composable
    fun PredefinedValuesInput(
    onAddDrink: (Int) -> Unit,
    ) {
    Row {
    Button(onClick = { onAddDrink(100) }) { Text("100 ml") }
    Button(onClick = { onAddDrink(250) }) { Text("250 ml") }
    Button(onClick = { onAddDrink(500) }) { Text("500 ml") }
    }
    }


    View Slide

70. #DroidKaigi2022 – @stewemetal
    Testing behavior
    • Test behavior with fake callbacks
    @Composable
    fun PredefinedValuesInput(
    onAddDrink: (Int) -> Unit,
    ) {
    Row {
    Button(onClick = { onAddDrink(100) }) { Text("100 ml") }
    Button(onClick = { onAddDrink(250) }) { Text("250 ml") }
    Button(onClick = { onAddDrink(500) }) { Text("500 ml") }
    }
    }


    View Slide

71. #DroidKaigi2022 – @stewemetal
    Testing behavior
    composeTestRule.apply {
    var addedDrinkValue = 0
    setContent {
    HydrationTrackerTheme {
    PredefinedValuesInput(
    onAddDrink = { value ->
    addedDrinkValue = value
    },
    )
    }
    }
    onNodeWithText("500 ml").performClick()
    assertEquals(500, addedDrinkValue)
    }


    View Slide

72. #DroidKaigi2022 – @stewemetal
    Testing behavior
    composeTestRule.apply {
    var addedDrinkValue = 0
    setContent {
    HydrationTrackerTheme {
    PredefinedValuesInput(
    onAddDrink = { value ->
    addedDrinkValue = value
    },
    )
    }
    }
    onNodeWithText("500 ml").performClick()
    assertEquals(500, addedDrinkValue)
    }


    View Slide

73. #DroidKaigi2022 – @stewemetal
    Testing behavior
    composeTestRule.apply {
    var addedDrinkValue = 0
    setContent {
    HydrationTrackerTheme {
    PredefinedValuesInput(
    onAddDrink = { value ->
    addedDrinkValue = value
    },
    )
    }
    }
    onNodeWithText("500 ml").performClick()
    assertEquals(500, addedDrinkValue)
    }


    View Slide

74. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing


    View Slide

75. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing
    • Adding Compose content to existing View-based layouts
    • Adding existing Views to the composition
    • Compose & Espresso in the same tests
    🪟
    🪟
    ☕
    &


    View Slide

76. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing – ComposeView


    View Slide

77. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing – ComposeView

    android:id="@+id/toolbar”
    style="@style/Widget.MaterialComponents.Toolbar.Primary"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    app:layout_constraintTop_toTopOf="parent” />
    android:id="@+id/compose_view"
    android:layout_width="match_parent"
    android:layout_height= "wrap_content"
    app:paddingTop=”8dp"
    app:layout_constraintTop_toBottomOf="@id/toolbar” />



    View Slide

78. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing – ComposeView

    android:id="@+id/toolbar”
    style="@style/Widget.MaterialComponents.Toolbar.Primary"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    app:layout_constraintTop_toTopOf="parent” />
    android:id="@+id/compose_view"
    android:layout_width="match_parent"
    android:layout_height= "wrap_content"
    app:paddingTop=”8dp"
    app:layout_constraintTop_toBottomOf="@id/toolbar” />



    View Slide

79. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing – ComposeView

    android:id="@+id/toolbar”
    style="@style/Widget.MaterialComponents.Toolbar.Primary"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    app:layout_constraintTop_toTopOf="parent” />
    android:id="@+id/compose_view"
    android:layout_width="match_parent"
    android:layout_height= "wrap_content"
    app:paddingTop=”8dp"
    app:layout_constraintTop_toBottomOf="@id/toolbar” />



    View Slide

80. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing – ComposeView
    class ComposeViewDemoActivity : AppCompatActivity() {
    private lateinit var binding: ActivityComposeViewDemoBinding
    // ...
    }
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    binding = ActivityComposeViewDemoBinding.inflate(layoutInflater)
    setContentView(binding.root)
    }


    View Slide

81. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing – ComposeView
    binding.toolbar.title = "ComposeView Demo Title"
    binding.composeView.apply {
    setViewCompositionStrategy(DisposeOnDetachedFromWindow)
    setContent {
    CustomButton(
    text = "Demo Button",
    modifier = Modifier
    .padding(horizontal = 8.dp)
    .testTag("demo_custom_button"),
    ) {}
    }
    }
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    binding = ActivityComposeViewDemoBinding.inflate(layoutInflater)
    setContentView(binding.root)
    }


    View Slide

82. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing – ComposeView
    @RunWith(AndroidJUnit4::class)
    class DemoComposeViewTest {
    @get:Rule
    val androidComposeTestRule =
    createAndroidComposeRule()
    @Test
    fun hybrid_ui_customComposeButton_isVisible() {
    androidComposeTestRule.apply {
    Espresso.onView(withText("ComposeView Demo Title"))
    .check(matches(isDisplayed()))
    onNodeWithText("Demo Button").assertIsDisplayed()
    }
    }
    }


    View Slide

83. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing – ComposeView
    @RunWith(AndroidJUnit4::class)
    class DemoComposeViewTest {
    @get:Rule
    val androidComposeTestRule =
    createAndroidComposeRule()
    @Test
    fun hybrid_ui_customComposeButton_isVisible() {
    androidComposeTestRule.apply {
    Espresso.onView(withText("ComposeView Demo Title"))
    .check(matches(isDisplayed()))
    onNodeWithText("Demo Button").assertIsDisplayed()
    }
    }
    }


    View Slide

84. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing – ComposeView
    @RunWith(AndroidJUnit4::class)
    class DemoComposeViewTest {
    @get:Rule
    val androidComposeTestRule =
    createAndroidComposeRule()
    @Test
    fun hybrid_ui_customComposeButton_isVisible() {
    androidComposeTestRule.apply {
    Espresso.onView(withText("ComposeView Demo Title"))
    .check(matches(isDisplayed()))
    onNodeWithText("Demo Button").assertIsDisplayed()
    }
    }
    }
    ✅


    View Slide

85. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing – ComposeView
    @RunWith(AndroidJUnit4::class)
    class DemoComposeViewTest {
    @get:Rule
    val androidComposeTestRule =
    createAndroidComposeRule()
    @Test
    fun hybrid_ui_customComposeButton_isVisible() {
    androidComposeTestRule.apply {
    Espresso.onView(withText("ComposeView Demo Title"))
    .check(matches(isDisplayed()))
    onNodeWithText("Demo Button").assertIsDisplayed()
    }
    }
    }
    ✅
    ✅


    View Slide

86. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing - AndroidView


    View Slide

87. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing - AndroidView
    class CustomButtonView @JvmOverloads constructor(
    context: Context,
    attrs: AttributeSet? = null,
    defStyleAttr: Int = 0,
    ) : ConstraintLayout(context, attrs, defStyleAttr) {
    "// ""...
    LayoutInflater.from(context).inflate(R.layout.view_custom_button, this, true)
    "// ""...
    fun setText(text: String) { button.text = text }
    override fun setOnClickListener(listener: OnClickListener?) {
    button.setOnClickListener { listener"?.onClick(button) }
    }
    }


    View Slide

88. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing - AndroidView
    @Composable
    fun AndroidViewDemo(
    onButtonClick: () -> Unit,
    ) {
    Scaffold(
    topBar = { TopAppBar(title = { Text("AndroidView Demo Title") }) },
    content = { padding ->
    AndroidView(
    modifier = Modifier.padding(padding).wrapContentHeight(),
    factory = { context ->
    CustomButtonView(context).apply {
    setText("Demo Button")
    setOnClickListener { onButtonClick() }
    }
    },
    )
    }
    )
    }


    View Slide

89. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing - AndroidView
    @Composable
    fun AndroidViewDemo(
    onButtonClick: () -> Unit,
    ) {
    Scaffold(
    topBar = { TopAppBar(title = { Text("AndroidView Demo Title") }) },
    content = { padding ->
    AndroidView(
    modifier = Modifier.padding(padding).wrapContentHeight(),
    factory = { context ->
    CustomButtonView(context).apply {
    setText("Demo Button")
    setOnClickListener { onButtonClick() }
    }
    },
    )
    }
    )
    }


    View Slide

90. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing - AndroidView
    @Composable
    fun AndroidViewDemo(
    onButtonClick: () -> Unit,
    ) {
    Scaffold(
    topBar = { TopAppBar(title = { Text("AndroidView Demo Title") }) },
    content = { padding ->
    AndroidView(
    modifier = Modifier.padding(padding).wrapContentHeight(),
    factory = { context ->
    CustomButtonView(context).apply {
    setText("Demo Button")
    setOnClickListener { onButtonClick() }
    }
    },
    )
    }
    )
    }


    View Slide

91. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing - AndroidView
    @get:Rule
    val composeTestRule = createComposeRule()
    @Test
    fun composable_withAndroidView() {
    composeTestRule.apply {
    // ...
    }
    }
    var buttonClicked = false
    setContent {
    HydrationTrackerTheme {
    AndroidViewDemo { buttonClicked = true }
    }
    }


    View Slide

92. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing - AndroidView
    onNodeWithText("AndroidView Demo Title").assertIsDisplayed()
    Espresso.onView(withText("Demo Button")).check(matches(isDisplayed()))
    Espresso.onView(withText("Demo Button")).perform(click())
    assertEquals(true, buttonClicked)
    var buttonClicked = false
    setContent {
    HydrationTrackerTheme {
    AndroidViewDemo { buttonClicked = true }
    }
    }


    View Slide

93. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing - AndroidView
    var buttonClicked = false
    setContent {
    HydrationTrackerTheme {
    AndroidViewDemo { buttonClicked = true }
    }
    }
    onNodeWithText("AndroidView Demo Title").assertIsDisplayed()
    Espresso.onView(withText("Demo Button")).check(matches(isDisplayed()))
    Espresso.onView(withText("Demo Button")).perform(click())
    assertEquals(true, buttonClicked)
    ✅


    View Slide

94. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing - AndroidView
    var buttonClicked = false
    setContent {
    HydrationTrackerTheme {
    AndroidViewDemo { buttonClicked = true }
    }
    }
    onNodeWithText("AndroidView Demo Title").assertIsDisplayed()
    Espresso.onView(withText("Demo Button")).check(matches(isDisplayed()))
    Espresso.onView(withText("Demo Button")).perform(click())
    assertEquals(true, buttonClicked)
    ✅
    ✅


    View Slide

95. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing - AndroidView
    var buttonClicked = false
    setContent {
    HydrationTrackerTheme {
    AndroidViewDemo { buttonClicked = true }
    }
    }
    onNodeWithText("AndroidView Demo Title").assertIsDisplayed()
    Espresso.onView(withText("Demo Button")).check(matches(isDisplayed()))
    assertEquals(true, buttonClicked)
    ✅
    ✅
    ✅❓
    ❌
    Espresso.onView(withText("Demo Button")).perform(click())


    View Slide

96. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing - AndroidView
    Doesn’t work as of Jetpack Compose 1.3.0-beta03 🙁
    https:!//issuetracker.google.com/issues/215231631
    Espresso.onView(withText("Demo Button")).perform(click())


    View Slide

97. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing - AndroidView
    Espresso.onView(withText("Demo Button")).check { view, _ ->
    view.performClick()
    }
    Unstable workaround
    https://issuetracker.google.com/issues/215231631


    View Slide

98. #DroidKaigi2022 – @stewemetal
    Hybrid UI testing - AndroidView
    var buttonClicked = false
    setContent {
    HydrationTrackerTheme {
    AndroidViewDemo { buttonClicked = true }
    }
    }
    onNodeWithText("AndroidView Demo Title").assertIsDisplayed()
    Espresso.onView(withText("Demo Button")).check(matches(isDisplayed()))
    assertEquals(true, buttonClicked)
    Espresso.onView(withText("Demo Button")).check { view, _ ->
    view.performClick()
    }
    ✅
    ✅
    ✅
    ✅❓


    View Slide

99. #DroidKaigi2022 – @stewemetal
    Topics to check out
    • Testing animations in Compose 👀
    • Synchronization and IdlingResources 🕞
    • Screenshot testing with Paparazzi, Showkase, etc. 📸


    View Slide

100. #DroidKaigi2022 – @stewemetal
     Topics to check out
     • Testing animations in Compose 👀
     • Synchronization and IdlingResources 🕞
     • Screenshot testing with Paparazzi, Showkase, etc. 📸


     View Slide

101. #DroidKaigi2022 – @stewemetal
     Resources
     • developer.android.com/jetpack/compose/testing
     • developer.android.com/jetpack/compose/testing-cheatsheet
     • developer.android.com/jetpack/compose/accessibility
     • developer.android.com/jetpack/compose/semantics
     • youtu.be/kdwofTaEHrs
     • adbackstage.libsyn.com/episode-171-compose-testing
     • github.com/android/compose-samples
     • adavis.info/2021/09/testing-hybrid-jetpack-compose-apps.html
     • github.com/stewemetal/composehydrationtracker


     View Slide

102. stewemetal
     How to Test Your Compose UI István Juhos
     • Testing based on the semantics tree
     • Planned accessibility = good testability
     • Testing composables in isolation helps a lot
     • Hybrid UI testing is supported out of the box
     Cover photo by Rob Mulally on Unsplash


     View Slide

103. #DroidKaigi2022 – @stewemetal
     Thank you! 🙏
     ありがとうございました


     View Slide
