From Big Band Web App to Serverless Bebop

From Big Band Web App to Serverless Bebop

(presented at JazzCon.Tech 2018: http://jazzcon.tech)

This talk will take a real-world look at what makes serverless so jazzy. Via a case study from Mapbox, we’ll see how to refactor a hard-to-maintain Node Express app into a collection of Lambda functions, and why we'd want to: lower bills, better code, and happier teams.

Anjana Sofia Vakil

March 22, 2018
Tweet

More Decks by Anjana Sofia Vakil

Other Decks in Programming

Transcript

  1. from
    Big Band Web App
    to
    Serverless
    Bebop
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  2. Hello!
    I’m @AnjanaVakil
    Recurse Center Non-Graduate
    Mozilla TechSpeaker & Outreachy Alumna
    Engineering Learning & Development Lead, Mapbox

    View Slide

  3. location data platform for developers
    maps, search, navigation
    web, iOS, Android, Unity...
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  4. @AnjanaVakil JazzCon.Tech 2018

    View Slide

  5. we use to
    ◍ get user stats
    ◍ monitor/test unpacker
    uploads
    ◍ ask yoda who’s on call
    ◍ see who’s out tmrw
    ◍ pick a random teammate
    Place your screenshot here
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  6. user-
    limits
    out
    unpacker
    yoda
    stats
    Express
    slack i/o
    auth
    our slack-commands app
    node
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  7. codebase
    slack-commands/
    ├─ readme.md
    ├─ cloudformation/ #app & cmd config
    │ └─ slack-commands.template.js
    ├─ index.js #express app
    ├─ commands/
    │ ├─ out.js
    │ ├─ stats.js
    │ └─ ...
    └─ test/
    ├─ index.test.js
    ├─ out.test.js
    ├─ stats.test.js
    └─ ...
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  8. All commands in a single app: Downsides
    Security
    ◍ Permissions?
    Secrets?
    ◍ Least privilege
    Maintenance
    ◍ Many different
    teams involved
    ◍ Ownership?
    Support?
    ◍ Code gumbo
    Cost
    ◍ Always running
    ◍ No per-command
    breakdown
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  9. enough
    about computers
    let’s talk about jazz
    @AnjanaVakil JazzCon.Tech 2018

    View Slide


  10. While swing music tended to feature
    orchestrated big band arrangements,
    bebop music highlighted improvisation.
    @AnjanaVakil JazzCon.Tech 2018
    wikipedia

    View Slide

  11. Big Band
    Glenn Miller Orchestra, c. 1940

    View Slide

  12. Big Band
    out unpacker
    status
    yoda
    Express
    slack i/o
    auth
    user-
    limits
    @AnjanaVakil JazzCon.Tech 2018

    View Slide


  13. I kept thinking there's bound to be something
    else. I could hear it sometimes. I couldn't play it....
    I found that by using the higher intervals of a
    chord as a melody line and backing them with
    appropriately related changes, I could play the
    thing I'd been hearing. It came alive.
    - Charlie Parker
    @AnjanaVakil JazzCon.Tech 2018
    wikipedia

    View Slide

  14. Bebop
    Tommy Potter, Charlie Parker, Max Roach, Miles Davis, & Duke Jordan, NYC c. 1945

    View Slide


  15. As bebop was not intended for dancing, it
    enabled the musicians to play at faster tempos.
    Bebop musicians explored advanced harmonies,
    complex syncopation, altered chords, extended
    chords, chord substitutions, asymmetrical
    phrasing, and intricate melodies.
    @AnjanaVakil JazzCon.Tech 2018
    wikipedia

    View Slide

  16. Bebop
    out
    unpacker
    status
    yoda user-limits
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  17. “there’s bound to be something else”
    ◍ Assign a single owner/gatekeeper?
    ◍ Multiple single-command apps?
    ◍ Separate commands from router app
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  18. “serverless” functions to the rescue
    AWS Lambda
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  19. what do you mean “serverless”
    Actual Server
    You own a computer
    You put code on it
    You run it constantly
    (and you pay constantly)
    You keep it healthy
    Cloud Server
    AWS owns a computer (or 2)
    You put code on it
    AWS runs it constantly
    (and you pay constantly)
    You tell AWS how to keep
    it healthy
    “No” Server
    AWS owns a computer
    You put code on it
    AWS runs it when you ask
    (and you pay only then)
    AWS keeps it healthy
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  20. ◍ Only concern: Input -> Output
    ◍ No state maintained between calls
    ◍ Can be side-effecting, though
    (e.g. API call, database write)
    ◍ Limited resources & exec time (5m)
    what do you mean “function”
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  21. Lose the server if it’s...
    ◍ small
    ◍ short-lived
    ◍ self-contained
    ◍ needed occasionally
    to lambda or not to lambda
    Keep the server if it’s...
    ◍ heavy
    ◍ long-running
    ◍ interdependent
    ◍ needed constantly
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  22. HTTP API
    endpoint
    AWS
    load
    balancer
    EC2s on ECS
    JS
    JS
    JS
    old architecture
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  23. HTTP API
    endpoint
    router
    new architecture
    stats
    out
    unpacker
    yoda
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  24. old
    codebase
    slack-commands/
    ├─ readme.md
    ├─ cloudformation/ #app & cmd config
    │ └─ slack-commands.template.js
    ├─ index.js #express app code
    ├─ commands/ #cmd code
    │ ├─ out.js
    │ ├─ stats.js
    │ └─ ...
    └─ test/ #app & cmd tests
    ├─ index.test.js
    ├─ out.test.js
    ├─ stats.test.js
    └─ ...
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  25. new
    codebase
    slack-commands/
    ├─ readme.md
    ├─ cloudformation/ #app config
    │ └─ slack-commands.template.js
    ├─ index.js #express app code
    ├─ commander.js #invoke lambdas
    └─ test/
    ├─ commander.test.js
    └─ index.test.js
    slack-command-{cmd}/
    ├ readme.md
    ├ cloudformation/ #cmd config
    │ └ slack-command-{cmd}.template.js
    ├ index.js #cmd code
    └ test/
    └ index.test.js
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  26. what does a
    function
    look like?
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  27. Place your screenshot here
    user stats commmand
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  28. module.exports.command = (event, context, callback) => {
    const { ApiCoreUrl, MapboxToken } = process.env;
    const user = event.args[0];
    const from = new Date(event.args[1] || (+new Date - 864e5*30)); // 30d
    const to = new Date(event.args[2] || (+new Date));
    if (isNaN(from)||isNaN(to)) return callback(new Error('invalid date'));
    const requrl = getStatsUrl(user, from, to, ApiCoreUrl, MapboxToken);
    request(requrl, (err, res, body) => {
    if (err||res.statusCode !== 200) return callback(err||res.statusCode);
    try { const data = JSON.parse(body); }
    catch(err) { return callback(err); }
    return callback(null, formatStatsMessage(user, data));
    });
    }
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  29. module.exports.command = (event, context, callback) => {
    const { ApiCoreUrl, MapboxToken } = process.env;
    const user = event.args[0];
    const from = new Date(event.args[1] || (+new Date - 864e5*30)); // 30d
    const to = new Date(event.args[2] || (+new Date));
    if (isNaN(from)||isNaN(to)) return callback(new Error('invalid date'));
    const requrl = getStatsUrl(user, from, to, ApiCoreUrl, MapboxToken);
    request(requrl, (err, res, body) => {
    if (err||res.statusCode !== 200) return callback(err||res.statusCode);
    try { const data = JSON.parse(body); }
    catch(err) { return callback(err); }
    return callback(null, formatStatsMessage(user, data));
    });
    }
    handler function
    (we tell Lambda its name)
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  30. module.exports.command = (event, context, callback) => {
    const { ApiCoreUrl, MapboxToken } = process.env;
    const user = event.args[0];
    const from = new Date(event.args[1] || (+new Date - 864e5*30)); // 30d
    const to = new Date(event.args[2] || (+new Date));
    if (isNaN(from)||isNaN(to)) return callback(new Error('invalid date'));
    const requrl = getStatsUrl(user, from, to, ApiCoreUrl, MapboxToken);
    request(requrl, (err, res, body) => {
    if (err||res.statusCode !== 200) return callback(err||res.statusCode);
    try { const data = JSON.parse(body); }
    catch(err) { return callback(err); }
    return callback(null, formatStatsMessage(user, data));
    });
    }
    execution environment
    we can configure
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  31. module.exports.command = (event, context, callback) => {
    const { ApiCoreUrl, MapboxToken } = process.env;
    const user = event.args[0];
    const from = new Date(event.args[1] || (+new Date - 864e5*30)); // 30d
    const to = new Date(event.args[2] || (+new Date));
    if (isNaN(from)||isNaN(to)) return callback(new Error('invalid date'));
    const requrl = getStatsUrl(user, from, to, ApiCoreUrl, MapboxToken);
    request(requrl, (err, res, body) => {
    if (err||res.statusCode !== 200) return callback(err||res.statusCode);
    try { const data = JSON.parse(body); }
    catch(err) { return callback(err); }
    return callback(null, formatStatsMessage(user, data));
    });
    }
    input { args: [ “vakila”, “1/1”, “3/22”] }
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  32. module.exports.command = (event, context, callback) => {
    const { ApiCoreUrl, MapboxToken } = process.env;
    const user = event.args[0];
    const from = new Date(event.args[1] || (+new Date - 864e5*30)); // 30d
    const to = new Date(event.args[2] || (+new Date));
    if (isNaN(from)||isNaN(to)) return callback(new Error('invalid date'));
    const requrl = getStatsUrl(user, from, to, ApiCoreUrl, MapboxToken);
    request(requrl, (err, res, body) => {
    if (err||res.statusCode !== 200) return callback(err||res.statusCode);
    try { const data = JSON.parse(body); }
    catch(err) { return callback(err); }
    return callback(null, formatStatsMessage(user, data));
    });
    }
    aws runtime info
    (e.g. time remaining - ignored here)
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  33. module.exports.command = (event, context, callback) => {
    const { ApiCoreUrl, MapboxToken } = process.env;
    const user = event.args[0];
    const from = new Date(event.args[1] || (+new Date - 864e5*30)); // 30d
    const to = new Date(event.args[2] || (+new Date));
    if (isNaN(from)||isNaN(to)) return callback(new Error('invalid date'));
    const requrl = getStatsUrl(user, from, to, ApiCoreUrl, MapboxToken);
    request(requrl, (err, res, body) => {
    if (err||res.statusCode !== 200) return callback(err||res.statusCode);
    try { const data = JSON.parse(body); }
    catch(err) { return callback(err); }
    return callback(null, formatStatsMessage(user, data));
    });
    }
    “ok, I’m done” function
    (AWS passes this when executing)
    error data
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  34. we wrote a function!
    yay
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  35. do we get it up there?
    how
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  36. Cloud::Formation templates
    ◍ JSON template - “just code”
    ◍ define your AWS stack components
    ◍ upload -> AWS builds your stack
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  37. Cloud::Formation templates
    {
    "AWSTemplateFormatVersion": "2010-09-09",
    "Description": "slack-command-stats",
    "Parameters": { "ApiCoreUrl": {...}, "MapboxToken": {...}
    "Resources": {
    "Command": {
    "Type": "AWS::Lambda::Function",
    "Properties": {...}
    },
    "CommandRole": {
    "Type": "AWS::IAM::Role",
    "Properties": {...}
    }
    },
    "Outputs": { ... }
    }
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  38. Cloud::Formation templates
    {
    "AWSTemplateFormatVersion": "2010-09-09",
    "Description": "slack-command-stats",
    "Parameters": { "ApiCoreUrl": {...}, "MapboxToken": {...}
    "Resources": {
    "Command": {
    "Type": "AWS::Lambda::Function",
    "Properties": {...}
    },
    "CommandRole": {
    "Type": "AWS::IAM::Role",
    "Properties": {...}
    }
    },
    "Outputs": { ... }
    }
    stack
    input
    params
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  39. Cloud::Formation templates
    {
    "AWSTemplateFormatVersion": "2010-09-09",
    "Description": "slack-command-stats",
    "Parameters": { "ApiCoreUrl": {...}, "MapboxToken": {...}
    "Resources": {
    "Command": {
    "Type": "AWS::Lambda::Function",
    "Properties": {...}
    },
    "CommandRole": {
    "Type": "AWS::IAM::Role",
    "Properties": {...}
    }
    },
    "Outputs": { ... }
    }
    aws
    permissions
    for function
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  40. Cloud::Formation templates
    {
    "AWSTemplateFormatVersion": "2010-09-09",
    "Description": "slack-command-stats",
    "Parameters": { "ApiCoreUrl": {...}, "MapboxToken": {...}
    "Resources": {
    "Command": {
    "Type": "AWS::Lambda::Function",
    "Properties": {...}
    },
    "CommandRole": {
    "Type": "AWS::IAM::Role",
    "Properties": {...}
    }
    },
    "Outputs": { ... }
    }
    actual
    lambda
    function
    the good stuff
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  41. Cloud::Formation templates
    "Command": {
    "Type": "AWS::Lambda::Function",
    "Properties": {
    "FunctionName": "slack-command-stats-production",
    "Code": { "S3Bucket": {...}, "S3Key": {...} },
    "Handler": "index.command",
    "Environment": { "Variables": {
    "ApiCoreUrl": { "Ref": "ApiCoreUrl" },
    "MapboxToken": { "Ref": "MapboxToken" } } },
    "Role": { "Fn::GetAtt": ["CommandRole","Arn"] },
    "Runtime": "nodejs4.3", "MemorySize": 128, "Timeout": 60,
    "Tags": [ { "Key": "Team", "Value": "EngOps"} ]
    }
    }
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  42. Cloud::Formation templates
    "Command": {
    "Type": "AWS::Lambda::Function",
    "Properties": {
    "FunctionName": "slack-command-stats-production",
    "Code": { "S3Bucket": {...}, "S3Key": {...} },
    "Handler": "index.command",
    "Environment": { "Variables": {
    "ApiCoreUrl": { "Ref": "ApiCoreUrl" },
    "MapboxToken": { "Ref": "MapboxToken" } } },
    "Role": { "Fn::GetAtt": ["CommandRole","Arn"] },
    "Runtime": "nodejs4.3", "MemorySize": 128, "Timeout": 60,
    "Tags": [ { "Key": "Team", "Value": "EngOps"} ]
    }
    }
    @AnjanaVakil JazzCon.Tech 2018
    function
    name
    helps find it later

    View Slide

  43. Cloud::Formation templates
    "Command": {
    "Type": "AWS::Lambda::Function",
    "Properties": {
    "FunctionName": "slack-command-stats-production",
    "Code": { "S3Bucket": {...}, "S3Key": {...} },
    "Handler": "index.command",
    "Environment": { "Variables": {
    "ApiCoreUrl": { "Ref": "ApiCoreUrl" },
    "MapboxToken": { "Ref": "MapboxToken" } } },
    "Role": { "Fn::GetAtt": ["CommandRole","Arn"] },
    "Runtime": "nodejs4.3", "MemorySize": 128, "Timeout": 60,
    "Tags": [ { "Key": "Team", "Value": "EngOps"} ]
    }
    }
    @AnjanaVakil JazzCon.Tech 2018
    code to run
    the good stuff

    View Slide

  44. Cloud::Formation templates
    "Command": {
    "Type": "AWS::Lambda::Function",
    "Properties": {
    "FunctionName": "slack-command-stats-production",
    "Code": { "S3Bucket": {...}, "S3Key": {...} },
    "Handler": "index.command",
    "Environment": { "Variables": {
    "ApiCoreUrl": { "Ref": "ApiCoreUrl" },
    "MapboxToken": { "Ref": "MapboxToken" } } },
    "Role": { "Fn::GetAtt": ["CommandRole","Arn"] },
    "Runtime": "nodejs4.3", "MemorySize": 128, "Timeout": 60,
    "Tags": [ { "Key": "Team", "Value": "EngOps"} ]
    }
    }
    @AnjanaVakil JazzCon.Tech 2018
    execution
    environment
    can pass in params

    View Slide

  45. Cloud::Formation templates
    "Command": {
    "Type": "AWS::Lambda::Function",
    "Properties": {
    "FunctionName": "slack-command-stats-production",
    "Code": { "S3Bucket": {...}, "S3Key": {...} },
    "Handler": "index.command",
    "Environment": { "Variables": {
    "ApiCoreUrl": { "Ref": "ApiCoreUrl" },
    "MapboxToken": { "Ref": "MapboxToken" } } },
    "Role": { "Fn::GetAtt": ["CommandRole","Arn"] },
    "Runtime": "nodejs4.3", "MemorySize": 128, "Timeout": 60,
    "Tags": [ { "Key": "Team", "Value": "EngOps"} ]
    }
    }
    @AnjanaVakil JazzCon.Tech 2018
    permissions
    from earlier

    View Slide

  46. Cloud::Formation templates
    "Command": {
    "Type": "AWS::Lambda::Function",
    "Properties": {
    "FunctionName": "slack-command-stats-production",
    "Code": { "S3Bucket": {...}, "S3Key": {...} },
    "Handler": "index.command",
    "Environment": { "Variables": {
    "ApiCoreUrl": { "Ref": "ApiCoreUrl" },
    "MapboxToken": { "Ref": "MapboxToken" } } },
    "Role": { "Fn::GetAtt": ["CommandRole","Arn"] },
    "Runtime": "nodejs4.3", "MemorySize": 128, "Timeout": 60,
    "Tags": [ { "Key": "Team", "Value": "EngOps"} ]
    }
    }
    @AnjanaVakil JazzCon.Tech 2018
    what to run it on
    totally not a server

    View Slide

  47. Cloud::Formation templates
    "Command": {
    "Type": "AWS::Lambda::Function",
    "Properties": {
    "FunctionName": "slack-command-stats-production",
    "Code": { "S3Bucket": {...}, "S3Key": {...} },
    "Handler": "index.command",
    "Environment": { "Variables": {
    "ApiCoreUrl": { "Ref": "ApiCoreUrl" },
    "MapboxToken": { "Ref": "MapboxToken" } } },
    "Role": { "Fn::GetAtt": ["CommandRole","Arn"] },
    "Runtime": "nodejs4.3", "MemorySize": 128, "Timeout": 60,
    "Tags": [ { "Key": "Team", "Value": "EngOps"} ]
    }
    }
    @AnjanaVakil JazzCon.Tech 2018
    arbitrary tags
    e.g. who owns this?

    View Slide

  48. Mapbox open-source AWS
    helpers
    github.com/mapbox/
    Command-line tools
    lambda-cfn create & deploy Node Lambda functions
    cfn-config configure/start/update CFN stacks
    JS libraries
    cloudfriend easily assemble CFN templates in JS
    decrypt-kms-env use secret environment vars
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  49. we deployed a function!
    yay
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  50. do we call it?
    how
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  51. testing in the AWS console (manually)
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  52. in Node with AWS SDK
    const AWS = require('aws-sdk');
    const runCommand = (req, res, next) => {
    const [commandName, ...args] = = req.slackText;
    const params = {
    FunctionName: `slack-command-${commandName}-production`, // our convention
    Payload: JSON.stringify({ args: args }), // the `event` Lambda receives
    };
    const lambda = new AWS.Lambda({ region: 'us-east-1' });
    lambda.invoke(params).promise()
    .catch((err) => err.message) // pass on error message as response data
    .then((data) => res.json(formatForSlack(data)));
    };
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  53. why
    did we do all that?
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  54. Before (single app)
    ◍ Many secrets in one
    stack
    ◍ Updating your code
    updates whole stack
    ◍ No fine-grained cost
    analysis
    Refactoring to Lambda: Benefits
    After (multiple Lambdas)
    ◍ Each stack only knows
    its own secrets
    ◍ Updating your code
    leaves others untouched
    ◍ Each stack/fn can be
    tagged & cost-monitored
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  55. HTTP API
    endpoint
    router
    next steps
    stats
    out
    unpacker
    yoda
    @AnjanaVakil JazzCon.Tech 2018

    View Slide

  56. HTTP API
    endpoint
    next steps
    stats
    out
    unpacker
    yoda
    @AnjanaVakil JazzCon.Tech 2018
    router

    View Slide

  57. Merci!
    @AnjanaVakil
    [email protected]
    ✌ Team Mapbox
    Young Hahn, Emily McAfee,
    Kelly Young, Jake Pruitt, Andrew Evans
    JazzCon.Tech Organizers
    Images from Wikimedia
    Template by SlidesCarnival.com

    View Slide
