High availability by offloading work - background jobs, message queues, or Kafka

Talk at RubyConf Colombia 2019

Transcript

1. Kerstin Puschke
   @titanoboa42
   High availability by offloading work -
   background jobs, message queues, or Kafka


   View Slide

2. @titanoboa42


   View Slide

3. @titanoboa42
   Different approaches to offload work to
   ensure high availability


   View Slide

4. @titanoboa42
   • High availability & offloading work
   Outline


   View Slide

5. @titanoboa42
   • High availability & offloading work
   • Background jobs
   Outline


   View Slide

6. @titanoboa42
   • High availability & offloading work
   • Background jobs
   • Message oriented middleware
   Outline


   View Slide

7. @titanoboa42
   • Event log
   Outline


   View Slide

8. @titanoboa42
   • Event log
   • Summary
   Outline


   View Slide

9. @titanoboa42
   High availability & offloading work


   View Slide

10. @titanoboa42
    High Availability


    View Slide

11. @titanoboa42


    users

    can interact

    with the system
    High Availability


    View Slide

12. @titanoboa42


    users

    can interact meaningfully

    with the system
    High Availability


    View Slide

13. @titanoboa42
    community of

    users

    can interact meaningfully

    with the system
    High Availability


    View Slide

14. @titanoboa42
    community of

    users

    can interact meaningfully

    with the system whenever needed
    High Availability


    View Slide

15. @titanoboa42
    community of

    users

    can interact meaningfully

    with the system whenever needed
    High Availability
    community of

    users

    can interact meaningfully

    with the system whenever needed


    View Slide

16. @titanoboa42
    Background jobs


    View Slide

17. @titanoboa42
    • Resque
    Background job backends


    View Slide

18. @titanoboa42
    • Resque
    • Sidekiq
    Background job backends


    View Slide

19. @titanoboa42
    • Resque
    • Sidekiq
    • …
    Background job backends


    View Slide

20. @titanoboa42
    Background job:

    Unit of work

    to be done later
    App
    Server
    Worker


    View Slide

21. @titanoboa42
    Asynchronous
    communication
    App
    Server
    Message
    Queue
    Worker


    View Slide

22. @titanoboa42
    Asynchronous
    communication
    App
    Server
    Message
    Queue
    Worker
    Task
    Queue


    View Slide

23. @titanoboa42
    Asynchronous
    communication
    App
    Server
    Message
    Queue
    Worker Worker
    Worker
    Task
    Queue


    View Slide

24. @titanoboa42
    Background job backend:

    task queue & broker


    View Slide

25. @titanoboa42
    Encapsulating

    async communication


    View Slide

26. @titanoboa42
    Features


    View Slide

27. @titanoboa42
    Task
    Queue
    Response times
    App
    Server
    Worker


    View Slide

28. @titanoboa42
    Task
    Queue
    Spikeability
    App
    Server
    Worker


    View Slide

29. @titanoboa42
    Task
    Queue
    Parallelization
    App
    Server
    Worker Worker
    Worker


    View Slide

30. @titanoboa42
    Task
    Queue
    Retries
    App
    Server
    Worker Worker
    Worker


    View Slide

31. @titanoboa42
    Mastering challenges


    View Slide

32. @titanoboa42
    Job queued and processed by different versions


    View Slide

33. @titanoboa42
    • No breaking changes to job parameters
    Job queued and processed by different versions


    View Slide

34. @titanoboa42
    • No breaking changes to job parameters
    • Changes need to be backwards compatible
    until legacy jobs have been processed
    Job queued and processed by different versions


    View Slide

35. @titanoboa42
    No exactly once delivery


    View Slide

36. @titanoboa42
    • “At least” vs. “at most” once delivery
    No exactly once delivery


    View Slide

37. @titanoboa42
    • “At least” vs. “at most” once delivery
    • Idempotent jobs & at least once delivery
    No exactly once delivery


    View Slide

38. @titanoboa42
    Non-transactional queuing


    View Slide

39. @titanoboa42
    • Don’t queue from within a db transaction
    Non-transactional queuing


    View Slide

40. @titanoboa42
    • Don’t queue from within a db transaction
    • Job runs before commit, or in case of rollback
    Non-transactional queuing


    View Slide

41. @titanoboa42
    • Don’t queue from within a db transaction
    • Job runs before commit, or in case of rollback
    • Commit first: Job not guaranteed to be queued
    Non-transactional queuing


    View Slide

42. @titanoboa42
    Non-transactional queuing


    View Slide

43. @titanoboa42
    • Stage transactionally
    Non-transactional queuing


    View Slide

44. @titanoboa42
    • Stage transactionally
    • Scheduler queues job, updates staging data
    Non-transactional queuing


    View Slide

45. @titanoboa42
    Local transactions


    View Slide

46. @titanoboa42
    • Eventual consistency at best
    Local transactions


    View Slide

47. @titanoboa42
    • Eventual consistency at best
    • SAGA command/orchestration
    Local transactions


    View Slide

48. @titanoboa42
    Out of order delivery


    View Slide

49. @titanoboa42
    • SAGA events/choreography: jobs queue jobs
    Out of order delivery


    View Slide

50. @titanoboa42
    • SAGA events/choreography: jobs queue jobs
    • easy to build, hard to maintain or debug
    Out of order delivery


    View Slide

51. @titanoboa42
    • SAGA events/choreography: jobs queue jobs
    • easy to build, hard to maintain or debug
    • SAGA command/orchestrator
    Out of order delivery


    View Slide

52. @titanoboa42
    Long running jobs - Resque


    View Slide

53. @titanoboa42
    • Prevent worker shutdown
    Long running jobs - Resque


    View Slide

54. @titanoboa42
    • Prevent worker shutdown
    • No deployments
    Long running jobs - Resque


    View Slide

55. @titanoboa42
    • Prevent worker shutdown
    • No deployments
    • Not cloud-friendly
    Long running jobs - Resque


    View Slide

56. @titanoboa42
    • Aborted and requeued
    Long running jobs - Sidekiq


    View Slide

57. @titanoboa42
    • Aborted and requeued
    • Job may not finish before being aborted again
    Long running jobs - Sidekiq


    View Slide

58. @titanoboa42
    Large collections


    View Slide

59. @titanoboa42
    • Split job into collection and task to be done
    Large collections


    View Slide

60. @titanoboa42
    • Split job into collection and task to be done
    • Checkpoint after iteration & requeue
    Large collections


    View Slide

61. @titanoboa42
    Interruptible job with automatic resuming


    View Slide

62. @titanoboa42
    • Shutdown workers anytime
    Interruptible job with automatic resuming


    View Slide

63. @titanoboa42
    • Shutdown workers anytime
    • Disaster prevention
    Interruptible job with automatic resuming


    View Slide

64. @titanoboa42
    • Shutdown workers anytime
    • Disaster prevention
    • Data integrity
    Interruptible job with automatic resuming


    View Slide

65. @titanoboa42
    github.com

    /Shopify/job-iteration


    View Slide

66. @titanoboa42
    Abstracting scaling issues

    simplifies

    concrete background jobs


    View Slide

67. @titanoboa42
    Task
    Queue
    Background jobs are
    ruby objects
    App
    Server
    Worker


    View Slide

68. @titanoboa42
    Task
    Queue
    Background jobs are
    ruby objects
    App
    Server
    Worker
    Broker
    Broker


    View Slide

69. @titanoboa42
    Offloading work to a worker
    running the same code base


    View Slide

70. @titanoboa42
    Background jobs

    Summary


    View Slide

71. @titanoboa42
    • Based on task queues
    Background jobs


    View Slide

72. @titanoboa42
    • Based on task queues
    • Complex overall system, simple concrete jobs
    Background jobs


    View Slide

73. @titanoboa42
    • Based on task queues
    • Complex overall system, simple concrete jobs
    • Great for monolith
    Background jobs


    View Slide

74. @titanoboa42
    Message oriented middleware


    View Slide

75. @titanoboa42
    • Implementations: RabbitMQ, ActiveMQ,…
    Message oriented middleware


    View Slide

76. @titanoboa42
    • Implementations: RabbitMQ, ActiveMQ,…
    • Protocols: AMQP, MQTT, Stomp,…
    Message oriented middleware


    View Slide

77. @titanoboa42
    Message
    Queue
    Messaging
    Middleware
    App
    Server
    Producer
    Data-based interface
    Worker
    Consumer


    View Slide

78. @titanoboa42
    Message
    Queue
    Messaging
    Middleware
    App
    Server
    Producer
    Data-based interface
    Worker
    Consumer
    Broker


    View Slide

79. @titanoboa42
    Features


    View Slide

80. @titanoboa42
    Commands & Events


    View Slide

81. @titanoboa42
    Propagating updates
    Business
    Partners
    Support
    Contracts
    Orders


    View Slide

82. @titanoboa42
    Propagating updates
    Business
    Partners
    Support
    Contracts
    Orders


    View Slide

83. @titanoboa42
    Messaging

    Middleware
    Resiliency
    Business
    Partners
    Orders


    View Slide

84. @titanoboa42
    Messaging

    Middleware
    Resiliency
    Business
    Partners


    View Slide

85. @titanoboa42
    Messaging

    Middleware
    Resiliency
    Business
    Partners
    Orders


    View Slide

86. @titanoboa42
    Topic with queues

    provides

    advanced routing
    App
    Server
    Business

    Partners
    Support

    Contracts
    Orders
    Messaging
    Middleware


    View Slide

87. @titanoboa42
    Topic with queues

    provides

    advanced routing
    App
    Server
    Message
    Queue
    Business

    Partners
    Support

    Contracts
    Orders
    Message
    Queue
    Messaging
    Middleware


    View Slide

88. @titanoboa42
    Messaging
    Middleware
    Anonymity for
    producer and
    consumer
    Business
    Partners
    Support
    Contracts
    Orders


    View Slide

89. @titanoboa42
    Messaging
    Middleware
    Anonymity for
    producer and
    consumer
    Business
    Partners
    Invoices
    Support
    Contracts
    Orders


    View Slide

90. @titanoboa42
    Messaging
    Middleware
    Anonymity for
    producer and
    consumer
    FraudScore
    Orders
    Support
    Contracts


    View Slide

91. @titanoboa42
    Messaging
    Middleware
    Anonymity for
    producer and
    consumer
    Invoices
    FraudScore
    Orders
    Support
    Contracts


    View Slide

92. @titanoboa42
    Mastering challenges


    View Slide

93. @titanoboa42
    Keep breaking changes manageable


    View Slide

94. @titanoboa42
    • Avoid n:m routing
    Keep breaking changes manageable


    View Slide

95. @titanoboa42
    • Avoid n:m routing
    • Better representation of domain:

    multiple messages routed 1:n, n:1 instead
    Keep breaking changes manageable


    View Slide

96. @titanoboa42
    • No exactly once delivery
    Lack of guarantees


    View Slide

97. @titanoboa42
    • No exactly once delivery
    • No strong consistency
    Lack of guarantees


    View Slide

98. @titanoboa42
    • No exactly once delivery
    • No strong consistency
    • Out of order delivery
    Lack of guarantees


    View Slide

99. @titanoboa42
    No single source of truth


    View Slide

100. @titanoboa42
     • Messages removed after processing
     No single source of truth


     View Slide

101. @titanoboa42
     • Messages removed after processing
     • No replayability
     No single source of truth


     View Slide

102. @titanoboa42
     Offloading work to decoupled
     services with no notion of system
     wide state


     View Slide

103. @titanoboa42
     Message oriented middleware

     Summary


     View Slide

104. @titanoboa42
     • Based on queues and topics
     Message oriented middleware


     View Slide

105. @titanoboa42
     • Based on queues and topics
     • Complex overall system
     Message oriented middleware


     View Slide

106. @titanoboa42
     • Based on queues and topics
     • Complex overall system
     • Simple message consumers
     Message oriented middleware


     View Slide

107. @titanoboa42
     • Great for decoupled microservices
     Message oriented middleware


     View Slide

108. @titanoboa42
     • Great for decoupled microservices
     • No system wide state
     Message oriented middleware


     View Slide

109. @titanoboa42
     Event log


     View Slide

110. @titanoboa42
     • Kafka
     Event logs


     View Slide

111. @titanoboa42
     • Kafka
     • …
     Event logs


     View Slide

112. @titanoboa42
     • Events persisted into append-only log
     Event log


     View Slide

113. @titanoboa42
     • Events persisted into append-only log
     • Consumers read shared log
     Event log


     View Slide

114. @titanoboa42
     • Events persisted into append-only log
     • Consumers read shared log
     • Stateless broker (no queues)
     Event log


     View Slide

115. @titanoboa42
     High throughput


     View Slide

116. @titanoboa42
     Single source of truth


     View Slide

117. @titanoboa42
     • Events are not removed after processing
     Single source of truth


     View Slide

118. @titanoboa42
     • Events are not removed after processing
     • Replayability
     Single source of truth


     View Slide

119. @titanoboa42
     Offloading work to services
     keeping the notion of system
     wide state


     View Slide

120. @titanoboa42
     Event log

     Summary


     View Slide

121. @titanoboa42
     • Based on shared log, no queues
     Event logs


     View Slide

122. @titanoboa42
     • Based on shared log, no queues
     • Complex overall system
     Event logs


     View Slide

123. @titanoboa42
     Event logs


     View Slide

124. @titanoboa42
     • Single source of truth (e.g. for event sourcing)
     Event logs


     View Slide

125. @titanoboa42
     • Single source of truth (e.g. for event sourcing)
     • High throughput applications
     Event logs


     View Slide

126. @titanoboa42
     Summary


     View Slide

127. @titanoboa42
     • Queues
     Background jobs


     View Slide

128. @titanoboa42
     • Queues
     • For monolithic code base
     Background jobs


     View Slide

129. @titanoboa42
     • Topics and Queues
     Message oriented middleware


     View Slide

130. @titanoboa42
     • Topics and Queues
     • For decoupled microservices
     Message oriented middleware


     View Slide

131. @titanoboa42
     • Shared log, no queues
     Event logs


     View Slide

132. @titanoboa42
     • Shared log, no queues
     • For event sourcing & high throughput
     applications
     Event logs


     View Slide

133. @titanoboa42
     BFCM video


     View Slide

134. @titanoboa42
     BFCM video


     View Slide

135. Thanks!

     Questions?

     @titanoboa42



     https://www.shopify.com/careers


     View Slide
