Build a Collaborative framework for your business applications with Communities

In this session we will show you business applications from different systems brought together under the collaborative umbrella of a Connections Community. Discuss, talk, engage around the applications that drive your business in context inside communities. Build small collaborative eco systems that drives people and the business forward.
We will also show you how to do this. Using Keycloak as an IdP you can login to connections using your Office 365 credentials, bring in applications from the Microsoft world on top of the already existing integrations. We will connect to HCL Domino backends to bring HCL Domino and HCL Volt applications alive inside Communities. And lastly we will show how to add an application from any external system that talks SAML or OIDC.
This session will have a non-technical and technical part so all are welcome to join.

Presented with Urs Meli at the Engage conference 2022

Transcript

1. Build a Collaborative framework
   for your business applications
   with HCL Connections Communities


   View Slide

2. Urs Meli
   • Senior Software Engineer
   @Belsoft Collaboration
   • @umeli
   • urs.meli@belsoft.ch
   • Paraglider
   Wannes Rams
   • Senior Cloud Architect @ISW
   • HCL Ambassador
   • Organiser @Let’sConnect
   • @wannesrams
   • wannes@isw.net.au
   • Table Tennis
   • Travel


   View Slide

3. Agenda
   • Introduction
   • Demo
   • How to implement the user interface
   • How to implement the tricky stuff


   View Slide

4. Why are we showing this
   • Your tools are fragmented
   • No central place to go
   • Communities are core to your business
   • HCL Connections got your back


   View Slide

5. Demo


   View Slide

6. Front End: How to
   • App Registry
   • HighLights widgets
   • Iframes
   • Navigation cleanup


   View Slide

7. App Registry
   • Easiest for embedding
   • Can be used in classic
   and higlights
   • Additional features
   available


   View Slide

8. Example Volt Application
   • Only needs URL
   • Width / Height set to 100%
   • Black / Whitelisting per:
   • User
   • Email
   • Regex
   • url


   View Slide

9. Highlights Widgets
   • Add custom widgets in the Highlights widget bar
   • Can only be used in Highlights


   View Slide

10. Highlights Widgets: Huddo Boards example


    View Slide

11. iFrame
    • Not recommended
    • Little controls
    • Only for internal sites / Same domain name or sites you can control


    View Slide

12. Navigation cleanup
    • Using an App Registry application
    • Inject CSS and Javascript


    View Slide

13. Navigation cleanup


    View Slide

14. Navigation cleanup


    View Slide

15. Caution ! More Technical parts ahead
    • Journey from plain Connections to Connections with SSO


    View Slide

16. New Loginpage for Connections
    Keycloak /
    IDP
    HCL Connections
    OIDC


    View Slide

17. Keycloak
    • OpenSource Identity and Access Managment:
    https://www.keycloak.org
    • Why Keycloak? Connections Multi Tenant requirement
    => We already had positive experience with it, and it’s free.
    • Increased Security:
    • Brute Force Detection
    • MultiFactor Authentication:
    • OTP Authenticator
    • WebAuthN


    View Slide

18. Connections Support for OIDC
    • OIDC is part of WebSphere Security
    • Connections needs only minor adjustments
    • Desktop plugin and mobile work
    • Keycloak can be replaced by any other OIDC capable identity provider


    View Slide

19. What else ? Connect Domino Servers
    Keycloak /
    IDP
    HCL Connections
    Domino Webapp
    Domino Volt
    Verse
    SAML
    OIDC
    SAML
    SAML


    View Slide

20. Why ?
    • Same Login experience
    • Same Security Settings
    • Works across domains


    View Slide

21. Setup Domino with SAML
    • 1. Create an Internet Site
    • 2. Export Identity Provider Metadata from Keycloak and import it in
    idpcat.nsf
    • 3. Export the Service Provider Metadata from idpcat and import it in
    Keycloak
    • 4. Set any additional mapping


    View Slide

22. Internet Site – SAML enabled
    Once the Internet Site exists. Hit the
    «Open IdP Configuration» button to open
    the idpcat.nsf file. If it does not exist,
    create it.


    View Slide

23. Create IDP Config – 1/3
    • Identity Provider Metadata is located in
    https://[host]/auth/realms/[realm]/protocol/saml/descriptor
    • Import that file into a new Idp Configuration document


    View Slide

24. Create IDP Config 2/3
    • Select the internet site
    • Check the Service Provider ID – needs to be consistent with the client
    ID in Keycloak


    View Slide

25. Create IDP Config 3/3
    • Create and export the ServiceProvider Metadata
    • Give it a unique Company name, then export the xml and save the
    attached ServiceProvider.xml


    View Slide

26. Keycloak client definition for Domino
    • Create a new client and import the ServiceProvider.xml
    • Verify the redirect URIs and client ID
    • Tricky part - Name ID Format:
    use email or username, defines which property from a keycloak user
    is used to match a Domino user
    • There are SAML-Tracer plugins for FireFox and Chrome available
    which help with debugging


    View Slide

27. Summary
    • Connections, Domino WebApps, Volt, Verse
    all use the same login now
    • Authentication is handled by Keycloak


    View Slide

28. Where are the Credentials?
    • Domino? AD? IBM-DS? OpenLDAP? Database ? Keycloak ?


    View Slide

29. What’s next ? M365 ?
    Keycloak /
    IDP
    M365 Login
    Page
    HCL Connections
    Domino Webapp
    Domino Volt
    Verse
    OIDC
    SAML
    SAML
    SAML
    SAML


    View Slide

30. Login Delegation
    Keycloak /
    IDP
    M365 Login
    Page
    HCL Connections
    OIDC SAML


    View Slide

31. Why would you do that ?
    • Login to HCL Connections, Verse, Xpages Apps, Volt
    with your M365 Account


    View Slide

32. Using M365 as Identity Provider
    • Create an «App registration» and download the
    FederationMetadata.xml from Azure
    • Create Identity Broker in keycloak and import the
    FederationMetadata.xml and export the ServiceProvider.xml
    • In Azure, create a new application «Azure AD SAML Toolkit» and
    import the ServiceProvider.xml
    • Make sure that the email address arrives at keycloak.


    View Slide

33. Azure 1/2 – FederationMetadata.xml


    View Slide

34. Azure 2/2 - FederationMetadata.xml


    View Slide

35. Keycloak add new SAML Identity Provider
    • Import the FederationMetadata.xml file
    • Once the identity provider has been saved, download the
    ServiceProvider.xml


    View Slide

36. Azure AD 1/3 - Import ServiceProvider.xml


    View Slide

37. Azure AD 2/3 – Import ServiceProvider.xml


    View Slide

38. Azure AD 3/3 – import ServiceProvider.xml


    View Slide

39. Result so far…
    • We now have a «Login with M365» button


    View Slide

40. Everybody has M365 Account
    • Keycloak allows automatic redirect to the M365 as shown in the
    demo
    Keycloak /
    IDP
    M365 Login
    Page
    HCL Connections
    OIDC SAML


    View Slide

41. Why add Keycloak then ?
    • M365 supports OIDC and SAML. It’s be possible to connect
    Connections and Domino servers directly to M365
    • It has been easier for us to setup Keycloak in a test environment
    • As Connections or Domino Admins, we don’t want to mess up the
    Azure AD J


    View Slide

42. What’s next ?
    Keycloak /
    IDP
    M365 Login
    Page
    HCL Connections
    Domino Webapp
    Domino Volt
    Verse
    Other Apps
    PowerBI
    Power Apps
    SAML/OIDC


    View Slide

43. Other Apps
    • Every WebApp that supports SAML 2.0 or OIDC/OAUTH
    • Grafana
    • Gitlab
    • SugarCRM
    • HubSpot
    • Zoho
    • Salesforce
    • Citrix Netscaler
    • Atlassian Jira
    • …


    View Slide

44. Is it that easy ?
    • Setting up authentication is simple as long as the app is able to
    handle either OIDC or SAML 2
    • Display app content can be done in 2 ways. Custom Widget or iFrame.
    Troubles ahead:
    • XSS
    • Custom Widget = Development and CORS
    • iFrame = Frameoptions / sandbox / Content-Security-Policies


    View Slide

45. Links
    • Keycloak: https://www.keycloak.org
    • IBM Documentation on OIDC:
    https://www.ibm.com/docs/en/was-nd/8.5.5?topic=users-configuring-openid-connect-relying-party
    • OIDC requires WAS 8.5.5.21 or an ifix: https://www.ibm.com/support/pages/node/6513845
    • HCL Connections and Keycloak:
    https://opensource.hcltechsw.com/connections-doc/v7/keycloak_authentication_sso/keycloak_auth_sso.html
    • Domino SAML authenticaton:
    https://help.hcltechsw.com/domino/12.0.0/admin/secu_configuring_nonfederated_saml_authentication.html
    • HCL Connections App Registry
    https://github.com/hclcnx/customizer/blob/master/docs/HCLConnectionsCustomizer.md
    • Creating a custom ICEC widget
    https://help.hcltechsw.com/connections/v7/connectors/icec/cec-custom-widget-api.html
    • Custom Huddo Boards ICEC widget
    https://docs.huddo.com/boards/connections/widgets-on-prem/
    • Enabling single sign-on with OIDC for Microsoft Azure AD
    https://help.hcltechsw.com/connections/v7/admin/secure/c_azure_oidc_container.html


    View Slide
