1. Ivan Yashchuk
   Aalto University | Quansight Labs
   Phase Field Methods
   + FEniCS/Firedrake
   CHiMaD Phase Field Methods Workshop XI
   ivan.yashchuk@aalto.fi


   View Slide

2. Content
   ●
   FEniCS/Firedrake introduction
   ○
   Composable solvers & preconditioning
   ○
   Time-dependent problems: firedrake-ts, Irksome
   ○
   Phase field specific example
   ●
   PFHub benchmarks
   ●
   Future developments (GPU, AMR)
   ●
   Embedding into optimization and machine learning packages
   ●
   Conclusions


   View Slide

3. FEniCS / Firedrake Introduction
   firedrakeproject.org
   fenicsproject.org


   View Slide

4. FEniCS / Firedrake
   Unified Form Language (UFL) is a domain specific language for specifying and
   manipulating variational (weak) forms, used in FEniCS, Firedrake, and Dune-Fem.
   Having a PDE problem specified using UFL, an efficient low-level code is generated
   from a higher-level description.
   FEniCS is implemented in C++ and has C++ and Python user interface.
   Firedrake is implemented in Python (with bits of Cython) and is tightly integrated
   with PETSc library.


   View Slide

5. Strong and weak formulations for a Poisson problem
   ✗
   Strong form:
   where
   Ω
   is the spatial domain and ∂
   Ω
   is the boundary of
   Ω
   .
   ✓
   Variational or weak form:


   View Slide

6. “Hello world!” / Stokes equation


   View Slide

7. UFL language for finite element forms
   Weak formulation is easy to work with for deriving adjoint Jacobian, matrix actions, etc.
   Source: FEniCS Book
   The adjoint a* of a bilinear form a is
   the form obtained by interchanging
   the two arguments
   The linear form Aa is the
   action of the bilinear form a


   View Slide

8. Some useful UFL operators
   Tensor algebra operators:
   transpose, tr, dor, inner, outer, cross, det, dev, sym, skew
   Differential operators:
   Spatial derivatives, gradient, divergence, curl, rot, variable derivatives, functional
   derivatives
   Discontinuous Galerkin operators:
   jump, avg, restriction
   UFL User Manual: https://fenicsproject.org/pub/documents/ufl/ufl-user-manual/ufl-user-manual.pdf


   View Slide

9. “Physics-based” preconditioners & solver composition in Firedrake
   Firedrake relies on PETSc KSP and PETSc SNES for solving linear and nonlinear
   problems.
   All the power of “command-line programming” of PETSc options is available
   separating the model and solver implementation. The code remains the same.
   ✓
   matrix-free methods
   ✓
   geometric multigrid
   ✓
   Schur complements
   ✓
   block Jacobi, block Gauss-Seidel
   Robert C. Kirby, Lawrence Mitchell “Solver composition across the PDE/linear
   algebra barrier”, https://arxiv.org/abs/1706.01346


   View Slide

10. Example | Runtime solver composition in Firedrake
    〈
    p, q
    〉
    −
    〈
    q, div u
    〉
    +
    λ 〈
    v, u
    〉
    +
    〈
    div v, p
    〉
    =
    〈
    f, q
    〉   ∀
    v
    ∈
    V
    ₁
    , q
    ∈
    V
    ₂
    https://www.firedrakeproject.org/solving-interface.html#preconditioning-mixed-finite-element-systems
    S=D−CA
    ⁻
    ¹B
    “diag” “lower”
    “upper”
    “FULL”


    View Slide

11. Solving time-dependent problems | Irksome
    The Irksome library provides
    Implicit Runge Kutta methods
    for Firedrake.
    https://github.com/firedrakeproject/Irksome


    View Slide

12. Solving time-dependent problems | firedrake-ts
    The firedrake-ts library
    provides an interface to
    PETSc TS for the scalable
    solution of DAEs arising from
    the discretization of
    time-dependent PDEs.
    https://github.com/IvanYashchuk/firedrake-ts


    View Slide

13. Solving time-dependent problems | firedrake-ts
    Plans: IMEX methods, interface to Julia’s DifferentialEquations.jl
    https://github.com/IvanYashchuk/firedrake-ts
    The current PETSc TS interface for solving time dependent problems
    assumes the problem is written in the form
    F(t, u,
    u
    ̇
    ) = 0, u(t
    ₀
    ) = u
    ₀
    .
    The Jacobian required by PETSc TS is automatically derived with UFL


    View Slide

14. Parallel support
    Parallelism is implemented using MPI.
    Usual workflow:
    ●
    initial solver implementation on a desktop/laptop for small scale problem
    ●
    run the same code on a supercomputer using many parallel processes
    mpirun -np 128 python script.py


    View Slide

15. Simple Allen-Cahn variationally derived


    View Slide

16. Simple Allen-Cahn variationally derived


    View Slide

17. Simple Allen-Cahn variationally derived | Code example
    R(
    ϕ̇
    ,
    ϕ
    , t) =
    τ
    (
    ϕ
    )
    〈ϕ̇
    , v
    〉
    +
    〈 δ
    F/
    δϕ
    , v
    〉 ∀
    v
    ∈
    V
    In code:
    R_AC = tau(phi) * inner(dphi_dt, v) * dx + derivative(F, phi, v) * dx
    Then just
    problem = firedrake_ts.DAEProblem(R_AC,phi,dphi_dt,(0.0, 1.0),bcs=bc)
    solver = firedrake_ts.DAESolver(problem)
    solver.solve()


    View Slide

18. PFHub benchmarks
    Great way to get started with implementing own phase field solver
    and share knowledge!
    https://pages.nist.gov/pfhub/


    View Slide

19. Benchmark Problem 1: Spinodal Decomposition
    The free energy of the system:
    Chemical free energy density:
    Note: Argyris and Bell finite elements are available for C¹ discretizations
    Robert C. Kirby, Lawrence Mitchell “Code generation for generally mapped finite elements”, https://arxiv.org/abs/1808.05513


    View Slide

20. Benchmark Problem 1: Spinodal Decomposition
    The free energy of the system:


    View Slide

21. Benchmark Problem 1: Spinodal Decomposition
    Chemical free energy density:


    View Slide

22. Benchmark Problem 1: Spinodal Decomposition
    Governing equation:


    View Slide

23. Benchmark Problem 1: Spinodal Decomposition
    Note: Argyris and Bell finite elements are available for C¹ discretizations
    Robert C. Kirby, Lawrence Mitchell “Code generation for generally mapped finite elements”, https://arxiv.org/abs/1808.05513


    View Slide

24. Benchmark Problem 1: Spinodal Decomposition (case “d”)


    View Slide

25. Benchmark Problem 2: Ostwald Ripening
    Vector Allen-Cahn + Cahn-Hilliard equations.
    The free energy of the system:


    View Slide

26. Benchmark Problem 2: Ostwald Ripening
    The chemical free energy density:


    View Slide

27. Benchmark Problem 2: Ostwald Ripening
    Cahn-Hilliard equation:
    Allen-Cahn equations:


    View Slide

28. Benchmark Problem 3: Dendritic Growth
    Allen-Cahn + Heat equations
    https://github.com/IvanYashchuk/pf-hub-benchmark3


    View Slide

29. Similar code for other benchmarks!
    ●
    Benchmark Problem 4: Elastic Precipitate
    Cahn-Hilliard + Linear Elasticity
    FEniCS demo for Hyperelasticity:
    https://fenicsproject.org/olddocs/dolfin/latest/python/demos/hyperelasticity/demo_hyperelasticity.py.html
    ●
    Benchmark Problem 5: Stokes Flow
    FEniCS demo for Stokes equations:
    https://fenicsproject.org/olddocs/dolfin/latest/python/demos/stokes-iterative/demo_stokes-iterative.py.html
    ●
    Benchmark Problem 6: Electrostatics
    Cahn-Hilliard + Poisson Equation


    View Slide

30. Example: Navier-Stokes+Cahn-Hilliard+Heat
    Tatu Pinomaa, Ivan Yashchuk, Matti Lindroos, Tom Andersson, Nikolas Provatas, Anssi Laukkanen
    “Process-Structure-Properties-Performance Modeling for Selective Laser Melting”, 2019, https://doi.org/10.3390/met9111138


    View Slide

31. Future developments | AMR with FEniCS
    ●
    Automatic AMR using adjoint/dual estimators
    ●
    There is no coarsening
    😔
    ●
    Adaptive meshing is removed in the new version FEniCS-X
    Melting of octadecane (Navier-Stokes+Advection-Diffusion)


    View Slide

32. Future developments | AMR with Firedrake
    ●
    There is no official support for AMR
    ●
    There is some effort and on some branch this functionality exists
    Nicolas Barral, et al.
    Anisotropic mesh adaptation in Firedrake with PETSc DMPlex, https://arxiv.org/abs/1610.09874, 2016
    April 2021 update:


    View Slide

33. Future developments | AMR with DUNE
    Did not try personally but looks promising! Same model specification using UFL.
    Peter Bastian, Markus Blatt, Andreas Dedner, Nils-Arne Dreier, Christian Engwer, René Fritze, Carsten Gräser, Christoph
    Grüninger, Dominic Kempf, Robert Klöfkorn, Mario Ohlberger, Oliver Sander
    “The DUNE Framework: Basic Concepts and Recent Developments”, https://arxiv.org/abs/1909.13672


    View Slide

34. Future developments | GPU support for Firedrake
    ✓
    PETSc supports GPUs
    ✗
    Firedrake doesn’t have an official support of assembling matrices and vectors on
    GPUs
    There is an ongoing work by Kaushik Kulkarni and Andreas Kloeckner (UIUC)
    SIAM CSE21 poster: https://ssl.tiker.net/nextcloud/s/rsSa6KsYEsA3xqk


    View Slide

35. Automatic Differentiation libraries
    + FEniCS/Firedrake
    FEniCS’21 presentation: https://fenics2021.com/talks/yashchuk.html
    Embedding of PDE solvers into optimization and machine learning packages


    View Slide

36. https://ivanyashchuk.github.io/fenics_pymccon2020/
    PyMC3


    View Slide

37. https://github.com/IvanYashchuk/PyFenicsAD.jl
    Julia | Turing.jl
    Summary Statistics
    parameters mean std naive_se mcse ess rhat
    Symbol Float64 Float64 Float64 Float64 Float64 Float64
    kappa0 1.2497 0.3789 0.0120 0.0357 130.3485 1.0001
    kappa1 0.5443 0.1711 0.0054 0.0155 139.7087 1.0001
    σ 0.0143 0.0019 0.0001 0.0001 178.8158 1.0043
    Quantiles
    parameters 2.5% 25.0% 50.0% 75.0% 97.5%
    Symbol Float64 Float64 Float64 Float64 Float64
    kappa0 0.5183 0.9850 1.2590 1.5483 1.9140
    kappa1 0.2295 0.4291 0.5424 0.6698 0.8579
    σ 0.0111 0.0130 0.0142 0.0154 0.0188


    View Slide

38. Conclusions
    Firedrake and FEniCS are powerful libraries with many useful tools for developing a phase field
    solver possibly mixed with different kind of physics.
    ●
    Keep the models and solvers separate
    ●
    Rely on UFL to do derivatives and other weak form transformations
    ●
    Mostly same code runs on supercomputers
    How to get started?
    1. Start with FEniCS tutorial “Solving PDEs in Python - The FEniCS Tutorial Volume I” by Hans Petter Langtangen, Anders Logg
    2. Join the FEniCS Discourse forum to ask questions on UFL or other aspects
    3. Continue with implementing PFHub benchmark problems
    4. Try using Firedrake and firedrake-ts
    ivan.yashchuk@aalto.fi
