  1. THE CLOUD CONNECTIVITY COMPANY
    1
    © Kong Inc.
    THE CLOUD
    CONNECTIVITY COMPANY
    Using Kong ingress controller for K3s
    施文翰(Wenhan Shi) – Solutions Engineer
    June 2022

    View Slide

  2. THE CLOUD CONNECTIVITY COMPANY
    2
    © Kong Inc. 2
    Who am I
    施 文翰(シ ブンカン) Wenhan Shi
    • 日立製作所 - Linux kernel module development/Support
    • Red Hat K.K. - GlusterFS/OpenShift Support
    • Canonical Japan K.K. - Ubuntu/OpenStack/Kubernetes Support
    • Rancher Lab/SUSE - Rancher Support
    • Kong Inc. - Solutions Engineer
    @shi_wenhan
    [email protected]

    View Slide

  3. THE CLOUD CONNECTIVITY COMPANY
    3
    © Kong Inc.
    ● Kong for Kubernetes intro
    ● Deployment
    ○ Kubernetes YAML
    ○ Helm
    ● Exposing, Securing, and
    Protecting a Service
    Agenda

    View Slide

  4. THE CLOUD CONNECTIVITY COMPANY
    4
    © Kong Inc. 4
    Kong for Kubernetes Intro

    View Slide

  5. THE CLOUD CONNECTIVITY COMPANY
    5
    © Kong Inc. 5
    • Kong for Kubernetes is a cloud native Kubernetes Ingress Controller
    • Kong Ingress Controller for Kubernetes(KIC) Github
    Intro
    https://docs.konghq.com/enterprise/2.5.x/deployment/installation/kong-for-kubernetes/#introduction

    View Slide

  6. THE CLOUD CONNECTIVITY COMPANY
    6
    © Kong Inc. 6
    • Kong and KIC will be deployed in one Pod.
    • Expose kubernetes’ service by Ingress Resource
    • KIC Receive event from API server and configure Kong
    • Kong container will Handle all traffic defined by Kong Ingress resources.
    Arch
    https://docs.konghq.com/kubernetes-ingress-controller/2.3.x/concepts/design/

    View Slide

  7. THE CLOUD CONNECTIVITY COMPANY
    7
    © Kong Inc. 7
    Intro - 2
    • Kong’s main components
    Kong Gateway : http://wenhan.io
    Route(/A)
    Route(/B)
    Route(/C)
    Service(1)
    Service(2)
    Service(3)
    Route(/D)
    LB
    API
    Client
    http://wenhan.io/A
    URL 1
    URL 2
    External API
    URL 2

    View Slide

  8. THE CLOUD CONNECTIVITY COMPANY
    8
    © Kong Inc. 8
    Intro - 3
    • Kong’s main components map to Kubernetes resource type
    Kong Gateway : http://wenhan.io
    Route(/A)
    Route(/B)
    Route(/C)
    Service(1)
    Service(2)
    Service(3)
    Route(/D)
    LB
    API
    Client
    http://wenhan.io/A
    URL 1
    URL 2
    External API
    URL 2
    Ingress
    Rules Kubernetes Service Kubernetes Pods

    View Slide

  9. THE CLOUD CONNECTIVITY COMPANY
    9
    © Kong Inc. 9
    Deployment

    View Slide

  10. THE CLOUD CONNECTIVITY COMPANY
    10
    © Kong Inc. 10
    Install Kong Gateway

    View Slide

  11. THE CLOUD CONNECTIVITY COMPANY
    11
    © Kong Inc. 11
    Deployment method
    YAML Helm
    DataBase DB-less only DB-less or DB-based
    Config store ETCD ETCD or DB
    mode Available for OSS, Enterprise
    Pros Easy and quick Fully customizable
    Component
    s
    Proxy Yes Yes
    Admin API No Yes
    Manager (GUI) No Yes
    Dev Portal No Yes
    Vitals No Yes

    View Slide

  12. THE CLOUD CONNECTIVITY COMPANY
    12
    © Kong Inc. 12
    DB-less mode?
    - Kong can be deploy in both DB-less or DB-related mode
    - Using a DB-less mode
    - Pros:
    - reduced dependencies: no need to manage a database
    - good fit for automation in CI/CD: configuration in a single source (local or Git)
    - Cons:
    - Higher memory usage
    - Not all the plugins are full Compatible in this mode
    - https://docs.konghq.com/konnect-platform/compatibility/plugins/
    https://docs.konghq.com/gateway/2.8.x/reference/db-less-and-declarative-config/#using-kong-in-db-less-mode

    View Slide

  13. THE CLOUD CONNECTIVITY COMPANY
    13
    © Kong Inc. 13
    Deploying with Kubernetes YAML - 1
    - Need license file for Enterprise deployment
    - There is no postgre DB pod
    ## on Kubernetes native
    kubectl create namespace kong
    ## Kong Gateway on Kubernetes native
    kubectl create secret generic kong-enterprise-license --from-file=./license -n kong
    kubectl apply -f https://bit.ly/k4k8s-enterprise-install
    ## Kong Gateway (OSS) on Kubernetes native
    kubectl apply -f https://bit.ly/kong-ingress-dbless
    $ kubectl get pod -n kong
    NAME READY STATUS RESTARTS AGE
    svclb-kong-proxy-4sfn5 2/2 Running 0 103s
    ingress-kong-677b9ccbf8-tczsf 2/2 Running 3 (79s ago) 103s

    View Slide

  14. THE CLOUD CONNECTIVITY COMPANY
    14
    © Kong Inc. 14
    Deploying with Kubernetes YAML - 2
    - Verify
    $ kubectl get svc -n kong
    NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
    kong-validation-webhook ClusterIP 10.43.98.37 443/TCP 110s
    kong-proxy LoadBalancer 10.43.98.177 10.0.134.197 80:30717/TCP,443:32221/TCP 110s
    $ http 10.0.134.197 Or $ http localhost:30717
    HTTP/1.1 404 Not Found
    Connection: keep-alive
    Content-Length: 48
    Content-Type: application/json; charset=utf-8
    Date: Mon, 18 Apr 2022 05:02:37 GMT
    Server: kong/2.8.0
    X-Kong-Response-Latency: 1
    {
    "message": "no Route matched with those values"
    }

    View Slide

  15. THE CLOUD CONNECTIVITY COMPANY
    15
    © Kong Inc. 15
    Deploying with Helm - all default settings -1
    - Deploy Kong using helm with all default settings
    ## pre-install
    kubectl create namespace kong
    helm repo add kong https://charts.konghq.com
    helm repo update
    ## Install Kong Gateway
    helm install kong/kong --generate-name

    View Slide

  16. THE CLOUD CONNECTIVITY COMPANY
    16
    © Kong Inc. 16
    Deploying with Helm - all default settings - 2
    - Verify
    ## By default, Kong is deployed in DB-less mode
    $ kubectl get pod
    NAME READY STATUS RESTARTS AGE
    svclb-kong-1650259566-kong-proxy-wfs7g 2/2 Running 0 90s
    kong-1650259566-kong-6b5d5c5758-psffx 2/2 Running 2 (87s ago) 90s
    ## Only kong proxy is available
    $ kubectl get svc
    NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
    kubernetes ClusterIP 10.43.0.1 443/TCP 39h
    kong-1650259566-kong-proxy LoadBalancer 10.43.40.186 10.0.134.197 80:31276/TCP,443:30182/TCP 49s
    $ http 10.0.134.197
    $ http localhost:31276
    HTTP/1.1 404 Not Found

    {
    "message": "no Route matched with those values"
    }

    View Slide

  17. THE CLOUD CONNECTIVITY COMPANY
    17
    © Kong Inc. 17
    Deploying with Helm - customize - 1
    - Use values.yaml to config Kong
    - Configuration parameters.
    - https://github.com/Kong/charts/blob/main/charts/kong/README.md#configuration
    - Examples
    - https://github.com/Kong/charts/tree/main/charts/kong/example-values
    ## pre-install
    kubectl create namespace kong
    helm repo add kong https://charts.konghq.com
    helm repo update
    ## Install Kong Gateway
    helm install my-kong kong/kong -n kong --values ./values.yaml

    View Slide

  18. THE CLOUD CONNECTIVITY COMPANY
    18
    © Kong Inc. 18
    Deploying with Helm - customize - 2
    - Verify
    ## A Postgre DB pod is running and also a localpath of PV
    $ kubectl get pod -n kong
    NAME READY STATUS RESTARTS AGE
    my-kong-postgresql-0 1/1 Running 0 7m2s
    my-kong-kong-init-migrations--1-drgk9 0/1 Completed 0 7m2s
    my-kong-kong-57c589bf8c-xm6c8 2/2 Running 2 (5m54s ago) 7m2
    $ kubectl get pv
    NAME CAPACITY ACCESS MODES RECLAIM POLICY STATUS CLAIM
    STORAGECLASS REASON AGE
    pvc-fc7353d4-bb9f-4d9e-8f74-cb1cb8546f40 8Gi RWO Delete Bound
    kong/data-my-kong-postgresql-0 local-path 8m41s
    ## Have all the features enabled.
    $ kubectl get svc -n kong
    NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
    my-kong-postgresql-headless ClusterIP None 5432/TCP 9m11s
    my-kong-kong-proxy NodePort 10.43.119.198 80:31000/TCP,443:31254/TCP 9m11s
    my-kong-kong-admin NodePort 10.43.191.164 8001:31001/TCP 9m11s
    my-kong-kong-portal NodePort 10.43.118.111 8003:31003/TCP 9m11s
    my-kong-postgresql ClusterIP 10.43.55.81 5432/TCP 9m11s
    my-kong-kong-manager NodePort 10.43.86.108 8002:31002/TCP 9m11s

    View Slide

  19. THE CLOUD CONNECTIVITY COMPANY
    19
    © Kong Inc.
    Environment now
    EC2 node
    k3s
    19
    Kong Gateway
    Admin API
    31001
    Kong Manager
    31002
    Kong Proxy
    31000

    View Slide

  20. THE CLOUD CONNECTIVITY COMPANY
    20
    © Kong Inc. 20
    Deploying with Helm - customize - 3
    $ http GET localhost:31001/status
    Kong-Admin-Token:kong
    HTTP/1.1 200 OK
    Access-Control-Allow-Credentials: true
    Access-Control-Allow-Origin:
    http://3.113.112.202:31002
    Connection: keep-alive
    Content-Length: 1824
    Content-Type: application/json; charset=utf-8
    Date: Tue, 19 Apr 2022 14:26:14 GMT
    Server: kong/2.8.1.0-enterprise-edition
    X-Kong-Admin-Latency: 6
    X-Kong-Admin-Request-ID:
    LO0bm1oNonBAMR0dooKrzcaGRZlIzVNM
    vary: Origin
    {
    "database": {
    "reachable": true
    },
    "memory": {
    "lua_shared_dicts": {
    "kong": {

    - Verify GUI on port 31002, admin API on port 31001

    View Slide

  21. THE CLOUD CONNECTIVITY COMPANY
    21
    © Kong Inc. 21
    Exposing, Securing,
    and Protecting a Service

    View Slide

  22. THE CLOUD CONNECTIVITY COMPANY
    22
    © Kong Inc.
    - First, let’s deploy an echo service/pod
    22
    Deploy a service and expose it by Kong
    $ kubectl get pod -n echo
    NAME READY STATUS RESTARTS AGE
    echo-554cb8b48b-nknfw 1/1 Running 0 60s
    $ kubectl get svc -n echo
    NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
    echo ClusterIP 10.43.57.39 80/TCP 66s

    View Slide

  23. THE CLOUD CONNECTIVITY COMPANY
    23
    © Kong Inc. 23
    recap
    • Kong’s main components map to Kubernetes resource type
    Kong Gateway : http://wenhan.io
    Route(/A)
    Route(/B)
    Route(/C)
    Service(1)
    Service(2)
    Service(3)
    Route(/D)
    LB
    API
    Client
    http://wenhan.io/A
    URL 1
    URL 2
    External API
    URL 2
    Ingress
    Rules Kubernetes Service Kubernetes Pods

    View Slide

  24. THE CLOUD CONNECTIVITY COMPANY
    24
    © Kong Inc.
    - Next, expose the echo service outside the Kubernetes cluster by defining Ingress rules.
    24
    Deploy a service and expose it by Kong
    # https://kubernetes.io/docs/concepts/services-networking/ingress/#the-ingress-resource
    $ echo '
    apiVersion: networking.k8s.io/v1
    kind: Ingress
    metadata:
    name: demo
    annotations:
    konghq.com/strip-path: "true”
    kubernetes.io/ingress.class: kong
    namespace: echo
    spec:
    rules:
    - http:
    paths:
    - path: /echo
    pathType: Prefix
    backend:
    service:
    name: echo
    port:
    number: 80
    ' | kubectl apply -f -
    <<<<< Using Kong Ingress Controller
    <<<<< access path is /echo
    <<<<< target service is echo, port is 80

    View Slide

  25. THE CLOUD CONNECTIVITY COMPANY
    25
    © Kong Inc.
    Environment now
    EC2 node (xxx.xxx.xxx.xxx)
    Kubernetes Cluster
    Kong Gateway
    Service
    “Echo”
    Admin API
    31001
    Kong Manager
    31002
    Kong Proxy
    31000
    Pod
    “echo”
    Ingress Rule
    “demo”
    80 80
    /echo
    http://xxx.xxx.xxx.xxx:31000/echo

    View Slide

  26. THE CLOUD CONNECTIVITY COMPANY
    26
    © Kong Inc. 26
    Access service from outside
    ❯ http http://3.113.112.202:31000/echo
    HTTP/1.1 200 OK
    Connection: keep-alive
    Content-Length: 1293
    Content-Type: application/json; charset=utf-8
    Date: Tue, 19 Apr 2022 14:51:03 GMT
    ETag: W/"50d-PK3UDIH5M5k5u0EVmQ6TSEQlQY8"
    Via: kong/2.8.1.0-enterprise-edition
    X-Kong-Proxy-Latency: 0
    X-Kong-Upstream-Latency: 8
    {
    "environment": {
    "ECHO_PORT": "tcp://10.43.57.39:80",
    "ECHO_PORT_80_TCP": "tcp://10.43.57.39:80",
    "ECHO_PORT_80_TCP_ADDR": "10.43.57.39",

    View Slide

  27. THE CLOUD CONNECTIVITY COMPANY
    27
    © Kong Inc. 27
    Protech the service - Rate Limit
    - Controls how many times a client can access the service in a specified time frame.

    View Slide

  28. THE CLOUD CONNECTIVITY COMPANY
    28
    © Kong Inc. 28
    Protech the service - Rate Limit - setup
    - To enforce rate limiting plugin
    - define a KongPlugin(Kong CRD) resource
    cat <apiVersion: configuration.konghq.com/v1
    kind: KongPlugin
    metadata:
    name: rl-by-ip
    annotations:
    kubernetes.io/ingress.class: kong
    namespace: echo
    config:
    minute: 5
    limit_by: ip
    policy: local
    plugin: rate-limiting
    EOF

    View Slide

  29. THE CLOUD CONNECTIVITY COMPANY
    29
    © Kong Inc. 29
    Protech the service - Rate Limit - setup
    - To enforce rate limiting plugin
    - annotate the service.
    - The plugin can also be applied at the Ingress or globally level
    - e.g. enforce a global rate limit for all services but enforce a different rate limit for
    specific services or consumers
    $ kubectl annotate svc echo konghq.com/plugins=rl-by-ip -n echo
    $ kubectl get svc -n echo -o yaml
    apiVersion: v1
    items:
    - apiVersion: v1
    kind: Service
    metadata:
    annotations:
    konghq.com/plugins: rl-by-ip

    View Slide

  30. THE CLOUD CONNECTIVITY COMPANY
    30
    © Kong Inc.
    EC2 node (3.113.112.202)
    Kubernetes Cluster
    Kong Gateway
    Service
    “Echo”
    Admin API
    31001
    Kong Manager
    31002
    Kong Proxy
    31000
    Pod
    “echo”
    Ingress Rule
    “demo”
    Ratelimit
    KongPlugin
    80 80
    /echo
    Environment now

    View Slide

  31. THE CLOUD CONNECTIVITY COMPANY
    31
    © Kong Inc. 31
    Protech the service - Rate Limit - verify
    - Now the service can only be access 5 times in 1 minutes
    ❯ http http://3.113.112.202:31000/echo
    ❯ http http://3.113.112.202:31000/echo
    ❯ http http://3.113.112.202:31000/echo
    ❯ http http://3.113.112.202:31000/echo
    ❯ http http://3.113.112.202:31000/echo
    ❯ http http://3.113.112.202:31000/echo
    HTTP/1.1 429 Too Many Requests
    Connection: keep-alive
    Content-Length: 41
    Content-Type: application/json; charset=utf-8
    Date: Tue, 19 Apr 2022 15:32:37 GMT
    RateLimit-Limit: 5
    RateLimit-Remaining: 0
    RateLimit-Reset: 23
    Retry-After: 23
    Server: kong/2.8.1.0-enterprise-edition
    X-Kong-Response-Latency: 1
    X-RateLimit-Limit-Minute: 5
    X-RateLimit-Remaining-Minute: 0

    View Slide

  32. THE CLOUD CONNECTIVITY COMPANY
    32
    © Kong Inc. 32
    Protech the service - Rate Limit - setup - by header
    - To enforce rate limiting plugin
    - define a KongPlugin(Kong CRD) resource
    cat <apiVersion: configuration.konghq.com/v1
    kind: KongPlugin
    metadata:
    name: rl-by-header
    annotations:
    kubernetes.io/ingress.class: kong
    namespace: echo
    config:
    minute: 5
    limit_by: header
    policy: local
    plugin: rate-limiting
    EOF

    View Slide

  33. THE CLOUD CONNECTIVITY COMPANY
    33
    © Kong Inc. 33
    Protech the service - Using 3rd party Identity Provider
    - Openid connect plugin(OIDC) can be configured to use a 3rd party IDP
    - Auth0
    - Amazon AWS Cognito
    - Connect2id
    - Curity
    - Dex
    - Gluu
    - Google
    - IdentityServer
    - Keycloak
    - Microsoft Azure Active Directory
    - Microsoft Active Directory Federation Services
    - Microsoft Live Connect
    - Okta
    - OneLogin
    - OpenAM
    - Paypal
    - PingFederate
    - Salesforce
    - WSO2
    - Yahoo!

    View Slide

  34. THE CLOUD CONNECTIVITY COMPANY
    34
    © Kong Inc. 34
    Setup OIDC plugin
    - Create OIDC plugin and configure to use Okta
    - Replace key-auth and acl plugins with OIDC plugin
    cat <apiVersion: configuration.konghq.com/v1
    kind: KongPlugin
    metadata:
    name: openid-connect
    namespace: echo
    annotations:
    kubernetes.io/ingress.class: kong
    config:
    issuer: https://dev-513727.okta.com/oauth2/default
    consumer_optional: true
    auth_methods:
    - client_credentials
    verify_parameters: false
    scopes: []
    plugin: openid-connect
    EOF
    $ kubectl annotate ingress demo konghq.com/plugins- -n echo
    $ kubectl annotate ingress demo konghq.com/plugins=openid-connect -n echo

    View Slide

  35. THE CLOUD CONNECTIVITY COMPANY
    35
    © Kong Inc.
    EC2 node
    Kubernetes Cluster
    Kong Gateway
    Service
    “Echo”
    Admin API
    31001
    Kong Manager
    31002
    Kong Proxy
    31000
    Pod
    “echo”
    Ingress Rule
    “demo”
    KongPluginR
    atelimit
    KongPlugin
    openid-connect
    Consumer
    Jason
    80 80
    /echo
    Environment now

    View Slide

  36. THE CLOUD CONNECTIVITY COMPANY
    36
    © Kong Inc. 36
    Verification
    - Access will be reject as we didn’t provided any auth information.
    - The service can be access if we provided correct authentication information.
    $ http http://3.113.112.202:31000/echo
    HTTP/1.1 401 Unauthorized
    Connection: keep-alive
    Content-Length: 26
    Content-Type: application/json; charset=utf-8
    Date: Wed, 20 Apr 2022 16:14:39 GMT
    Server: nginx
    WWW-Authenticate: Bearer realm="dev-513727.okta.com"
    X-Kong-Response-Latency: 1
    {
    "message": "Unauthorized"
    }
    $ http GET http://3.113.112.202:31000/echo authorization:"Basic
    MG9hM2dqZXJ3elRJNXlqN3AzNTc6QS10eWNzc083TldEOEtRNWh6ZWhwWTVtQ0Z2emxIRE93cVpETHYyZA=="
    HTTP/1.1 200 OK
    Connection: keep-alive
    Content-Encoding: gzip

    View Slide

  37. THE CLOUD CONNECTIVITY COMPANY
    37
    © Kong Inc. 37
    本セッションについて
    このセッションはKong Academy KGLL-108 Learning Lab: Kong for Kubernetes をベースに
    日本語ででお届けします
    - https://education.konghq.com/
    - 全てレベル100、無償でオンライン受講可能(自習形式)
    - レベル200以上は有償で提供(サブスクリプション)
    - 講師によるトレーニングを実施
    - Kong認定証を授与

    View Slide

  38. THE CLOUD CONNECTIVITY COMPANY
    38
    © Kong Inc. 38
    Thank you

    View Slide
