1. UNIX Linking and GNU Toolchain Debugging UNIX programs before runtime Artyom Gavrichenkov engineer, HP Russia Best Shore Application Services mailto: artyom.gavrichenkov@hp.com
2. Presentation structure • C/C++ runtime linking in UNIX ▫ ELF ▫ Name mangling ▫ The concept of binary interpreter ▫ Environment variables • GNU Toolchain ▫ readelf ▫ objdump ▫ c++filt
3. Executable file types in UNIX • Plain text ▫ “Hashbang”: #!/bin/sh • Binary ▫ a.out Don’t mess with the default compiler output! Very old and deprecated format ▫ COFF/ECOFF/XCOFF Superseded by ELF ▫ ELF • Almost all UNIX systems allow user to find out of what type a file is ▫ /usr/bin/file
4. Executable and Linking Format (1/2) • Stores almost any possible compiled code ▫ Binary executable files ▫ Shared libraries (*.so ones) ▫ Object code • With ELF, there is only one difference between an executable file and shared library ▫ an executable file has an entry point – main()
5. Executable and Linking Format (2/2) • Stores data divided into sections ▫ .bss ▫ .data .rodata ▫ dynamic ▫ .interp ▫ .text ▫ Others man page: ELF(5)
6. Name mangling/“decoration” (1/2) • ELF structure has been designed for pure C (and Fortran) programs ▫ Then, C++ arrived • Consider an example: ▫ How to put all these “main” functions in a single binary? class foo { void main(int); void main(int, char); }; int main(int, char **) {}
7. Name mangling/“decoration” (2/2) • A hack introduced to make C++ code fit into C libraries ▫ void main(char, int) -> void _Z1mainci(char, int) ▫ An underscore (or two) before the new name helps not to mess the generated names with manually chosen ones • Wikipedia has a perfect article on how different compilers mangle the same functions:
8. Binary interpreter • Dynamic linker • Always used to live in /lib/ld.so ▫ On GNU/Linux: /lib/ld.so* for a.out files /lib/ld-linux.so* (currently .2) for ELF ▫ On HP-UX: /usr/lib/hpux{32,64}/{u,d}ld.so ▫ man pages: ld.so(8), dld.so(5) • There may be multiple BIs on the system! ▫ .interp ELF section ▫ On HP-UX, /usr/bin/ld has an +interp option
9. dlopen • Sometimes we don’t know the name of an external function or library during compilation ▫ Runtime linker offers the dlopen() mechanism • Example: • Links: ▫ http://www.opengroup.org/onlinepubs/009695399/basedefs/dlf cn.h.html ▫ http://tldp.org/HOWTO/C++-dlopen/ /* open the needed object */ handle = dlopen("/usr/home/me/libfoo.so", RTLD_LOCAL); /* find the address of function objects */ *(void **)(&fptr) = dlsym(handle, "my_function"); /* invoke function, passing value of integer as a parameter */ (*fptr)(42);
10. Environment • /lib/ld*so* uses environment variables to locate dynamic libraries during the start of a program ▫ By default, it looks at: /lib and /usr/lib /etc/ld.so.cache and /etc/ld.so.preload • The commonly used variables are: ▫ LD_LIBRARY_PATH ▫ LD_PRELOAD How /usr/bin/strace works? ▫ LD_TRACE_LOADED_OBJECTS /usr/bin/ldd
11. GNU toolchain • Includes: ▫ make ▫ GCC Who remembers what does it mean? ▫ GNU autotools Autoconf Automake Libtool ▫ GNU binutils
12. GNU binutils • A subset of binutils: ▫ as ▫ ld ▫ gprof ▫ addr2line ▫ c++filt ▫ nm ▫ objdump ▫ readelf ▫ strings • More and more to come ▫ http://www.gnu.org/software/binutils
13. c++filt • Demangles C++ name information • Knows multiple decoration types ▫ GNU ▫ HP ▫ Java • Decoration type autodetection by default
14. objdump • The Binary File Descriptor library ▫ Core dumps ▫ Support for more binary formats ▫ The internal file representation of BFD is similar to the ELF one • Useful options: ▫ --demangle Kills the need in c++filt ▫ --disassemble-all
15. readelf • Only for ELF files ▫ But more detailed ELF debugging • Useful options: ▫ --dynamic ▫ --symbols ▫ --all for short
16. Questions?
