Choose Your Own Consistency

A concurrent talk about CRDTs and Strong Consistency in Riak 2.0 --delivered with Chris Meiklejohn (@cmeik) at Erlang Factory Lite Toronto.

Transcript

1. Choose your own
   Consistency


   View Slide

2. A concurrent talk by:
   @cmeik & @tsantero


   View Slide

3. Leveraging Riak’s New Data Types
   Conflict-Free Replicated Datatypes
   Chris Meiklejohn
   @cmeik
   EFL Toronto 2013


   View Slide

4. cmeiklejohn


   View Slide

5. Riak Made Consistent
   Strong Consistency in Riak 2.0
   Tom Santero
   @tsantero
   EFL Toronto 2013


   View Slide

6. @
   basho.com
   tsantero


   View Slide

7. Riak Overview


   View Slide

8. Riak Overview
   Erlang implementation of Dynamo


   View Slide

9. Riak Overview
   Erlang implementation of Dynamo


   View Slide

10. Riak Object


    View Slide

11. Key Value


    View Slide

12. Riak Overview
    Consistent hashing


    View Slide

13. View Slide

14. View Slide

15. View Slide

16. Riak Overview
    Dynamic membership


    View Slide

17. Riak Overview
    Replication factor


    View Slide

18. Replica Replica Replica


    View Slide

19. High Availability
    “...any non-failing node can respond to any request”
    --Gilbert & Lynch


    View Slide

20. Eventual Consistency
    “Eventual consistency is a consistency model used in
    distributed computing that informally guarantees that, if no
    new updates are made to a given data item, eventually all
    accesses to that item will return the last updated value.”
    --Wikipedia


    View Slide

21. Riak Overview
    Two Writes: {Writer, Value, Time}


    View Slide

22. [{a, v1, t1}] [{b, v1, t2}] [{a, v1, t1}]


    View Slide

23. Riak Overview
    Last Writer Wins
    Allow Mult


    View Slide

24. Riak Overview
    Last Writer Wins [{b, v1, t2}]
    [{b, v1, t2}]
    [{b, v1, t2}]


    View Slide

25. Riak Overview
    Allow Mult [{a, v1, t1}, {b, v1, t2}]
    [{a, v1, t1}, {b, v1, t2}]
    [{a, v1, t1}, {b, v1, t2}]


    View Slide

26. User specificed
    Merge


    View Slide

27. CRDTs


    View Slide

28. CRDTs
    Convergent Replicated Data Types


    View Slide

29. CRDTs
    Commutative Replicated Data Types


    View Slide

30. CRDTs
    Synchronization-free data structures


    View Slide

31. CRDTs
    Monotonic and confluent; convergent


    View Slide

32. CRDTs
    Create siblings; resolve via merge.


    View Slide

33. The Theory


    View Slide

34. View Slide

35. View Slide

36. View Slide

37. Bounded Join Semilattices


    View Slide

38. Bounded Join Semilattices
    Partially ordered set; least upper bound; ACI.


    View Slide

39. Bounded Join Semilattices
    Associativity: (X · Y) · Z = X · (Y · Z)


    View Slide

40. Bounded Join Semilattices
    Commutativity: X · Y = Y · X


    View Slide

41. Bounded Join Semilattices
    Idempotence: X · X = X


    View Slide

42. Bounded Join Semilattices
    Objects grow over time; merge computes LUB


    View Slide

43. Bounded Join Semilattices
    Monotonic and confluent; convergent


    View Slide

44. Bounded Join Semilattices
    Map into another via monotone functions


    View Slide

45. Bounded Join Semilattices
    Examples


    View Slide

46. b a c
    a, b a, c
    a, b, c
    Set; merge function: union.
    b, c


    View Slide

47. 3 5 7
    5 7
    7
    Increasing natural; merge function: max.


    View Slide

48. F F T
    F T
    T
    Booleans; merge function: or.


    View Slide

49. x <= y montone f(x) <= f(y)


    View Slide

50. CvRDT Examples
    OR-SET


    View Slide

51. [ [{1, a}], [] ] [ [{1, a}], [] ]


    View Slide

52. [ [{1, a}], [] ] [ [{1, a}], [] ]
    [ [{1, a}], [{1, a}] ]
    [ [{1, a}], [{1, a}] ]


    View Slide

53. [ [{1, a}], [] ] [ [{1, a}], [] ]
    [ [{1, a}], [{1, a}] ]
    [ [{1, a}], [{1, a}] ]
    [ [{1, a}, {2, a}], [{1, a}] ]


    View Slide

54. [ [{1, a}], [] ] [ [{1, a}], [] ]
    [ [{1, a}], [{1, a}] ]
    [ [{1, a}], [{1, a}] ]
    [ [{1, a}, {2, a}], [{1, a}] ]
    [ [{1, a}, {2, a}], [{1, a}] ]


    View Slide

55. [ [{1, a}], [] ] [ [{1, a}], [] ]


    View Slide

56. [ [{1, a}], [] ] [ [{1, a}], [] ]
    [ [{1, a}, {2, b}], [] ]


    View Slide

57. [ [{1, a}], [] ] [ [{1, a}], [] ]
    [ [{1, a}, {2, b}], [] ]
    [ [{1, a}], [{1, a}] ]


    View Slide

58. [ [{1, a}], [] ] [ [{1, a}], [] ]
    [ [{1, a}, {2, b}], [] ]
    [ [{1, a}], [{1, a}] ]
    [ [{1, a}, {2, b}], [{1, a}] ]


    View Slide

59. riak_dt
    git clone git@github.com:basho/riak_dt.git


    View Slide

60. -­‐type  crdt()  ::  term().
    -­‐type  operation()  ::  term().
    -­‐type  actor()  ::  term().
    -­‐type  value()  ::  term().
    -­‐type  error()  ::  term().
    -­‐callback  new()  -­‐>  crdt().
    -­‐callback  value(crdt())  -­‐>  term().
    -­‐callback  value(term(),  crdt())  -­‐>  value().
    -­‐callback  update(operation(),  actor(),  crdt())  -­‐>
                          {ok,  crdt()}  |  {error,  error()}.
    -­‐callback  merge(crdt(),  crdt())  -­‐>  crdt().
    -­‐callback  equal(crdt(),  crdt())  -­‐>  boolean().
    -­‐callback  to_binary(crdt())  -­‐>  binary().
    -­‐callback  from_binary(binary())  -­‐>  crdt().
    riak_dt/src/riak_dt.erl


    View Slide

61. Riak 1.4


    View Slide

62. Riak 1.4
    Counters: G-Counter, PN-Counter


    View Slide

63. Riak 1.4
    Counters: non-idempotent; O(Actors)


    View Slide

64. riak_dt/src/riak_dt_gcounter.erl
    -­‐module(riak_dt_gcounter).
    -­‐export([new/0,  new/2,  value/1,  value/2,  update/3,  merge/2,
     equal/2,  to_binary/1,  from_binary/1]).
    -­‐export_type([gcounter/0,  gcounter_op/0]).
    -­‐opaque  gcounter()  ::  orddict:orddict().
    -­‐type  gcounter_op()  ::  increment  |  {increment,  pos_integer()}.


    View Slide

65. riak_dt/src/riak_dt_pncounter.erl
    -­‐module(riak_dt_pncounter).
    -­‐export([new/0,  new/2,  value/1,  value/2,
                     update/3,  merge/2,  equal/2,  to_binary/1,  from_binary/1]).
    -­‐export_type([pncounter/0,  pncounter_op/0]).
    -­‐opaque  pncounter()    ::  [{Actor::riak_dt:actor(),  Inc::pos_integer(),
                                                       Dec::pos_integer()}].
    -­‐type  pncounter_op()  ::  riak_dt_gcounter:gcounter_op()  |  decrement_op().
    -­‐type  decrement_op()  ::  decrement  |  {decrement,  pos_integer()}.
    -­‐type  pncounter_q()    ::  positive  |  negative.


    View Slide

66. Riak 2.0


    View Slide

67. Riak 2.0
    Requires bucket types; HTTP and protobuff API


    View Slide

68. Riak 2.0
    Caveats: 2i, MapReduce, Yokozuna


    View Slide

69. Riak 2.0
    Sets: Add, Remove, Membership; Idempotent


    View Slide

70. Riak 2.0
    Sets: Add wins; O(Actors + Elements)


    View Slide

71. riak_dt/src/riak_dt_gset.erl
    -­‐module(riak_dt_gset).
    -­‐behaviour(riak_dt).
    %%  API
    -­‐export([new/0,  value/1,  update/3,  merge/2,  equal/2,
                     to_binary/1,  from_binary/1,  value/2]).
    -­‐export_type([gset/0,  binary_gset/0,  gset_op/0]).
    -­‐opaque  gset()  ::  members().
    -­‐type  binary_gset()  ::  binary().
    -­‐type  gset_op()  ::  {add,  member()}.


    View Slide

72. riak_dt/src/riak_dt_orset.erl
    -­‐module(riak_dt_orset).
    -­‐behaviour(riak_dt).
    %%  API
    -­‐export([new/0,  value/1,  update/3,  merge/2,  equal/2,
                     to_binary/1,  from_binary/1,  value/2,  precondition_context/1]).
    -­‐export_type([orset/0,  binary_orset/0,  orset_op/0]).
    -­‐opaque  orset()  ::  orddict:orddict().
    -­‐type  binary_orset()  ::  binary().  %%  A  binary  that  from_binary/1  will
    operate  on.
    -­‐type  orset_op()  ::  {add,  member()}  |  {remove,  member()}  |
                                           {add_all,  [member()]}  |  {remove_all,  [member()]}  |
                                           {update,  [orset_op()]}.
    -­‐type  actor()  ::  riak_dt:actor().
    -­‐type  member()  ::  term().


    View Slide

73. riak_dt/src/riak_dt_orswot.erl
    -­‐module(riak_dt_orswot).
    -­‐behaviour(riak_dt).
    -­‐export_type([orswot/0,  orswot_op/0,  binary_orswot/0]).
    -­‐opaque  orswot()  ::  {riak_dt_vclock:vclock(),  entries()}.
    -­‐type  binary_orswot()  ::  binary().  %%  A  binary  that  from_binary/1  will  operate
    on.
    -­‐type  orswot_op()  ::    {add,  member()}  |  {remove,  member()}  |
                                               {add_all,  [member()]}  |  {remove_all,  [member()]}  |
                                               {update,  [orswot_op()]}.
    -­‐type  orswot_q()    ::  size  |  {contains,  term()}.
    -­‐type  actor()  ::  riak_dt:actor().
    -­‐type  entries()  ::  [{member(),  minimal_clock()}].
    -­‐type  minimal_clock()  ::  [dot()].
    -­‐type  dot()  ::  {actor(),  Count::pos_integer()}.
    -­‐type  member()  ::  term().


    View Slide

74. Riak 2.0
    Maps: Recursive; Associative Array; Nestable


    View Slide

75. Riak 2.0
    Maps: Update wins; O(Actors + Elements)


    View Slide

76. riak_dt/src/riak_dt_map.erl
    -­‐module(riak_dt_map).
    -­‐behaviour(riak_dt).
    %%  API
    -­‐export([new/0,  value/1,  value/2,  update/3,  merge/2,
                     equal/2,  to_binary/1,  from_binary/1,  precondition_context/1]).
    -­‐export_type([map/0,  binary_map/0,  map_op/0]).
    -­‐type  binary_map()  ::  binary().  %%  A  binary  that  from_binary/1  will  accept
    -­‐type  map()  ::  {riak_dt_vclock:vclock(),  valuelist()}.
    -­‐type  field()  ::  {Name::term(),  Type::crdt_mod()}.
    -­‐type  crdt_mod()  ::  riak_dt_pncounter  |  riak_dt_lwwreg  |
                                           riak_dt_od_flag  |
                                           riak_dt_map  |  riak_dt_orswot.
    -­‐type  valuelist()  ::  [{field(),  entry()}].
    -­‐type  entry()  ::  {minimal_clock(),  crdt()}.
    -­‐type  crdt()    ::    riak_dt_pncounter:pncounter()  |  riak_dt_od_flag:od_flag()  |
                                       riak_dt_lwwreg:lwwreg()  |
                                       riak_dt_orswot:orswot()  |
                                       riak_dt_map:map().
    -­‐type  map_op()  ::  {update,  [map_field_update()  |  map_field_op()]}.


    View Slide

77. Riak 2.0
    Maps: LWW-Register, Booleans, Sets, and Maps


    View Slide

78. Riak 2.0
    LWW-Register: last writer wins


    View Slide

79. -­‐module(riak_dt_lwwreg).
    -­‐export([new/0,  value/1,  value/2,  update/3,  merge/2,
                     equal/2,  to_binary/1,  from_binary/1]).
    -­‐export_type([lwwreg/0,  lwwreg_op/0]).
    -­‐opaque  lwwreg()  ::  {term(),  non_neg_integer()}.
    -­‐type  lwwreg_op()  ::  {assign,  term(),  non_neg_integer()}    |  {assign,
    term()}.
    -­‐type  lww_q()  ::  timestamp.
    riak_dt/src/riak_dt_lwwreg.erl


    View Slide

80. Riak 2.0
    Boolean: Enabled, Disabled; O(Actors)


    View Slide

81. -­‐module(riak_dt_enable_flag).
    -­‐behaviour(riak_dt).
    -­‐export([new/0,  value/1,  value/2,  update/3,  merge/2,
     equal/2,  from_binary/1,  to_binary/1]).
    riak_dt/src/riak_dt_enable_flag.erl


    View Slide

82. This project is funded by the European Union,
    7th Research Framework Programme, ICT call 10,
    grant agreement n°609551.


    View Slide

83. View Slide

84. Strong Consistency


    View Slide

85. Strong Consistency
    Why?


    View Slide

86. Strong Consistency
    Why? atomicity


    View Slide

87. Strong Consistency
    Why? recency


    View Slide

88. Strong Consistency
    Why? partial writes


    View Slide

89. A A A


    View Slide

90. A A A
    Val = <<“B”>>.


    View Slide

91. A A A
    Val = <<“B”>>.


    View Slide

92. B A A


    View Slide

93. B A A
    riakc_pb_socket:get(PBC, <<“Bucket”>>, <<“Key”>>).


    View Slide

94. B A A
    riakc_pb_socket:get(PBC, <<“Bucket”>>, <<“Key”>>).


    View Slide

95. B A A
    riakc_pb_socket:get(PBC, <<“Bucket”>>, <<“Key”>>).
    B B


    View Slide

96. Strong Consistency
    Single key atomic operations


    View Slide

97. Strong Consistency
    any get sees most recent put


    View Slide

98. Strong Consistency
    get/modify/put cycle fails if object is changed


    View Slide

99. Strong Consistency
    put w/o vclock fails if object exists


    View Slide

100. Consensus


     View Slide

101. Distributed Consensus
     “The problem of reaching agreement among remote
     processes is one of the most fundamental problems in
     distributed computing and is at the core of many
     algorithms for distributed data processing, distributed
     file management, and fault-tolerant distributed
     applications.”
     --Fischer, Lynch, Paterson


     View Slide

102. Consensus
     Guarantees: termination, agreement, validity


     View Slide

103. Termination
     processes eventually decide on a value


     View Slide

104. Agreement
     processes that decide do so on the same value


     View Slide

105. Validity
     values must have been proposed


     View Slide

106. Consensus Algorithms


     View Slide

107. Consensus Algorithms
     Paxos, ZAB, Raft


     View Slide

108. Paxos
     Lamport 1990: “The Part-Time Parliament”


     View Slide

109. View Slide

110. ZAB
     ZooKeeper Atomic Broadcast


     View Slide

111. Raft
     Ousterhout, Ongaro 2013:
     In search of an understandable consensus
     algorithm


     View Slide

112. Paxos
     coordinated requests; leaders


     View Slide

113. Paxos
     2 round trips / request


     View Slide

114. Node 1 Node 2 Node 3
     N++
     prepare(N)
     promise(N, V )
     b
     promise(N, V )
     c
     V = f(V , V , V )
     b c
     a
     N commit(N, V )
     N
     accept(N)


     View Slide

115. Multi-Paxos
     First Request


     View Slide

116. Node 1 Node 2 Node 3
     N++; I = 0
     prepare(N, I)
     promise(N, I, V )
     b
     promise(N, I, V )
     c
     V = f(V , V , V )
     b c
     a
     N commit(N, I, V )
     N
     accept(N, I)


     View Slide

117. Multi-Paxos
     Each Additional Request


     View Slide

118. Node 1 Node 2 Node 3
     I++
     commit(N, I, V)
     accept(N, I)


     View Slide

119. Multi-Paxos
     Each Request: ship entire state


     View Slide

120. Riak


     View Slide

121. Riak
     Key/Value


     View Slide

122. Riak
     Keys are Independent


     View Slide

123. Riak
     read-repair, active-anti entropy


     View Slide

124. Riak
     individual key = isolated state


     View Slide

125. Riak
     multi-paxos per key


     View Slide

126. Consensus Groups


     View Slide

127. Consensus Groups
     participants in decisioning; ensembles


     View Slide

128. Consensus Groups
     preference lists (preflists) in Riak


     View Slide

129. preflist


     View Slide

130. View Slide

131. View Slide

132. View Slide

133. View Slide

134. Consensus Groups
     one group/ensemble per preflist


     View Slide

135. Consensus Groups
     ring_size = 256, 256 ensembles


     View Slide

136. Ensembles


     View Slide

137. Ensembles
     leader election; Epochs; get/put operations


     View Slide

138. Get Operations
     leader reads local object; if Epoch old: refresh


     View Slide

139. Node 1 Node 2 Node 3
     obj.epoch < epoch
     get(key)
     reply(Epoch , Seq , Val )
     b
     Val = latest(Val , Val , Val )
     Val.epoch = epoch
     write(Epoch, ++Seq, Val)
     ack(Epoch, Seq)
     b b
     reply(Epoch , Seq , Val )
     c c c
     a b c


     View Slide

140. Node 1 Node 2 Node 3
     obj.epoch == epoch
     Reply = local_get(Key)


     View Slide

141. Get Operations
     Worst Case: 2 roundtrips / request
     Best Case: 0 roundtrips / request


     View Slide

142. Put Operations
     leader reads local object; if Epoch old: refresh
     modify object
     commit modified object


     View Slide

143. Node 1 Node 2 Node 3
     obj.epoch < epoch
     get(key)
     reply(Epoch , Seq , Val )
     b
     Latest = latest(Val , Val , Val )
     Val = modify(Latest)
     write(Epoch, ++Seq, Val)
     ack(Epoch, Seq)
     b b
     reply(Epoch , Seq , Val )
     c c c
     a b c


     View Slide

144. Node 1 Node 2 Node 3
     obj.epoch == epoch
     Latest = local_get(Key)
     Val = modify(Latest)
     write(Epoch, ++Seq, Val)
     ack(Epoch, Seq)


     View Slide

145. Put Operations
     Worst Case: 2 roundtrips / write
     Best Case: 1 roundtrips / write


     View Slide

146. Failed Quorums
     Leader Re-election ; new Epoch


     View Slide

147. Cluster Membership


     View Slide

148. Cluster Membership
     add/remove nodes


     View Slide

149. Cluster Membership
     consensus state


     View Slide

150. Cluster Membership
     multi-paxos joint consensus


     View Slide

151. Existing Ensemble Joining Ensemble
     riak_01
     riak_02
     riak_03
     riak_07
     riak_08
     riak_09
     [{riak_01}, {riak_02}, {riak_03}] [{riak_07}, {riak_08}, {riak_09}]


     View Slide

152. Joint-Consensus Ensemble
     [{riak_01}, {riak_02}, {riak_03}, {riak_07}, {riak_08}, {riak_09}]


     View Slide

153. Joint-Consensus Ensemble
     [{riak_01}, {riak_02}, {riak_03}, {riak_07}, {riak_08}, {riak_09}]


     View Slide

154. New Ensemble
     riak_07
     riak_08
     riak_09
     [{riak_07}, {riak_08}, {riak_09}]


     View Slide

155. Q & A


     View Slide
