An Efficient Static Assets Pipeline With WebPack February 2015
About me Alexandrine Boissière Technical Engineering Manager at Hootsuite @theasta
None
Agenda 1. What is a static assets pipeline? 2. Why
does it matter? 3. What are the requirements? 4. Webpack In Action
Sta.c Assets? JS CSS PNG JPEG GIF SVG EOT WOFF
TTF SWF TXT …
Sta.c Assets Pipeline? Compile Concatenate Minify Compress ...
Single Page Applica.on ⌘- aRgh
How to ensure Code Quality?
Reliability Security Efficiency Maintainability
All about the code? The Static Assets Pipeline plays a
significant role in achieving three of those characteristics.
Maintainability • Modularity • Dependency Management • Dead Code Elimination
The codebase should contain hundreds of files.
Efficiency • Web Performance • Minimize the number of HTTP
requests • Cache Resources Serve only a few bundles from a CDN
Reliability Development Environment == Production Environment !=
== Reliability Development Environment == Production Environment
Requirements Broad Module Format Compatibility Fast Build Times
User Pathway homepage.js login.js app.js plans.js
A Faster Website common.js homepage.js login.js app.js plans.js
Need for Speed - Craitza
$$$ by cutting CDN costs Save
Requirements Broad Module Format Compatibility Fast Build Times Create Common
Bundle(s)
app.js SPA -‐ Mul.ple Sec.ons section 1 common.js section 2
section 3
On-‐Demand Loading app.js section 1 common.js section 2 section 3
Requirements Broad Module Format Compatibility Fast Build Times Create Common
Bundle(s) Load Files On Demand
Caching HTTP Validation Model HTTP Expiration Model
HTTP Valida.on Model BROWSER SERVER 200 OK Etag: 776cdb1 (data)
HTTP Header Last-Modified / If-Modified-Since Etag / If-None-Match GET/ file
HTTP Valida.on Model BROWSER SERVER 304 Not Modified (no message-body)
HTTP Header Last-Modified / If-Modified-Since Etag / If-None-Match GET/ file If-None-Match: 776cdb1
HTTP Expira.on Model HTTP Header Cache-Control: max-age=3600 Expires: Tue, 26
Mar 2015 05:00:00 GMT BROWSER SERVER 200 OK Cache-control: max-age= 2628000 (data) GET/ file
HTTP Expira.on Model HTTP Header Cache-Control: max-age=3600 Expires: Tue, 26
Mar 2015 05:00:00 GMT BROWSER SERVER No Round-Trip
Cache Busting Explosion - Itsme1985
Assets Versioning Per-release strategy - /1.2.0/js/common.js - /1.2.0/js/homepage.js Per-file strategy
- /js/common.a36k2i672.js - /js/homepage.f7we0kiq.js
More complex than it seems Filenames must be updated in:
• Server-side templates • Client-side templates • CSS (background-image, font-face, ...)
Requirements Broad Module Format Compatibility Fast Build Times Create Common
Bundle(s) Load Files On Demand Version Assets On A Per-file Basis
On The Lookout For A Bundler
The main contenders
RequireJS Module Format Compatibility AMD, CommonJS* Fast Build Times No
( too slow on Dev) Create common bundles Yes ( w/ manual config) Load files on demand Yes Version assets per file No
Browserify Module Format Compatibility CommonJS, AMD*, ES6* Fast Build Times
OK Create common bundles Yes ( w/ plugin) Load files on demand No Version assets per file No
The Outsider Standing Out - Ben Cameron
Webpack by Tobias Koppers
Compa.ble Module Formats • AMD • CommonJS • ES6 Modules
(with a loader)
Compila.on Time in seconds for 33 bundles Browserify Webpack
0 7.5 15 22.5 30
None
Why only JavaScript?! Modules are more than JavaScript files. require("./style.less");
require("./template.jade"); require("./image.png");
Loaders Transform the module content at build time. { test:
/\.jade$/, loader: "jade" }, { test: /\.css$/, loader: "style!css" }, { test: /\.png$/, loader: "url?limit=500" }
Serving Suggestion:
webpack -‐-‐watch Incremental builds DEMO: Sample Application on Github
Webpack Dev Server Hot Module Replacement DEMO: https://github.com/theasta/paris-webpack- react#demo-5---webpack-dev-server-and-hot- module-replacement
Common Chunks webpack.optimize.CommonsChunkPlugin can automatically create a common bundle. Webpack
analysis tool can provide hints. DEMO: https://github.com/theasta/paris-webpack- react#demo-2---common-chunks
On-‐Demand Loading?
Code SpliRng
None
On-‐Demand Loading DEMO: https://github.com/theasta/paris-webpack- react#demo-3---code-splitting
Assets Versioning Version all required files automatically and update all
filenames accordingly DEMO: https://github.com/theasta/paris-webpack- react#demo-4---assets-versioning
Webpack ✓ Broad Module Format Compatibility ✓ Fast Build Times
✓ Create Common Bundle(s) ✓ Load Files On Demand ✓ Version Assets Per File ✓ [bonus] Update Assets Filenames In Templates and CSS
but there is more...
≈ 3% smaller Bundles size (homepage + login funnel) 0
150 300 450 600 Webpack RequireJS
None
Performance RequireJS Webpack 0 1.25 2.5 3.75 5 DomContentLoaded Load
Dynamic Require require("./models/" + type + ".js"); Includes all JS
files in the models folder. Especially useful with the FactoryPattern and templates.
Embedded Stylesheets • Possible to include CSS directly in JavaScript
• Eliminate CSS bottleneck by breaking down styles in smaller chunks that can be loaded on demand. • Possible to extract the styles with the extract- text-webpack-plugin
Pro Tips
CommonJS
OccurrenceOrderPlugin Highly recommended! Ensure the hash digest remains exactly the
same between two builds of the same codebase.
Shimming • Webpack for browserify users • Webpack for RequireJS
• exports = exports loader • deps = imports loader • paths = resolve.alias
Resources • Webpack Configuration Helper • Version Retrieval Plugin •
Temporary Async Loader: head.load.js • Assets Versioning Plugin: grunt-assets-versioning
La Fin • Alexandrine Boissière - @theasta • Sample Application:
github.com/theasta/paris-webpack-react • Webpack: webpack.github.io Tube - tullstedt.se
